TOYOTA SEQUOIA 2001 Service Repair Manual

A23342
10 mm Hexagon
Wrench
A14399
Timing Mark
Crankshaft
Pulley Bolt
Turn
Idler Pulley Bolt
A23354
B02636
Seal Packing EM±64
± ENGINE MECHANICALCYLINDER HEAD
2643 Author: Date:
2005 SEQUOIA (RM1146U)
(e) Align the camshaft knock pin with the knock pin groove of
the timing tube, and push the timing tube by hand until you
it touches the bottom.
(f) Using a 10 mm hexagon wrench, install the bolt.
Torque: 78 N´m (790 kgf´cm, 58 ft´lbf)
(g) Install the seal washer and screw plug.
Torque: 15 N´m (150 kgf´cm, 11 ft´lbf)
8. INSTALL CAMSHAFTS
NOTICE:
Since the thrust clearance of the camshaft is small, the
camshaft must be kept level while it is being installed. If the
camshaft is not kept level, the portion of the cylinder head
receiving the shaft thrust may crack or be damaged, caus-
ing the camshaft to seize or break. To avoid this, the follow-
ing steps should be carried out.
(a) Set the crankshaft pulley position.
Turn the pulley clockwise or counterclockwise, and align
the timing mark of the crankshaft pulley with the centers
of the crankshaft pulley bolt and idler pulley bolt.
NOTICE:
Having the crankshaft pulley at the wrong angle can cause
the piston head and valve head to come into contact with
each other when you install the camshaft, causing dam-
age. So always set the crankshaft pulley at the correct
angle.
(b) Install the LH camshafts.
(1) Apply MP grease to the thrust portion of the intake
and exhaust camshafts.
(2) Align the timing marks (2±dot mark) of the camshaft
drive and driven main gears, and place the intake
and exhaust camshafts.
(3) Apply seal packing to the camshaft housing plug.

Remove the old packing material (FIPG).

Apply seal packing to the housing plug.
Seal packing: Part No. 08826±00080 or equivalent

A23355
A16831
Seal Packing
Seal Width
1.5 mm
A23356
± ENGINE MECHANICALCYLINDER HEAD
EM±65
2644 Author: Date:
2005 SEQUOIA (RM1146U)
(4) Install the camshaft housing plug to the cylinder
head as shown in the illustration.
(5) Install the strainer to the cylinder head.
NOTICE:
Be careful of the installation direction.
(6) Apply seal packing to the front bearing cap.

Remove any old packing material (FIPG) and
be careful not to drop any oil on the contact
surfaces of the bearing cap and cylinder
head.
Using a razor blade and gasket scraper, re-
move all the old packing material (FIPG) from
the gasket surfaces and groove.
Thoroughly clean all components to remove
all the loose material.
Using a non±residue solvent, clean both
sealing surfaces.

Apply seal packing to the bearing cap as
shown in the illustration.
Install a nozzle that has been cut to a 1.5 mm
(0.059 in.) opening.
Parts must be assembled within 5 minutes of
application. Otherwise the material must be
removed and reapplied.
Immediately remove the nozzle from the tube
and reinstall cap.
Seal packing: Part No. 08826±00080 or equivalent
NOTICE:
Do not apply seal packing to the front bearing cap grooves.
(7) Install the front bearing cap.
HINT:
Installing the front bearing cap will determine the thrust portion
of the camshaft.
(8) Install the other bearing caps in the sequence
shown with the arrow mark facing forward.

A23357
Push
A23337
A
B
C
D
E A
BC
D E
E
EE
EEE
EEEE
EE
A23337
1
4
22
8
9 2
321
6 10
17
18
5
71314
19121115
1620
A23335
Service Bolt EM±66
± ENGINE MECHANICALCYLINDER HEAD
2645 Author: Date:
2005 SEQUOIA (RM1146U)
(9) Push in the camshaft oil seal.
(10) Install 4 new seal washers to the bearing cap bolts
(A and B).
(11) Apply a light coat of engine oil to the threads and un-
der the heads of the bearing cap bolts (D and E).
NOTICE:
Do not apply engine oil under the heads of the bearing cap
bolts (A), (B) and (C).
HINT:
Each bolt length is indicated in the illustration.
Bolt length:
94 mm (3.70 in.) for A with seal washer
72 mm (2.83 in.) for B with seal washer
25 mm (0.98 in.) for C
52 mm (2.05 in.) for D
38 mm (1.50 in.) for E
(12) Install the oil feed pipe and the 22 bearing cap bolts
as shown in the illustration.
(13) Uniformly tighten the 22 bearing cap bolts in several
steps, in the sequence shown.
Torque:
7.5 N´m (76 kgf´cm, 66 in.´lbf) for bolt C
16 N´m (160 kgf´cm, 12 ft´lbf) for others
(14) Remove the service bolt.

