TOYOTA SEQUOIA 2020 Owners Manual (in English)

3715-3. Using the storage features
5
Interior features
SEQUOIA_OM_USA_OM0C021U_20MY
Luggage compartment features
The cargo hooks are provided for
securing loose items.
The cargo net itself is not included as original equipment.
To hang the cargo net, use the
cargo net hooks.
Cargo hooks
Cargo net hooks

3725-3. Using the storage features
SEQUOIA_OM_USA_OM0C021U_20MY
To hang shopping bags, use the
grocery bag hooks.
Grocery bag hooks

3735-3. Using the storage features
5
Interior features
SEQUOIA_OM_USA_OM0C021U_20MY
Ty p e A
Pull the lever upwards to lift the
deck board.
Type B (if equipped)
Open the cover.
Storage compartment

3745-3. Using the storage features
SEQUOIA_OM_USA_OM0C021U_20MY
WARNING
■When the cargo hooks are not in use
To avoid injury, always return the cargo hooks to their stowed positions.
■ Caution while driving
Keep the auxiliary box closed. Injuries may result in the event of an accident
or sudden braking.
NOTICE
■ To prevent damage to the cargo net hooks
Avoid hanging things other than a cargo net on them.
■ Grocery bag hook weight capacity
Do not hang any object heavier than 8.8 lb. (4 kg) on the groce ry bag hooks.

3755-4. Other interior features
5
Interior features
SEQUOIA_OM_USA_OM0C021U_20MY
Other interior features
■Main visor
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
■Sub visor (if equipped)
Flip it down.
Sun visors

3765-4. Other interior features
SEQUOIA_OM_USA_OM0C021U_20MY
Vehicles without vanity light
Open the cover.
Vehicles with vanity light
Open the cover.
The light turns on when the cover
is opened.
Adjust the brightness of the
light.
Vanity mirrors
NOTICE
To prevent battery discharge, do not leave the vanity lights on for extended
periods while the engine is not running.

3775-4. Other interior features
5
Interior features
SEQUOIA_OM_USA_OM0C021U_20MY■
12 V DC
Please use as a power supply for electronic goods that use less than
12 VDC/10 A (power c onsumption of 120 W).
When using electronic goods, make sure that the power consumption
of all the connected power outlets is less than 120 W.
Power outlets
Instrument panelFront console box (outside)
(if equipped)
Open the lid. Open the lid.
Luggage compartment
Open the lid.

3785-4. Other interior features
SEQUOIA_OM_USA_OM0C021U_20MY
Front console box (inside)
Lift the lid while pulling up the
knob to release the lock.
Open the lid.
■120 V AC (if equipped)
Accessories that use less than 100 W.
Open the lid.
1
2

3795-4. Other interior features
5
Interior features
SEQUOIA_OM_USA_OM0C021U_20MY
■The power outlets can be used when
12 V DC
The engine switch is in ACC or ON.
120 V AC
The engine switch is in ON.
■ When turning the engine switch off
Disconnect electrical devices with charging functions, such as mobile battery
packs.
If such devices are left connected, the engine switch may not b e turned off
normally.
NOTICE
● To avoid damaging the power outlets, close the power outlet lid when the
power outlet is not in use.
Foreign objects or liquids that enter the power outlet may caus e a short
circuit.
● To prevent blown fuse:
12 V DC
Do not use an accessory that uses more than 12 V 10 A.
120 V AC
Do not use a 120 V AC appliance that requires more than 100 W.
If a 120 V AC appliance that consumes more than 100 W is used, the pro-
tection circuit will cut the power supply.
● To prevent battery discharge, do not use the power outlet longe r than nec-
essary when the engine is not running.
● The following 120 V AC appliances may not operate properly even if their
power consumption is under 100 W:
• Appliances with high initial peak wattage
• Measuring devices that process precise data
• Other appliances that require an extremely stable power supply

3805-4. Other interior features
SEQUOIA_OM_USA_OM0C021U_20MY
The USB charging ports are used to supply 2.1 A of electricity at 5 V
to external devices.
The USB charging ports are for charging only. They are not desi gned
for data transfer or other purposes.
Depending on the external device, it may not charge properly. R efer to
the manual included with the dev ice before using a USB charging
port.
■Using the USB charging ports
Open the lid.
■ The USB charging ports can be used when
The engine switch is in ACC or ON.
■ Situations in which the USB charg ing ports may not operate correctly
● If a device which consumes more than 2.1 A at 5 V is connected
● If a device designed to communicate with a personal computer, s uch as a
USB memory device, is connected
● If the connected external device is turned off (depending on de vice)
● If the temperature inside the vehicle is high, such as after the vehicle has
been parked in the sun
■ About connected external devices
Depending on the connected external device, charging may occasi onally be
suspended and then start again. This is not a malfunction.
USB charging ports
