843-1. Basic operation
Select to display nearby traf-
fic information. (P.84)
Select to display a map with
predictive traffic data.
( P.84)
Select to display traffic along
the saved routes. ( P.85)
When the route has been set
Select to display traffic infor-
mation for the set route.
( P.84)
Select to display nearby traf-
fic information. ( P.84)
Select to display a map with
predictive traffic data.
( P.84)
Select to display traffic along
the saved routes. ( P.85)
●If a large amount of information is
being received, it may take longer
than normal for the information to
be displayed on the screen.
●If traffic information cannot be
received because the vehicle is
outside of HD Ra dio coverage
area, it may still be able to be
received using DCM. ( P.172)
A list of current traffic informa-
tion can be displayed along with
information on the location of
each incident.
1 Display the traffic incidents
screen. ( P.83)
2 Select “Traffic Events on Cur-
rent Road”, “Traffic Events on
Current Route” or “Traffic
Events Nearby”.
3 Select the desired traffic
information.
When “Traffic Events Nearby”
is selected, depending on
whether the traffic flow infor-
mation is enabled/disabled,
the following will be displayed:
When enabled: Traffic event and
congestion information
When disabled: Traffic event infor-
mation only
4Check that the traffic informa-
tion is displayed.
“Detail”: Select to display detailed
traffic information.
A map with predictive traffic data
can be displayed.
1Display the traffic incidents
screen. ( P.83)
2 Select “Predictive Traffic
Map”.
B
C
D
A
B
C
D
Displaying traffic informa-
tion
Displaying predictive traf-
fic information

853-1. Basic operation
3
Navigation system
3Scroll the map to the desired
point ( P.77) and set the
time of predictive traffic infor-
mation.
 The time of the predictive traf-
fic information can be
changed in 15-minute inter-
vals up to +45 minutes.
“<”: Moves the time forward 15 min-
utes.
“>”: Moves the time back 15 min-
utes.
Traffic information along the
saved routes can be displayed.
To use this function, it is neces-
sary to register a route.
( P.112)
1 Display the traffic incidents
screen. ( P.83)
2 Select “My Traffic Routes”.
 If map data has been
updated, a confirmation
screen will be displayed.
Select “OK” or “Do Not Tell
Me Again”.
3 Select the desired route.
“Options”: Select to add, edit or
delete personal traffic routes.
( P.112)
 If routes have not been regis-
tered yet, a confirmation
screen will be displayed.
Select “Yes” to register the
route.
4 Select the desired traffic
information. 5
Check that the traffic informa-
tion is displayed.
“Detail”: Select to display detailed
traffic information.
1Select on the map
screen.
2 Select “Traffic Information”.
3 Check that the traffic informa-
tion is displayed.
●The icons indicate traffic incidents
such as construction, accidents,
etc. Select an icon to hear more
detail by voice.
●The arrows indicate the flow of
traffic. The color changes depend-
ing on the speed.
My traffic routes
Displaying traffic informa-
tion on the map

873-2. Destination search
3
Navigation system
nation from a different state
(province) by using “Address” or
“Point of Interest”.
1Display the destination
screen. ( P.86)
2 Select “Address” or “Point of
Interest”.
3 Select “Change State/Prov-
ince”.
 If a state (province) has not
been selected yet,
“State/Province” screen is dis-
played directly.
4 Select the desired state
(province).
 To change countries, select
“Change Country”.
To use this function, it is neces-
sary to register a home address.
( P.104)
1 Display the destination
screen. ( P.86)
2 Select “Home”.
 The navigation system per-
forms a search for the route
and the route overview is dis- played. (
P.94)
The destination can be
searched by entering various
keywords.
1 Display the destination
screen. ( P.86)
2 Select “Search”.
3 Enter characters on the key-
board.
4 Select “Search”.
5 When there is more than 1
result, select the desired item
from the list.
: Select to display updated infor-
mation about the selected entry.
This function is displayed only
when there is information from the
Cloud.
●To search for a facility name using
multiple search words, put a
space between each word.
●Search results may differ depend-
ing on the Connected Services
subscription status and communi-
cation status.
To use this function, it is neces-
Setting home as destina-
tion
Searching by keyword
Searching by favorites list

