892. Instrument cluster
2
Instrument cluster
SEQUOIA_OM_USA_OM0C013U_19MY
WARNING
■The information display at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal
information display. At extremely low temperatures, the information display
monitor may respond slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear
number appearing on the display. This lag could cause the drive r to down-
shift again, causing rapid and excessive engine braking and pos sibly an
accident resulting in personal death or injury.
NOTICE
■ To prevent damage to the engine and its components
● Do not let the indicator needle of the tachometer enter the red zone, which
indicates the maximum engine speed.
● The engine may be overheating if the engine coolant temperature gauge is
in the red zone (H). In this case, immediately stop the vehicle in a safe
place, and check the engine after it has cooled completely. ( P. 484)
■ Voltmeter
When the voltmeter indicates 19 V or higher or 9 V or lower while the engine
is running, there may be a battery or charging system malfunction. Have the
vehicle inspected at your Toyota dealer.
■ Engine oil pressure gauge
When the value of the engine oil pressure gauge drops while the engine is
running, stop the vehicle in a safe place immediately and check the amount
of engine oil. ( P. 395)
When the oil pressure drops even though the engine oil amount has not
decreased, or if the oil pressure does not increase when engine oil is
added, contact your Toyota dealer, as there may be a problem wi th the lubri-
cation system.

1684-1. Before driving
SEQUOIA_OM_USA_OM0C013U_19MY
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
■When taking a nap in the vehicle
Always turn the engine off. Otherwise, if you accidentally move the shift
lever or depress the accelerator pedal, this could cause an acc ident or fire
due to engine overheating. Additionally, if the vehicle is parked in a poorly
ventilated area, exhaust gases may collect and enter the vehicl e, leading to
death or a serious health hazard.
■ When braking
● When the brakes are wet, drive more cautiously.
Braking distance increases when the brakes are wet, and this may cause
one side of the vehicle to brake differently than the other side. Also, the
parking brake may not securely hold the vehicle.
● If the brake booster device does not operate, do not follow oth er vehicles
closely and avoid hills or shar p turns that require braking.
In this case, braking is still possible, but the brake pedal should be
depressed more firmly than usual. Also, the braking distance will increase.
Have your brakes fixed immediately.
● Do not pump the brake pedal if the engine stalls.
Each push on the brake pedal uses up the reserve for the power-assisted
brakes.
● The brake system consists of 2 individual hydraulic systems; if one of the
systems fails, the other will still operate. In this case, the brake pedal
should be depressed more firmly than usual and the braking dist ance will
increase.
If this happens, do not continue to drive the vehicle. Have you r brakes
fixed immediately.
■ If the vehicle becomes stuck (4WD models)
Do not spin the wheels excessively when any of the tires is up in the air, or
the vehicle is stuck in sand, mud, etc. This may damage the driveline com-
ponents or propel the vehicle forward or backward, causing an accident.

1904-1. Before driving
SEQUOIA_OM_USA_OM0C013U_19MY
●Avoid jerky starts or sudden acceleration.
● Avoid jerky steering and sharp turns, and slow down before maki ng
turns.
● Note that when making a turn, the trailer wheels will be closer than
the vehicle wheels to the inside of the turn. Compensate by mak ing
a wider than normal turning radius.
● Slow down before making a turn, in cross winds, on wet or slipp ery
surfaces, etc.
Increasing vehicle speed can destabilize the trailer.
● Take care when passing other vehicles. Passing requires consider-
able distance. After passing a vehicle, do not forget the lengt h of
your trailer, and be sure you have plenty of room before changi ng
lanes.
● To maintain engine braking efficiency and charging system perfo r-
mance when using engine braking, do not put the transmission in
D.
● Instability happens more frequently when descending steep or lo ng
downhill grades. Before descending, slow down and downshift. Do
not make sudden downshifts while descending steep or long down-
hill grades.
● Avoid holding the brake pedal down too long or applying the bra kes
too frequently. This could cause the brakes to overheat and result in
reduced braking efficiency.
● Due to the added load of the trailer, your vehicle’s engine may over-
heat on hot days (at temperatures over 85 °F [30 °C]) when driv ing
up a long or steep grade. If the engine coolant temperature gau ge
indicates overheating, immediately turn off the air conditionin g (if in
use), pull your vehicle off the road and stop in a safe spot.
(  P. 484)

2074-2. Driving procedures
4
Driving
SEQUOIA_OM_USA_OM0C013U_19MY
Parking brake
To set the parking brake, fully
depress the parking brake pedal
with your left foot while depress-
ing the brake pedal with your right
foot.
(Depressing the pedal again
releases the parking brake.)
■Parking the vehicle engaged warning buzzer
P. 460
■ Parking the vehicle
P. 160
■ Usage in winter time
P. 315
U.S.A.Canada
NOTICE
■Before driving
Fully release the parking brake.
Driving the vehicle with the parking brake set will lead to bra ke components
overheating, which may affect braking performance and increase brake
wear.

3345-1. Using the air conditioning system and defogger
SEQUOIA_OM_USA_OM0C013U_19MY■
Rear seat (vehicles with rear console box)
High heating temperature
The indicator (yellow) comes
on.
Press lightly on the opposite
side to turn off.
Low heating temperature
The indicator (green) comes
on.
Press lightly on the opposite
side to turn off.
■The seat heaters/seat ventilators can be used when
The engine switch is in the “ON” position.

