stop start TOYOTA SEQUOIA 2019 (in English) Owner's Guide

4877-2. Steps to take in an emergency
SEQUOIA_OM_USA_OM0C013U_19MY
7
When trouble arises
If the vehicle becomes stuck
Stop the engine. Set the parking brake and shift the shift lever to P.
Remove the mud, snow or sand from around the stuck tire.
Place wood, stones or some other material under the tires to help
provide traction under the tires.
Restart the engine.
Lock the center differential. ( P. 296)
Shift the shift lever to D or R position and carefully apply th e accel-
erator to free the vehicle.
■ When it is difficult to free the vehicle
Turn off TRAC or VSC/Trailer Sway Control if these functions ar e hampering
your attempts to free the vehicle. ( P. 304)
Carry out the following procedures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
Press to turn off TRAC or VSC/Trailer
Sway Control.
1
2
3
4
5
6

541What to do if... (Troubleshooting)
SEQUOIA_OM_USA_OM0C013U_19MY
●Is the shift lever in P? (P. 198)
●Is the battery discharged? ( P. 480)
●Is the engine switch in the “ON” position?
If you cannot release the shift lever by depressing the brake p edal with the
engine switch in the “ON” position. ( P. 204)
●It is locked to prevent theft of the vehicle if the key is pulled from the engine
switch. (P. 199)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( P. 149)
If you think something is wrong
The engine does not start
The shift lever cannot be shifted from P even if you depress
the brake pedal
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches

542What to do if... (Troubleshooting)
SEQUOIA_OM_USA_OM0C013U_19MY
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts?
(P. 451)
Depending on the situation, other types of warning buzzer may a lso sound.
( P. 448, 457)
●Did anyone inside the vehicle open a door during setting the al arm?
The sensor detects it and the alarm sounds. ( P. 76)
To stop the alarm, start the engine.
●When a warning light turns on, refer to P. 448.
●When a warning light turns on or a warning message or indicator is dis-
played, refer to P. 448, 457.
A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning light turns on or a warning message is displayed

547Alphabetical index
SEQUOIA_OM_USA_OM0C013U_19MY
EDR (Event data recorder) ........ 10
Electronically modulated air suspension ....................... 289
Emergency flashers ................ 438
Emergency, in case of
If a warning buzzer sounds ................................ 448
If a warning light turns on ....................................... 448
If a warning message
is displayed......................... 457
If the engine will not start ...... 479
If the vehicle battery is discharged .......................... 480
If you have a flat tire ............. 465
If you think something is wrong .............................. 446
If your vehicle becomes stuck ................................... 487
If your vehicle has to be stopped in an emergency ... 439
If your vehicle needs
to be towed ......................... 441
If your vehicle overheats ....... 484 Engine
Compartment ........................ 394
Engine switch ....................... 198
Hood ..................................... 393
How to start the engine......... 198
Identification number ............ 492
If the engine will not start ...... 479
Ignition switch
(engine switch) ................... 198
Overheating .......................... 484
Engine coolant......................... 398
Capacity................................ 496
Checking............................... 398
Preparing and checking before winter ...................... 314
Engine coolant temperature gauge ....................................... 86
Engine immobilizer system ...... 74
Engine oil ................................. 395 Capacity................................ 494
Checking............................... 395
Preparing and checking before winter ...................... 314
Engine switch .......................... 198
Event data recorder (EDR)........ 10
E
