traction control TOYOTA SEQUOIA 2021 Owners Manual (in English)

9
SEQUOIA_OM_USA_OM0C035UThe installation of a mobile two-way radio system in your vehic
le could affect
electronic systems such as:
● Multiport fuel injection system/sequential multiport fuel injection system
● Toyota Safety Sense P
● Dynamic radar cruise control system
● Anti-lock brake system
● SRS airbag system
● Seat belt pretensioner system
Be sure to check with your Toyota dealer for precautionary meas ures or spe-
cial instructions regarding instal lation of a mobile two-way radio system.
The vehicle is equipped with sophisticated computers that will record certain
data, such as:
• Engine speed / Electric motor speed (traction motor speed)
• Accelerator status
• Brake status
• Vehicle speed
• Operation status of the driving assist systems
• Images from the front camera (available only when certain safe ty sys-
tems are activated, which varies depending on the vehicle specifica-
tions).
The recorded data varies according to the vehicle grade level and options
with which it is equipped.
These computers do not record conversations or sounds, and only record
images outside of the vehicle in certain situations.
●Data Transmission
Your vehicle may transmit the data recorded in these computers to Toyota
without notification to you.
Installation of a mobile two-way radio system
Vehicle data recording

12
SEQUOIA_OM_USA_OM0C035UThe SRS airbag and seat belt pretensioner devices in your Toyot
a contain
explosive chemicals. If the vehicle is scrapped with the airbag s and seat belt
pretensioners left as they are, this may cause an accident such as fire. Be
sure to have the systems of the SRS airbag and seat belt preten sioner
removed and disposed of by a qualified service shop or by your Toyota dealer
before you scrap your vehicle.
Special handling may apply,
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate. These compo-
nents may include airbag, seat belt pretensioners, and wireless remote con-
trol batteries.
Scrapping of your Toyota
Perchlorate Material
WARNING
■ General precautions while driving
Driving under the influence: Never drive your vehicle when unde r the influ-
ence of alcohol or drugs that have impaired your ability to operate your vehi-
cle. Alcohol and certain drugs delay reaction time, impair judg ment and
reduce coordination, which could lead to an accident that could result in
death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistake s that other
drivers or pedestrians might make and be ready to avoid acciden ts.
Driver distraction: Always give your full attention to driving. Anything that
distracts the driver, such as adjusting controls, talking on a cellular phone or
reading can result in a collision with resulting death or serio us injury to you,
your occupants or others.
■ General precaution regar ding children’s safety
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by p laying with
the windows, the moon roof, or other features of the vehicle. In addition,
heat build-up or extremely cold temperatures inside the vehicle can be fatal
to children.

3154-5. Using the driving support systems
4
Driving
SEQUOIA_OM_USA_OM0C035U
Four-wheel drive system
“2WD” (high speed position, two-wheel drive)
Use this for normal driving on dry hard-surfaced roads. This position gives
greater economy, quietest ride and least wear.
“4H” (high speed position, four-wheel drive)
Use this for driving only on tracks that permit the tires slide , like off-road,
icy or snow-covered roads. This position provides greater tract ion than
two-wheel drive.
The “4HI” indicator will come on.
“4L” (low speed position, four-wheel drive)
Use this for maximum power and traction. Use “4L” for climbing or
descending steep hills, off-road driving, and hard pulling in s and, mud or
deep snow.
The “4LO” indicator will come on.
Center differentia l lock switch (P. 316)
Indicators
Use the front-wheel drive control lever or switch to select the fol-
lowing transfer modes:

3204-5. Using the driving support systems
SEQUOIA_OM_USA_OM0C035U
AUTO LSD system
The system can be used on 2WD models and in 2WD mode on 4WD
models.
The system is activated when driving at a speed under 62 mph
(100 km/h).
The AUTO LSD system will be activated with the following two pr oce-
dures.
■TRAC off mode
Press briefly to turn on the
system. The “AUTO LSD” indi-
cator will come on.
To turn off the system, press
again.
■
AUTO LSD mode
Stop the vehicle completely,
and press for more than 3
seconds. The “AUTO LSD” and
VSC off indicators will come on.
To turn off the system, press
again.
The AUTO LSD system aids trac tion by using the traction con-
trol system to control engine performance and braking when
one of the drive wheels begins to spin.
The system should be used only when one of the drive wheels
spinning occurs in a ditch or rough surface.
System operation

3224-5. Using the driving support systems
SEQUOIA_OM_USA_OM0C035U
Driving assist systems
◆ABS (Anti-lock Brake System)
Helps to prevent wheel lock when the brakes are applied suddenl y,
or if the brakes are applied while driving on a slippery road surface
◆Brake assist
Generates an increased level of braking force after the brake p edal
is depressed when the system de tects a panic stop situation
◆VSC (Vehicle Stability Control)
Helps the driver to control skidding when swerving suddenly or
turning on slippery road surfaces
◆Trailer Sway Control
Helps the driver to control trailer sway by selectively applying brake
pressure for individual wheels and reducing driving torque when
trailer sway is detected.
◆TRAC (Traction Control)
Helps to maintain drive power and prevent the drive wheels from
spinning when starting the vehicl e or accelerating on slippery roads
◆Hill-start assist control
Helps to reduce the backward movement of the vehicle when start -
ing on an uphill
To keep driving safety and perf ormance, the following systems
operate automatically in respon se to various driving situations.
Be aware, however, that these systems are supplementary and
should not be relied upon too heav ily when operating the vehi-
cle.

