run flat TOYOTA SEQUOIA 2014 2.G Owners Manual

486 4-2. Maintenance
Vehicle exterior
ItemsCheck points
Doors • Operate smoothly?
Engine hood • The lock system works properly?
Fluid leaks • Is there any leakage after park-
ing?
Tire • Inflation pressure is correct?
• Tire surfaces not worn or dam-
aged?
• Tires rotated according to the maintenance schedule?
• Wheel nuts are not loose?
Windshield wipers/rear window
wiper • The wiper blades should not
show any signs of cracking,
splitting, wear, contamination or
deformation.
• The wiper blades should clear the windshield rear window
without streaking or skipping.
CAUTION
■ If the engine is running
Turn the engine off and ensure that there is adequate ventilation before per-
forming maintenance checks.

5
When trouble arises
553
5-1. Essential information
If your vehicle needs to be towed
Before towingThe following may indicate a problem with your transmission. Contact
your Toyota dealer before towing.
● The engine is running, but the vehicle will not move.
● The vehicle makes an abnormal sound.
Emergency towing
If a tow truck is not available, in an emergency your vehicle may be
temporarily towed using a cable or chain secured to the emergency
towing eyelet. This should only attempted on hard, surfaced roads for
short distances at low speeds.
A driver must be in the vehicle to steer and operate the brakes. The
vehicle’s wheels, drive train, axles, steering and brakes must be in
good condition.
Type A Towing eyelet
If towing is necessary, we recommend having your vehicle towed by
your Toyota dealer or a commerci al towing service, using a lift-type
truck or a flat bed truck.
Use a safety chain system for all to wing, and abide by all state/pro-
vincial and local laws.
The wheels and axle on the groun d must be in good condition.
If they are damaged, use a towing dolly or flat bed truck.

5
When trouble arises
559
5-1. Essential information
If you think something is wrong
If you notice any of the following symptoms, your vehicle probably
needs adjustment or repair. Contact your Toyota dealer as soon as
possible.
■ Visible symptoms
●Fluid leaks under the vehicle
(Water dripping from the air cond itioning after use is normal.)
● Flat-looking tires or uneven tire wear
● Engine coolant temperature g auge needle continually points
higher or lower than normal
● Voltmeter continually points higher or lower than normal
● Engine oil pressure gauge continually points higher or lower
than normal
● Automatic transmission fluid temperature gauge needle con-
tinually points higher or lower than normal (if equipped)
■ Audible symptoms
●Changes in exhaust sound
● Excessive tire squeal when cornering
● Strange noises related to the suspension system
● Pinging or other noises related to the engine
■ Operational symptoms
●Engine misfire, stumbling or running rough
● Appreciable loss of power
● Vehicle pulls heavily to one side when braking
● Vehicle pulls heavily to one side when driving on a level road
● Loss of brake effectiveness, s pongy feeling, pedal almost
touches the floor

5
When trouble arises
585
5-2. Steps to take in an emergency
■After completing the tire change
The tire pressure warning
system must be reset. (P. 509)
■When using the temporary spare tire
As the temporary spare tire is not equipped with the tire pressure warn-
ing valve and transmitter, low inflation pressure of the temporary spare
tire will not be warned. Also, if you re place the temporary spare tire after
the tire pressure warning light comes on, the light remains on.
CAUTION
■Using the jack
Improper use of the jack may lead to death or serious injuries due to the
vehicle suddenly falling off the jack.
●Do not use the jack for any purpose other than replacing tires or install-
ing and removing tire chains.
●Only use the jack that comes with this vehicle for replacing a flat tire.
Do not use it on other vehicles, an d do not use other jacks for replac-
ing tires on this vehicle.
●Always check that the jack is securely set to the jack point.
●Do not put any part of your body under the vehicle supported by a jack.
●Do not start or run the engine while your vehicle is supported by the
jack.
●Do not raise the vehicle while someone is in it.
●When raising the vehicle, do not put an object on or under the jack.
●Do not raise the vehicle to a hei ght greater than that required to
replace the tire.
●Use a jack stand if it is necessary to get under the vehicle.
Take particular care when lowering the vehicle to ensure that no one
working on or near the vehicle will be injured.
■Using the jack handle
Insert the square head securely until you hear a click to prevent the
extension parts from coming apart unexpectedly.

658 Alphabetical index
Cruise controlCruise control ........................ 202
Dynamic laser cruise
control ................................. 206
Cup holders .............................. 426
Curtain shield airbags ............. 112
Customizable features............. 631
Daytime running light system .................................... 191
Defogger Rear window ......................... 317
Side mirrors ........................... 317
Dimension................................. 604
Dinghy towing .......................... 301
Display Trip information ..................... 178
Warning message ................. 572
Do-it-yourself main tenance..... 488
Door courtesy lights Door courtesy lights .............. 406
Wattage ................................. 614
Doors Back door ................................40
Door glasses ...........................91
Door lock ...........................31, 35
Side doors ...............................35
Side mirrors .............................85
Driver’s seat belt reminder light ......................................... 563
Driving
Break-in tips .......................... 149
Correct posture ..................... 110
Procedures ............................ 148
Winter driving tips.................. 277
Driving position memory...........63
DVD player
*
Electronically modulated air suspension ............................ 244
Emergency flashers Switch ................................... 552
Emergency, in case of
If the engine will not start ...... 589
If the shift lever cannot be shifted from P ..................... 591
If the vehicle has discharged battery................................. 593
If the warning buzzer
sounds ................................ 561
If the warning light turns on........................................ 561
If the warning message is displayed ............................ 572
If you have a flat tire ............. 578
If you lose your keys ............. 592
If you think something is wrong .................................. 559
If your vehicle becomes stuck ................................... 599
If your vehicle has to
be stopped in an
emergency .......................... 600
If your vehicle needs to be
towed .................................. 553
If your vehicle overheats ....... 596
Engine
Compartment ........................ 493
Engine switch ........................ 158
Hood ..................................... 492
How to start the engine ................................. 158
Identification number............. 606
If the engine will not start ...... 589
Ignition switch ...................... 158
Overheating .......................... 596
D
E

665
What to do if...
What to do if...
A tire puncturesP. 578If you have a flat tire
The engine does not start
P. 589If the engine will not start
P. 105Engine immobilizer system
P. 593If the vehicle battery is discharged
The shift lever cannot be
moved outP. 591If the shift lever cannot be shifted
from P
The engine coolant temperature
gauge enters the red zone
Steam can be seen coming
from under the hood
P. 596If your vehicle overheats
The key is lostP. 592If you lose your keys
The battery runs outP. 593If the vehicle battery is discharged
The doors cannot be lockedP. 3 5Side doors
P. 4 0Back door
The horn begins to sound.P. 107Alarm
The vehicle is stuck in
mud or sandP. 599If the vehicle becomes stuck
