TOYOTA SEQUOIA 2021 Accessories, Audio & Navigation (in English)

1634-8. Rear seat entertainment system operation
4
Audio/visual system
4-8.Rear seat entertainment system operation
Selecting a control icon
Inputting the selected control
icon
Volume up/down
Fast-forward/rewind
Play/pause
Stop
Displaying the menu screen
Displaying the option screen
Changing the audio language
Selecting a chapter
Turning on the BD/DVD
mode
Playing A Blu-ray
Disc™ (BD) and DVD
discs
This system can play Blu-
ray Disc™ (BD) videos with
digital sound. In addition to
commercial BD and DVD
titles, AVCHD, BDAV videos
and Video CD can be played
on this system, so digital TV
recorded by home digital
video recorders and
BD/DVD home videos
recorded by home digital
video cameras can also be
played on this system.
Press the “DISC” button if a
disc has already been
loaded in the disc slot.
WA R N I N G
●BD/DVD video precaution
• Conversational speech on some
BDs/DVDs is recorded at a low
volume to emphasize the
impact of sound effects. If you
adjust the volume assuming
that the conversations represent
the maximum volume level that
the BD/DVD will play, you may
be startled by louder sound
effects or startled when you
change to a different audio
source. Loud sounds may have
a significant impact on the
human body or pose a driving
hazard. Keep this in mind when
you adjust the volume.
Remote controller
A
B
C
D
E
F
G
H
I
J
K

1644-8. Rear seat entertainment system operation
1Insert a disc or press the
“DISC” button.
 The player will start to play
the disc automatically.
1 Press the button to
play/pause.
 Press and hold the but-
ton while pausing, the video is
played slowly.
1 Press the “MENU” button.
2 Select the menu item, and
press the “ENT” button to
enter.
Press the “OPTION” button
while watching a BD/DVD video,
the following screen appears.
Press the “OPTION” button
once again or select “Hide But-
tons” to turn off the option screen.
When there are two pages,
select “>” or “<” to change the
page.
BD video
DVD video
Turning on the BD/DVD
mode
Playing/pausing a disc
Operating the disc menu
Option screen

1654-8. Rear seat entertainment system operation
4
Audio/visual system
AV C H D
BDAV
Video CDDisplaying the initial setup
screen
Turning off the option screen
Displaying the top menu
screen
Displaying the pop-up menu
Rewind
Stop
Play/pause
Fast-forward
Searching for a title
A
B
C
D
E
F
G
H
I

1664-8. Rear seat entertainment system operation
Searching for a chapter
Returning to the predeter-
mined scene
Changing the audio language
Changing the subtitle lan-
guage
Changing the angle
Displaying the color key but-
tons
Displaying the 10 key pad
Displaying the secondary
video (Picture-in-picture)
Changing the secondary
audio
Displaying the menu screen
Changing the playback mode
Changing the audio channel
Searching by track
Returning to the previous
page screen (with the disc
menu displayed)
Proceeding to the next page
screen (with the disc menu
displayed)
BD video
Some BD video discs have a
pop-up navigation menu that
can be called up and be oper-
ated on the screen without inter-
rupting playback. 1
Select “Pop-up Menu”.
2 Select the menu item, and
press the “ENT” button to
enter.
BD video, DVD video,
AVCHD, BDAV
1 Select “Title”, “Chapter” or
“Search”.
2 Input the title number or
chapter number, and select
“OK”.
BD video, DVD video, BDAV
The angle can be changed for
discs that are multi-angle com-
patible when the angle mark
appears on the screen.
1 Select “Angle”.
Displaying the pop-up menu
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
6HDUFKLQJIRUDWL\
WOHRUFKDS
WHU
&KDQJLQJWKHDQJOH

1674-8. Rear seat entertainment system operation
4
Audio/visual system
2Each time “Angle” is
selected, the angle changes.
BD video, DVD video, AVCHD
The subtitle language can be
changed for discs with multiple
subtitle languages.
1 Select “Subtitle”.
2 Each time “Subtitle” is
selected, another language
available on the disc is
selected.
“Hide”: Subtitle can be hidden.
BD video
“Style”: Subtitle style can be
changed.
BD video, DVD video,
AVCHD, BDAV
The audio language can be
changed for discs with multiple
audio languages.
1 Select “Audio”.
2 Each time “Audio” is
selected, another language
available on the disc is
selected.
BDAV, Video CD
The audio channel can be
changed for discs with multiple
audio channels.
1 Each time “Main/Sub” is
selected, the mode changes
in the following order:
“Main”: Main audio channel
Changing the subtitle lan-
guage
Changing the audio lan-
guage
Changing the audio channel

