’06_SEQUOIA_U (L/O 0508)
38
WHEN THE SYSTEM IS SET
Activating the system
The system will sound the alarm under
the following conditions:
If any of the side doors is unlocked or
opened without the key or wireless re-
mote control transmitter, or if the back
door or hood is forcibly opened
If the battery terminal is disconnected
and then reconnected
Vehicles with the glass breakage sensor—
The side windows are tapped or bro-
ken.
The indicator light will come on when the
system is activated.
If the alarm has been activated and the
key is not in the ignition switch, all the
side doors and back door will re −lock au-
tomatically.
After one minute, the alarm will automati-
cally stop and the indicator light will starts
flashing again. Reactivating the alarm
Once set, the system automatically resets
the alarm after the alarm stops.
The alarm will activate again under the
same circumstances described in
“Activating the system”.
Stopping the alarm
The alarm will be stopped by the following
two ways:
Turn the ignition key from the “LOCK”
to “ON” position.
Unlock any of the side doors or back
door with the key or wireless remote
control transmitter.
These ways cancel the system at the
same time. TESTING THE SYSTEM
1. Open all the windows.
2. Set the system as described above. The side doors and back door should
be locked with the key or wireless re-
mote control transmitter. Be sure to
wait until the indicator light goes off or
starts flashing.
3. Unlock any side door from the inside. The system should activate the alarm.
4. Stop the alarm as described above.
5. Repeat this operation for the other doors and hood. When testing the
hood, also check that the system is
activated when the battery terminal is
disconnected and then reconnected.
If the system does not work properly,
have it checked by your Toyota dealer.

’06_SEQUOIA_U (L/O 0508)
145
The lights automatically turn off after 30
seconds when all the side doors and back
door are closed with the ignition key in
the “ACC” or “LOCK” position and the le-
ver at position 2.
The lights also automatically turn off when
the driver ’s door is opened with the lever
at position 1.
If the doors are locked by the wireless
remote control transmitter, the lights auto-
matically turn off immediately.
To turn them on again, turn the key to the
“ON” position or actuate the headlight
switch.
If you are going to park for over one
week, make sure the headlight switch is
off.
The time before the headlights turn off
can be changed. For details, contact your
Toyota dealer.
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights on
for a long period when the engine is
not running.
Daytime running light system (all mod-
els sold in Canada and some models
sold in the U.S.A.)
The headlights turn on when the parking
brake is released with the engine started,
even with the light switch in the “OFF”
position. They will not go off until the
ignition switch is turned off.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
position 1.
Under the daytime running light system,
the headlights turn on at reduced intensity.
Twist the knob to position 2 to turn to full
intensity for driving at night.
HighLow beams—For high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)—Pull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights
with the knob turned to “OFF”.

’06_SEQUOIA_U (L/O 0508)
149
To turn on the front fog lights, twist
the band of the headlight and turn sig-
nal switch lever. They will come on
only when the headlights are on low
beam.To turn on the personal light, push the
switch. To turn the light off, push the
switch once again.
ILLUMINATED ENTRY SYSTEM
When the center interior light switch is in
the “DOOR” position and any of the side
doors is opened, the personal light will
come on. After all the side doors are
closed, the light remains on for a certain
time before fading out.
However, in the following cases, the light
goes out immediately:
All the side doors are closed when the
ignition key is in the “ACC” or “ON”
position.
The ignition key is turned to the “ACC”,
“ON” or “START” position after all the
side doors are closed.
All the doors are locked when the light
is still on.
When all the doors are unlocked using
either the key or the wireless remote con-
trol transmitter simultaneously, the light
come on for about 15 seconds before fad-
ing out.
The following adjustments can be made in
this system. For details, contact your
Toyota dealer.
Cancelling the door key or wireless re-
mote control transmitter linked opera-
tion
Changing the timing for the light turn-
ing off
To prevent the battery being discharged,
the light will automatically turn off when
the key is removed and the door is left
opened with the center interior light switch
in “DOOR” position for 20 minutes or
more.
For details about center interior light, see
“Center interior and personal lights” on
page 150 or “Center interior light” on page
151 in this Section.
Front fog lights Personal lights

’06_SEQUOIA_U (L/O 0508)
150
Without electric moon roof
With electric moon roof
CENTER INTERIOR LIGHT
To turn on the interior light, slide the
switch.
The interior light switch has the following
positions:
“ON”—Keeps the light on all the time.
“OFF”—Turns the light off.
“DOOR”—Turns the light on when any of
the side doors is opened. The light re-
mains on when all the side doors are
closed.
ILLUMINATED ENTRY SYSTEM
When the switch is in the “DOOR” posi-
tion and any of the side doors is opened,
the light will come on. After all the side
doors are closed, the light remains on for
a certain time before fading out.
However, in the following cases, the light
goes out immediately:
All the side doors are closed when the
ignition key is in the “ACC” or “ON”
position.
The ignition key is turned to the “ACC”,
“ON” or “START” position after all the
side doors are closed.
All the doors are locked when the light
is still on.When all the doors are unlocked using
either the key or the wireless remote con-
trol transmitter simultaneously, the light
come on for about 15 seconds before fad-
ing out.
The following adjustments can be made in
this system. For details, contact your
Toyota dealer.
Cancelling the door key or wireless re-
mote control transmitter linked opera-
tion
Changing the timing for the light turn-
ing off
To prevent the battery being discharged,
the light will automatically turn off when
the key is removed and the door is left
opened with the switch in “DOOR” position
for 20 minutes or more.
CENTER PERSONAL LIGHTS
To turn on the center personal light,
push the switch. To turn the light off,
push the switch once again.
Center interior and personal
lights

