Fuel type:Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher
Fuel tank capacity, L (gal., Imp. gal.): 98.5 (26, 21.6) ENGINE
Valve clearance (engine cold), mm (in.):
Intake 0.15—0.25 (0.006—0.010)
Exhaust 0.25—0.35 (0.010—0.014)
Spark plug type: DENSO K20RU
NGK BKR6EYA
Spark plug gap, mm (in.): 0.8 (0.031)
ENGINE LUBRICATION
Oil capacity (drain and ref ill),
L (qt., Imp. qt.): With filter 6.2 (6.5, 5.5)
Without filter 5.7 (6.0, 5.0)
“Toyota Genuine Motor Oil” is f illed in
your Toyota vehicle. Use Toyota approved
“Toyota Genuine Motor Oil” or equivalent
to satisfy the following grade and
viscosity. Oil grade:
API grade SL “EnergyConserving” or
ILSAC multigrade engine oil
Recommended oil viscosity: SAE 5W30
Outside temperature
Please contact your Toyota dealer for fur-
ther details.
Fuel Service specifications

03_SEQUOIA_U (L/O 0301)
386
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):With rear heater 13.4 (14.1, 11.8)
Without rear heater 11.7 (12.4, 10.2)
Coolant type:
“Toyota Genuine Long Life Coolant” is
filled in your Toyota vehicle. In order to
avoid technical problems, we strongly
recommend using “Toyota Genuine Long
Life Coolant” or equivalent.
With ethyleneglycol type coolant for a
proper corrosion protection of aluminum
components
Do not use alcohol type antifreeze or
plain water alone.
Please contact your Toyota dealer for
further details.
BATTERY
Open voltage
∗ at 20 C (68 F):
12.6—12.8 V Fully charged
12.2—12.4 V Half charged
11.8—12.0 V Discharged
∗: Voltage that is checked 20 minutes af-
ter the key is removed with all the
lights turned off
Charging rates: 5 A max. AUTOMATIC TRANSMISSION
Fluid capacity (drain and ref
ill),
L (qt., Imp. qt.):
Up to 2.0 (2.1, 1.8)
Fluid type: Toyota Genuine ATF Type TIV
Change automatic transmission fluid only
as necessary.
Generally, it is necessary to change
automatic transmission fluid only if your
vehicle is driven under one of the Special
Operating Conditions listed in your
“Scheduled Maintenance Guide” or
“Owner ’s Manual Supplement”. When
changing the automatic transmission fluid,
use only “Toyota Genuine ATF Type TIV”
(ATF JWS3309 or NWS6500) to aid in
assuring optimum transmission perfor-
mance.
Notice: Using automatic transmission
fluid other than “Toyota Genuine ATF
Type TIV” may cause deterioration in
shift quality, locking up of your trans-
mission accompanied by vibration, and
ultimately damage the automatic trans-
mission of your vehicle.
Please contact your Toyota dealer for fur-
ther details. TRANSFER
Oil capacity, L (qt., Imp. qt.):
1.2 (1.3, 1.1)
Oil type: Gear oil API GL4 or GL5
Recommended oil viscosity: SAE 75W90
DIFFERENTIAL
Oil capacity, L (qt., Imp. qt.): Front1.15 (1.2, 1.0)
Rear 3.65 (3.9, 3.3)
Oil type: Hypoid gear oil API GL5
Recommended oil viscosity:
FrontSAE 75W90
Rear Synthetic oil SAE 75W140
CHASSIS LUBRICATION
Propeller shafts: Spiders and slide yokes
Lithium base chassis grease, NLGI
No.2

03_SEQUOIA_U (L/O 0301)
387
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
BRAKES
Minimum pedal clearance when depressed
with the force of 490 N (50 kgf, 110 lbf)
with the engine stopping and after de-
pressing the brake pedal several times,
mm (in.):113 (4.5)
Pedal free play, mm (in.): 1—6 (0.04—0.24)
Pad wear limit, mm (in.): 1.0 (0.04)
Lining wear limit, mm (in.): 1.0 (0.04)
Parking brake adjustment when depressed
with the force of 300 N (31 kgf, 67 lbf): 6—9 clicks
Fluid type: SAE J1703 or FMVSS No.116 DOT 3
STEERING
Wheel free play: Less than 30 mm (1.2 in.)
Power steering fluid type: Automatic transmission fluid DEXRON II
or III

