stop start TOYOTA SEQUOIA 2020 (in English) Owner's Guide

4797-2. Steps to take in an emergency
7
When trouble arises
SEQUOIA_OM_USA_OM0C021U_20MY
Indicates a malfunction in the BSM (Blind Spot
Monitor)A buzzer also sounds.
 Have the vehicle inspected by your Toyota
dealer immediately.
Indicates a malfunction in the RCTA (Rear Cross
Traffic Alert)
A buzzer also sounds.
 Have the vehicle inspected by your Toyota
dealer immediately.
Indicates a malfunction in the intuitive parking
assist sensor (if equipped)
The malfunctioning assist-sensor is flashing.
 Have the vehicle inspected by your Toyota
dealer immediately.
Indicates a malfunction in:
• The automatic headlight leveling system; or
• The LED headlight system.
A buzzer also sounds.
 Have the vehicle inspected by your Toyota
dealer.
Indicates a malfunction in the tire pressure
monitoring system
Stop the vehicle in a safe place and turn
the engine off then start again.
If the tire pressure warning indicator
flashes for 1 minute then illuminates,
there is a malfunction in the system.
Have the vehicle inspected by your Toy-
ota dealer.
Indicates that the BSM (Blind Spot Monitor) sen-
sors or the surrounding area on the bumper is
dirty or covered with ice
A buzzer also sounds.
 Clean the sensor and its surrounding area
on the bumper.
Warning messageDetails/Actions
Blind Spot Monitor Malfunction
Visit Your Dealer
Rear Cross Traffic Alert Malfunction
Visit Your Dealer
Parking Assist Malfunction
Headlight System Malfunction
Visit Your Dealer
Tire Pressure Warning System Malfunction, Visit Your Dealer
(Flashes and
then remains
on)
Blind Spot Monitor
Unavailable

5067-2. Steps to take in an emergency
SEQUOIA_OM_USA_OM0C021U_20MY
■Stopping the engine
Shift the shift lever to P and press the engine switch as you normally do when
stopping the engine.
■ Replacing the key battery
As the above procedure is a temporary measure, it is recommende d that the
electronic key battery be replaced immediately when the battery is depleted.
( P. 444)
■ Changing engine switch modes
Within 10 seconds of the buzzer sounding, release the brake ped al and press
the engine switch.
The engine does not start and modes will be changed each time t he switch is
pressed. ( P. 215)

5127-2. Steps to take in an emergency
SEQUOIA_OM_USA_OM0C021U_20MY
Add engine coolant if neces-
sary.
Water can be used in an emer-
gency if engine coolant is unavail-
able.
Start the engine to check that the radiator cooling fan operate and
to check for coolant leaks from the radiator or hoses.
If the fan are not operating:
Stop the engine immediately and contact your Toyota dealer.
If the fan are operating:
Have the vehicle ins pected at the nearest Toyota dealer.
5
WARNING
■When inspecting under th e hood of your vehicle
Observe the following precautions.
Failure to do so may result in serious injury such as burns.
● If steam is seen coming from under the hood, do not open the ho od until
the steam has subsided. The engine compartment may be very hot.
● Keep hands and clothing (especially a tie, a scarf or a muffler ) away from
the fans and belts.
● Do not loosen the radiator cap and the coolant reservoir cap wh ile the
engine and radiator are hot.
High temperature steam or coolant could spray out.
6
7

5147-2. Steps to take in an emergency
SEQUOIA_OM_USA_OM0C021U_20MY
If the vehicle becomes stuck
Stop the engine. Set the parking brake and shift the shift lever to P.
Remove the mud, snow or sand from around the stuck tire.
Place wood, stones or some other material under the tires to help
provide traction under the tires.
Restart the engine.
Lock the center differential. ( P. 316)
Shift the shift lever to D or R position and carefully apply th e accel-
erator to free the vehicle.
■ When it is difficult to free the vehicle
Turn off TRAC or VSC/Trailer Sway Control if these functions ar e hampering
your attempts to free the vehicle. ( P. 324)
Carry out the following procedures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
Press to turn off TRAC or VSC/Trailer
Sway Control.
1
2
3
4
5
6

571What to do if... (Troubleshooting)
SEQUOIA_OM_USA_OM0C021U_20MY
●Did you press the engine switch while firmly depressing the brake pedal?
( P. 214)
●Is the shift lever in P? ( P. 216)
●Is the electronic key anywhere detectable inside the vehicle? ( P. 129)
●Is the steering wheel unlocked? (P. 217)
●Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way. ( P. 505)
●Is the battery discharged? (P. 507)
●Is the engine switch in ON?
If you cannot release the shift lever by depressing the brake p edal with the
engine switch in ON. ( P. 223)
●It is locked automatically to prevent theft of the vehicle. ( P. 2 1 7 )
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( P. 165)
If you think something is wrong
The engine does not start
The shift lever cannot be shifted from P even if you depress
the brake pedal
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches

