display TOYOTA SEQUOIA 2008 2.G Navigation Manual

BASIC FUNCTIONS
31
1U5038F
Details of POIs in some buildings may be
displayed.
For detailed POI information, touch the
building name. You can see details of the
selected POIs.
— Orientation of the map
1U5039F
Northup screen
1U5040F
Headingup screen
The orientation of the map can be changed
from North−up to Heading−up by touching
the orientation symbol at the top left of the
screen.
Northup symbol
Regardless of the direction of vehicle trav-
el, North is always up.
Headingup symbol
The direction of vehicle travel is always up.
A red arrow indicates North.

DESTINATION SEARCH
34
The “Destination” screen allows you to search for a destination. To display the
“Destination” screen, push the “DEST” button.
0U5078X
1“Address”
A house number and the street address
can be input by using the input keys.
39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2“POI Name”
Select one of the many POIs (Points of In-
terest) that have already been stored in the
system’s database. 43. . . . . . . . . . . . . . . .
3“POI Category”
A destination can be selected from the POI
category. 46. . . . . . . . . . . . . . . . . . . . . . . . .
4“Previous”
A destination can be selected from any of
the last 100 previously set destinations
and from the previous starting point.
51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5“Memory”
The location can be selected from the reg-
istered “Memory points”. (To register
memory points, see “ — Registering
memory points” on page 87.) 50. . . . . . . .
6“Emergency”
One of the four categories of emergency
service points that are already stored in the
system’s database can be selected.
50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Quick reference (“Destination” screen)

DESTINATION SEARCH
35
7“Map”
A destination can be selected simply by
touching the location on the displayed
map.
51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8“Intersection”
The names of two intersecting streets can
be entered. This is helpful if only the gen-
eral vicinity, not the specific address, is
known.
52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9“Freeway Ent./Exit”
The name of a freeway (interstate) en-
trance or exit can be entered. 53. . . . . . .
10“?”
Function help for the “Destination” screen
can be viewed on this screen. 22. . . . . . .
11“Change”
To change the search area, touch this
touch−screen button. 36. . . . . . . . . . . . . .
12Quick access touchscreen but-
tons
One of 5 preset destinations can be
selected by touching the screen directly.
To use this function, it is necessary to set
the “Quick Access” for each memory point.
(To register a “Quick Access”, see “ —
Editing memory points” on page 88.)
38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Home touchscreen button
A personal home address can be selected
without entering the address each time. To
use this function, it is necessary to set
“Home” for the memory point. (To register
“Home”, see “ — Registering home” on
page 94.)
38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14“Phone #”
A destination can be entered by the tele-
phone number. 54. . . . . . . . . . . . . . . . . . . .
15“Coordinates”
A destination can be set by using latitude
and longitude as coordinates. 54. . . . . . .
XS00302
Push the “DEST” button and the
“Destination” screen appears.
2U5001F
You can use one of 13 different methods to
search your destination. (See pages 38
through 54.)
INFORMATION
When searching the destination, the
response to the touchscreen button
may be slow.
Destination search —

DESTINATION SEARCH
36
SELECTING THE SEARCH AREA ON
THE DESTINATION SCREEN
1. Push the “DEST” button.
XS00329
2. Touch “Change” on the “Destina-
tion” screen to display a map of the
United States and Canada divided into
12 areas. (For map database information
and updates, see “Map database informa-
tion and updates” on page 250.)
2U5067F
3. Touch one of “US1” through “CAN”
to select a search area.
4. Touch “OK” and the “Destination”
screen returns.SELECTING THE SEARCH AREA ON
THE INPUT SCREEN
Change the search area in order to set a
destination from a different area by using
“Address”, “POI Name”, “Freeway
Ent./Exit”, or “Intersection”.
2U5004aF
1. Touch the search area button like
“US9” on the input screen to display a
map of the United States and Canada
divided into 12 areas. (For map data-
base information and updates, see “Map
database information and updates” on
page 250.)
2U5067F
2. Touch one of “US1” through “CAN”
to select a search area.
3. Touch “OK” and the previous
screen returns.
— Selecting the search area