03_SEQUOIA_U (L/O 0301)
388
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
Engine compartment
Fuses (type A)1. HLP RH 10 A (with daytime running light system): Righthand headlight
(high beam)
2. HLP LH 10 A (with daytime running light system): Lefthand headlight
(high beam)
3. STA 7.5 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, electronic throttle control sys-
tem
4. HLP RL 10 A (with daytime running light system): Righthand headlight
(low beam)
Tires
Tire size Tire pressure
kPa (kgf/cm2 or bar, psi)
Front Rear
P245/70R16
P265/70R16 220 (2.2, 32) 240 (2.4, 35)
220 (2.2, 32) 220 (2.2, 32) Wheel size
16 7J or 7JJ
16 7J or 7JJ
NOTE: For a complete information on tires (e.g. replacing tires or replacing wheels), see “Checking tire pressure” through “Aluminum wheel precautions”, pages
363 through 369, in Section 72.
Wheel nut torque, N⋅ m (kgf⋅m, ft ⋅lbf):
11 0 ( 11 . 5 , 8 3 )
Tire size, pressure and wheel size:
P265/65R17 220 (2.2, 32) 220 (2.2, 32) 17
7 1/ 2J J
Fuses

03_SEQUOIA_U (L/O 0301)
389
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
Engine compartment
5. HLP LL 10 A (with daytime runninglight system): Lefthand headlight (low
beam)
6. RSE 7.5 A: Rear seat audio system,
rear seat entertainment system
7. TOWING TAIL 30 A: Trailer lights (tail
lights)
8. BATT CHARGE 30 A: Trailer sub bat-
tery
9. TOWING BRK 30 A: Trailer brake con-
troller
10. CDS FAN 25 A: Electric cooling fan
11. SPARE 15 A: Spare fuse
Engine compartment
12. SPARE 20 A: Spare fuse
13. SPARE 30 A: Spare fuse
14. ETCS 10 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system, electronic throttle control
system
15. EFI NO.1 20 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system, electric throttle control
system
16. HLP RH 15 A (without daytime run- ning light system): Righthand head-
light
Instrument panel
17. TOWING 30 A: Trailer lights (stop
lights, turn signal lights)
18. ALTS 7.5 A: Charging system
19. DRL 15 A (with daytime running light system): Multiplex communication sys-
tem (power door lock system, security
system, auto door locking system, au-
tomatic light control system, headlight
delay off system, tail light auto cut
system, illuminated entry system, day-
time running light system)
HLP LH 15 A (without daytime run-
ning light system): Lefthand head-
light

03_SEQUOIA_U (L/O 0301)
390
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
20. AM2 25 A: Starting system, multiport
fuel injection system/sequential multi-
port fuel injection system, electronic
throttle control system, “IGN 1” and
“IGN 2” fuses
21. TURNHAZ 20 A: Turn signal lights,
emergency flashers
22. RAD NO.3 20 A: Car audio/video sys-
tem
23. ST 30 A: Starting system, “STA” fuse
24. HORN 10 A: Horns
25. EFI NO.2 10 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system, electronic throttle control
system
26. DOME 10 A: Center interior and per-
sonal lights, personal lights, luggage
compartment light, air conditioning sys-
tem, wireless remote control system,
garage door opener, ignition switch
light, door courtesy lights, foot light,
vanity lights, power antenna 27. ECUB 7.5 A:
Multiplex communication
system (power door lock system, secu-
rity system, autodoor locking system,
automatic light control system, head-
light delay off system, tail light auto
cut system, illuminated entry system,
daytime running light system), back
door lock system, driver and front pas-
senger door lock system, gauges and
meters
28. MIR HTR 15 A: Outside rear view mir-
ror heaters
29. RAD NO.1 25 A: Car audio system
30. TAIL 15 A: Tail lights, back door cour-
tesy light, license plate lights
31. ECUIG 10 A: Charging system, cruise
control system, antilock brake system,
vehicle skid control system, traction
control system (twowheel drive mod-
els), active traction control system
(fourwheel drive models), electronical-
ly controlled automatic transmission
system, power antenna, electric moon
roof, back door lock system, driver and
front passenger door lock system,
gauges and meters, multiinformation
display, SRS airbag system, front seat
belt pretensioners
32. WSH 25 A: Wipers and washer
33. AC INV 15 A: Power outlets 34. IGN 2 20 A:
Starting system
35. PWR NO.3 20 A: Rear passenger ’s
power window (right side)
36. PWR NO.4 20 A: Rear passenger ’s
power window (left side)
37. CIG 15 A: Air conditioning systems,
power rear view mirror control, ciga-
rette lighter
38. RAD NO.2 7.5 A: Car audio/video sys-
tem, power antenna, power outlets,
multiplex communication system (power
door lock system, security system,
autodoor locking system, automatic
light control system, headlight delay off
system, tail light auto cut system, illu-
minated entry system, daytime running
light system)
39. 4WD 20 A: A.D.D. control system,
fourwheel drive system
40. STOP 15 A: Stop lights, highmounted
stop lights, multiport fuel injection sys-
tem/sequential multiport fuel injection
system, vehicle skid control system,
traction control system (twowheel
drive models), active traction control
system (fourw heel drive models), mul-
tiplex communication system (autodoor
locking system)

