display TOYOTA SEQUOIA 2022 Owners Manual

TABLE OF CONTENTS2
SEQUOIA_OM_USA_OM0C047UFor your information....................... 8
Reading this manual .................... 14
How to search .............................. 15
Pictorial index .............................. 16
1-1. For safe use
Before driving ...................... 26
For safe driving ................... 28
Seat belts ............................ 30
SRS airbags ........................ 40
Front passenger occupant classification system ......... 51
Safety information for children ............................. 57
Child restraint systems ........ 58
Installing child restraints ...... 62
Exhaust gas precautions ..... 75
1-2. Emergency assistance Safety Connect.................... 76
1-3. Theft deterrent system Engine immobilizer system............................... 82
Alarm ................................... 84
2. Instrument cluster Warning lights and indicators........................... 88
Gauges and meters............. 94
Multi-information display ..... 98
Fuel consumption information ...................... 104 3-1. Key information
Keys................................... 108
3-2. Opening, closing and locking the doors
Side doors ......................... 113
Back door .......................... 118
Smart key system .............. 128
3-3. Adjusting the seats Front seats......................... 136
Rear seats ......................... 138
Driving position memory .... 149
Head restraints .................. 154
3-4. Adjusting the steering wheel and mirrors
Steering wheel ................... 156
Inside rear view mirror ....... 158
Outside rear view mirrors ............................. 161
3-5. Opening, closing the windows and
moon roof
Power windows.................. 165
Power back window ........... 168
Moon roof .......................... 171
1For safety and security
2Instrument cluster
3Operation of
each component

5
1
8 7
6
5
4
3
2
9
SEQUOIA_OM_USA_OM0C047U6-1. Maintenance and care
Cleaning and protecting the vehicle exterior .......... 400
Cleaning and protecting the vehicle interior ........... 404
6-2. Maintenance Maintenance requirements ................... 407
General maintenance ........ 409
Emission inspection and maintenance (I/M)
programs ......................... 412
6-3. Do-it-yourself maintenance
Do-it-yourself service precautions ..................... 413
Hood.................................. 416
Engine compartment ......... 417
Tires .................................. 428
Tire inflation pressure........ 440
Wheels .............................. 443
Air conditioning filter .......... 446
Electronic key battery ........ 448
Checking and replacing fuses ............................... 450
Light bulbs ......................... 453 7-1. Essential information
Emergency flashers ........... 462
If your vehicle has to be stopped in an
emergency....................... 463
If the vehicle is submerged or water on
the road is rising .............. 465
7-2. Steps to take in an emergency
If your vehicle needs to be towed .......................... 466
If you think something is wrong............................... 470
Fuel pump shut off system ............................. 471
If a warning light turns on or a warning buzzer
sounds ............................. 472
If a warning message is displayed ......................... 481
If you have a flat tire .......... 493
If the engine will not start ................................. 507
If the electronic key does not operate properly ........ 509
If the vehicle battery is discharged ....................... 511
If your vehicle overheats.... 515
If the vehicle becomes stuck ................................ 518
6Maintenance and care7When trouble arises

19Pictorial index
SEQUOIA_OM_USA_OM0C047UMulti-information display . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 98
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 98
When the warning messages are displayed . . . . . . . . . . . . . . P. 481
Parking brake pedal. . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . P. 226
Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 226
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 337
Warning buzzer/message . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 484
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 225
Headlight switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 227
Headlights/parking lights/side marker lights/tail lights/
daytime running lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 227
Fog lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 236
Windshield wipers and washer switch . . . . . . . . . . . . . . . . P. 238
Rear window wiper and washer switch . . . . . . . . . . . . . . . . P. 241
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 238, 241
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 427
Warning message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 485
Emergency flasher switch . . . . . . . . . . . . . . . . . . . . . . . . . . P. 462
Hood lock release lever. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 416
Tilt and telescopic steering lock release lever
*1 . . . . . . . . P. 156
Tilt and telescopic steering control switch
*1 . . . . . . . . . . . P. 156
Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 156
Driving position memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 149
Front air conditioning system . . . . . . . . . . . . . . . . . . . . . . . P. 342
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 342
Rear window defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 345
Multimedia system
*2
*1: If equipped
*2: Refer to “NAVIGATION AND MULT IMEDIA SYSTEM OWNER’S MANUAL”.

621-1. For safe use
SEQUOIA_OM_USA_OM0C047U
Installing child restraints
Child restraint LATCH anchors
LATCH anchors are provided for all of the second seats. (Buttons display-
ing the location of the anchors are attached to the seats.)
Seat belts equipped with a child
restraint locking mechanism
(ALR/ELR belts except driver’s
seat belt) ( P. 34)
Follow the child restraint system manufacturer’s instructions.
Firmly secure child restraints to the seats using the LATCH
(Lower Anchors and Tethers for Ch ildren) anchors or a seat belt.
Attach the top tether strap when installing a child restraint.
The lap/shoulder belt can be used if your child restraint syste m
is not compatible wi th the LATCH system.
Second seat (separated type)Second seat (bench type)

