window TOYOTA SEQUOIA 2005 1.G Owner's Guide

05_SEQUOIA_U (L/O 0409)
354
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
Ti r e relat ed ter mMeaning
Accessory weight
the combined weight (in excess of those standard items which may be
replaced) of automatic transmission, power steering, power brakes, power
windows, power seats, radio, and heater, to the extent that these items
are available as factory−installed equipment (whether installed or not)
Cold tire inflation pressure
tire inflation pressure when the vehicle has been parked for at least 3
hours or more, or it has not been driven more than 1.5 km or 1 mile
under that condition
Curb weight
the weight of a motor vehicle wi th standard equipment including the
maximum capacity of fuel, oil, and coolant, and, if so equipped, air
conditioning and additional weight optional engine
Intended outboard sidewall
(A) the sidewall that contains a whitewall, bears white lettering or bears manufacturer, brand, and/or model name molding that is higher or
deeper than the same molding on th e other sidewall of the tire, or
(B) the outward facing sidewall of an asymmetrical tire that has a particular side that must always face outward when mounted on a vehicle
Maximum inflation pressurethe maximum cold inflation pressure to which a tire may be inflated and it
is shown on the sidewall of the tire
Maximum loaded vehicle weight
t he sum of —
(a) curb weight;
(b) accessory weight;
(c) vehicle capacity weight; and
(d) production options weight
—Glossary of tire terminology

05_SEQUOIA_U (L/O 0409)
370
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
Keep ice and snow from accumulating
under the fenders.
Ice and snow built up under your fenders
can make steering difficult. During bad
winter driving, stop and check under the
fenders occasionally.
Depending on where you are driving,
we recommend you carry some emer-
gency equipment.
Some of the things you might put in the
vehicle are tire chains, window scraper,
bag of sand or salt, flares, small shovel,
jumper cables, etc.
Your vehicle is not designed to be
dinghy towed (with four wheels on the
ground) behind a motorhome.
NOTICE
Do not tow your vehicle with four
wheels on the ground. This may
cause serious damage to your vehicle.
Your vehicle is designed primarily as a
passenger−and− load− carrying vehicle.
Towing a trailer will have an adverse
effect on handling, performance, braking,
durability and driving economy (fuel
consumption, etc.). Your safety and
satisfaction depend on the proper use of
correct equipment and cautious driving
habits. For your safety and the safety of
others, you must not overload your
vehicle or trailer. Ask your local Toyota
dealer for further details before towing.
CAUTION
Vehicles with rear height control air
suspension system: When disconnect-
ing a trailer, set the vehicle height to
“LO” in automatic control mode, then
select manual control mode by push-
ing the height control mode select
switch. Otherwise, the vehicle height
may change because of the automatic
leveling function, resulting in an acci-
dent. For details, see “Rear height
control air suspension” on page 189
in Section 17.
Dinghy towing Trailer towing

05_SEQUOIA_U (L/O 0409)
403
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
CAUTION
If the emergency towing hook is used
to get out when your vehicle becomes
stuck in mud, sand or other condition
from which the vehicle cannot be
driven out under its own power, make
sure to observe the precautions men-
tioned below. Otherwise, excessive
stress will be put on the hook and
the towing cable or chain may break,
causing serious injury or damage.
If the towing vehicle can hardly
move, do not forcibly continue the
towing. Contact your Toyota dealer
or a commercial tow truck service
for assistance.
Tow the vehicle as straight ahead
as possible.
Keep away from the vehicle during
towing.
The following methods are effective to
get out when your vehicle is stuck in
mud, sand or other condition from
which the vehicle cannot be driven out
under its own power. Use extreme cau-
tion when towing vehicles. In addition,
keep away from the vehicles and towing
cable or chain when towing.
Remove the soil and sand in the front
and the back of the tires.
Place a stone or wood under the tires.You can purchase a new key at your
Toyota dealer if you can give them the
key number and master key.
Even if you lose only one key, contact
your Toyota dealer to make a new key. If
you lose all your master keys, you cannot
make new keys; the whole engine immobi-
lizer system must be replaced.
See the suggestion given in “Keys” on
page 14 in Section 1
−2.
If your keys are locked in the vehicle and
you cannot get a duplicate, many Toyota
dealers can still open the door for you,
using their special tools. If you must
break a window to get in, we suggest
breaking the smallest side window be-
cause it is the least expensive to replace.
Be extremely cautious to avoid cuts from
the glass.
—Tips for towing a stuck
vehicle If you lose your keys

