17Pictorial index
SEQUOIA_OM_USA_OM0C035UFuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 244
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 244
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 523
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 426
Tire size/inflation pressure . . . . . . . . . . . . . . . . . .
. . . . . . . . . . P. 529
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 334
Checking/rotation/tire pressure warning system . . . . . . . . . . . P. 426
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 491
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 414
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 414
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 524
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 513
Camera
*2
Headlights/parking lights/front side marker lights/
daytime running lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 227
Front turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 225
Fog lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 236
Stop/tail lights/rear side marker lights . . . . . . . . . . . . . . . . P. 227
Hill-start assist control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 322
Rear turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 225
Tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 227
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 220
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 227
Light bulbs of the exterior lights for driving
(Replacing method: P. 451, Wattages: P. 530)
*1: If equipped
*2: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”

571-1. For safe use
1
For safety and security
SEQUOIA_OM_USA_OM0C035U
Safety information for children
●It is recommended that children sit in the rear seats to avoid acci-
dental contact wit h the shift lever, wiper lever, etc.
● Use the rear door child-protector lock or the window lock switc h to
avoid children opening the door while driving or operating the
power window accidentally.
● Do not let small children operate equipment which may catch or
pinch body parts, such as the power window, hood, back door,
seats, etc.
Observe the following precautions when children are in the vehi -
cle.
Use a child restraint system app ropriate for the child, until the
child becomes large enough to properly wear the vehicle’s seat
belt.
WARNING
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by p laying with
the windows, the moon roof or other features of the vehicle. In addition, heat
build-up or extremely cold temperatures inside the vehicle can be fatal to
children.

841-3. Theft deterrent system
SEQUOIA_OM_USA_OM0C035U
Alar m
The alarm uses light and sound to give an alert when an intrusion is
detected.
The alarm is triggered in the following situations when the ala rm is
set:
● A locked door is unlocked or opened in any way other than using
the entry function, wireless remote control or mechanical key. (The
doors will lock aga in automatically.)
● The hood is opened.
● Vehicles with the glass breaka ge sensor: The side windows are
tapped or broken.
● The battery is reconnected.
Close the doors and hood, and
lock all the doors. The system will
be set automatically after 30 sec-
onds.
The indicator light changes from
being on to flashing when the sys-
tem is set.
Do one of the following to d eactivate or stop the alarms:
● Unlock the doors.
● Turn the engine switch to ACC or ON, or start the engine. (The
alarm will be deactivated or s topped after a few seconds.)
The alarm
Setting the alarm system
Deactivating or stopping the alarm

851-3. Theft deterrent system
1
For safety and security
SEQUOIA_OM_USA_OM0C035U
■System maintenance
The vehicle has a maintenance-free type alarm system.
■ Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft , make sure of
the following:
● Nobody is in the vehicle.
● The windows and moon roof are closed before the alarm is set.
● No valuables or other personal items are left in the vehicle.
■ Triggering of the alarm
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)
●A person inside the vehicle opens a door
or the hood.
● The battery is recharged or replaced
when the vehicle is locked.

2534-5. Using the driving support systems
4
Driving
SEQUOIA_OM_USA_OM0C035U■
If a warning message is displayed on the multi-information disp lay
A system may be temporarily unavailable or there may be a malfu nction in
the system.
● In the following situations, perform the actions specified in t he table. When
the normal operating conditions are detected, the message will disappear
and the system will become operational.
If the message does not disappear, contact your Toyota dealer.
SituationActions
When the area around a camera
is covered with dirt, moisture
(fogged up, covered with con-
densation, ice, etc.), or other for-
eign matter
Using the wiper and A/C function, remove
the dirt and other attached matter
( P. 342).
When the temperature around
the front camera is outside of
the operational range, such as
when the vehicle is in the sun or
in an extremely cold environ-
ment
If the front camera is hot, such as after the
vehicle had been parked in the sun, use
the air conditioning system to decrease
the temperature around the front camera.
If a sunshade was used when the vehicle
was parked, depending on its type, the
sunlight reflected from the surface of the
sunshade may cause the temperature of
the front camera to become excessively
high.
If the front camera is cold, such after the
vehicle is parked in an extremely cold
environment, use the air conditioning sys-
tem to increase the temperature around
the front camera.
The area in front of the front
camera is obstructed, such as
when the hood is open or a
sticker is attached to the part of
the windshield in front of the
front camera.
Close the hood, remove the sticker, etc. to
clear the obstruction.
When “Pre-Collision System
Unavailable” is displayedCheck whether there is attached materi-
als on the radar sensor and radar sensor
cover, and if there is, remove it.

4146-3. Do-it-yourself maintenance
SEQUOIA_OM_USA_OM0C035U
Hood
Pull the hood lock release lever.
The hood will pop up slightly.
Pull up the hood catch lever
and lift the hood.
Release the lock from the inside of the vehicle to open the hood.
1
2
WARNING
■Pre-driving check
Check that the hood is fully closed and locked.
If the hood is not locked properly, it may open while the vehic le is in motion
and cause an accident, which may result in death or serious inj ury.