DESTINATION SEARCH
38
1. Push the “DEST” button.
2U5006F
2. Touch the home touchscreen but-
ton on the “Destination” screen.
The screen changes and displays the map
location for home and the route prefer-
ence. (See “Starting route guidance” on
page 55.)
To use this function, it is necessary to set
“Home” for the memory point. (To register
“Home”, see page 94.)
INFORMATION
Guidance starts from the current ve-
hicle position to your home if “Enter”
is touched even while driving.
1. Push the “DEST” button.
2U5007F
2. Touch any of the quick access
touchscreen buttons on the “Destina-
tion” screen.
The screen changes and displays the map
location of the quick access point and the
route preference. (See “Starting route
guidance” on page 55.)
To use this function, it is necessary to set
“Quick access” for each memory point. (To
register “Quick Access”, see page 90.)
INFORMATION
Guidance starts from the current
vehicle position to the quick access
point if “Enter” is touched even while
driving.
— Destination search by
H
ome
— Destination search by
Quick access

DESTINATION SEARCH
39
There are 2 ways to input a destination by
address.
1. Push the “DEST” button.
2. Touch “Address” on the “Destina-
tion” screen.
2U5008F
(a) Inputting a house number and a
street name
2U5009F
1. Touch numerals directly on the
screen to input a house number.
After inputting a house number, touch
“OK” to display the screen for inputting a
street name.
It is possible to input a street name first.
Touch “Street” to display the screen for in-
putting a street name.
2U5010F
2. Input the street name and touch
“List”.
— Destination search by
“Address”

DESTINATION SEARCH
40
2U5011F
3. When the desired street name is
found, touch the corresponding touch
screen button.
The screen changes and displays the map
location of the selected destination and the
route preference. (See “Starting route
guidance” on page 55.)
If the same address exists in more than
one city, the current screen changes to the
city list screen.
2U5012F
4. Select or enter the desired city.
“Input Name”: To narrow down the listed
items by inputting the city name.
2U5013F
If inputting a street name first, the screen
changes. The house number can then be
input.
2U5014F
If the above screen appears, an address
range on the screen can be selected.
2U5015F
If the same address exists in more than
one city, the current screen changes to the
city list screen.

DESTINATION SEARCH
41
(b) Selecting a city to search
2U5016F
Touch “City”.
2U5017F
To search by city, the following three meth-
ods are possible.
1. Input the city name
2. Select from the nearest 5 cities
3. Select from the last 5 cities
INFORMATION
To change the search area, touch
“Search Area”.
To cancel the city setting, touch
“Any City”.
INPUTTING THE CITY NAME
1. Touch “Input City Name”.
2U5018F
2. Input a city name.
2U5019F
3. Touch the touchscreen button of
the desired city name from the dis-
played list.
“Map”: To display the selected destination
and the route preference. (See “Starting
route guidance” on page 55.)
The current screen changes to the screen
for inputting a house number or a street
name. (See “(a) Inputting a house number
and a street name” on page 39.)

DESTINATION SEARCH
42
SELECTING FROM THE NEAREST 5
CITIES
1. Touch “Nearest 5 Cities”.
2U5020F
2. Touch the touchscreen button of
the desired city name from the dis-
played list.
The current screen changes to the screen
for inputting a house number or a street
name. (See “(a) Inputting a house number
and a street name” on page 39.)SELECTING FROM THE LAST 5 CITIES
2U5021F
Touch the touchscreen button of the
desired city name.
If the navigation has never been used, no
cities will be displayed on the screen.
The current screen changes to the screen
for inputting a house number or a street
name. (See “(a) Inputting a house number
and a street name” on page 39.)

DESTINATION SEARCH
43
1. Push the “DEST” button.
2. Touch “POI Name” on the
“Destination” screen.
2U5022F
3. Input the name of the Point of Inter-
est.
2U5023F
4. Touch the touchscreen button of
the desired destination.
The screen changes and displays the map
location of the selected destination and the
route preference. (See “Starting route
guidance” on page 55.)
When inputting the name of a specific
Point of Interest, and there are two or more
sites with the same name, the list screen
is displayed.
2U5024F
Touch the touchscreen button of the
desired destination.
If the same name exists in more than one
city, a search can be performed more
easily with “City” and “Category”. (See
“(a) Selecting a city to search” on page 44
and “(b) Selecting from the categories” on
page 46.)
INFORMATION
The desired Point of Interest can be
displayed on the map screen. (See “
— Display POI icons” on page 72.)
— Destination search by
“POI Name”
