radio controls TOYOTA SEQUOIA 2009 2.G Navigation Manual

8
2009 SEQUOIA Navigation from Aug.08 Prod.(OM34473U)
6 Audio/video System
Quick reference188
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Using your audio/video system 189
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Some basics 189
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Radio operation 195
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
CD changer operation 205
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DVD player operation 217
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video remote controls 240
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video system operating hints 241
. . . . . . . . . . . . . . . . . . . . . . . . . .
7 Rear View Monitor System
Rear view monitor system 252
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 Appendix
Limitations of the navigation system 256
. . . . . . . . . . . . . . . . . . . . . . . . .
Map database information and updates NO TAG
. . . . . . . . . . . . . . . .
Changing the map DVD −ROM 267
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Index269
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . .
For information about the optional “Rear seat entertainment
system” , please refer to the Owner’s Manual .

SECTION 6
AUDIO/VIDEO SYSTEM
187
AUDIO/VIDEO SYSTEM
Quick reference 188 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
 Using your audio/video system 189
. . . . . . . . . . . . . . . . . . . . . . .
Some basics 189 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Radio operation 195 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

CD changer operation 205 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DVD player operation 217 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Audio/video remote controls 240 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Audio/video system operating hints 241 . . . . . . . . . . . . . . . . . . . . . .

AUDIO/VIDEO SYSTEM
189
This section describes some of the basic
features of your audio system. Some in-
formation may not pertain to your system.
Your audio system works when the engine
switch is turned to the ACC or ON position.
NOTICE
To prevent the battery from being dis-
charged, do not leave the audio sys-
tem on longer than necessary when
the engine is not running.
CAUTION
For vehicles sold in U.S.A. and
Canada:
Part 15 of the FCC Rules
FCC Warning:
Changes or modifications in
construction not expressly approved
by the party responsible for com-
pliance could void the user’s author-
ity to operate the equipment. Radio
frequency exposure. This device is
approved for Mobile Application only
and, to comply with applicable FCC
radio frequency exposure regula-
tions, must be used with a distance of
at least 7.9 in. (20 cm) between the an-
tenna and the body of any person at
all time during use.
Laser products
 Do not take this unit apart or at-
tempt to make any changes
yourself. This is an intricate unit
that uses a laser pickup to re-
trieve information from the sur-
face of compact discs. The laser
is carefully shielded so that its
rays remain inside the cabinet.
Therefore, never try to disas-
semble the player or alter any of
its parts since you may be ex-
posed to laser rays and danger-
ous voltages.
 This product utilizes a laser.
Use of controls or adjustments
or performance of procedures
other than those specified here-
in may result in hazardous radi-
ation exposure.
Using your audio/video
system —
— Some basics

AUDIO/VIDEO SYSTEM
240
XS00323
Some parts of the audio system can be ad-
justed using the switches on the steering
wheel.
Details of the specific switches, controls,
and features are described below.
1. Volume control switch
2. “MODE” switch
3. “ ” switch
1. Volume control switch
Push “+” side to increase the volume. The
volume continues to increase while the
switch is being pressed.
Push “” side to decrease the volume.
The volume continues to decrease while
the switch is being pressed.
2. “MODE” switch
Push “MODE” switch to select an audio
mode. Each push changes the mode se-
quentially if the desired mode is ready to
use.
To turn the audio/video system on, push
the “MODE” switch.
To turn the audio/video system off, push
and hold the “MODE” switch until you hear
a beep. 3. “
” switch
Radio
This switch has the following features—
To select a preset station:
Quickly push and release the “ ” or “ ”
side of the switch. Do this again to select
the next preset station.
To seek a station:
Push and hold the “ ” or “ ” side of the
switch until you hear a beep. Do this again
to find the next station. If you push the
switch on either side during the seek
mode, seeking will be cancelled.
To step up or down the frequency, push
and hold the switch even after you hear a
beep. When you release from the switch,
the radio will begin seeking up or down for
a station. Do this again to find the next sta-
tion.
XM
 Satellite Radio∗—
To select a preset channel, push the “ ”
or “ ” side of the switch. Repeat until a
desired channel is found.
∗: Use of satellite radio requires XM tun-
er and service. Contact your Toyota
dealer for details.
Audio/video remote
controls (steering switches)