4847-2. Steps to take in an emergency
SEQUOIA_OM_USA_OM0C013U_19MY
If your vehicle overheats
●The needle of the engine coolant temperature gauge ( P. 8 6 )
enters the red zone o r a loss of engine power is experienced.
(For example, the vehicle speed does not increase.)
● Steam comes out f rom under the hood.
Stop the vehicle in a safe place and turn off the air condition ing sys-
tem, and then stop the engine.
If you see steam:
Carefully lift the hood after the steam subsides.
If you do not see steam:
Carefully lift the hood.
After the engine has cooled
down sufficiently, inspect the
hoses and radiator core (radia-
tor) for any leaks. Radiator
Cooling fan
If a large amount of coolant
leaks, immediately contact your
Toyota dealer.
The coolant level is satisfactory
if it is between the “FULL” and
“LOW” lines on the reservoir.Reservoir
“FULL” line
“LOW” line
Radiator cap
The following may indicate that your vehicle is overheating:
Correction procedures
1
2
3
4

546Alphabetical index
SEQUOIA_OM_USA_OM0C013U_19MY
Child safety ................................ 55Airbag precautions .................. 40
Back door precautions .......... 114
Battery precautions ....... 403, 483
Child restraint system ............. 56
How your child should
wear the seat belt ................. 32
Installing child restraints ......... 60
Moon roof precautions .......... 158
Power window lock switch .... 149
Power window precautions ... 151
Rear door child-protectors .... 106
Removed key battery precautions ......................... 425
Seat belt extender precautions ........................... 37
Seat belt precautions .............. 34
Seat heater precautions........ 332
Child-protectors....................... 106
Cleaning ........................... 378, 381 Aluminum wheels.................. 379
Exterior ................................. 378
Interior................................... 381
Seat belts .............................. 382
Climate control seat ................ 333
Compass .................................. 372
Condenser ................................ 399
Console box ..................... 340, 342
Conversation mirror ................ 360
Cooling system Engine overheating ............... 484
Cruise control .......................... 256
Cup holders.............................. 345
Curtain shield airbags ............... 38
Customizable features ............ 516 Daytime running light
system.................................... 210
Defogger Outside rear view mirrors ..... 323
Rear window ......................... 323
Windshield ............................ 323
Dimension ................................ 490
Dinghy towing.......................... 197
Display Multi-information display ......... 90
Warning message................. 457
Do-it-yourself maintenance .... 390
Door courtesy lights ............... 335 Wattage ................................ 500
Doors Automatic door locking and
unlocking systems .............. 107
Back door ............................. 110
Door lock ...................... 104, 110
Door windows ....................... 149
Open door warning buzzer ... 460
Outside rear view mirrors ..... 145
Rear door child-protector ...... 106
Side doors ............................ 104
Drive information....................... 91
Driver’s seat position memory .................................. 133
Driving ...................................... 160 Break-in tips.......................... 162
Correct driving posture ........... 26
Driving assist systems .......... 302
Off-road precautions ............. 309
Procedures ........................... 160
Winter drive tips .................... 314D

547Alphabetical index
SEQUOIA_OM_USA_OM0C013U_19MY
EDR (Event data recorder) ........ 10
Electronically modulated air suspension ....................... 289
Emergency flashers ................ 438
Emergency, in case of
If a warning buzzer sounds ................................ 448
If a warning light turns on ....................................... 448
If a warning message
is displayed......................... 457
If the engine will not start ...... 479
If the vehicle battery is discharged .......................... 480
If you have a flat tire ............. 465
If you think something is wrong .............................. 446
If your vehicle becomes stuck ................................... 487
If your vehicle has to be stopped in an emergency ... 439
If your vehicle needs
to be towed ......................... 441
If your vehicle overheats ....... 484 Engine
Compartment ........................ 394
Engine switch ....................... 198
Hood ..................................... 393
How to start the engine......... 198
Identification number ............ 492
If the engine will not start ...... 479
Ignition switch
(engine switch) ................... 198
Overheating .......................... 484
Engine coolant......................... 398
Capacity................................ 496
Checking............................... 398
Preparing and checking before winter ...................... 314
Engine coolant temperature gauge ....................................... 86
Engine immobilizer system ...... 74
Engine oil ................................. 395 Capacity................................ 494
Checking............................... 395
Preparing and checking before winter ...................... 314
Engine switch .......................... 198
Event data recorder (EDR)........ 10
E

551Alphabetical index
SEQUOIA_OM_USA_OM0C013U_19MY
MaintenanceDo-it-yourself maintenance ... 390
General maintenance ........... 386
Maintenance data ................. 490
Maintenance requirements ... 384
Reset the maintenance data .................................... 385
Malfunction indicator lamp ..... 448
Master warning light........ 451, 457
Meter ........................................... 86 Indicators ................................ 83
Instrument panel light control................................... 88
Meters ..................................... 86
Multi-information display ......... 90
Warning lights ......................... 81
Mirrors Inside rear view mirror .......... 142
Outside rear view mirror defoggers ........................... 323
Outside rear view mirrors...... 145
Vanity mirrors........................ 356
Moon roof ................................. 155 Door lock linked moon roof operation ............................ 157
Jam protection function......... 156
Operation .............................. 155
MP3 disc
*
Multi-information display .......... 90 Drive information..................... 91
Language ................................ 92
LDA (Lane Departure Alert) ................................... 248
PCS (Pre-Collision system) ........ ....................... 234
Settings ................................... 92
Warning message ................. 457 Navigation system
*
Noise from under vehicle ........... 8
Odometer ................................... 86
Off-road precaution
s ............... 309
Oil Differential oil ........................ 497
Engine oil ...................... 395, 494
Transfer oil............................ 497
Opener Back door ............................. 111
Fuel filler door ....................... 227
Hood ..................................... 393
Outer foot lights ...................... 335
Outside rear view mirrors ....... 145
Adjusting and folding ............ 145
BSM (Blind Spot Monitor) ..... 276
Outside rear view mirror defoggers ................. 323
Outside temperature
display...................................... 86
Overhead console ................... 344
Overheating, Engine ............... 484
MN
O
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
