1694-8. Rear seat entertainment system operation
4
Audio/visual system
BD video
The color key button is used for
various uses according to direc-
tions of contents.
1 Select “Color Keys”.
2 The color key buttons are
displayed on the screen.
BD video
The 10 key pad is used when
inputting numbers according to
directions of contents.
1 Select “Keypad”.
2 The 10 key pad is displayed
on the screen.
Video CD
1 Select “Select Number”.
2 Input the track number, and
select “OK”.
Video CD
If there is the next or previous
page while the disc menu is dis-
played, the page can be
switched.
1 Select “Prev. Page” or “Next
Page”.
2 Next or previous page is dis-
played.
BD video, DVD video,
AVCHD, BDAV
The initial setting can be
changed.
1 Select “Setup”.
Displaying the color key but-
tons
Displaying the 10 key pad
Searching by track
Displaying the next or previ-
ous page
Initial setup

1744-8. Rear seat entertainment system operation
MP3/WMA/AAC
1 Press “ ” or “” on the
“FOLDER” button until the
desired folder number
appears.
 Press and hold “ ” on the
“FOLDER” button, the top file
stored in the top folder in the
disc will be selected.
1 Each time is selected,
the mode changes as follow:
Audio CD
track repeat  off
MP3/WMA/AAC
file repeat  folder repeat  off
1Each time is selected,
the mode changes as follow:
Audio CD
random  off
MP3/WMA/AAC
1 folder random  1 disc random
 off
Selecting a control icon
Inputting the selected control
icon
Volume up/down
Fast-forward/rewind
Play/pause
Stop
Displaying the option screen
Selecting a folder
Repeat play
Random playback
Playing an SD card
This system can play music,
still pictures and video that
are stored in an SD card.
Press the “SD” button if an
SD card has already been
inserted in the SD card slot.
Remote controller
A
B
C
D
E
F
G

1764-8. Rear seat entertainment system operation
Random playback
You can display still pictures that
are stored on an SD card.
1 Select “Picture”.
2 Select the desired still picture
to show.
 Select or to show the
next or previous page.
3 Selected picture is displayed
on the screen.
 Press the or button to display the next or previous
still picture.
 Press the “SD” button to
return to the SD menu screen.
Press the “OPTION” button
while displaying a still picture,
the following screen appears.
Press the “OPTION” button
once again or select “Hide But-
tons” to turn off the option
screen.
Turning off the option screen
Displaying the slideshow
setup screen
Returning to “Library View”
screen
Zooming out the still pictures
Rotating the still pictures
Displaying the detail informa-
tions of the still picture
Starting slideshow
You can display still pictures one
by one at a constant interval.
Playing still pictures
B
2SWLRQVFUHHQ
6WDUWLQJVOLGHVKRZ
A
B
C
D
E
F
G

1774-8. Rear seat entertainment system operation
4
Audio/visual system
1Select “Slideshow” to start
slideshow.
 When pressing the or
button during slideshow, the
previous or next still picture
will be shown, and the slide-
show will continue from that
picture.
 Press the “ENT” or “OPTION”
button to stop slideshow.
1 Select or to rotate a
still picture.
 The rotate information will be
maintained until the system is
turned off or the SD card is
removed.
1 Select to zoom out the
still pictures.
 Select again to cancel
zoom out.
 This function is only available
for smallsized still pictures.
1 Select “Detailed Information”. 2
Detail informations of the still
picture are displayed.
1 Select “Setup”.
2 The slideshow settings can
be changed. After the set-
tings are changed, select
“OK”.
Selects slideshow interval
time (seconds)
5  10  15  30  60
Selects slideshow effect
“Fade”  “Slide”  “Wipe1” 
“Wipe2”  “Dissolve”  “Zoom” 
“Off”
Selects on/off repeat slide-
show
Restores default settings
Rotating the still pictures
Zoom out the still pictures
Displaying the detail infor-
mations of the still picture
Slideshow setup
A
B
C
D

1794-8. Rear seat entertainment system operation
4
Audio/visual system
MovieTurning off the option screen
Displaying the detail informa-
tion
Rewind
Stop
Play/pause
Fast-forward
Searching for a title
Searching for a chapter
Changing the playback mode
Changing the audio channel
Displaying the top menu
screen
Returning to the predeter-
mined scene
Changing the audio language
Changing the subtitle lan-
guage
1 Select “Detailed Information”. 2
Detail informations of the
video are displayed.
SD video
SD AVCHD
Movie
SD video, SD AVCHD
1 Select “Title” or “Chapter”.
Displaying the detail infor-
mations of the video
A
B
C
D
E
F
G
H
I
J
K
L
M
N
6HDUFKLQJIRUDWL\
WOHRUFKDS
WHU

