2009 SEQUOIA Navigation from Aug.08 Prod.(OM34473U)
Table of Contents
Quick Guide —
— Overview buttons and guidance screen 10. . . . . . . . . .
— Registering home 13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
— Registering preset memory point
(Quick access) 15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
— Operation flow: guiding the route 17 . . . . . . . . . . . . . . . .
— Setting home as the destination 18 . . . . . . . . . . . . . . . . .
Navigation system function index 19 . . . . . . . . . . . . . . . . . .
1 Basic Functions
〈 Basic information before operation 〉
Initial screen 24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Touch screen operation 26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Inputting letters and numbers/list screen operation 26
. . . . . . . . . . . . . .
Function help 30
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Map screen operation 30
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Current position display 30
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screen scroll operation 31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switching the screens 35
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Map scale 37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Foot print map 38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Orientation of the map 39
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Map icons 40
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
2 Destination Search
Quick reference (“Destination” screen) 42
. . . . . . . . . . . . . . . . . . . . . . . .
Destination search 43
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Selecting the search area 44
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by Home 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by Quick access 46
. . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Address” 47
. . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “POI
∗ Name” 51
. . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “POI∗ Category” 54
. . . . . . . . . . . . . . . . . . . . .
Destination search by “Emergency” 58
. . . . . . . . . . . . . . . . . . . . . . . .
∗
: Point of Interest
Quick
Guide

152009 SEQUOIA Navigation from Aug.08 Prod.(OM34473U)
XS00301
0U5007F
0U5008F
0U5009F
1Push “MENU” button.
2Touch “My Places”.
3Touch “Register” of the memory
points.
4There are 13 different methods to
search a preset memory point.
See “Destination search” on page 43.
— Registering preset memory point
(Quick access)

16
2009 SEQUOIA Navigation from Aug.08 Prod.(OM34473U)
0U5010F
0U5011F
0U5012F
0U5013F
5Touch “Enter”.
The “Memory Point” screen is displayed.
6Touch “Quick Access”.
7Touch one of preset buttons 1 to
5.
8Touch “OK”.
Registration of the preset memory point is
complete.
You can change the icon, quick access,
name, location and phone number. (See
“ — Editing memory points” on page 96.)
The registered points can be used on the
“Destination” screen. (See “ — Destination
search by Quick access” on page 46.)

DESTINATION SEARCH
43
7“Map”
A destination can be selected simply by
touching the location on the displayed
map. 59
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8“Intersection”
The names of two intersecting streets can
be entered. This is helpful if only the gen-
eral vicinity, not the specific address, is
known. 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9“Freeway Ent./Exit”
The name of a freeway (interstate) en-
trance or exit can be entered. 61 . . . . . . .
10“?”
Function help for the “Destination” screen
can be viewed on this screen. 30 . . . . . . .
11“Change”
To change the search area, touch this
touch−screen button. 44
. . . . . . . . . . . . . .
12Quick access touchscreen but-
tons
One of 5 preset destinations can be
selected by touching the screen directly.
To use this function, it is necessary to set
the “Quick Access” for each memory point.
(To register a “Quick Access”, see “ —
Editing memory points” on page 96.) 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Home touchscreen button
A personal home address can be selected
without entering the address each time. To
use this function, it is necessary to set
“Home” for the memory point. (To register
“Home”, see “ — Registering home” on
page 102.) 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14“Phone #”
A destination can be entered by the tele-
phone number. 62 . . . . . . . . . . . . . . . . . . . .
15“Coordinates”
A destination can be set by using latitude
and longitude as coordinates. 62 . . . . . . .
XS00302
Push the “DEST” button and the
“Destination” screen appears.
2U5001F
You can use one of 13 different methods to
search your destination. (See pages 46
through 62.)
INFORMATION
When searching the destination, the
response to the touchscreen button
may be slow.
Destination search —

ADVANCED FUNCTIONS
108
The previous destination can be deleted.
1. Push the “MENU” button.
2. Touch “My Places”.
4U5053F
3. Touch “Delete Previous Points”.
4U5054F
4. Touch the touchscreen button you
want to delete.
“Delete All”: To delete all previous points
in the system.
4U5055F
5. To delete the point, touch “Yes”. To
cancel the deletion, touch “No”. Setting the items shown on the “Setup”
screen can be done. (See page 89.)
XS00301
1. Push the “MENU” button.
4U5056aF
2. Touch “Setup”.
4U5057F
3. Touch the items to be set.
4. Touch “OK”.
The previous screen will be displayed.
INFORMATION
To reset all setup items, touch “De-
fault”.
— Deleting previous pointsSetup