05_SEQUOIA_U (L/O 0409)
409
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
CAUTION
Vehicles with side airbags and cur-
tain shield airbags:
Be careful not to splash water or
spill liquid on the floor. This may
prevent the side and curtain shield
airbags from activating correctly, re-
sulting in serious injury.
Do not wash the vehicle floor with
water, or allow water to get onto
the floor when cleaning the vehicle
interior or exterior. Water may get
into audio components or other
electrical components above or un-
der the floor carpet (or mat) and
cause a malfunction; and it may
cause body corrosion.
Vinyl interior
The vinyl upholstery may be easily
cleaned with a mild soap or detergent
and water.
First vacuum over the upholstery to re-
move loose dirt. Then, using a sponge or
soft cloth, apply the soap solution to the
vinyl. After allowing it to soak in for a few
minutes to loosen the dirt, remove the dirt
and wipe off the soap with a clean damp
cloth. If all the dirt does not come off,
repeat the procedure. Commercial foam-
ing−type vinyl cleaners are also available
which work well. Follow the manufacturer’s
instructions.
NOTICE
Do not use solvent, thinner, gasoline
or window cleaner on the interior.
Carpets
Use a good foamtype shampoo to
clean the carpets.
Begin by vacuuming thoroughly to remove
as much dirt as possible. Several types of
foam cleaners are available; some are in
aerosol cans and others are powders or
liquids which you mix with water to pro-
duce a foam. To shampoo the carpets,
use a sponge or brush to apply the foam.
Rub in overlapping circles.
Do not apply water—the best results are
obtained by keeping the carpet as dry as
possible. Read the shampoo instructions
and follow them closely.
Seat belts
The seat belts may be cleaned with
mild soap and water or with lukewarm
water.
Use a cloth or sponge. As you are clean-
ing, check the belts for excessive wear,
fraying, or cuts.
NOTICE
 Do not use dye or bleach on the
belts—it may weaken them.
 Do not use the belts until they be-
come dry.
Cleaning the interior

05_SEQUOIA_U (L/O 0409)
410
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
Windows
The windows may be cleaned with any
household window cleaner.
NOTICE
When cleaning the inside of the
back window, be careful not to
scratch or damage the heater wires
or connectors.
 When cleaning the inside of the
rear quarter window, be careful not
to scratch or damage the printed
antenna.
Air conditioning control panel, audio
panel, instrument panel, console panel,
and switches
Use a soft damp cloth for cleaning.
Soak a clean soft cloth in water or luke-
warm water then lightly wipe off dirt.
NOTICE
Do not use organic substances (sol-
vents, kerosene, alcohol, gasoline,
etc.) or alkaline or acidic solutions.
These chemicals can cause discol-
oring, staining or peeling of the
surface.
 If you use cleaners or polishing
agents, make sure their ingredients
do not include the substances men-
tioned above.
 If you use a liquid car freshener, do
not apill the liquid onto the ve-
hicle’s interior surfaces. It may con-
tain the ingredients mentioned
above. Immediately clean any spill
using the method mentioned above.
Leather Interior
The leather upholstery may be cleaned
with neutral detergent for wool.
Remove dirt using a soft cloth dampened
with 5% solution of neutral detergent for
wool. Then thoroughly wipe off all traces
of detergent with a clean damp cloth. After cleaning or whenever any part of the
leather gets wet, dry with a soft clean
cloth. Allow the leather to dry in a venti-
lated shaded area.
NOTICE

If a stain should fail to come out
with a neutral detergent, apply a
cleaner that does not contain an
organic solvent.
 Never use organic substances such
as benzine, alcohol or gasoline, or
alkaline or acid solutions for clean-
ing the leather as these could
cause discoloring.
 Use of a nylon brush or synthetic
fiber cloth, etc. may scratch the
fine grained surface of the leather.
 Mildew may develop on soiled leath-
er upholstery. Be especially careful
to avoid oil spots. Try to keep your
upholstery always clean.
 Long exposure to direct sunlight
may cause the leather surface to
harden and shrink. Keep your ve-
hicle in a shaded area, especially in
the summer.

05_SEQUOIA_U (L/O 0409)
417
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
Tire inflation pressure
Check the pressure with a gauge ev-
ery two weeks, or at least once a
month. See page 431 in Section 7−2
for additional information.
Tire surface and wheel nuts
Check the tires carefully for cuts,
damage or excessive wear. See page
434 in Section 7− 2 for additional in-
formation. When checking the tires,
make sure no nuts are missing, and
check the nuts for looseness. Tighten
them if necessary.
Tire rotation
Rotate the tires according to the
maintenance schedule. (For sched-
uled maintenance information, please
refer to the “Scheduled Maintenance
Guide” or “Owner ’s Manual Supple-
ment”.) See page 436 in Section 7 −2
for additional information.Be on the alert for changes in perfor-
mance, sounds, and visual tip −offs that
indicate service is needed. Some impor-
tant clues are as follows:
Engine missing, stumbling, or pinging
Appreciable loss of power
Strange engine noises
A leak under the vehicle (however, wa-
ter dripping from the air conditioning
after use is normal.)
Change in exhaust sound (This may
indicate a dangerous carbon monoxide
leak. Drive with the windows open and
have the exhaust system checked im-
mediately.)
Flat −looking tire; excessive tire squeal
when cornering; uneven tire wear
Vehicle pulls to one side when driving
straight on a level road
Strange noises related to suspension
movement
Loss of brake effectiveness; spongy
feeling brake pedal; pedal almost
touches floor; vehicle pulls to one side
when braking
Engine coolant temperature continually
higher than normal
Engine continually runs hot; oil pres-
sure gauge stays low
If you notice any of these clues, take your
vehicle to your Toyota dealer as soon as
possible. It probably needs adjustment or
repair.
CAUTION
Do not continue driving with the ve-
hicle unchecked. It could result in se-
rious vehicle damage and possibly
personal injury.
Does your vehicle need
repairing?

