phone TOYOTA SEQUOIA 2009 2.G Navigation Manual

DESTINATION SEARCH
62
1. Push the “DEST” button.
2. Touch “Coordinates” on the
“Destination” screen.
2U5056F
3. Input the latitude and the longitude.
4. When the input is finished, touch
“OK”.
By touching the touch− screen button of the
desired point, the screen changes and dis-
plays the map location of the selected des-
tination and the route preference. (See
“Starting route guidance” on page 63.) 1. Push the “DEST” button.
2. Touch “Phone #” on the “Destina-
tion” screen.
2U5057F
3. Input a telephone number.
4. After inputting a telephone number,
touch “OK”.
The screen changes and displays the map
location of the selected destination and the
route preference. (See “Starting route
guidance” on page 63.)
If there is more than one site having the
same number, the following screen will be
displayed.
2U5066F
INFORMATION
If there is no match for the tele-
phone number inputted, a list of
identical numbers with different
area codes will be displayed.
To set a memory point as a destina-
tion using the phone number, the
number must be registered pre-
viously. (See page 101.)
— Destination search by
“Coordinates”
— Destination search by
“Phone #”

DESTINATION SEARCH
63
After inputting the destination, the screen
changes and displays the map location of
the selected destination and the route pref-
erence.
2U5059F
1. When an arrow facing the desired
point is touched, the map scrolls in that
direction.
Releasing the finger from the arrow will
stop the scrolling.
2. Touch “Enter”.
The system starts route search and dis-
plays recommended routes.
If there is already a set destination, “Add
to
” and “Replace ” are displayed.
“Add to
”: To add a destination.
“Replace
”: To delete the existing des-
tinations and set a new one.
“Route Preference”: To change the route
preference. (See page 64.)
“Info.”: If this touch− screen button is dis-
played on the top of the screen, touch it to
view items such as name, address, and
phone number.
2U5060F
1Current position
2Destination point
3Type of the route and the distance
4Distance of the entire route
3. To start guidance, touch “Guide”.
“3 Routes”: To select the desired route
from three possible routes. (See page 65.)
“Route”: To change the route. (See
pages 74 and 76.)
Starting route guidance

ADVANCED FUNCTIONS
96
4U5019F
5. Touch “OK”.
To edit registered information, see “ —
Editing memory points” on page 96.
INFORMATION
Up to 106 memory points can be reg-
istered.
The icon, attribute, name, location and/or
telephone number of a registered memory
point can be edited.
1. Push the “MENU” button.
2. Touch “My Places”.
4U5020F
3. Touch “Edit”.
4U5021F
4. Touch the desired memory point
button.
— Editing memory points

ADVANCED FUNCTIONS
97
4U5022F
5. Touch the touchscreen button to
be edited.
“Icon”: To select icons to be displayed on
the map. (See page 97.)
“Quick Access”: To set an attribute.
Memory points with a set attribute can be
used as a “Quick access” or “Home” but-
ton. (See page 98.)
“Name”: To edit memory point names.
The names can be displayed on the map.
(See page 99.)
“Location”: To edit location information.
(See page 100.)
“Phone #”: To edit telephone numbers.
(See page 101.)
6. Touch “OK”.
To change “Icon”
1. Touch “Icon” on the “Memory
Point” screen.
4U5023F
2. Touch the desired icon.
Turn the page by touching “Page 1”,
“Page 2” or “with Sound”.

ADVANCED FUNCTIONS
101

To change “Phone #” (telephone
number)
1. Touch “Phone #” on the “Memory
Point” screen.
4U5033F
2. Enter the number using numeral
keys.
3. Touch “OK”.
The previous screen will be displayed. 1. Push the “MENU” button.
2. Touch “My Places”.
4U5034F
3. Touch “Delete”.
4U5035F
4. Touch the touchscreen button to
be deleted.
“Delete All”: To delete all memory points
in the system.
5. To delete the memory point, touch
“Yes”. To cancel the deletion, touch
“No”.
— Deleting memory points