883-2. Destination search
sary to register a favorites list
entry. (P.105)
1 Display the destination
screen. ( P.86)
2 Select “Favorites”.
3 Select the desired favorites
list entry.
*: This function is not made avail-
able in some countries or areas.
A Destination Assist operator
can search for a destination.
You can request a specific busi-
ness, address, or ask for help
locating your desired destina-
tion. ( P.279)
1 Display the destination
screen. ( P.86)
2 Select “Dest Assist”.
1 Display the destination
screen. ( P.86)
2 Select “Recent”. 3
Select the desired destina-
tion.
“Sort/Delete”: Sele ct to sort (date,
name) or delete destination(s).
●Up to 100 previous ly set destina-
tions are displayed on the screen.
1 Select “Sort/Delete”.
2 Select “Delete Recent Desti-
nations”.
3 Select the desired recent
destination(s) to be deleted.
4 Select “Yes” when the confir-
mation screen appears.
“Sort/Delete All”: Select to sort
(date, name) desti nations or delete
all.
1 Display the destination
screen. ( P.86)
2 Select “Emergency”.
3 Select the desired emer-
gency category.
Searching by Destination
Assist*
Searching by recent desti-
nations
Deleting recent destina-
tions
Searching by emergency

893-2. Destination search
3
Navigation system
4Select the desired destina-
tion.
●The navigation system does not
guide in areas where route guid-
ance is unavailable. ( P.117)
To use this function, it is neces-
sary to have contact data which
had been transferred to the nav-
igation system from a registered
Bluetooth
® phone. ( P.240)
1 Display the destination
screen. ( P.86)
2 Select “Contacts”.
3 Select the desired contact.
4 Select “Addresses”.
5 Select the desired address.
6 Follow the steps in “Search-
ing by keyword” from step 4.
( P.87)
●This function may not be available
depending on the type of
Bluetooth
® phone.
1Display the destination
screen. ( P.86)
2 Select “Address”.
3 Enter a house number and
select “Search”.
4 Enter a street name and
select “Search”.
5 Select the desired street
name.
6 Enter a city name and select
“Search”.
7 Select the desired city name.
 If multiple locations with the
same address exist, the
address list screen will be dis-
played. Select the desired
address.
●A street name can be searched
using only the body part of its
name.
For example: S WESTERN AVE
• A search can be performed by entering “S WESTERN AVE”,
“WESTERN AVE” or “WEST-
ERN”.
Searching by contact
Searching by address

903-2. Destination search
There are 3 methods to search
for a destination by Points of
Interest.
1Display the destination
screen. ( P.86)
2 Select “Point of Interest”.
3 Select the desired search
method.
Select to change the search
area. ( P.86)
Select to search by name.
( P.90)
Select to search by cate-
gory. ( P.90)
Select to search by phone
number. ( P.91)
1 Select “Name”.
2 Enter a POI name and select
“Search”.
3 Select the desired POI.
“Sort/Category/Cit y”: Select to sort
(name, distance) the displayed
entries, change the POI category,
or enter a city name.
 When entering the name of a
specific POI, and there are 2
or more sites with the same
name, the list screen will be
displayed. Select the desired
POI.
●To search for a facility name using
multiple search words, put a
space between each word.
1 Select “Sort/Category/City”.
2 Select “Enter a city name”.
3 Enter a city name and select
“Search”.
“Any City”: Select to cancel the city
setting.
4Select the desired city name.
5 Select the desired POI.
1 Select “Sort/Category/City”.
2 Select “Change POI cate-
gory”.
3 Select the desired category.
 If there is more than 1 result
for the selected category, a
detailed list will be displayed.
“List All Categorie s”: Select to dis-
play all POI categories.
4 Select the desired POI.
1 Select “Category”.
Searching by point of
interest
Searching by name
A
B
C
D
6HOHFWLQJDFLW\WRVHDUFK
6HOHFWLQJIURPWKHFDWHJR
ULHV
6HDUFKLQJE\FDWHJRU\

913-2. Destination search
3
Navigation system
2Select the desired search
point.
Select to search for POIs
near your current position.
Select to search for POIs
along the set route.
Select to search for POIs
near a specific city center.
( P.91)
Select to search for POIs
near a destination.
When more than 1 destina-
tion has been set, a list will
be displayed on the screen.
Select the desired destina-
tion.
3 Select the desired POI cate-
gory.
 If there is more than 1 result
for the selected category, a
detailed list will be displayed.
 Select “Other POIs” to select
other than default POI catego-
ries. The following button can
be displayed.
“List All Categories”: Select to dis-
play all POI categories.
“Favorite POI Categories”: Select to
use the 6 POIs tha t have been pre-
viously set. ( P.109)
4 Select the desired POI.
●The names of POIs located within
approximately 200 miles (320 km)
from the selected search point can
be displayed. They are displayed
up to 200 names.
1Select “Near a City Center in
XX
*”.
2 Enter a city name and select
“Search”.
“Last 5 Cities”: Select the desired
city name from the list of the last 5
cities.
3Select the desired city name.
4 Select “OK” when the city
center map screen is dis-
played.
5 Follow the steps in “Search-
ing by category” from step 3.
( P.90)
*: XX represents the selected
search area name.
●If the navigation system has never
been used, selecting the city
name from “Last 5 Cities” will not
be available.
1 Select “Phone #”.
2 Enter a phone number and
select “OK”.
 If multiple locations with the
same phone number exist,
A
B
C
D
When “Near a City Center in
XX
*” is selected
Searching by phone num-
ber