’06_SEQUOIA_U (L/O 0508)
151
The interior lights operate separately
with each outer switch.
To turn on the light, push the switch.
To turn the light off, push the switch
once again.
The interior light switch has the following
positions:
“DOOR”—Turns the light on when any of
the side doors is opened. The light re-
mains on when all the side doors are
closed.
“OFF”—The lights are off unless you oper-
ate either outside switch.ILLUMINATED ENTRY SYSTEM
When the switch is in the “DOOR” posi-
tion and any of the side doors is opened,
the light will come on. After all the side
doors are closed, the light remains on for
a certain time before fading out.
However, in the following cases, the light
goes out immediately:
All the side doors are closed when the
ignition key is in the “ACC” or “ON”
position.
The ignition key is turned to the “ACC”,
“ON” or “START” position after all the
side doors are closed.
All the side doors are locked when the
light is still on.
When all the doors are unlocked using
either the key or the wireless remote con-
trol transmitter simultaneously, the light
come on for about 15 seconds before fad-
ing out.
The following adjustments can be made in
this system. For details, contact your
Toyota dealer.
Cancelling the door key or wireless re-
mote control transmitter linked opera-
tion
Changing the timing for the light turn-
ing off To prevent the battery being discharged,
the light will automatically turn off when
the key is removed and the door is left
opened with the switch in “DOOR” position
for 20 minutes or more.
Center interior light

’06_SEQUOIA_U (L/O 0508)
152
To turn on the luggage compartment
light, slide the switch.
The luggage compartment light switch has
the following positions:
“ON”—Keeps the light on all the time.
“OFF”—Turns the light off.
“DOOR”—Turns the light on when any of
the side doors or back door are opened.
The light goes off immediately when the
back door is closed. However, the light
remains on when all the side doors are
closed.ILLUMINATED ENTRY SYSTEM
When the switch is in “DOOR” position
and any door is opened, the light will
come on. After all the side doors are
closed, the light remains on for about 15
seconds before fading out.
However, in the following cases, the lights
go off immediately.
All the side doors and back door are
closed when the ignition key is in the
“ACC” or “ON” position.
The ignition key is turned to the “ACC”,
“ON”, or “START” position after all the
side doors and back door are closed.
All the side doors and back door are
closed and locked.
When all the doors are unlocked using
either the key or the wireless remote con-
trol transmitter simultaneously, the light
will come on and remain on for about 15
seconds before fading out.
The following adjustments can be made in
this system. For details, contact your
Toyota dealer.
Cancelling the door key or wireless re-
mote control transmitter linked opera-
tion
Changing the timing for the light turn-
ing off
For easy access to the ignition switch,
the ignition switch light comes on when
any of the side doors are opened.
The light remains on for some time after
all the side doors are closed.
However, in the following cases, the lights
go off immediately.
All the side doors are closed when the
ignition key is in the “ACC” or “ON”
position.
The ignition key is turned to the “ACC”,
“ON”, or “START” position after all the
side doors are closed.
All the side doors are closed and
locked.
Luggage compartment light Ignition switch light

’06_SEQUOIA_U (L/O 0508)
383
IN CASE OF AN EMERGENCY
In case of an emergency
If your vehicle will not start384
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your engine stalls while driving 387
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you cannot increase engine speed 388
. . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats 388
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
If you have a flat tire 389
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
If your vehicle becomes stuck 398
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle needs to be towed 399
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you lose your keys 403
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
If you lose your wireless remote control transmitter 404
. . . . . . . . . . . . .
SECTION 4

’06_SEQUOIA_U (L/O 0508)
462
Instrument panel
18. ETCS 10 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system, electronic throttle control
system
19. EFI NO.1 20 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system, on −board diagnosis sys-
tem
20. HLP RH 15 A (without daytime run- ning light system): Right−hand head-
light
21. TOWING 30 A: Trailer lights (stop
lights, turn signal lights, tail lights)
22. ALTS 7.5 A: Charging system 23. DRL 15 A (with daytime running light
system): Daytime running light system
HLP LH 15 A (without daytime run-
ning light system): Left−hand head-
light
24. AM2 25 A: Starting system, multiport
fuel injection system/sequential multi-
port fuel injection system, electronic
throttle control system, “IGN 1” and
“IGN 2” fuses
25. TURNHAZ 20 A: Turn signal lights,
emergency flashers
26. RAD NO.3 30 A: Audio/video system
27. ST 30 A: Starting system, “STA” fuse
28. HORN 10 A: Horns
29. EFI NO.2 10 A: Multiport fuel injection
system/se quential multiport fuel injec-
tion system
30. DOME 10 A: Center interior and per-
sonal lights, personal lights, luggage
compartment light, air conditioning sys-
tem, wireless remote control system,
garage door opener, ignition switch
light, door courtesy lights, foot light,
vanity lights, gauges and meters 31. ECUB 7.5 A:
Multiplex communication
system (power door lock system, secu-
rity system, auto −door locking system,
automatic light control system, head-
light delay off system, tail light auto
cut system, illuminated entry system,
daytime running light system), back
door lock system, driver and front pas-
senger door lock system, gauges and
meters
32. MIR HTR 15 A: Outside rear view mir-
ror heaters
33. RAD NO.1 20 A: Audio system, rear
seat entertainment system
34. TAIL 15 A: Tail lights, back door cour-
tesy light, license plate lights
35. ECUIG 10 A: Charging system, anti −
lock brake system, vehicle stability
control system, traction control system
(two −wheel drive models), active trac-
tion control system (four −wheel drive
models), electric moon roof, back door
lock system, driver and front passenger
door lock system, gauges and meters,
multi −information display, auto anti−
glare inside rear view mirror, power
outlets, multiplex communication sys-
tem
36. WSH 25 A: Wipers and washer
37. AC INV 15 A: Power outlets