03_SEQUOIA_U (L/O 0301)
391
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
41. OBD 7.5 A: Onboard diagnosis sys-
tem
42. PANEL 7.5 A: Instrument panel lights,
glove box light, lights of seat heaters,
cigarette lighter, ashtrays, multiinfor-
mation display, car audio/video system,
gauge and meters, air conditioning sys-
tems
43. PWR NO.1 25 A: Driver ’s door lock
system
44. WIP 25 A: Wiper and washers
45. IGN 1 10 A: Charging system
46. SUN ROOF 25 A: Electric moon roof
47. PWR NO.2 25 A: Front passengers’
door lock system
48. HTR 10 A: Air conditioning systems,
electric cooling fan, back window de-
fogger, outside rear view mirror heater
49. FOG 15 A: Front fog lights
50. GAUGE 15 A: Backup lights, seat
heaters, gauge and meters, air condi-
tioning systems
51. PWR OUTLET 15 A: Power outlets
52. SEAT HTR 15 A: Seat heaters Fuses (type B)
53. RR HEATER 30 A: Rear air condition-
ing system
54. HEATER 40 A: Front air conditioning
system
55. DEFOG 40 A: Back window defogger
56. MAIN 40 A: Starting system, “HLP
RH”, “HLP LH” and “STA” fuses
57. DOOR NO.2 30 A: Multiplex commu-
nication system (power door lock sys-
tem, security system, autodoor locking
system)
58. PWR SEAT 30 A: Power front seats
59. AM1 40 A: “HTR”, “CIG”, “GAUGE”,
“RAD NO.2”, “ECUIG”, “WIPER”,
“WSH” and “4WD” fuses
60. PWR NO.5 30 A: Power door lock sys-
tem, back door lock system Fuses (type C)
61. ALT 140 A: “AM1”, “PWR SEAT”,
“TAIL”, “STOP”, “SUN ROOF”, “PANEL”,
“OBD”, “FOG”, “PWR NO.1”, “PWR
NO.2”, “PWR NO.5”, “PWR NO.3”,
“PWR NO.4”, “PWR OUTLET” and
“SEAT HTR” fuses
62. ABS 60 A: Antilock brake system,
vehicle skid control system, traction
control system (twowheel drive mod-
els), active traction control system
(fourwheel drive models)

03_SEQUOIA_U (L/O 0301)
392
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)

03_SEQUOIA_U (L/O 0301)
393
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
REPORTING SAFETY DEFECTS FOR U.S.
OWNERS AND UNIFORM TIRE QUALITY
GRADING
Reporting safety defects for U.S. owners and uniform
tire quality grading
Reporting safety defects for U.S. owners394
. . . . . . . . . . . . . . . . . . . . . .
Uniform tire quality grading 394
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 9

03_SEQUOIA_U (L/O 0301)
394
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
If you believe that your vehicle
has a defect which could cause a
crash or could cause injury or
death, you should immediately in-
form the National Highway Traffic
Safety Administration (NHTSA) in
addition to notifying Toyota Motor
Sales, U.S.A., Inc.
(Tollfree: 18003314331).
If NHTSA receives similar com-
plaints, it may open an investiga-
tion, and if it finds that a safety
defect exists in a group of ve-
hicles, it may order a recall and
remedy campaign. However,
NHTSA cannot become involved
in individual problems between
you, your dealer, or Toyota Motor
Sales, U.S.A., Inc.To contact NHTSA, you may ei-
ther call the Auto Safety Hotline
tollfree at 18004249393 (or
3660123 in Washington, D.C.
area) or write to: NHTSA, U.S.
Department of Transportation,
Washington, D.C. 20590. You can
also obtain other information about
motor vehicle safety from the Hot-
line.This information has been prepared in ac-
cordance with regulations issued by the
National Highway Traffic Safety Adminis-
tration of the U.S. Department of Trans-
portation. It provides the purchasers and/
or prospective purchasers of Toyota
vehicles with information on uniform tire
quality grading.
Your Toyota dealer will help answer any
questions you may have as you read this
information.
DOT quality grades—All passenger car
tires must conform to Federal Safety
Requirements in addition to these
grades. Quality grades can be found
where applicable on the tire sidewall
between tread shoulder and maximum
section width. For example: Treadwear
200 Traction AA Temperature A
Reporting safety defects for
U.S. owners
Uniform tire quality grading