1684-8. Rear seat entertainment system operation
“Sub”: Sub audio channel
“Main/Sub”: Both the main and sub
audio channels
BDAV
The playback mode can be
changed to program mode or
playlist mode. Playlist mode
cannot be selected if a playlist is
not stored on the disc.
1 Select “Playback Mode”.
2 Each time “Playback Mode”
is selected, the mode
changes in the following
order:
“Program” mode: Playback the disc
in order of program number
“Playlist” mode: P layback the disc
in order of playlist number
BD video
Picture-in-picture is a secondary
video that plays embedded in
the primary video. The second-
ary video can be played from a
disc compatible with the picture-
in-picture function. 1
Select “PinP”.
2 The secondary video is dis-
played on the screen. Each
time “PinP” is selected,
another secondary video
available on the disc is
selected.
“Hide”: Secondary video can be
hidden.
BD video
The secondary audio that for the
secondary video can be
changed.
1 Select “PinP Audio”.
2 Each time “PinP Audio” is
selected, another secondary
audio stored on the disc is
selected.
“Off”: Secondary audio can be
turned off
Changing the playback mode
Displaying the secondary
video
Changing the secondary
audio

1694-8. Rear seat entertainment system operation
4
Audio/visual system
BD video
The color key button is used for
various uses according to direc-
tions of contents.
1 Select “Color Keys”.
2 The color key buttons are
displayed on the screen.
BD video
The 10 key pad is used when
inputting numbers according to
directions of contents.
1 Select “Keypad”.
2 The 10 key pad is displayed
on the screen.
Video CD
1 Select “Select Number”.
2 Input the track number, and
select “OK”.
Video CD
If there is the next or previous
page while the disc menu is dis-
played, the page can be
switched.
1 Select “Prev. Page” or “Next
Page”.
2 Next or previous page is dis-
played.
BD video, DVD video,
AVCHD, BDAV
The initial setting can be
changed.
1 Select “Setup”.
Displaying the color key but-
tons
Displaying the 10 key pad
Searching by track
Displaying the next or previ-
ous page
Initial setup

1704-8. Rear seat entertainment system operation
2Select the settings to be
changed. After the settings
are changed, select “OK”.
Changing the initial audio
language
Changing the initial subtitle
language
Changing the initial lan-
guage of the disc menu
Setting the angle mark
Setting the DVD parental
control level
Setting the BD parental con-
trol age
Setting a quick playback
Setting a sound dynamic
range
Restores default settings
BD history data such as
bookmarks and resume point can be deleted.
 Select or to show the
next or previous page.
■Changing the initial audio
language
1 Select “Audio Language”.
2 Select the desired language.
 If you cannot find the desired
language, select “Other” and
input the desired language
code. ( P.194)
■Changing the initial subtitle
language
1 Select “Subtitle Language”.
2 Select the desired language.
 If you cannot find the desired
language, select “Other” and
input the desired language
code. ( P.194)
A
B
C
D
E
F
G
H
I
J

1714-8. Rear seat entertainment system operation
4
Audio/visual system
■Changing the initial lan-
guage of the disc menu
1 Select “Menu Language”.
2 Select the desired language.
 If you cannot find the desired
language, select “Other” and
input the desired language
code. ( P.194)
■Setting the angle mark
If the BD/DVD disc has angle
options, you can turn the angle
mark on/off.
1 Each time “Angle Mark” is
selected, “On” or “Off” can be
selected.
■Setting the DVD parental
control level
DVD video
The level of viewer restrictions
can be set.
1 Select “Parental Control
Level”. 2
Input the 4-digit personal
code and then select “OK”.
 Select 10 times to reset
the personal code in case the
code was forgotten.
3 Select a restriction level (1-
8).
■Setting the BD parental con-
trol age
BD video
The age of viewer restrictions
can be set.
1 Select “BD Parental Control
Age”.

1724-8. Rear seat entertainment system operation
2Input the 4-digit personal
code and then select “OK”.
 Select 10 times to reset
the personal code in case the
code was forgotten.
3 Input a restriction age (0-255)
and then select “OK”.
■Setting a quick playback
BD video
After inserting a BD disc you
can skip over to the first play-
back point and can immediately
playback the main story. 1
Each time “Quick Play” is
selected, “On” or “Off” can be
selected.
■Setting a sound dynamic
range
The difference between the low-
est and highest sound volumes
can be adjusted.
1 Select “Sound Dynamic
Range”.
2 Select the desired setting.
“MAX”: Maximum sound dynamic
range
“MID”: Medium sound dynamic
range
“MIN”: Minimum sound dynamic
range
