TOYOTA SEQUOIA 2001 Service Repair Manual

H01007
H10600H40997H24650
CGTCDTC B1635/24 DLC3
Curtain Shield Airbag
Sensor Assembly LH
Airbag
Sensor
Assembly
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1199
1393 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
CAUTION:
Be sure to perform the following procedures before troubleshooting to avoid unexpected airbag de-
ployment.
(a) Turn the ignition switch to the LOCK position.
(b) Disconnect the negative (±) terminal cable from the battery, and wait for at least 90 seconds.
(c) Disconnect the connectors from the airbag sensor assembly.
(d) Disconnect the connectors from the steering wheel pad.
(e) Disconnect the connectors from the front passenger airbag assembly.
(f) w/ Side and curtain shield airbag:
Disconnect the connectors from the side airbag assembly LH and RH.
(g) w/ Side and curtain shield airbag:
Disconnect the connectors from the curtain shield airbag assembly LH and RH.
(h) Disconnect the connectors from the front seat outer belt LH and RH.
1 Check DTC.
PREPARATION:
(a) Connect the connectors to the airbag sensor assembly.
(b) Connect the negative (±) terminal cable to the battery,
and wait for at least 2 seconds.
CHECK:
(a) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(b) Clear the DTCs stored in memory (see page DI±1147).
(c) Turn the ignition switch to the LOCK position.
(d) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(e) Check the DTCs (see page DI±1147).
OK:
DTC B1635/24 is not output.
HINT:
Codes other than DTC B1635/24 may be output at this time, but
they are not related to this check.
NG Go to step 2.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check (see page DI±1137).

C91384H01010G27652H23575
Curtain Shield
Airbag Sensor
Assembly LH
Floor Wire No. 2
Airbag
Sensor
Assembly
VUCL
ESCL
A
B C D
VUCL ESCLSST
A19S26
DI±1200
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1394 Author: Date:
2005 SEQUOIA (RM1146U)
2 Check connection of connectors.
PREPARATION:
(a) Turn the ignition switch to the LOCK position.
(b) Disconnect the negative (±) terminal cable from the battery, and wait for at least 90 seconds.
CHECK:
Check that the connectors are properly connected to the airbag sensor assembly and the curtain shield air-
bag sensor assembly LH.
OK:
The connectors are connected securely.
NG Connect connectors, then go to step 1.
OK
3 Check floor wire No. 2 (open).
PREPARATION:
(a) Disconnect the connectors from the airbag sensor as-
sembly and the curtain shield airbag sensor assembly LH.
(b) Using SST, connect S26±2 (VUCL) and S26±1 (ESCL) of
connector ºCº.
SST 09843±18040
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
A19±20 (VUCL) ±
A19±22 (ESCL)AlwaysBelow 1 W
NG Repair or replace floor wire No. 2.
OK

C91384H01010G27652H23572
Curtain Shield
Airbag Sensor
Assembly LH
Floor Wire No. 2
Airbag
Sensor
Assembly
VUCL ESCL
A
B
C D
A19
C91384H01010G27652H23572
Curtain Shield
Airbag Sensor
Assembly LH
Floor Wire No. 2
Airbag
Sensor
Assembly
VUCL ESCL
A
B
C D
A19
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1201
1395 Author: Date:
2005 SEQUOIA (RM1146U)
4 Check floor wire No. 2 (short).
PREPARATION:
Disconnect the SST from connector ºCº.
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
A19±20 (VUCL) ±
A19±22 (ESCL)Always1 MW or higher
NG Repair or replace floor wire No. 2.
OK
5 Check floor wire No. 2 (short to B+).
PREPARATION:
(a) Connect the negative (±) terminal cable to the battery,
and wait for at least 2 seconds.
CHECK:
(a) Turn the ignition switch to the ON position.
(b) Measure the voltage according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
A19±20 (VUCL) ±
Body groundIgnition switch ONBelow 1 V
A19±22 (ESCL) ±
Body groundIgnition switch ONBelow 1 V
NG Repair or replace floor wire No. 2.
OK

C91384H01010G27652H23572
Curtain Shield
Airbag Sensor
Assembly LH
Floor Wire No. 2
Airbag
Sensor
Assembly
VUCL ESCL
A
B
C D
A19
DI±1202
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1396 Author: Date:
2005 SEQUOIA (RM1146U)
6 Check floor wire No. 2 (short to ground).
PREPARATION:
(a) Turn the ignition switch to the LOCK position.
(b) Disconnect the negative (±) terminal cable from the bat-
tery, and wait for at least 90 seconds.
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
A19±20 (VUCL) ±
Body groundAlways1 MW or higher
A19±22 (ESCL) ±
Body groundAlways1 MW or higher
NG Repair or replace floor wire No. 2.
OK

H01007
H10600H42066H40997H23576
CG
TCDTC B1630/23
DLC3
Curtain Shield Airbag
Sensor Assembly RH
DTC B1635/24 Airbag
Sensor
Assembly
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1203
1397 Author: Date:
2005 SEQUOIA (RM1146U)
7 Check curtain shield airbag sensor assembly LH.
PREPARATION:
(a) Connect the connectors to the airbag sensor assembly.
(b) Interchange the curtain shield airbag sensor assembly
RH with LH and connect the connectors to them.
(c) Connect the negative (±) terminal cable to the battery,
and wait for at least 2 seconds.
CHECK:
(a) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(b) Clear the DTCs stored in memory (see page DI±1147).
(c) Turn the ignition switch to the LOCK position.
(d) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(e) Check the DTCs (see page DI±1147).
OK:
DTC B1635/24 is output.A
DTC B1630/23 is output.B
DTC B1630/23 and B1635/24 are not
output.C
HINT:
Codes than other DTC B1630/23 and B1635/24 may be output
at this time, but they are not related to this check.
A Replace airbag sensor assembly
(see page RS±82).
B Replace curtain shield airbag sensor assembly
LH (see page RS±97).
C
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check (see page DI±1137).

