TOYOTA SEQUOIA 2001 Service Repair Manual

05_SEQUOIA_U (L/O 0408)
392
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
Front Rear
5. Position the jack at the correct
jack point as shown.
Make sure the jack is positioned on
a level and solid place.
JACK POINTS:
FrontÐUnder the frame side rail
RearÐUnder the rear axle hous-
ing
Put a jack handle, jack handle exten-
sion and jack handle end together as
shown in the illustration.
1 Jack handle end
2 Jack handle extension
3 Jack handle
NOTICE
Tighten all joints securely.
Otherwise, the extension may
come off and it may damage
the paint or vehicle body.
6. After making sure that no one
is in the vehicle, raise it high
enough so that the spare tire
can be installed.
Remember you will need more ground
clearance when putting on the spare
tire than when removing the flat tire.
ÐPositioning the jack ÐRaising your vehicle

05_SEQUOIA_U (L/O 0408)
393
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
To raise the vehicle, insert the jack
handle extension in to the jack (it is
a loose fit) and turn it clockwise with
the handle, making sure the handle
remains firmly fitted onto the jack
handle extension. As the jack touches
the vehicle and begins to fit, double±
check that it is properly positioned.
CAUTION
Never get under the vehicle when
the vehicle is supported by the
jack alone.
7. Remove the wheel nuts and
change tires.
Lift the flat tire straight off and put it
aside.
Roll the spare wheel into position and
align the holes in the wheel with the
bolts. Then lift up the wheel and get
at least the top bolt started through
its hole. Wiggle the tire and press it
back over the other bolts.Before putting on wheels, remove any
corrosion on the mounting surfaces
with a wire brush or such. Installation
of wheels without good metal±to±met-
al contact at the mounting surface can
cause wheel nuts to loosen and
eventually cause a wheel to come off
while driving.
ÐChanging wheels

05_SEQUOIA_U (L/O 0408)
394
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
8. Reinstall all the wheel nuts fin-
ger tight.
Reinstall the wheel nuts (tapered end
inward) and tighten them as much as
you can by hand. Press back on the
tire back and see if you can tighten
them more.
CAUTION
Never use oil or grease on the
bolts or nuts. Doing so may lead
to overtightening the nuts and
damaging the bolts. The nuts
may loose and the wheels may
fall off, which could cause a seri-
ous accident. If there is oil or
grease on any bolt or nut, clean
it.
9. Lower the vehicle completely
and tighten the wheel nuts.
Turn the jack handle extension coun-
terclockwise with handle to lower the
vehicle, making sure the handle re-
mains firmly fitted onto the jack han-
dle extension.
Use only the wheel nut wrench and
turn it clockwise to tighten the nuts.
Do not use other tools or any addition-
al leverage other than your hands,
such as a hammer, pipe or your foot.
Make sure the wrench is securely en-
gaged over the nut.
ÐReinstalling wheel nuts ÐLowering your vehicle

05_SEQUOIA_U (L/O 0408)
395
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
Tighten each nut a little at a time in
the order shown. Repeat the process
until all the nuts are tight.
CAUTION

When lowering the vehicle,
make sure all portions of your
body and all other persons
around will not be injured as
the vehicle is lowered to the
ground.

Have the wheel nuts tightened
with torque wrench to 110 N´m
(11.5 kgf´m, 83 ft´lbf), as soon
as possible after changing
wheels. Otherwise, the nuts
may loosen and the wheels
may fall off, which could cause
a serious accident.
Ty p e A
Ty p e B10.Reinstall the wheel ornament.
Put the wheel ornament into position
and then tap it firmly with the side or
heel of your hand to snap it into place.
CAUTION
Take due care in handling the or-
nament to avoid unexpected per-
sonal injury.
ÐReinstalling wheel ornament

