odometer TOYOTA SEQUOIA 2022 Owners Manual

942. Instrument cluster
SEQUOIA_OM_USA_OM0C047U
Gauges and meters
Tachometer
Displays the engine speed in revolutions per minute
Engine oil pressure gauge
Displays the engine oil pressure
Outside temperature display
Displays the outside temperature within the range of -40 °F (-40 °C) to
122 °F (50 °C). Low outside temperature indicator comes on when the
ambient temperature is 37 ° F (3 °C) or lower.
Multi-information display
Presents the driver with a variety of vehicle data ( P. 98)
Displays warning messages in case of a malfunction ( P. 481)
Vo l t m e t e r
Displays the charge state
Speedometer
Displays the vehicle speed
Odometer/Trip meter switching and trip meter resetting button
P. 9 5
Fuel gauge
Displays the quantity of fuel remaining in the tank
The displayed content may differ depending on the type of
meter.

952. Instrument cluster
2
Instrument cluster
SEQUOIA_OM_USA_OM0C047U
Odometer and trip meter display
P. 9 5
Shift position and shift range display
Displays the selected shift position or selected shift range ( P. 220)
Engine coolant temperature gauge
Displays the engine coolant temperature
Instrument panel light control button (P. 9 6 )
Pressing the button changes the
display change button display as
follows.
■Odometer
Displays the total distance the vehicle has been driven.
■Tr i p m e t e r A*/trip meter B*
Displays the distance the vehicl e has been driven since the met er
was last reset. Trip meters A and B can be used to record and d is-
play different distances independently.
*: Press and hold the display change button to reset.
Changing the odometer/t rip meter display

584Alphabetical index
SEQUOIA_OM_USA_OM0C047U
LightsFog light switch ..................... 236
Front Interior light.................. 359
Headlight switch.................... 227
Illuminated entry system ....... 360
Interior lights list .................... 357
Personal lights ...................... 359
Rear interior light .................. 359
Replacing light bulbs............. 453
Turn signal lever ................... 225
Vanity lights .......................... 378
Wattage ................................ 532
Load capacity........................... 193
Lock steering column ................................... 156
Luggage compartment features .................................. 373
Maintenance Do-it-yourself maintenance ... 413
General maintenance ........... 409
Maintenance data ................. 522
Maintenance requirements ... 407
Reset the maintenance data .................................... 408
Malfunction indicator lamp ..... 472
Master warning light........ 474, 481
Meter ........................................... 94 Indicators ................................ 91
Instrument panel light control................................... 96
Meters ..................................... 94
Multi-information display ......... 98
Warning lights ......................... 89 Mirrors
Inside rear view mirror .......... 158
Outside rear view mirror
defoggers ........................... 345
Outside rear view mirrors ..... 161
Vanity mirrors ....................... 378
Moon roof ................................. 171 Door lock linked moon roof
operation ............................ 173
Jam protection function ........ 172
Operation .............................. 171
MP3 disc
*
Multi-information display.......... 98 Drive information .................... 99
Language.............................. 100
LDA (Lane Departure Alert)................................... 268
PCS (Pre-Collision system)......... ...................... 255
Settings................................. 100
Warning message................. 481
Navigation system
*
Noise from under vehicle ........... 8
Odometer ................................... 94
Off-road precaution s ............... 331
Oil Differential oil ........................ 529
Engine oil ...................... 418, 526
Transfer oil............................ 529
Opener
Back door ............................. 120
Fuel filler door ....................... 246
Hood ..................................... 416
M
N
O