H02750
O6
Occupant Classification ECU
FSR+
BL13
WW
A2116Airbag Sensor Assembly
A2124
B B
BL15
FSR±FSR+
FSR± 8
4 DI±1204
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1398 Author: Date:
2005 SEQUOIA (RM1146U)
DTC B1650/32 Occupant Classification System
Malfunction
CIRCUIT DESCRIPTION
The occupant classification system circuit consists of the airbag sensor assembly and the occupant classifi-
cation system.
If the airbag sensor assembly receives signals from the occupant classification ECU, it determines whether
or not the front passenger airbag assembly, side airbag assembly RH and seat belt pretensioner RH should
be operated.
DTC B1650/32 is recorded when a malfunction is detected in the occupant classification system circuit.
DTC No.DTC Detecting ConditionTrouble Area
B1650/32

Occupant classification system malfunction

The airbag sensor assembly receives a line short circuit
signal, an open circuit signal, a short circuit to ground sig-
nal or a short circuit to B+ signal in the occupant classifi-
cation system circuit for 2 seconds.

Airbag sensor assembly malfunction

Occupant classification system

Airbag sensor assembly

Floor wire

Seat wire No. 1
WIRING DIAGRAM
DIDGY±01

H10600H01065H08008
H24037
Airbag
Sensor
Assembly
DLC3
CG TCOccupant
Classification ECU
DTC B1650/32
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1205
1399 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
1 Check DTC (occupant classification ECU).
CHECK:
(a) Turn the ignition switch to the ON position, and wait for at least 10 seconds.
(b) Using the hand±held tester, check the DTCs of the occupant classification ECU (see page DI±1147).
OK:
DTC is not output of the occupant classification ECU.
NG Go to inspection procedure of DTC output
(see page DI±1155).
OK
2 Check DTC (airbag sensor assembly).
CHECK:
(a) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(b) Clear the DTCs stored in memory (see page DI±1147).
HINT:
First clear DTCs stored in the occupant classification ECU and
then in the airbag sensor assembly.
(c) Turn the ignition switch to the LOCK position.
(d) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(e) Check the DTCs (see page DI±1147).
OK:
DTC B1650/32 is not output.
HINT:
Codes other than DTC B1650/32 may be output at this time, but
they are not related to this check.
NG Go to step 3.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check (see page DI±1137).

DI±1206
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1400 Author: Date:
2005 SEQUOIA (RM1146U)
3 Check connection of connectors.
PREPARATION:
(a) Turn the ignition switch to the LOCK position.
(b) Disconnect the negative (±) terminal cable from the battery, and wait for at least 90 seconds.
CHECK:
Check that the connectors are properly connected to the airbag sensor assembly and the occupant classifi-
cation ECU.
OK:
The connectors are connected securely.
NG Connect connectors, then go to step 1.
OK
4 Prepare for inspection.
CAUTION:
Be sure to perform the following procedures before troubleshooting to avoid unexpected airbag de-
ployment.
(a) Disconnect the connectors from the airbag sensor assembly.
(b) Disconnect the connectors from the steering wheel pad.
(c) Disconnect the connectors from the front passenger airbag assembly.
(d) w/ Side and curtain shield airbag:
Disconnect the connectors from the side airbag assembly LH and RH.
(e) w/ Side and curtain shield airbag:
Disconnect the connectors from the curtain shield airbag assembly LH and RH.
(f) Disconnect the connectors from the front seat outer belt LH and RH.
NEXT

C84207G27650H43694H24002
Occupant
Classification ECUAirbag
Sensor
Assembly
D
FSR±FSR+ CBA
FSR+
FSR± O6
E F
A21
Service Wire
C84205G27650H24003
Occupant
Classification ECUAirbag
Sensor
Assembly
D
A21
FSR±FSR+CBA
E F
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1207
1401 Author: Date:
2005 SEQUOIA (RM1146U)
5 Check occupant classification system circuit (open).
PREPARATION:
(a) Disconnect the connector from the occupant classifica-
tion ECU.
(b) Using a service wire, connect O6±8 (FSR+) and O6±4
(FSR±) of connector ºEº.
NOTICE:
Do not forcibly insert a service wire into the terminals of the
connector when connecting.
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
A21±16 (FSR+) ±
A21±24 (FSR±)AlwaysBelow 1 W
NG Go to step 9.
OK
6 Check occupant classification system circuit (short).
PREPARATION:
Disconnect the service wire from connector ºEº.
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
A21±16 (FSR+) ±
A21±24 (FSR±)Always1 MW or higher
NG Go to step 10.
OK

C84205G27650H24003
Occupant
Classification ECUAirbag
Sensor
Assembly
D
A21
FSR±FSR+CBA
E F
DI±1208
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1402 Author: Date:
2005 SEQUOIA (RM1146U)
7 Check occupant classification system circuit (short to B+).
PREPARATION:
Connect the negative (±) terminal cable to the battery, and wait
for at least 2 seconds.
CHECK:
(a) Turn the ignition switch to the ON position.
(b) Measure the resistance according to the value(s) in the
table below.
OK:
Tester ConnectionConditionSpecified Condition
A21±16 (FSR+) ±
Body groundIgnition switch ONBelow 1 V
A21±24 (FSR±) ±
Body groundIgnition switch ONBelow 1 V
NG Go to step 11.
OK