05_SEQUOIA_U (L/O 0408)
396
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
11. Check the air pressure of the re-
placed tire.
Adjust the air pressure to the specifi-
cation designated on page 458 in
Section 8. If the pressure is lower,
drive slowly to the nearest service
station and fill to the correct pressure.
Do not forget to reinstall the tire infla-
tion valve cap as dirt and moisture
could get into the valve core and
possibly cause air leakage. If the cap
is missing, have a new one put on as
soon as possible.
12.Restow all the tools, jack and
flat tire securely.
With a spare tire of the same wheel
type as the installed tiresÐ
As soon after changing wheels as
possible, tighten the wheel nuts to the
torque specified on page 458 in Sec-
tion 8 with a torque wrench. Have a
technician repair the flat tire.With a spare tire of different wheel
type from the installed tiresÐ
As soon after changing wheels as
possible, tighten the wheel nuts to the
torque specified on page 458 in Sec-
tion 8 with a torque wrench. Have a
technician repair the flat tire and re-
place the spare tire with it.
Initial adjustment of the tire pres-
sure warning system is necessary
after you have replaced your tires
or wheels. See ªTire pressure
warning systemº on page 198 in
Section 1±7.
CAUTION
Before driving, make sure all the
tools, jack and flat tire are se-
curely in place in their storage
location to reduce the possibility
of personal injury during a colli-
sion or sudden braking.
If your vehicle becomes stuck in snow,
mud, sand, etc., then you may attempt
to rock the vehicle free by moving it
forward and backward.
Two±wheel drive modelsÐTurn off the
traction control system to become un-
stuck to allow the tires to spin enough
to remove the vehicle from the obstruc-
tion. (For details, see ªTraction control
systemº on page 182 in Section 1±7.)
CAUTION
Do not attempt to rock the vehicle
free by moving it forward and back-
ward if people or objects are any-
where near the vehicle. During the
rocking operation the vehicle may
suddenly move forward or backward
as it becomes unstuck, causing injury
or damage to nearby people or ob-
jects.
ÐAfter changing wheels If your vehicle becomes stuck

05_SEQUOIA_U (L/O 0408)
397
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
NOTICE
If you rock your vehicle, observe the
following precautions to prevent dam-
age to the transmission and other
parts.

Do not depress the accelerator ped-
al while shifting the selector lever
or before the transmission is com-
pletely shifted to forward or reverse
gear.

Do not race the engine and avoid
spinning the wheels.

If your vehicle remains stuck after
rocking the vehicle several times,
consider other ways such as tow-
ing.
(a) Towing with wheel lift type truckÐ
ÐFrom front
ÐFrom rear
(b) Using flat bed truck
Two±wheel drive models(a) Towing with wheel lift type truckÐ
ÐFrom front
ÐFrom rear
(b) Using flat bed truck
Four±wheel drive models
If your vehicle needs to be
towedÐ

05_SEQUOIA_U (L/O 0408)
398
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
If towing is necessary, we recom-
mended you have it done by your
Toyota dealer or a commercial tow
truck service. In consultation with them,
have your vehicle towed using either (a)
or (b).
Only when you cannot receive a towing
service from a Toyota dealer or com-
mercial tow truck service, tow your ve-
hicle carefully in accordance with the
instructions given in ªÐEmergency tow-
ingº on page 399 in this Section.
Proper equipment will help ensure that
your vehicle is not damaged while being
towed. Commercial operators are generally
aware of the state/provincial and local
laws pertaining to towing.
Your vehicle can be damaged if it is
towed incorrectly. Although most operators
know the correct procedure, it is possible
to make a mistake. To avoid damage to
your vehicle, make sure the following pre-
cautions are observed. If necessary, show
this page to the tow truck driver.TOWING PRECAUTIONS:
Use a safety chain system for all towing,
and abide by the state/provincial and local
laws. The wheels and axle on the ground
must be in good condition. If they are
damaged, use a towing dolly.
CAUTION
Vehicles with rear height control air
suspension system: When your ve-
hicle is towed, set the vehicle height
to ªNº in automatic control mode,
then select manual control mode by
pushing the mode select switch.
Otherwise, the vehicle height may
change because of the automatic lev-
eling function, resulting in an acci-
dent. For details, see ªRear height
control air suspensionº on page 189
in Section 1±7.
Two±wheel drive modelsÐ
(a) Towing with wheel lift type truck
From frontÐ
Use a towing dolly under the rear wheels.
NOTICE
Never tow a vehicle from the front
with the rear wheels on the ground,
as this may cause serious damage to
the transmission.
From rearÐ
Place the ignition key in the ªACCº posi-
tion.
NOTICE

When lifting wheels, take care to
ensure adequate ground clearance
for towing at the opposite end of
the raised vehicle. Otherwise, the
bumper and/or underbody of the
towed vehicle will be damaged dur-
ing towing.

Do not tow with the key removed or
in the ªLOCKº position, as the
steering lock mechanism is not
strong enough to hold the front
wheels straight while towing.