1824-8. Rear seat entertainment system operation
●Wi-Fi® is a registered trademark
of Wi-Fi Alliance®.
●The Wi-Fi® networks serve best-
effort traffic.
Selecting a control icon
Inputting the selected control
icon
Using the DLNA mode
Plays or displays music,
pictures and video that are
stored on a DLNA server.
This device supports a
DLNA renderer function.
This device can play and
display content from
devices equipped with a
DLNA server function.
Make sure to install DMC-
compatible software on the
DLNA server.
Press the “INPUT” button
repeatedly until the DLNA
mode is selected.
WA R N I N G
●Use Wi-Fi® devices only when
safe and legal to do so.
●Your audio unit is fitted with Wi-
Fi® antennas. People with
implantable cardiac pacemak-
ers, cardiac resynchronization
therapy-pacemakers or implant-
able cardioverter defibrillators
should maintain a reasonable
distance between themselves
and the Wi-Fi
® antennas. The
radio waves may affect the
operation of such devices.
●Before using Wi-Fi® devices,
users of any electrical medical
device other than implantable
cardiac pacemakers, cardiac
resynchronization therapy-
pacemakers or implantable car-
dioverter defibrillators should
consult the manufacturer of the
device for information about its
operation under the influence of
radio waves. Radio waves could
have unexpected effects on the
operation of such medical
devices.
NOTICE
●Do not leave your smartphone
in the vehicle. In particular, high
temperatures inside the vehicle
may damage the smartphone.
Remote controller
A
B

1834-8. Rear seat entertainment system operation
4
Audio/visual system
Turning on the DLNA mode
Volume up/down
Fast-forward/rewind
Play/pause
Displaying the option screen
1 Press the button to
play/pause.
 Press and hold the but-
ton while pausing, the video is
played slowly.
1 Press and hold /
or / .
1 Display the DLNA operation
screen.
2 Check that “Wi-Fi” is on. 3
Connect a device to the rear
seat entertainment system
via Wi-Fi
®.
4 Operate the device to stream
video/music/photos.
●DLNA streaming will stop in the
following situations:
• Select “Refresh” button to change
the Wi-Fi
® setting information.
(  P.183)
• The DLNA connection is turned off
on the device.
•The Wi-Fi
® function is turned off.
(  P.186)
• The rear seat entertainment sys-
tem source is changed to different
source. ( P.158)
After a device has been con-
nected to the vehicle Wi-Fi
®
access point once, the access
point information will remain on
the device, enabling it automati-
cally connect the next time the
device is brought within access
point range, unless the access
point name or password is
changed.
To change the access point
name and password, select
“Refresh” If changed while a
device is connected to the
access point, the connection will
be canceled.
Playing/pausing a
video/music
Fast forwarding or
rewinding a track/file
Connecting the system
C
D
E
F
G
&KDQJLQJWKHDFFHVVSRLQW
QDPHDQGSDVVZRUG

1844-8. Rear seat entertainment system operation
1Select “Refresh”.
2 Select “Yes”.
●When the Wi-Fi® information is
refreshed, connected devices are
disconnected, so make sure to do
the wireless connection settings
again.
●The access point name and pass-
word are only changed when
“Refresh” is selected (they are not
changed when the engine switch
is turned off and back on).
The Wi-Fi® function is turned
on/off. Select to display Wi-Fi
® sys-
tem information
1 Connect your smartphone to
a Wi-Fi
® network and send a
picture from a DLNA-compat-
ible application.
2 Picture is displayed on the
screen.
 Press the “INPUT” button to
return to the DLNA menu
screen. To display the picture
again, select “DLNA”.
1 Connect your smartphone to
a Wi-Fi
® network and send a
DLNA operation
A
3OD\LQJVWLOO\
SLFWXUHV
3OD\LQJYLGHR
B

1854-8. Rear seat entertainment system operation
4
Audio/visual system
video from a DLNA-compati-
ble application.
2 Video will start playing.
 Press the “INPUT” button to
return to the DLNA menu
screen. To display the video
again, select “DLNA”.
1 Press the “OPTION” button
while watching a video, the
following screen appears.
Turning off the option screen
Rewind Play/pause
Fast-forward
1 Connect your smartphone to
a Wi-Fi
® network and send
music from a DLNA-compati-
ble application.
2 Music will start playing.
1 Use the DLNA-compatible
application on your smart-
phone to stop sending con-
tent.
Option screen
A
B
3OD\LQJPXVLF
6WRSSLQJSOD\\
EDFN
C
D

1864-8. Rear seat entertainment system operation
2Playback stops.
1 Select “Wi-Fi”.
2 DLNA standby stops.
●Wi-Fi® is a registered trademark
of Wi-Fi Alliance®.
●Miracast™ is a trademark of Wi-Fi
Alliance®.
●The Wi-Fi® networks serve best-
effort traffic.
●If a connected device is taken out
of the Wi-Fi® connection area, the
connection will be severed.
●Depending on the environment in
which the access point is used,
the communication speed may be
low or communication may not be
possible.
●When a device is connected to the
rear seat entertainment system
via Wi-Fi
®, the device may not be
Stop DLNA standby
Using the Miracast™
mode
The screen of a Miracast™-
compatible device (with
Android OS version 4.4 or
later) can be displayed on
the rear seat entertainment
system display.
This function is not avail-
able if the smartphone is
not certified by Wi-Fi Alli-
ance as Miracast™ device.
Refer to the instruction
manual and other documen-
tation included with the
external device to determine
whether it supports Mira-
cast™.
Press the “INPUT” button
repeatedly until the Mira-
cast™ mode is selected.