A23358
Approx. 10°
B02636
Seal Packing
A23359
± ENGINE MECHANICALCYLINDER HEAD
EM±67
2646 Author: Date:
2005 SEQUOIA (RM1146U)
(c) Install the RH camshafts.
(1) Apply MP grease to the thrust portions of the intake
and exhaust camshafts.
(2) Align the timing marks (1±dot mark) of the camshaft
drive and driven main gears, and place the intake
and exhaust camshafts.
(3) Set the timing mark (1±dot mark) of the camshaft
drive and driven main gears at approx. 10° angle.
(4) Apply seal packing to the camshaft housing plug.

Remove the old packing material (FIPG).

Apply seal packing to the housing plug.
Seal packing: Part No. 08826±00080 or equivalent
(5) Install the camshaft housing plug to the cylinder
head as shown in the illustration.
(6) Install the strainer to the cylinder head.
NOTICE:
Be careful of the installation direction.

A16832
Seal Packing
Seal Width
1.5 mm
A23360
A23361
Push EM±68
± ENGINE MECHANICALCYLINDER HEAD
2647 Author: Date:
2005 SEQUOIA (RM1146U)
(7) Apply seal packing to the front bearing cap.

Remove any old packing material (FIPG) and
be careful not to drop any oil on the contact
surfaces of the bearing cap and cylinder
head.
Using a razor blade and gasket scraper, re-
move all the old packing material (FIPG) from
the gasket surfaces and groove.
Thoroughly clean all components to remove
all the loose material.
Using a non±residue solvent, clean both
sealing surfaces.

Apply seal packing to the bearing cap as
shown in the illustration.
Install a nozzle that has been cut to a 1.5 mm
(0.059 in.) opening.
Parts must be assembled within 5 minutes of
application. Otherwise the material must be
removed and reapplied.
Immediately remove the nozzle from the tube
and reinstall cap.
Seal packing: Part No. 08826±00080 or equivalent
NOTICE:
Do not apply seal packing to the front bearing cap grooves.
(8) Install the front bearing cap.
HINT:
Installing the front bearing cap will determine the thrust portion
of the camshaft.
(9) Install the other bearing caps in the sequence
shown with the arrow mark facing forward.
(10) Push in the camshaft oil seal.

A23340
A
B
C
E
EA
B C
EE
E
EE
EE D
E EEE
ED
A23340
1
4
22
82
3 21
6
57
13 141912
11
15
1620
9
1017
18
A23338
Service Bolt
EM7143
Seal Packing
± ENGINE MECHANICALCYLINDER HEAD
EM±69
2648 Author: Date:
2005 SEQUOIA (RM1146U)
(11) Install 4 new seal washers to the bearing cap bolts
(A and B).
(12) Apply a light coat of engine oil on the threads and
under the heads of the bearing cap bolts (D and E).
NOTICE:
Do not apply engine oil under the heads of the bearing cap
bolts (A), (B) and (C).
HINT:
Each bolt length is indicated in the illustration.
Bolt length:
94 mm (3.70 in.) for A with seal washer
72 mm (2.83 in.) for B with seal washer
25 mm (0.98 in.) for C
52 mm (2.05 in.) for D
38 mm (1.50 in.) for E
(13) Install the oil feed pipe and the 22 bearing cap bolts
as shown in the illustration.
(14) Uniformly tighten the 22 bearing cap bolts in several
steps, in the sequence shown.
Torque:
7.5 N´m (76 kgf´cm, 66 in.´lbf) for bolt C
16 N´m (160 kgf´cm, 12 ft´lbf) for others
(15) Remove the service bolt.
9. CHECK AND ADJUST VALVE CLEARANCE
(See page EM±4)
Turn the camshaft so that the cam lobe faces upward, and
check and adjust the valve clearance.
10. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE
(See page SF±48)
11. INSTALL SEMI±CIRCULAR PLUGS
(a) Remove any old packing material (FIPG).
(b) Apply seal packing to the semi±circular plug grooves.
Seal packing:
Part No. 08826±00080 or equivalent

A23362
RH Bank
LH Bank
A23363: Seal Packing
A14369
A23364: Seal Packing
EM±70
± ENGINE MECHANICALCYLINDER HEAD
2649 Author: Date:
2005 SEQUOIA (RM1146U)
(c) Install the 4 semi±circular plugs to the cylinder heads as
shown in the illustration.
12. INSTALL LH CYLINDER HEAD COVER
(a) Remove any old packing material (FIPG).
(b) Apply seal packing to the cylinder heads as shown in the
illustration.
Seal packing: Part No. 08826±00080 or equivalent
(c) Install the gasket to the cylinder head cover.
(d) Install the seal washer to the bolt.
(e) Install the cylinder head cover with the 9 bolts. Uniformly
tighten the bolts in several steps.
Torque: 6.0 N´m (60 kgf´cm, 53 in.´lbf)
13. INSTALL RH CYLINDER HEAD COVER
(a) Remove any old packing material (FIPG).
(b) Apply seal packing to the cylinder heads as shown in the
illustration.
Seal packing: Part No. 08826±00080 or equivalent