5167-2. Steps to take in an emergency
SEQUOIA_OM_USA_OM0C035U
If the vehicle becomes stuck
Stop the engine. Set the parking brake and shift the shift lever to P.
Remove the mud, snow or sand from around the stuck tire.
Place wood, stones or some other material under the tires to help
provide traction under the tires.
Restart the engine.
Lock the center differential. ( P. 316)
Shift the shift lever to D or R position and carefully apply th e accel-
erator to free the vehicle.
■ When it is difficult to free the vehicle
Turn off TRAC or VSC/Trailer Sway Control if these functions ar e hampering
your attempts to free the vehicle. ( P. 324)
Carry out the following procedures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
Press to turn off TRAC or VSC/Trailer
Sway Control.
1
2
3
4
5
6

5388-1. Specifications
SEQUOIA_OM_USA_OM0C035U
This information has been prepared in accordance with regulations
issued by the National Highway Tr affic Safety Administration of the
U.S. Department of Transportation.
It provides the purchasers and/or prospective purchasers of Toyota
vehicles with info rmation on uniform ti re quality grading.
Your Toyota dealer will help answer any questions you may have as
you read this information.
■DOT quality grades
All passenger vehicle tires must conform to Federal Safety Requ ire-
ments in addition to these grades. Quality grades can be found
where applicable on the tire sidewall between tread shoulder an d
maximum section width.
For example: Treadwear 200 Traction AA Temperature A
■Treadwear
The treadwear grade is a comparative rating based on the wear
rate of the tire when tested under controlled conditions on a s peci-
fied government t est course.
For example, a tire graded 150 would wear one and a half (1 - 1 /2)
times as well on the government course as a tire graded 100.
The relative performance of tires depends upon the actual condi -
tions of their use. Performance ma y differ significantly from the norm
due to variations in driving habits, service practices and diff erences
in road characteristics and climate.
■Traction AA, A, B, C
The traction grades, from highest to lowest, are AA, A, B and C ,
and they represent the tire’s ability to stop on wet pavement a s
measured under controlled conditions on specified government te st
surfaces of asphalt and concrete.
A tire marked C may have p oor traction performance.
Warning: The traction grade assigned to this tire is based on b raking
(straight ahead) traction tests and does not include cornering (turn-
ing) traction.
Uniform Tire Quality Grading

586Alphabetical index
SEQUOIA_OM_USA_OM0C035U
Tire pressure warning system .................................... 427
Function ................................ 427
Installing tire pressure warning valves and
transmitters......................... 427
Registering ID codes ............ 429
Warning light ......................... 472
Tires .......................................... 426 Chains................................... 336
Checking ............................... 426
If you have a flat tire ............. 491
Inflation pressure .................. 529
Information ............................ 534
Replacing .............................. 491
Rotating tires......................... 427
Size ....................................... 529
Snow tires ............................. 337
Spare tire .............................. 491
Tire pressure warning system ......... ....................... 427
Warning light ......................... 472
Tissue pocket .......................... 361
Tools ......................................... 492
Top tether strap ......................... 70
Total load capacity .......... 193, 521
Towing
Dinghy towing ....................... 213
Emergency towing ................ 467
Trailer towing ........................ 194
Toyota Safety Sense P ............ 247 Automatic High Beam ........... 231
Dynamic radar cruise control................................. 276
LDA (Lane Departure Alert) ................................... 268
PCS (Pre-Collision system) ........ ....................... 255 TRAC (Traction Control) ......... 322
Trailer Sway Control ............... 322
Transmission ........................... 220
Automatic transmission ........ 220
If the shift lever cannot be shifted from P ..................... 223
S mode ................................. 221
Trip information ....................... 104
Trip meters ................................. 94
Turn signal lights .................... 225 Replacing light bulbs .... 452, 457
Turn signal lever ................... 225
Wattage ................................ 530
USB charging ports................. 380
USB port
*
Valet key ................................... 108
Vanity lights ............................. 376 Wattage ................................ 530
Vanity mirrors .......................... 376
Vehicle data recording ................ 9
Vehicle identification number ................................... 522
Vehicle Stability Control (VSC) ...................................... 322
Ventilators (seat ventilators) ................... 352
VSC
(Vehicle Stability Control) .... 322
U
V
