TOYOTA SEQUOIA 2021 Accessories, Audio & Navigation (in English)

1834-8. Rear seat entertainment system operation
4
Audio/visual system
Turning on the DLNA mode
Volume up/down
Fast-forward/rewind
Play/pause
Displaying the option screen
1 Press the button to
play/pause.
 Press and hold the but-
ton while pausing, the video is
played slowly.
1 Press and hold /
or / .
1 Display the DLNA operation
screen.
2 Check that “Wi-Fi” is on. 3
Connect a device to the rear
seat entertainment system
via Wi-Fi
®.
4 Operate the device to stream
video/music/photos.
●DLNA streaming will stop in the
following situations:
• Select “Refresh” button to change
the Wi-Fi
® setting information.
(  P.183)
• The DLNA connection is turned off
on the device.
•The Wi-Fi
® function is turned off.
(  P.186)
• The rear seat entertainment sys-
tem source is changed to different
source. ( P.158)
After a device has been con-
nected to the vehicle Wi-Fi
®
access point once, the access
point information will remain on
the device, enabling it automati-
cally connect the next time the
device is brought within access
point range, unless the access
point name or password is
changed.
To change the access point
name and password, select
“Refresh” If changed while a
device is connected to the
access point, the connection will
be canceled.
Playing/pausing a
video/music
Fast forwarding or
rewinding a track/file
Connecting the system
C
D
E
F
G
&KDQJLQJWKHDFFHVVSRLQW
QDPHDQGSDVVZRUG

1844-8. Rear seat entertainment system operation
1Select “Refresh”.
2 Select “Yes”.
●When the Wi-Fi® information is
refreshed, connected devices are
disconnected, so make sure to do
the wireless connection settings
again.
●The access point name and pass-
word are only changed when
“Refresh” is selected (they are not
changed when the engine switch
is turned off and back on).
The Wi-Fi® function is turned
on/off. Select to display Wi-Fi
® sys-
tem information
1 Connect your smartphone to
a Wi-Fi
® network and send a
picture from a DLNA-compat-
ible application.
2 Picture is displayed on the
screen.
 Press the “INPUT” button to
return to the DLNA menu
screen. To display the picture
again, select “DLNA”.
1 Connect your smartphone to
a Wi-Fi
® network and send a
DLNA operation
A
3OD\LQJVWLOO\
SLFWXUHV
3OD\LQJYLGHR
B

1854-8. Rear seat entertainment system operation
4
Audio/visual system
video from a DLNA-compati-
ble application.
2 Video will start playing.
 Press the “INPUT” button to
return to the DLNA menu
screen. To display the video
again, select “DLNA”.
1 Press the “OPTION” button
while watching a video, the
following screen appears.
Turning off the option screen
Rewind Play/pause
Fast-forward
1 Connect your smartphone to
a Wi-Fi
® network and send
music from a DLNA-compati-
ble application.
2 Music will start playing.
1 Use the DLNA-compatible
application on your smart-
phone to stop sending con-
tent.
Option screen
A
B
3OD\LQJPXVLF
6WRSSLQJSOD\\
EDFN
C
D

1864-8. Rear seat entertainment system operation
2Playback stops.
1 Select “Wi-Fi”.
2 DLNA standby stops.
●Wi-Fi® is a registered trademark
of Wi-Fi Alliance®.
●Miracast™ is a trademark of Wi-Fi
Alliance®.
●The Wi-Fi® networks serve best-
effort traffic.
●If a connected device is taken out
of the Wi-Fi® connection area, the
connection will be severed.
●Depending on the environment in
which the access point is used,
the communication speed may be
low or communication may not be
possible.
●When a device is connected to the
rear seat entertainment system
via Wi-Fi
®, the device may not be
Stop DLNA standby
Using the Miracast™
mode
The screen of a Miracast™-
compatible device (with
Android OS version 4.4 or
later) can be displayed on
the rear seat entertainment
system display.
This function is not avail-
able if the smartphone is
not certified by Wi-Fi Alli-
ance as Miracast™ device.
Refer to the instruction
manual and other documen-
tation included with the
external device to determine
whether it supports Mira-
cast™.
Press the “INPUT” button
repeatedly until the Mira-
cast™ mode is selected.

1874-8. Rear seat entertainment system operation
4
Audio/visual system
able to be connected to the inter-
net via mobile network (3G or 4G).
1Display the Miracast™ oper-
ation screen. 2
Check that the following
screen is displayed.
3 Using your Miracast™-com-
patible device, perform a
Miracast™ connection opera-
tion to connect to the rear
seat entertainment system
display.
4 The screen of the Mira-
cast™-compatible device is
displayed on the rear seat
display.
 Press the “INPUT” button to
return to the “Rear-Mira-
cast™” screen. To display the
video again, select “Mira-
cast™”.
●Depending on the device, Mira-
cast™ may be displayed as
“screen mirroring”, “media output”,
etc.
●Miracast™ stream ing will stop in
the following situations:
• The Miracast™ function of the connected device is turned off.
• Select “Disconnect” on the “Rear- Miracast™” screen.
• The rear seat entertainment sys-
tem source is changed to a differ-
ent source. ( P.158)
WA R N I N G
●Use Wi-Fi® devices only when
safe and legal to do so.
●Your audio unit is fitted with Wi-
Fi® antennas. People with
implantable cardiac pacemak-
ers, cardiac resynchronization
therapy-pacemakers or implant-
able cardioverter defibrillators
should maintain a reasonable
distance between themselves
and the Wi-Fi
® antennas. The
radio waves may affect the
operation of such devices.
●Before using Wi-Fi® devices,
users of any electrical medical
device other than implantable
cardiac pacemakers, cardiac
resynchronization therapy-
pacemakers or implantable car-
dioverter defibrillators should
consult the manufacturer of the
device for information about its
operation under the influence of
radio waves. Radio waves could
have unexpected e ffects on the
operation of such medical
devices.
NOTICE
●Do not leave your smartphone
in the vehicle. In particular, high
temperatures inside the vehicle
may damage the smartphone.
Connecting to the system