A04015
Wire
Clamp
Bracket
A23333
Rear Water Bypass Joint
A23332
Front Water Bypass Joint
A23331
± ENGINE MECHANICALCYLINDER HEAD
EM±71
2650 Author: Date:
2005 SEQUOIA (RM1146U)
(c) Install the gasket to the cylinder head cover.
(d) Install the seal washer to the bolt.
(e) Install the cylinder head cover with the 9 bolts. Uniformly
tighten the bolts in several steps. Install the 2 cylinder
head covers.
Torque: 6.0 N´m (60 kgf´cm, 53 in.´lbf)
(f) Install the wire clamp bracket on the engine wire to the
camshaft bearing cap.
14. INSTALL ENGINE HANGERS
Torque: 37 N´m (380 kgf´cm, 27 ft´lbf)
15. INSTALL VVT SENSORS (See page SF±77)
16. INSTALL OIL DIPSTICK AND GUIDE FOR ENGINE
17. INSTALL OIL DIPSTICK AND GUIDE FOR A/T
18. INSTALL IGNITION COILS (See page IG±6)
19. INSTALL REAR WATER BYPASS JOINT
(a) Install 2 new gaskets to the cylinder head.
(b) Install the the water bypass joint with the 4 nuts to the cyl-
inder heads. Alternately tighten the nuts.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
20. INSTALL NO.2 AIR SWITCHING VALVES
(See page EC±26)
21. INSTALL AIR PUMP ASSEMBLY (See page EC±26)
22. INSTALL FRONT WATER BYPASS JOINT
Install 2 new gaskets and the water bypass joint with the 4 nuts.
Alternately tighten the nuts.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
23. INSTALL WATER INLET AND INLET HOUSING AS-
SEMBLY (See page CO±8)
24. ASSEMBLE INTAKE MANIFOLDS
(a) Install the 2 delivery pipes and 8 injectors (see page
SF±31).
(b) Install 2 new gaskets and fuel pulsation damper.
(c) Install a new O±ing and fuel pressure regulator with the
2 bolts.
(d) Install the fuel return pipe to the intake manifold with the
3 bolts.
(e) Connect the fuel return hose to the fuel pressure regula-
tor.

B17510
A23330
(j)(j)
(i)(h)
(h) (h)
A23365
A23329
EM±72
± ENGINE MECHANICALCYLINDER HEAD
2651 Author: Date:
2005 SEQUOIA (RM1146U)
(f) Install the VSV for ACIS with the bolt.
Torque: 7.5 N´m (76 kgf´cm, 66 in.´lbf)
(g) Install the throttle body (See page SF±43).
(h) Install 4 new gaskets and front fuel pipe with the bolt and
2 unions to the intake manifold.
Torque:
39 N´m (400 kgf´cm, 29 ft´lbf) for union bolts
7.5 N´m (80 kgf´cm, 66 in.´lbf) for bolt
(i) Install the VSV for EVAP with the bolt to the intake man-
ifold and connect the EVAP hose.
Torque: 7.5 N´m (76 kgf´cm, 66 in.´lbf)
(j) Install the 2 VSVs for air injection system with the 2 bolts.
Torque: 7.5 N´m (76 kgf´cm, 66 in.´lbf)
25. INSTALL INTAKE MANIFOLD ASSEMBLY
(a) Place 2 new gaskets on the intake manifold.
(b) Place the intake manifold assembly on the cylinder
heads.
(c) Install and uniformly tighten the 6 bolts and 4 nuts in sev-
eral steps.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)

A23328
A23327
A23325
A23326
Wire Clamp
± ENGINE MECHANICALCYLINDER HEAD
EM±73
2652 Author: Date:
2005 SEQUOIA (RM1146U)
(d) Install the throttle body cover bracket to the intake man-
ifold.
Torque: 7.5 N´m (76 kgf´cm, 66 in.´lbf)
(e) Install the wire bracket to the intake manifold with the bolt.
Torque: 7.5 N´m (76 kgf´cm, 66 in.´lbf)
(f) Connect the engine wire to the engine hanger and wire
bracket.
(g) Install the engine wire to the LH No.1 timing belt rear
plate.
(h) Connect the wire protector to the intake manifold and cyl-
inder heads with the 2 bolts.
(i) Install the 2 ground cables with the 2 bolts to the RH and
LH cylinder heads.
(j) Connect the 2 water bypass hoses to the throttle body.
(k) Connect the 2 wire clamps to the wire clamp bracket on
the RH delivery pipe.