572What to do if... (Troubleshooting)
SEQUOIA_OM_USA_OM0C021U_20MY
●The auto power off function will be operated if the vehicle is left in ACC or
ON (the engine is not running) for a period of time. ( P. 216)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts?
(P. 471)
Depending on the situation, other types of warning buzzer may a lso sound.
( P. 469, 477)
●Did anyone inside the vehicle open a door during setting the al arm?
The sensor detects it and the alarm sounds. ( P. 84)
To stop the alarm, start the engine.
●Is the electronic key left inside the vehicle?
Check the message on the multi-information display. ( P. 477)
●When a warning light turns on, refer to P. 469.
●When a warning light turns on or a warning message or indicator is dis-
played, refer to P. 469, 477.
The engine switch is tur ned off automatically
A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning buzzer sounds w hen leaving the vehicle
A warning light turns on or a warning message is displayed

577Alphabetical index
SEQUOIA_OM_USA_OM0C021U_20MY
EDR (Event data recorder) ........ 11
Electronically modulated air suspension ....................... 309
Emergency flashers ................ 458
Emergency, in case of
If a warning buzzer sounds ................................ 469
If a warning light turns on ....................................... 469
If a warning message
is displayed......................... 477
If the engine will not start ...... 503
If the vehicle battery is discharged .......................... 507
If the vehicle is trapped in rising water ..................... 461
If you have a flat tire ............. 489
If you think something is wrong .............................. 467
If your vehicle becomes stuck ................................... 514
If your vehicle has to be
stopped in an emergency ... 459
If your vehicle needs to be towed ......................... 462
If your vehicle overheats ....... 511 Engine
Compartment ........................ 414
Engine switch ....................... 214
Hood ..................................... 413
How to start the engine......... 214
Identification number ............ 520
If the engine will not start ...... 503
Ignition switch
(engine switch) ................... 214
Overheating .......................... 511
Engine coolant......................... 418
Capacity................................ 524
Checking............................... 418
Preparing and checking before winter ...................... 334
Engine coolant temperature gauge ....................................... 94
Engine immobilizer system ...... 76
Engine oil ................................. 415 Capacity................................ 522
Checking............................... 415
Preparing and checking before winter ...................... 334
Engine switch .......................... 214
Event data recorder (EDR)........ 11
E

584Alphabetical index
SEQUOIA_OM_USA_OM0C021U_20MY
Shift lever ................................. 220Automatic transmission......... 220
If the shift lever
cannot be shifted from P .... 223
Shift lock system ..................... 222
Side airbags ............................... 40
Side marker lights ................... 227 Light switch ........................... 227
Replacing light bulbs..... 450, 455
Wattage ................................ 528
Side mirrors ............................. 161
Adjusting and folding ............ 161
Blind Spot Monitor ................ 296
Heaters ................................. 343
Side turn signal lights ............. 225 Replacing light bulbs............. 455
Turn signal lever ................... 225
Smart key system .................... 128 Antenna location ................... 128
Entry functions ...................... 113
Starting the engine................ 214
Warning message ................. 485
Snow tires ................................ 337
Spare tire .................................. 489
Inflation pressure .................. 527
Storage location .................... 490
Spark plug ................................ 524
Specifications .......................... 518
Speedometer .............................. 94
Steering lock ............................ 217
Steering wheel ......................... 156
Adjustment ............................ 156
Audio switches
*
Meter control switches ............ 99
Telephone switches
*
Stop lightsReplacing light bulbs ............ 450
Wattage ................................ 528
Storage feature ........................ 359
Storage precautions................ 190
Stuck If the vehicle becomes stuck ................................... 514
Sun visors ................................ 375
Switches Audio remote control switches
*
Automatic High Beam
switch ................................. 231
AVS (Adaptive Variable
Suspension System)
switch ................................. 314
Cruise control switch ............ 276
Center differential lock
switch ................................. 316
Door lock switches................ 114
Driving position memory
switches ............................. 149
Emergency flashers switch ... 458
Engine switch ....................... 214
Fog light switch ..................... 236
Front-wheel drive control switch ................................. 315
Garage door opener switches ............................. 385
Height control switches......... 309
