1. Side vents
2. Instrument cluster
3. Center vents
4. Multi−information display
5. Personal lights
6. Garage door opener box or auxiliary box
7. Electric moon roof switches
8. Side defroster outlet
9. Glove box
10. Power door lock switches
11. Power window switches
12. Power outlets
13. Seat heater switches
14. Rear console box
15. Rear air conditioning controls
16. Headphone input jacks and headphone volume control dials
17. Input terminal adapter
18. Cup holders
19. Power rear view mirror control switches
20. Front drive control lever
21. Lower vent
Instrument panel overview

04_SEQUOIA_U (L/O 0309)
255
2004 SEQUOIA from Sep. ’03 Prod. (OM34423U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Other equipment
Multi−information display 256
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock 267
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtrays 267
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power outlets 268
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Power outlet 269
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
Glove box 270
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . .
Garage door opener box 271
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Auxiliary boxes 273
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Rear console box 275
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . .
Note pad holder 276
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
Coin holder 277
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Compact disc and cassette tape holder 278
. . . . . . . . . . . . . . . . . . . . . . .
Cup holders 279
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Tie −down hooks 280
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
Grocery bag hooks 280
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Cargo net hooks 280
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
Roof luggage carrier 281
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
Floor mat 282
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . .
SECTION 1 10

04_SEQUOIA_U (L/O 0309)
270
2004 SEQUOIA from Sep. ’03 Prod. (OM34423U)
NOTICE
To prevent the battery from being
discharged, do not use the power
outlet longer than necessary when
the engine is not running.
 Close the power outlet lid when the
power outlet is not in use. Inserting
a foreign object other than the ap-
propriate plug that fits the outlet
may cause electrical failure or short
circuits.
The power outlet is not designed for
the following electric appliances even
though their power consumption is un-
der 115 VAC/100W. These appliances
may not operate properly.
Appliances with high initial peak watt-
age: cathode −ray tube type televisions,
compressor −driven refrigerators, electric
pumps, electric tools, etc.
Measuring devices which process pre-
cise data: medical equipment, measur-
ing instruments, etc.
Other appliances requiring an extremely
stable power supply: microcomputer −
controlled electric blankets, touch sen-
sor lamps, etc.
Certain electrical appliances may cause
radio noise.
To use the glove box, pull the lever.
The glove box light will come on when the
glove box is open with the instrument pan-
el lights on.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the glove box door
closed while driving.
Glove box

04_SEQUOIA_U (L/O 0309)
320
2004 SEQUOIA from Sep. ’03 Prod. (OM34423U)
SERVICE CONNECTOR FOR TOWING
BRAKE CONTROLLER (with towing
package)
Your vehicle is equipped with a service
connector for the towing brake controller
as shown. Link the connector to the tow-
ing brake controller via the sub wire har-
ness stored in the glove box. The detailed
explanation of the sub wire harness circuit
is packed together with the sub wire har-
ness.
Be sure to position the towing brake con-
troller where it does not prevent the driver
from operating the pedal.
Toyota recommends that the sub wire har-
ness be stored in the glove box when it
is not in use.TIRES
Ensure that your vehicle’s tires are
properly inflated. See page 375 in Sec-
tion 7
−2 and page 402 in Section 8 for
instructions.
The trailer tires should be inflated to
the pressure recommended by the trail-
er manufacturer in respect to the total
trailer weight.
4pin connector
7pin connector

04_SEQUOIA_U (L/O 0309)
390
2004 SEQUOIA from Sep. ’03 Prod. (OM34423U)
The following illustrations show how to
gain access to the bulbs. When replacing
a bulb, make sure the ignition switch and
light switch are off. Use bulbs with the
wattage ratings given in the table.
CAUTION
To prevent burning yourself, do not
replace the light bulbs while they
are hot.
Halogen bulbs have pressurized gas
inside and require special handling.
They can burst or shatter if
scratched or dropped. Hold a bulb
only by its plastic or metal case.
Do not touch the glass part of a
bulb with bare hands.
NOTICE
Only use a bulb of the listed type.
Light bulbsBulbNo.WTy p e
Headlights—60/55A
Front fog lights900655B
Parking, front side
marker and front
turn signal lights3157 NA27/8C
Rear turn signal
lights744021D
Stop/tail and rear
side marker lights744321/5D
Back −up lights92118D
Tail lights1685D
License plate lights1685D
High mounted stop
light1685D
Interior lights—8E
Personal lights—3.8D
Glove box light—1.2D
Luggage
compartment light—8E
Vanity lights—3D
Door courtesy
lights1943.4D
A: HB2 halogen bulbs
B: HB4 halogen bulbs
C: Wedge base bulbs (amber)
D: Wedge base bulbs (clear)
E: Double end bulbs
Replacing light bulbs—

04_SEQUOIA_U (L/O 0309)
405
2004 SEQUOIA from Sep. ’03 Prod. (OM34423U)
41. OBD 7.5 A: On−board diagnosis sys-
tem
42. PANEL 7.5 A: Instrument panel lights,
glove box light, lights of seat heaters,
cigarette lighter, ashtrays, multi −infor-
mation display, car audio/video system,
gauge and meters, air conditioning sys-
tems
43. PWR NO.1 25 A: Driver ’s door lock
system
44. WIP 25 A: Wiper and washers
45. IGN 1 10 A: Charging system
46. SUN ROOF 25 A: Electric moon roof
47. PWR NO.2 25 A: Front passengers’
door lock system
48. HTR 10 A: Air conditioning systems,
electric cooling fan, back window de-
fogger, outside rear view mirror heater
49. FOG 15 A: Front fog lights
50. GAUGE 15 A: Back−up lights, seat
heaters, gauge and meters, air condi-
tioning systems
51. PWR OUTLET 15 A: Power outlets
52. SEAT HTR 15 A: Seat heaters Fuses (type B)
53. RR HEATER 30 A: Rear air condition-
ing system
54. HEATER 40 A: Front air conditioning
system
55. DEFOG 40 A: Back window defogger
56. MAIN 40 A: Starting system, “H −LP
RH”, “H− LP LH” and “STA” fuses
57. DOOR NO.2 30 A: Multiplex commu-
nication system (power door lock sys-
tem, security system, auto −door locking
system)
58. PWR SEAT 30 A: Power front seats
59. AM1 40 A: “HTR”, “CIG”, “GAUGE”,
“RAD NO.2”, “ECU −IG”, “WIPER”,
“WSH” and “4WD” fuses
60. PWR NO.5 30 A: Power door lock sys-
tem, back door lock system Fuses (type C)
61. ALT 140 A: “AM1”, “PWR SEAT”,
“TAIL”, “STOP”, “SUN ROOF”, “PANEL”,
“OBD”, “FOG”, “PWR NO.1”, “PWR
NO.2”, “PWR NO.5”, “PWR NO.3”,
“PWR NO.4”, “PWR OUTLET” and
“SEAT HTR” fuses
62. ABS 60 A: Anti−lock brake system,
vehicle stability control system, traction
control system (two −wheel drive mod-
els), active traction control system
(four −wheel drive models)
