4146-3. Do-it-yourself maintenance
SEQUOIA_OM_USA_OM0C021U_20MY
Engine compartment
Washer fluid tank (P. 424)
Engine oil level dipstick ( P. 415)
Engine coolant reservoir ( P. 418)
Engine oil filler cap ( P. 416)
Brake fluid reservoir ( P. 420) Fuse box (
P. 446)
Battery ( P. 422)
Radiator ( P. 419)
Cooling fans
Condenser ( P. 419)
Power steering fluid reservoir ( P. 421)

4466-3. Do-it-yourself maintenance
SEQUOIA_OM_USA_OM0C021U_20MY
Checking and replacing fuses
Turn the engine switch to OFF.
Open the fuse box cover.
Engine compartment
Push the tab in and lift the lid
off.
Under the instrument panel
Remove the lid.
Remove the fuse with the pull-
out tool.
Only type A fuse can be removed
using the pullout tool.
If any of the electrical components do not operate, a fuse may
have blown. If this happens, che ck and replace the fuses as nec-
essary.
1
2
3

4476-3. Do-it-yourself maintenance
6
Maintenance and care
SEQUOIA_OM_USA_OM0C021U_20MY
Check if the fuse is blown.Normal fuse
Blown fuse
Type A, B:
Replace the blown fuse with a new fuse of an appropriate ampera ge rat-
ing. The amperage rating can be found on the fuse box lid.
Type C:
Contact your Toyota dealer.
4
Ty p e AType B
Ty p e C

4486-3. Do-it-yourself maintenance
SEQUOIA_OM_USA_OM0C021U_20MY
■After a fuse is replaced
●If the lights do not turn on even after the fuse has been repla ced, a bulb may
need replacement. ( P. 449)
● If the replaced fuse blows again, have the vehicle inspected by your Toyota
dealer.
■ If there is an overload in a circuit
The fuses are designed to blow, protecting the wiring harness f rom damage.
■ When replacing light bulbs
Toyota recommends that you use genuine Toyota products designed for this
vehicle. Because certain bulbs are connected to circuits designed to prevent
overload, non-genuine parts or parts not designed for this vehicle may be
unusable.
WARNING
■ To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failure to do so may cause damage to the vehicle, and possibly a fire or
injury.
● Never use a fuse of a higher amperage rating than that indicate d, or use
any other object in place of a fuse.
● Always use a genuine Toyota fuse or equivalent.
Never replace a fuse with a wire, even as a temporary fix.
● Do not modify the fuses or fuse boxes.
NOTICE
■Before replacing fuses
Have the cause of electrical overload determined and repaired b y your
Toyota dealer as soon as possible.

578Alphabetical index
SEQUOIA_OM_USA_OM0C021U_20MY
Flat tire...................................... 489
Floor mats .................................. 26
FluidAutomatic transmission......... 525
Brake .................................... 526
Power steering ...................... 526
Washer ................................. 424
Fog lights ................................. 236 Replacing light bulbs............. 455
Switch ................................... 236
Four-wheel drive system .................................... 315
Front passenger occupant
classification system .............. 51
Front personal lights ............... 357
Front seats ............................... 136 Adjustment ............................ 136
Cleaning................................ 401
Correct driving posture ........... 28
Driving position memory ....... 149
Head restraints ..................... 154
Seat heaters ......................... 352
Seat position memory ........... 149
Seat ventilators ..................... 352 Front side marker lights ......... 227
Light switch ........................... 227
Replacing light bulbs ............ 455
Front turn signal lights ........... 225 Replacing light bulbs ............ 455
Turn signal lever ................... 225
Fuel ........................................... 244 Capacity................................ 521
Fuel gauge.............................. 94
Fuel pump shut off system ... 468
Information............................ 529
Refueling .............................. 244
Type...................................... 521
Warning light......................... 470
Fuel consumption ................... 104
Fuel filler door ......................... 246 Refueling .............................. 244
Fuel pump shut off system..... 468
Fuses ........................................ 446
Garage door opener ................ 385
Gauges ....................................... 94
Glove box ................................. 360
Grocery bag hooks.................. 372
F
G

582Alphabetical index
SEQUOIA_OM_USA_OM0C021U_20MY
Parking brake ........................... 226Operation .............................. 226
Parking brake engaged warning buzzer/
message ............................. 480
Parking lights ........................... 227 Light switch ........................... 227
Replacing light bulbs............. 455
PCS (Pre-Collision system) .... 254 Enabling/disabling
the system ................... ....... 258
Pen holder ................................ 361
Personal lights ......................... 357
Power back window ................ 168 Jam protection function......... 169
Operation .............................. 168
Power outlets ........................... 377
Power steering Fluid .............................. 421, 526
Warning light ......................... 470
Power windows........................ 165 Door lock linked window
operation ............................ 166
Jam protection function......... 166
Operation .............................. 165
Window lock switch............... 165
Pre-Collision system (PCS) ...................................... 254 Enabling/disabling
the system ................... ....... 258Radiator .................................... 419
Radio
*
RCTA (Rear Cross Traffic
Alert)....................................... 296
Rear air conditioning system.................................... 348
Rear console box .................... 363
Rear seats
Adjustment............................ 138
Folding down ................ 141, 144
Rear side sunshade ................ 383
Rear step bumper .................... 121
Rear turn signal lights ............ 225 Replacing light bulbs ............ 450
Turn signal lever ................... 225
Wattage ................................ 528
Rear view mirror Inside rear view mirror .......... 158
Outside rear view mirrors ..... 161
Rear view monitor system
*
Rear window ............................ 168
Rear window defoggers .......... 343
Rear window wiper .................. 241
Refueling .................................. 244 Capacity................................ 521
Fuel types ............................. 521
Opening the fuel tank cap..... 246
Replacing Fuses .................................... 446
Key battery ........................... 444
Light bulbs ............................ 449
Tires...................................... 489
Reporting safety defects for U.S. owners...................... 558
Resetting the message
indicating maintenance
is required.............................. 405
Roof luggage carrier ............... 187
PR