923-2. Destination search
the list screen will be dis-
played.
●If there is no match for the entered
phone number, a list of identical
numbers with different area codes
will be displayed.
To use this function, it is neces-
sary to register a home and/or a
favorite location. Up to 2 favor-
ites can be registered as preset
destinations. (P.104, 105)
To set the home or a preset des-
tination as the destination,
select the corresponding button.
1 Turn the power switch to
ACC or ON.
2 Press the “MAP” button.
3 Select the desired item.
Select to set the registered
home as the destination.
Select to set a registered
favorite as the destination.
(Up to 2 favorites can be reg-
istered as preset destina-
tions.) 
The estimated time of arrival
to the registered home and
preset destinations from the
current position will be dis-
played.
 If the home or a preset desti-
nation has not been regis-
tered, “Save Home” or “Save
Favorite” will be displayed,
respectively. To register a
home or preset destination,
select the corresponding but-
ton.
●When the destination is very close
to the current po sition, “Nearby”
will be displayed.
●The one-touch buttons for home
and favorites will disappear after
the vehicle has been driven for a
while.
●The color of the estimated arrival
time indicator may change
depending on the traffic informa-
tion received.
●This function is available when
“Automatic Destination List Info” is
set to on. ( P.108)
One-touch setting
home/favorite as a desti-
nation
A
B

933-2. Destination search
3
Navigation system
1Select “Go” on the confirm
destination screen.
 For details about this screen:
P.93
2 Select “OK” on the route
overview screen.
 For details about this screen:
P.94
●The route for returning may not be
the same as that for going.
●The route guidance to the destina-
tion may not be the shortest route
or a route without traffic conges- tion.
●Route guidance may not be avail-
able if there is no road data for the
specified location.
●When setting the destination on a
map with a scale more than 0.5
mile (800 m), the map scale
changes to 0.5 mile (800 m) auto-
matically. If this occurs, set the
destination again.
●If a destination that is not located
on a road is set, the vehicle will be
guided to the point on a road near-
est to the destination. The road
nearest to the selected point is set
as the destination.
Select to search for the route.
(
P.93)
• If a destination has already been
set, “Go Directly” and “Add to
Route” will be displayed.
“Go Directly”: Select to delete the
existing destination(s) and set a
new one.
Starting route guid-
ance
When the destination is set,
the entire route map from
the current position to the
destination is displayed.
Starting route guidance
WARNING
●Be sure to obey traffic regula-
tions and keep road conditions
in mind while dri ving. If a traffic
sign on the road has been
changed, the r oute guidance
may not indicate such changed
information.
Confirm destination
screen
A

943-2. Destination search
“Add to Route”: Select to add a
destination to the current route.
Select to register as a mem-
ory point.
Select to call the registered
number.
Select to update information
about the selected entry.
*
*: This function is displayed only when there is information from
the Cloud. ( P.87)
Current position
Destination point
Select to display a list of the
turns required to reach the
destination. ( P.95)
Select to change the route.
( P.95)
Select the desired route from
3 possible routes. ( P.94)
Type of route and its distance
Distance of the entire route
Select to start guidance.
Select and hold to start demo
mode. ( P.94) Displayed when the route
displayed is from the Cloud.
(
P.96)
Before starting the route guid-
ance, the demonstration of the
route guidance can be viewed.
1 Select and hold “OK” on the
route overview screen until a
beep sounds.
 Press the “HOME” or “MAP”
button to end demo mode.
1 Select “3 Routes”.
2 Select the desired route.
Displayed when the route
displayed is available from
the Cloud. ( )
Select to display the quick-
est route.
Select to display the route
that is the shortest distance
to the set destination.
Select to display the alterna-
tive route.
Route overview screen
B
C
D
A
B
C
D
E
F
G
H
6WDUWLQJGHPRPRGH
URXWHVVHOHFWLRQ
I
A
B
C
D