INDEX
274
Selecting the group158
. . . . . . . . . . . . . . . .
Selecting the search area 44
. . . . . . . . . . .
Sending a tone 142
. . . . . . . . . . . . . . . . . . . .
Sending a tone by the speed
tone 145
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting and deleting destination 74 . . . . .
Setting home as the destination 18 . . . . .
Setting route 76
. . . . . . . . . . . . . . . . . . . . . . .
Setting the phone book 155
. . . . . . . . . . . .
Setting the voice recognition 159 . . . . . . .
Setup 108
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup button 88,89,108
. . . . . . . . . . . . . . . .
Setup menu 231
. . . . . . . . . . . . . . . . . . . . . . .
Setup screen 89,108
. . . . . . . . . . . . . . . . . . .
Single map 36
. . . . . . . . . . . . . . . . . . . . . . . .
Single map screen 35
. . . . . . . . . . . . . . . . . .
Sort 29
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sound icons 98
. . . . . . . . . . . . . . . . . . . . . . .
Speech command switch 175
. . . . . . . . . . .
Speech command system 175
. . . . . . . . . .
Speech command system indicator 10,175
. . . . . . . . . . . . . . . . . . . . .
Speed dial 140,146,147
. . . . . . . . . . . . . . . .
Speed tone 148,149,150
. . . . . . . . . . . . . . .
Starting route from adjacent road 79 . . . .
Starting route guidance 63
. . . . . . . . . . . . .
Steering switches 129,175,240
. . . . . . . . .
Street name 47
. . . . . . . . . . . . . . . . . . . . . . .
Subtitle language 231
. . . . . . . . . . . . . . . . .
Suspend guidance 90
. . . . . . . . . . . . . . . . .
Suspend Guidance button 88,90 . . . . . . .
Suspending and resuming guidance 90
. . . . . . . . . . . . . . . . . . . . . . . .
Switch color 182
. . . . . . . . . . . . . . . . . . . . . . .
Switching between audio functions 191
. . . . . . . . . . . . . . . . . . . . . . .
Switching the screens 35
. . . . . . . . . . . . . .
T
Talk on the Bluetooth phone 144 . . . . . . .
Telephone switch 129 . . . . . . . . . . . . . . . . . .
Time Zone 89,111 . . . . . . . . . . . . . . . . . . . . .
Tire change calibration 117,118 . . . . . . . .
Title 239 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tone 142,179 . . . . . . . . . . . . . . . . . . . . . . . . .
Tone and balance 192 . . . . . . . . . . . . . . . . .
Touch screen operation 26 . . . . . . . . . . . . .
TRACK LIST button 209 . . . . . . . . . . . . . . .
Traffic announcement 199 . . . . . . . . . . . . .
Traffic Restrict. Notification 89,114 . . . . .
Transfer phone book data 156 . . . . . . . . . .
Transferring a telephone number 156 . . .
TREB 192 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TUNE·FILE knob 188,195,213 . . . . . . . . . .
Turn list screen 35,70 . . . . . . . . . . . . . . . . . . Turning the audio system on
and off 190 . . . . . . . . . . . . . . . . . . . . . . . . . .
TYPE SCAN button 202 . . . . . . . . . . . . . . . .
TYPE SEEK button 198 . . . . . . . . . . . . . . . .
Typical voice guidance prompts 71 . . . . .
U
User selection 92
. . . . . . . . . . . . . . . . . . . . .
Using your audio/video system 189 . . . . .
V
Video CD controls 236
. . . . . . . . . . . . . . . . .
Viewer restrictions 239
. . . . . . . . . . . . . . . .
Voice Guidance in All Modes 89,115 . . . .
Voice Recognition Guidance 89,114 . . . .
Voice tag 141,159
. . . . . . . . . . . . . . . . . . . . .
Vo l u m e 9 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Volume button 88,91
. . . . . . . . . . . . . . . . . .
X
XM Satellite Radio broadcast 199 . . . . . .
Z
Zoom in button 10,37
. . . . . . . . . . . . . . . . . .
Zoom out button 10,37
. . . . . . . . . . . . . . . . .