87
Instrument cluster2
SEQUOIA_OM_USA_OM0C047U2. Instrument cluster
Warning lights and indicators .......................... 88
Gauges and meters ............ 94
Multi-information display ..... 98
Fuel consumption information ...................... 104

902. Instrument cluster
SEQUOIA_OM_USA_OM0C047U
*1: These lights turn on when the engine switch is turned to ON to indicate thata system check is being performed. They will turn off after the engine is
started, or after a few seconds. There may be a malfunction in a system if
the lights do not come on, or do not turn off. Have the vehicle inspected by
your Toyota dealer.
*2: The light illuminates on the multi-information display.
*3: The light comes on to indicate a malfunction.
Low fuel level warning
light ( P. 474)*1
Tire pressure warning
light (P. 474)
*1
Seat belt reminder light
(P. 474)*1
Master warning light
(P. 474)

922. Instrument cluster
SEQUOIA_OM_USA_OM0C047U
*1: These lights turn on when the engine switch is turned to ON to indicate thata system check is being performed. They will turn off after the engine is
started, or after a few seconds. There may be a malfunction in a system if
the lights do not come on, or do not turn off. Have the vehicle inspected by
your Toyota dealer.
*2: This light illuminates on the multi-information display.
*3: The light flashes to indicate that the system is operating.
*4: In order to confirm operation, the BSM outside rear view mirro r indicators
illuminate in the following situations:
• When the engine switch is turned to ON, the BSM function is en abled on
the screen of the multi-information display.
• When the BSM function is enabled on the screen of the multi-infor- mation display, the engine switch is turned to ON.
If the system is functioning correctly, the BSM outside rear vi ew mirror
indicators will turn off after a few seconds.
If the BSM outside rear view mirror indicators do not illuminat e or do not
turn off, there may be a malfunction in the system.
If this occurs, have the vehicle inspected by your Toyota deale r.
*5: This light illuminates on the center panel.
*6: This light turns on when the system is off.
(if equipped)
High speed four-wheel
drive indicator (P. 3 1 7 )
*1, 5
“AIR BAG ON/OFF” indi-
cators (P. 51)
(if equipped)
Low speed four-wheel
drive indicator ( P. 3 1 7 )
(if equipped)
“TOW/HAUL” indicator
(P. 222)
(if equipped)
Center differential lock
indicator ( P. 317)*2Low outside tempera-
ture indicator ( P. 94)
*1
(if equipped)
“AUTO LSD” indicator
(P. 322, 325)

942. Instrument cluster
SEQUOIA_OM_USA_OM0C047U
Gauges and meters
Tachometer
Displays the engine speed in revolutions per minute
Engine oil pressure gauge
Displays the engine oil pressure
Outside temperature display
Displays the outside temperature within the range of -40 °F (-40 °C) to
122 °F (50 °C). Low outside temperature indicator comes on when the
ambient temperature is 37 ° F (3 °C) or lower.
Multi-information display
Presents the driver with a variety of vehicle data ( P. 98)
Displays warning messages in case of a malfunction ( P. 481)
Vo l t m e t e r
Displays the charge state
Speedometer
Displays the vehicle speed
Odometer/Trip meter switching and trip meter resetting button
P. 9 5
Fuel gauge
Displays the quantity of fuel remaining in the tank
The displayed content may differ depending on the type of
meter.

952. Instrument cluster
2
Instrument cluster
SEQUOIA_OM_USA_OM0C047U
Odometer and trip meter display
P. 9 5
Shift position and shift range display
Displays the selected shift position or selected shift range ( P. 220)
Engine coolant temperature gauge
Displays the engine coolant temperature
Instrument panel light control button (P. 9 6 )
Pressing the button changes the
display change button display as
follows.
■Odometer
Displays the total distance the vehicle has been driven.
■Tr i p m e t e r A*/trip meter B*
Displays the distance the vehicl e has been driven since the met er
was last reset. Trip meters A and B can be used to record and d is-
play different distances independently.
*: Press and hold the display change button to reset.
Changing the odometer/t rip meter display

962. Instrument cluster
SEQUOIA_OM_USA_OM0C047U
The brightness of the instrument panel lights can be adjusted.
Pressing the button will adjust
brightness of the instrument panel
light.
Short press: 1 step change of
brightness level.
Long press: continues change of
brightness level until released.
■ The meters and display illuminate when
The engine switch is in ON.
■ Instrument panel bri ghtness adjustment
When the tail lights are turned on, the display’s brightness will be reduced
slightly unless the meter brightness level adjustment is set to the brightest
setting.
■ Outside temperature display
●In the following situations, the correct outside temperature ma y not be dis-
played, or the display may take longer than normal to change.
• When stopped, or driving at low speeds (less than 12 mph [20 k m/h])
• When the outside temperature has changed suddenly (at the entr ance/
exit of a garage, tunnel, etc.)
● When “--” or “E” is displayed, the system may be malfunctioning. Take your
vehicle to your Toyota dealer.
■ Liquid crystal display
Small spots or light spots may appear on the display. This phen omenon is
characteristic of liquid crystal displays, and there is no prob lem continuing to
use the display.
Instrument panel light control