SECTION 5
OTHER FUNCTIONS
11 9
OTHER FUNCTIONS
Maintenance information 120
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance information setting 120 . . . . . . . . . . . . . . . . . . . . . . .
Dealer setting 122 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
 Calendar with memo 124
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding a memo 126 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Editing a memo 127 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Memo list 127 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
 Handsfree system (for cellular phone) 129
. . . . . . . . . . . . . . . .
Enter a Bluetooth
 phone 134
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Call on the Bluetooth phone 137
. . . . . . . . . . . . . . . . . . . . . . . . . .
Receive on the Bluetooth phone 143
. . . . . . . . . . . . . . . . . . . . . .
Talk on the Bluetooth phone 144
. . . . . . . . . . . . . . . . . . . . . . . . .
Change the settings of the Bluetooth phone 146
. . . . . . . . . . . .
Set a Bluetooth phone 169
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Speech command system 175
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Help screen 178
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
 Screen adjustment 179
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Screen setting 181
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
 Delete personal data 183
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Beep setting 184
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
 Select a language 185
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

OTHER FUNCTIONS
122
It is possible to register a dealer in the sys-
tem. With dealer information registered,
route guidance to the dealer is available.
1. Push the “INFO” button.
2. Touch “Maintenance” on the
“Information” screen.
3. Touch “Set Dealer” on the
“Maintenance” screen.
5U5004F
4. If the dealer has not been registered,
enter the location of the dealer in the
same way as for a destination search.
(See “Destination search” on page 43.)
When “Set Dealer” registration is finished,
the “Edit Dealer” screen will be displayed.
5U5005F
5. Touch the touchscreen button to
be edited.
“Dealer”: To enter the name of a dealer.
(See page 123.)
“Contact”: To enter the name of a dealer
member. (See page 123.)
“Location”: To set a location. (See page
123.)
“Phone #”: To set a telephone number.
(See page 124.)
“Delete Dealer”: To delete the dealer in-
formation displayed on the screen.
“Enter
”: To set the displayed dealer as
a destination. (See “Starting route
guidance” on page 63.)
— Dealer setting

OTHER FUNCTIONS
124

To edit “Phone #” (telephone num-
ber)
1. Touch “Phone #” on the “Edit
Dealer” screen.
5U5008F
2. Enter the number using numeral
keys.
3. Touch “OK”.
The previous screen will be displayed. It is possible to enter memos for particular
dates on the calendar.
The system informs
you of the memo entry when the system is
turned on. (See page 25.)
Memos can also be used for route guid-
ance if the memo has been registered with
location information.
XS00303
1. Push the “INFO” button.
5U5009aF
2. Touch “Calendar”.
Calendar with memo —

OTHER FUNCTIONS
129
Handsfree system allows you to make
or receive a call without taking your
hands off the steering wheel by con-
necting your cellular phone.
This system supports Bluetooth
.
Bluetooth is a wireless data system by
which you can call without your cellular
phone being connected with a cable or
placed on a cradle.
If your cellular phone does not support
Bluetooth
, this system can not function.
CAUTION
While you are driving, do not use a
cellular phone or connect the Blue-
tooth
 phone.
NOTICE
Do not leave your cellular phone in
the car. The temperature indoor may
be high and damage the phone.
INFORMATION
In the following conditions, the sys-
tem may not function.
The cellular phone is turned OFF.
The current position is outside the
communication area.
The cellular phone is not con-
nected.
The cellular phone has a low bat-
tery.
XS00304
Steering switches
By pushing the telephone switch
above, you can receive a call or hang up
without taking your hands off the steer-
ing wheel.
Handsfree system
(for cellular phone) —

OTHER FUNCTIONS
130
XS00305
Microphone (T ype A)
XS00306
Microphone (Type B)
You can use the microphone above
when talking on the phone.
The other party’s voice outputs from the
driver’s speaker. When the received calls
or received voice outputs, the audio from
the Audio system or voice guidance from
the Navigation system will be muted.
INFORMATION
 Talk alternately with the other party
on the phone. If you talk at the
same time, the voice may not reach
each other. (It is not a malfunction.)
 Keep the volume of receiving voice
down. Otherwise, echo is coming
up. When you talk on the phone,
speak clearly towards the micro-
phone.
 In the following situations, your
voice may not reach the other
party.
Driving on unpaved road. (Mak-
ing a traffic noise.)
Driving at the high speed.
The window is open.
Turning the airconditioning
vents towards the microphone.
The sound of the aircondition-
ing fan is loud.