OTHER FUNCTIONS
120
When the Navigation System is turned on,
the “Information” screen displays when it is
time to replace a part or certain compo-
nents. (See page 25.)
XS00303
1. Push the “INFO” button.
5U5001aF
2. Touch “Maintenance”.
5U5002F
3. Touch the desired touchscreen
button.
For details of each touch −screen button,
see “INFORMATION ITEMS” on page 121.
“Delete All”: To cancel all conditions
which have been inputted.
“Reset All”: To reset the item which has
satisfied a condition.
“Set Dealer”: To register or edit dealer in-
formation. (See “ — Dealer setting” on
page 122.)
If “ON” is selected, the system gives main-
tenance information with the “Information”
screen when the system is turned on. (See
page 25.)
If “OFF” is selected, the “Information”
screen is disabled.
When the vehicle needs to be serviced, the
touch−screen button color will change to
orange.
Maintenance information —
— Maintenance information
setting

OTHER FUNCTIONS
121
INFORMATION ITEMS
“ENGINE OIL”: Replace engine oil
“OIL FILTER”: Replace engine oil filter
“ROTATION”: Rotate tires
“TIRES”: Replace tires
“BATTERY”: Replace battery
“BRAKE PAD”: Replace brake linings
“WIPERS”: Replace wiper blades
“LLC”: Replace engine coolant
“BRAKE OIL”: Replace brake fluid
“ATF”: Replace ATF
“SERVICE”: Scheduled maintenance
“AIR FILTER”: Replace air filter
“PERSONAL”: New information items
can be created separately from provided
ones
5U5003F
4. Input the conditions.
Notice of “Date”: The next maintenance
date can be input.
Notice of “Distance”: The driving dis-
tance until the next maintenance check
can be input.
“Delete”: To cancel the date and distance
conditions.
“Reset”: To reset the date and distance
conditions .
5. Touch “OK”.
The screen then returns to the
“Maintenance” screen.
INFORMATION
 For scheduled maintenance
information, please refer to the
“Scheduled Maintenance Guide”
or “Owner’s Manual Supplement”.
 Depending on driving or road con-
ditions, the actual date and dis-
tance may differ from the stored
date and distance in the system.

OTHER FUNCTIONS
154

Auto answer
When a call is received, the display au-
tomatically changes to the talking
screen and you can start to talk on the
phone (without touching any switch) af-
ter the preset time.
5U5092F
Touch “ON” of “Auto Answer” and “”
or “+” to adjust the waiting time of auto
answer within 1 60 seconds.
The Bluetooth connection status
at startup
5U5093F
When the engine switch is turned to the
ACC or ON position and the Bluetooth
is automatically connected, the con-
nection check is displayed.
5U5094F
Touch “ON” or “OFF” of “Show
Bluetooth∗ connection status at
startup”.
∗: Bluetooth is a registered trademark of Bluetooth SIG. Inc.

AUDIO/VIDEO SYSTEM
196
6U5008F
(b) Presetting a station
1. Tune in the desired station.
2. Touch one of the touchscreen but-
tons (1 — 6) you want and hold it until
a beep is heard. This sets the station to
the touchscreen button and the fre-
quency appears on the touchscreen
button.
Each radio mode (AM, FM1 or FM2) can
store up to 6 stations. To change the pre-
set station to a different one, follow the
same procedure.
The preset station memory is cancelled
when the power source is interrupted by
battery disconnection or a blown fuse. (c) Selecting a station
Tune in the desired station using
one of the
following methods.
Preset tuning: Touch the touch−screen
button (1 — 6) for the station you want.
The touch−screen button is highlighted
and the station frequency appears on the
screen.
Seek tuning: Push the “SEEK/TRACK”
button on either side. The radio will begin
seeking up or down for a station of the
nearest frequency and will stop on recep-
tion. Each time you push the button, the
stations will be searched automatically
one after another.
To scan all the frequencies: Touch
“SCAN” on the screen or push the
“SCAN” button briefly. “SCAN” appears
on the screen. The radio will find the next
station and stay there for a few seconds,
and then scan again. To select a station,
touch “SCAN” or push the “SCAN” but-
ton again.
To scan the preset stations: Touch
“SCAN” on the screen or push the
“SCAN” button for longer than a second.
“P. SCAN” appears on the screen. The ra-
dio will tune in the next preset station, stay
there for a few seconds, and then move to
the next preset station. To select a station,
touch “SCAN” or push the “SCAN” but-
ton again.

AUDIO/VIDEO SYSTEM
201
(d) Channel category
5U5013F
Touch either “TYPE ” or “TYPE ” to
go to the next or previous category. (e) Presetting a channel
1. Tune in the desired channel.
5U5014F
2. Touch one of the channel selector
buttons (1 —
6) and hold it until a beep
is heard.
This sets the channels to the touch −
screen button and the name and number
of the channel appears on the touch −
screen button.
Each touch− screen button can store three
SAT channels. To change the preset chan-
nel to a different one, follow the same pro-
cedure.
The preset channel memory is cancelled
when the power source is interrupted by
battery disconnection or a blown fuse.
