TOYOTA SEQUOIA 2001  Service Repair Manual SA0L6±03
± SUSPENSION AND AXLEHEIGHT CONTROL VALVE
SA±167
3163 Author: Date:
2005 SEQUOIA   (RM1146U)
INSTALLATION
Installation is in the reverse order of removal (See page SA±166).

Page 3172 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual SA1I9±03
F16849
N´m (kgf´cm, ft´lbf) : Specified torque
29 (300, 21)
5.4 (55, 48 in.´lbf)
Rear Height
Control Sensor
SA±168
± SUSPENSION AND AXLEREAR HEIGHT CONTROL SENSOR
3164 Author: Date:

Page 3173 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual SA2D3±01
F16835Matchmarks
F16836
± SUSPENSION AND AXLEREAR HEIGHT CONTROL SENSOR
SA±169
3165 Author: Date:
2005 SEQUOIA   (RM1146U)
REMOVAL
1. DISCONNECT CONNECTOR
2. DISCONNECT HEIGHT CONTROL SE

Page 3174 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual SA1IB±03
SA±170
± SUSPENSION AND AXLEREAR HEIGHT CONTROL SENSOR
3166 Author: Date:
2005 SEQUOIA   (RM1146U)
INSTALLATION
Installation is in the reverse order of removal (See page SA±169).

Page 3175 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual SA2CW±01
F16828
F16828
± SUSPENSION AND AXLESUSPENSION CONTROL ECU
SA±171
3167 Author: Date:
2005 SEQUOIA   (RM1146U)
SUSPENSION CONTROL ECU
REPLACEMENT
1. DISCONNECT CABLE FROM NEGATIVE BATTERY

Page 3176 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual BR0A9±04
± BRAKEBRAKE SYSTEM
BR±1
3168 Author: Date:
2005 SEQUOIA   (RM1146U)
BRAKE SYSTEM
PRECAUTION
Care must be taken to replace each part properly as it could affect the performance of the b

Page 3177 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual BR08P±07
BR±2
± BRAKETROUBLESHOOTING
3169 Author: Date:
2005 SEQUOIA   (RM1146U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
Use the table below to help you find the cause of the problem. The numbers

Page 3178 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual ± BRAKETROUBLESHOOTING
BR±3
3170 Author: Date:
2005 SEQUOIA   (RM1146U) Hard pedal but brake inefficient
1. Fluid leaks for brake system
2. Air in brake system
3. Pad (Worn)
4. Pad (Cracked or dis

Page 3179 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual BR08Q±05
F13310
F13311
F13312
BR3885
BR±4
± BRAKEBRAKE FLUID
3171 Author: Date:
2005 SEQUOIA   (RM1146U)
BRAKE FLUID
BLEEDING
HINT:
If any work is done on the brake system or if air is suspected

Page 3180 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual ± BRAKEBRAKE FLUID
BR±5
3172 Author: Date:
2005 SEQUOIA   (RM1146U)
(e) Repeat the procedure on the previous page to bleed the
air out of brake line for each wheel.
4. CHECK FLUID LEVEL IN RESERVO