05_SEQUOIA_U (L/O 0409)
420
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
1. Windshield and back window washerfluid tank
2. Power steering fluid reservoir
3. Engine oil level dipstick
4. Engine oil filler cap
5. Brake fluid reservoir
6. Fuse blocks
7. Battery
8. Engine coolant reservoir
9. Condenser
10. Radiator
Engine compartment overview

05_SEQUOIA_U (L/O 0409)
461
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
Engine compartment
Fuses (type A)1. AIR SUS No.2 10 A: Rear height con-
trol air suspension system
2. RSE 7.5 A: Rear seat audio system,
rear seat entertainment system
3. A/F 20 A: A/F sensor
4. SECURITY 15 A: Multiplex communica-
tion system
5. DEF I/UP 7.5 A: Rear window defog-
ger, outside rear view mirror defoggers,
multiport fuel injection system/sequen-
tial multiport fuel injection system
Engine compartment
6. HLP LL 10 A (with daytime running light system): Left−hand headlight (low
beam)
7. HLP RL 10 A (with daytime running light system): Right−hand headlight
(low beam)
8. STA 7.5 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, electronic throttle control sys-
tem
9. HLP LH 10 A (with daytime running light system): Left−hand headlight
(high beam)
Engine compartment
10. HLP RH 10 A (with daytime running light system): Right−hand headlight
(high beam)
11. TOWING TAIL 30 A: Trailer lights (tail
lights)
12. BATT CHARGE 30 A: Trailer sub bat-
tery
13. TOWING BRK 30 A: Trailer brake con-
troller
14. CDS FAN 25 A: Electric cooling fan
15. SPARE 15 A: Spare fuse
16. SPARE 20 A: Spare fuse
17. SPARE 30 A: Spare fuse
Fuses

05_SEQUOIA_U (L/O 0409)
463
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
38. IGN 2 20 A: Starting system
39. PWR NO.3 20 A: Rear passenger ’s
power window (right side)
40. PWR NO.4 20 A: Rear passenger ’s
power window (left side)
41. CIG 15 A: Air conditioning systems,
power rear view mirror control, ciga-
rette lighter
42. RAD NO.2 7.5 A: Audio/video system,
power outlets, multiplex communication
system (power door lock system, secu-
rity system, auto −door locking system,
automatic light control system, head-
light delay off system, tail light auto
cut system, illuminated entry system,
daytime running light system)
43. 4WD 20 A: A.D.D. control system,
four −wheel drive system
44. STOP 15 A: Stoplights, high−mounted
stoplights, multiport fuel injection sys-
tem/sequential multiport fuel injection
system, vehicle stability control system,
traction control system (two −wheel
drive models), active traction control
system (four −wheel drive models), mul-
tiplex communication system
45. OBD 7.5 A: On−board diagnosis sys-
tem 46. PANEL 7.5 A:
Instrument panel lights,
glove box light, seat heaters, cigarette
lighter, ashtrays, multi −information dis-
play, audio/video system, gauge and
meters, air conditioning systems
47. PWR NO.1 25 A: Driver ’s door lock
system
48. WIP 25 A: Wiper and washers
49. IGN 1 10 A: Charging system
50. SUN ROOF 25 A: Electric moon roof
51. PWR NO.2 25 A: Front passengers’
door lock system
52. HTR 10 A: Air conditioning systems,
electric cooling fan, back window de-
fogger, outside rear view mirror heater
53. FOG 15 A: Front fog lights
54. GAUGE 15 A: Back−up lights, seat
heaters, gauge and meters, air condi-
tioning systems
55. PWR OUTLET 15 A: Power outlets
56. SEAT HTR 15 A: Seat heaters Fuses (type B)
57. MAIN 40 A: Starting system, “H −LP
RH”, “H− LP LH” and “STA” fuses
58. DOOR NO.2 30 A: Multiplex commu-
nication system (power door lock sys-
tem, security system, auto −door locking
system)
59. PWR SEAT 30 A: Power seats
60. AM1 40 A: “HTR”, “CIG”, “GAUGE”,
“RAD NO.2”, “ECU −IG”, “WIP”, “WSH”
and “4WD” fuses
6

1. PWR NO.5 30 A: Power door lock sys-
tem, back door lock system
Fuses (type C)
62. RR HEATER 30 A: Rear air condition-
ing system
63. DEFOG 40 A: Back window defogger
64. HEATER 50 A: Front air conditioning
system
65. AIR SUS 50 A: Rear height control air
suspension system
66. TOWING R/B 60 A: Trailer brake con-
troller, trailer lights (tail lights), trailer
sub battery