5097-2. Steps to take in an emergency
SEQUOIA_OM_USA_OM0C035U
7
When trouble arises
If the vehicle batter y is discharged
If you have a set of jumper (or booster) cables and a second ve hicle
with a 12-volt battery, you can jump start your vehicle by foll owing the
steps below.
Confirm that the key is being
carried.
When connecting the jumper (or
booster) cables, depending on the
situation, the alarm may activate
and doors locked. ( P. 86)
Open the hood ( P. 414)
The following procedures may be used to start the engine if the
vehicle’s battery is discharged.
You can also call your Toyota de aler or a qualified repair shop.
1
2

5147-2. Steps to take in an emergency
SEQUOIA_OM_USA_OM0C035U
Add engine coolant if neces-
sary.
Water can be used in an emer-
gency if engine coolant is unavail-
able.
Start the engine to check that the radiator cooling fan operate and
to check for coolant leaks from the radiator or hoses.
If the fan are not operating:
Stop the engine immediately and contact your Toyota dealer.
If the fan are operating:
Have the vehicle ins pected at the nearest Toyota dealer.
5
WARNING
■When inspecting under th e hood of your vehicle
Observe the following precautions.
Failure to do so may result in serious injury such as burns.
● If steam is seen coming from under the hood, do not open the ho od until
the steam has subsided. The engine compartment may be very hot.
● Keep hands and clothing (especially a tie, a scarf or a muffler ) away from
the fans and belts.
● Do not loosen the radiator cap and the coolant reservoir cap wh ile the
engine and radiator are hot.
High temperature steam or coolant could spray out.
6
7

580Alphabetical index
SEQUOIA_OM_USA_OM0C035U
Front side marker lights.......... 227Light switch ........................... 227
Replacing light bulbs............. 457
Front turn signal lights ........... 225 Replacing light bulbs............. 457
Turn signal lever ................... 225
Fuel ........................................... 244 Capacity ................................ 523
Fuel gauge .............................. 94
Fuel pump shut off system.... 469
Information ............................ 531
Refueling............................... 244
Type ...................................... 523
Warning light ......................... 472
Fuel consumption.................... 104
Fuel filler door.......................... 246 Refueling............................... 244
Fuel pump shut off system ..... 469
Fuses ........................................ 448
Garage door opener ................ 385
Gauges ....................................... 94
Glove box ................................. 360
Grocery bag hooks .................. 372
Hands-free system (for cellular phone)
*
Head restraints ........................ 154
Headlights ................................ 227 Automatic High Beam system ......... ....................... 231
Light switch ........................... 227
Replacing light bulbs............. 457
Heaters Air conditioning
system ....... ................. 340, 348
Outside rear view mirrors...... 343
Seat heaters ......................... 352
Hill-start assist control............ 322
Hood ......................................... 414 Hooks
Cargo hooks ......................... 371
Cargo net hooks ................... 371
Grocery bag hooks ............... 372
Retaining hooks (floor mat) .... 26
Horn .......................................... 157
I/M test ...................................... 410
Identification Engine .................................. 522
Vehicle .................................. 522
Ignition switch
(engine switch) ...................... 214
Illuminated entry system ........ 358
Immobilizer system ................... 76
Indicators ................................... 91
Initialization Maintenance ......................... 406
Moon roof ............................. 173
Power back window .............. 169
Power windows..................... 166
Tire pressure warning
system .......... ...................... 428
Inside rear view mirror ............ 158
Instrument panel light
control ...................................... 96
Interior lights ........................... 355
Intuitive parking assist ........... 290 Function ................................ 290
Warning message......... 481, 483
Jack Vehicle-equipped jack .......... 492
Jack handle .............................. 495
Jam protection function Moon roof ............................. 172
Power back door................... 121
Power back window .............. 169
Power windows..................... 166
G
H
I
J

582Alphabetical index
SEQUOIA_OM_USA_OM0C035U
MirrorsInside rear view mirror .......... 158
Outside rear view mirror
defoggers ........................... 343
Outside rear view mirrors...... 161
Vanity mirrors........................ 376
Moon roof ................................. 171 Door lock linked moon roof
operation ............................ 173
Jam protection function......... 172
Operation .............................. 171
MP3 disc
*
Multi-information display .......... 98 Drive information..................... 99
Language .............................. 100
LDA (Lane Departure Alert) ................................... 268
PCS (Pre-Collision system) ........ ....................... 255
Settings ................................. 100
Warning message ................. 479
Navigation system
*
Noise from under vehicle............ 8
Odometer.................................... 94
Off-road precaution s ............... 329
Oil Differential oil ........................ 527
Engine oil ...................... 416, 524
Transfer oil ............................ 527
Opener
Back door.............................. 120
Fuel filler door ....................... 246
Hood ..................................... 414
Outer foot lights....................... 355
Outside rear view mirrors ....... 161 Adjusting and folding ............ 161
BSM (Blind Spot Monitor) ..... 296
Outside rear view mirror defoggers ................. 343 Outside temperature
display...................................... 94
Overhead console ................... 365
Overheating, Engine ............... 513
Parking brake........................... 226 Operation .............................. 226
Parking brake engaged warning buzzer/
message............................. 482
Parking lights........................... 227 Light switch ........................... 227
Replacing light bulbs ............ 457
PCS (Pre-Collision system) .... 255 Enabling/disabling
the system ......... ................. 259
Pen holder ................................ 361
Personal lights......................... 357
Power back window ................ 168 Jam protection function ........ 169
Operation .............................. 168
Power outlets ........................... 377
Power steering Fluid .............................. 422, 528
Warning light......................... 471
Power windows ....................... 165 Door lock linked window operation ............................ 166
Jam protection function ........ 166
Operation .............................. 165
Window lock switch .............. 165
Pre-Collision system (PCS) ...................................... 255 Enabling/disabling
the system ......... ................. 259
N
O
P