05_SEQUOIA_U (L/O 0408)
399
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
(b) Using flat bed truck
Four±wheel drive modelsÐ
(a) Towing with wheel lift type truck
From frontÐ
Use a towing dolly under the rear wheels.
NOTICE
Never tow a vehicle from the front
with the rear wheels on the ground,
as this may cause serious damage to
the transmission.
From rearÐ
We recommend using a towing dolly under
the front wheels. If you do not use a
towing dolly, place the ignition key in the
ªACCº position, put the transmission in
neutral and the transfer in ª2WDº mode.
NOTICE
Do not tow with the key removed or
in the ªLOCKº position when towing
from the rear without a towing dolly.
The steering lock mechanism is not
strong enough to hold the front
wheels straight.
(b) Using flat bed truck
(c) Towing with sling type truck
All modelsÐ
(c) Towing with sling type truck
NOTICE
Do not tow with sling type truck, ei-
ther from the front or rear. This may
cause body damage.
If towing is necessary, we recommend
you to have it done by your Toyota
dealer or a commercial tow truck ser-
vice.
If towing service is not available in an
emergency, your vehicle may be tempo-
rarily towed by a cable or chain se-
cured to the emergency towing hook
under the front of the vehicle. Use ex-
treme caution when towing the vehicle.
NOTICE
Only use specified towing hook;
otherwise your vehicle may be dam-
aged.
ÐEmergency towing

05_SEQUOIA_U (L/O 0408)
400
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
A driver must be in the vehicle to steer
it and operate the brakes.
Towing in this manner may be done only
on hard±surfaced roads for a short dis-
tance and at low speeds. Also, the
wheels, axles, drive train, steering and
brakes must all be in good condition.
CAUTION
Use extreme caution when towing the
vehicle. Avoid sudden starts or errat-
ic driving maneuvers which would
place excessive stress on the emer-
gency towing hook and towing cable
or chain. The hook and towing cable
or chain may break and cause serious
injury or damage.
NOTICE
Use only a cable or chain specifically
intended for use in towing vehicles.
Securely fasten the cable or chain to
the towing hook provided.
Before towing, release the parking brake,
put the transmission in ªNº and as to the
four±wheel drive models, moreover, set
the transfer in ª2WDº mode. The key must
be in ªACCº (engine off) or ªONº (engine
running).
CAUTION
If the engine is not running, the pow-
er assist for the brakes and steering
will not work so steering and braking
will be much harder than usual.

Before emergency towing, check that
the hook is not broken or damaged and
that the installation bolts are not loose.

Fasten the towing cable or chain se-
curely to the hook.

Do not jerk the hook. Apply steady and
even force.

To avoid damaging the hook, do not
pull from the side or at a vertical
angle. Always pull straight ahead.
ÐEmergency towing hook
precautions

05_SEQUOIA_U (L/O 0408)
401
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
CAUTION
If the emergency towing hook is used
to get out when your vehicle becomes
stuck in mud, sand or other condition
from which the vehicle cannot be
driven out under its own power, make
sure to observe the precautions men-
tioned below. Otherwise, excessive
stress will be put on the hook and
the towing cable or chain may break,
causing serious injury or damage.

If the towing vehicle can hardly
move, do not forcibly continue the
towing. Contact your Toyota dealer
or a commercial tow truck service
for assistance.

Tow the vehicle as straight ahead
as possible.

Keep away from the vehicle during
towing.
The following methods are effective to
get out when your vehicle is stuck in
mud, sand or other condition from
which the vehicle cannot be driven out
under its own power. Use extreme cau-
tion when towing vehicles. In addition,
keep away from the vehicles and towing
cable or chain when towing.

Remove the soil and sand in the front
and the back of the tires.

Place a stone or wood under the tires.You can purchase a new key at your
Toyota dealer if you can give them the
key number and master key.
Even if you lose only one key, contact
your Toyota dealer to make a new key. If
you lose all your master keys, you cannot
make new keys; the whole engine immobi-
lizer system must be replaced.
See the suggestion given in ªKeysº on
page 14 in Section 1±2.
If your keys are locked in the vehicle and
you cannot get a duplicate, many Toyota
dealers can still open the door for you,
using their special tools. If you must
break a window to get in, we suggest
breaking the smallest side window be-
cause it is the least expensive to replace.
Be extremely cautious to avoid cuts from
the glass.
ÐTips for towing a stuck
vehicleIf you lose your keys