1884-8. Rear seat entertainment system operation
Select to disconnect the
Miracast™ device.
●With Miracast™, the screen of the
Miracast™-compatible device is
sent unmodified. Therefore, if
video playback is stopped on the
device that is sending data via
Miracast™, the video on the rear
seat display also stops.
●When Bluetooth® (Bluetooth®
audio, hands-free function or con-
nected services) is being used in
the front seats, Miracast™ cannot
be used on the rear seat display.
Turning on the external mode
Volume up/down
Miracast™ operation
A
Using the exter nal
mode
The rear seat entertainment
system plays videos and
sound when audio/visual
equipment is connected to
the A/V input port.
Press the “INPUT” button
repeatedly until the external
mode is selected.
Remote controller
A
B

1894-8. Rear seat entertainment system operation
4
Audio/visual system
1Open the cover and connect
audio-video equipment to the
A/V input port.
 The A/V input port is com-
posed of 3 input jacks.
Yellow: Video input
White: Left channel audio input
Red: Right channel audio input
2 Turn on the power of the
audio-video equipment.
3 Press the “INPUT” button to
turn on the video mode.
●The volume can be adjusted using
the vehicle’s audio controls. All
other operations must be made on
the audio-visual equipment itself.
For details about operation of
audio-visual equipment, refer to
the manufacturer’ s instructions.
Using the A/V input port
NOTICE
●When the A/V input port is not in
use, keep the A/V input port
cover closed. Inserting any-
thing other than an appropriate
plug may cause electrical fail-
ure.

1904-9. Tips for operating rear seat entertainment system
4-9.Tips for operating rear seat entertainment system
■Certification
For vehicles sold in the U.S.A and
Canada
CAUTION:
• Part 15 of the FCC Rules
Changes or modifications not
expressly approved by the party
responsible for compliance could
void the user’s aut hority to operate
the equipment.
• Laser products
USE OF CONTROL OF ADJUST-
MENT OR PERFORMANCE OF
PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIA-
TION EXPOSURE.
THE USE OF OPTICAL INSTRU-
MENTS WITH THIS PRODUCT
WILL INCREASE EYE HAZARD.
 The following discs cannot be
used on this system:
• SACD
• Ultra HD Blu-ray™
• BDXL™ disc
• BD-RE with the cartridge
• HD DVD
•DVD-Audio
Operating infor mation
CD/DVD/Blu-ray Disc™
player and discs
Discs that can be used

1914-9. Tips for operating rear seat entertainment system
4
Audio/visual system
Compatible media: Media that
can be used for playback are
BD-ROMs, BD-Rs, BD-REs,
DVD-ROMs, DVD-Rs and
DVD-RWs.
 Compatible disc formats: Disc
formats that can be used for
playback are BD video for-
mats, BDAV formats, AVCHD
formats, DVD video formats
and Video CD formats.
 This player conforms to
NTSC/PAL color TV formats.
 Region codes: Some BD/DVD
video discs have a region
code indicating the region in
which you can use the
BD/DVD video disc. If the BD
video disc is not labeled “A” or
“ABC” or if the DVD video disc
is not labeled “1” or “ALL”, you
cannot use it on this player. If
you attempt to play BD/DVD
video discs with incompatible
region codes on this player,
NOTICE
●Do not special shaped, trans-
parent/translucent, low quality
or labeled discs such as those
shown in the illu strations. The
use of such discs may damage
the player, or it may be impossi-
ble to eject the disc.
• Special shaped discs
• Transparent/translucent discs
• Low quality discs
• Labeled discs
●This system is not designed for
use of Dual Discs. Do not use
Dual Discs because they may
cause damage to the player.
●Do not use discs with a protec-
tion ring. The use of such discs
may damage the player, or it
may be impossible to eject the
disc.
●Do not use print able discs. The
use of such discs may damage
the player, or it may be impossi-
ble to eject the disc.
BD/DVD video discs

1924-9. Tips for operating rear seat entertainment system
an error message appears on
the screen. Even if the
BD/DVD video disc does not
have a region code, in some
cases it cannot be used. Even
if a BD video disc has a com-
patible region code, depend-
ing on the intention of the
maker, the BD video disc may
not be able to play in a spe-
cific region or country.
 When storing content on BD-
R, BD-RE, DVD-R or DVD-
RW discs, they must be final-
ized using a recorder. Discs
that are not finalized cannot
be played by this system.
 Discs that are recorded with
multi session cannot be
played by this system.
 BD-Live™ is not supported.
 Blu-ray 3D™ discs is not sup-
ported in 3D playback, it will
play back in 2D.
Parental controls
This feature limits what can be
viewed in conformity with the level
of restrictions of the country. The
level of restrictions varies depend-
ing on the BD/DVD video disc.
Some BD/DVD video discs cannot
be played at all, or violent scenes
are skipped or replaced with other
scenes.
•DVD video
Level 1: DVD vid eo discs for chil-
dren can be played.
Symbols shown on
BD/DVD video discs
SymbolMeaning
Indicates PAL/NTSC for-
mat
Indicates the number of
audio tracks
Indicates the number of
language subtitles
Indicates the number of
angles
Indicates the screen dis-
play ratios available
Wide screen: 16:9
Standard: 4:3
Indicates the disc’s
region code
 BD video
“ABC”: all regions
Alphabet: region code
 DVD video
“ALL”: all regions
Number: region code
BD/DVD video disc infor-
mation
SymbolMeaning
