lane assist TOYOTA SEQUOIA 2022 Owners Manual

3
1
8 7
6
5
4
3
2
9
SEQUOIA_OM_USA_OM0C047U4-1. Before driving
Driving the vehicle ............. 176
Cargo and luggage............ 187
Vehicle load limits ............. 193
Trailer towing..................... 194
Dinghy towing.................... 213
4-2. Driving procedures Engine (ignition) switch ..... 214
Automatic transmission ..... 220
Turn signal lever................ 225
Parking brake .................... 226
4-3. Operating the lights and wipers
Headlight switch ................ 227
Automatic High Beam ....... 231
Fog light switch ................. 236
Windshield wipers and washer ............................ 238
Rear window wiper and washer ............................ 241
4-4. Refueling Opening the fuel tank cap .................................. 244 4-5. Using the driving
support systems
Toyota Safety Sense P ...... 247
PCS (Pre-Collision System)..... 255
LDA (Lane Departure Alert)..... 268
Dynamic radar cruise control ............................. 276
Intuitive parking assist ....... 290
BSM (Blind Spot Monitor)......... 297
• BSM function ................. 302
• RCTA function ............... 305
Electronically modulated air suspension ................. 311
AVS (Adaptive Variable Suspension System) ....... 316
Four-wheel drive system ............................. 317
AUTO LSD system ............ 322
Driving assist systems ....... 324
4-6. Driving tips Off-road precautions .......... 331
Winter driving tips .............. 336
4Driving

175
Driving4
SEQUOIA_OM_USA_OM0C047U4-1. Before driving
Driving the vehicle ............. 176
Cargo and luggage ........... 187
Vehicle load limits ............. 193
Trailer towing..................... 194
Dinghy towing ................... 213
4-2. Driving procedures Engine (ignition) switch ..... 214
Automatic transmission ..... 220
Turn signal lever................ 225
Parking brake .................... 226
4-3. Operating the lights and wipers
Headlight switch ................ 227
Automatic High Beam ....... 231
Fog light switch ................. 236
Windshield wipers and washer ............................ 238
Rear window wiper and washer ............................ 241 4-4. Refueling
Opening the fuel tank cap .................................. 244
4-5. Using the driving support systems
Toyota Safety Sense P ..... 247
PCS (Pre-Collision System) .... 255
LDA (Lane Departure Alert) .... 268
Dynamic radar cruise control .................. 276
Intuitive parking assist....... 290
BSM (Blind Spot Monitor) ........ 297
• BSM function ................ 302
• RCTA function .............. 305
Electronically modulated air suspension ................. 311
AVS (Adaptive Variable Suspension System) ....... 316
Four-wheel drive system ............................ 317
AUTO LSD system............ 322
Driving assist systems ...... 324
4-6. Driving tips Off-road precautions ......... 331
Winter driving tips ............. 336

2474-5. Using the driving support systems
4
Driving
SEQUOIA_OM_USA_OM0C047U
Toyota Safety Sense P
◆PCS (Pre-Collision System)
P. 2 5 5
◆LDA (Lane Departure Alert)
P. 2 6 8
◆Automatic High Beam
P. 2 3 1
◆Dynamic radar cruise control
P. 2 7 6
The Toyota Safety Sense P consists of the following drive assis t
systems and contributes to a safe and comfortable driving expe-
rience:
Driving assist system
WARNING
■ Toyota Safety Sense P
The Toyota Safety Sense P is designed to operate under the assumption
that the driver will drive safely, and is designed to help reduce the impact to
the occupants and the vehicle in the case of a collision or assist the driver in
normal driving conditions.
As there is a limit to the degree of recognition accuracy and control perfor-
mance that this system can provide, do not overly rely on this system. The
driver is always responsible for paying attention to the vehicl e’s surround-
ings and driving safely.

2724-5. Using the driving support systems
SEQUOIA_OM_USA_OM0C047U
LDA indicator
The illumination condition of the
indicator informs the driver of the
system operation status.
Illuminated in green:
LDA system is operating.
Flashing in yellow:
Lane departure alert function is
operating.
Lane departure alert function
display
Displayed when the multi-informa-
tion display is switched to the driv-
ing assist system information
screen.
Indications on multi-information display
Inside of displayed white lines
is whiteInside of displayed white lines
is black
Indicates that the system is recog-
nizing white (yellow) lines. When
the vehicle departs from its lane,
the white line displayed on the
side the vehicle departs from
flashes orange. Indicates that the system is not
able to recognize white (yellow)
lines or is tempo
rarily canceled.

2974-5. Using the driving support systems
4
Driving
SEQUOIA_OM_USA_OM0C047U
BSM (Blind Spot Monitor)
The Blind Spot Monitor is a system that has 2 functions;
● The BSM (Blind Spot Monitor) function
Assists the driver in making t he decision when changing lanes
● The RCTA (Rear Cross Tra ffic Alert) function
Assists the driver when backing up
These functions use same sensors.
Summary of the Blind Spot Monitor

3294-5. Using the driving support systems
4
Driving
SEQUOIA_OM_USA_OM0C047U
WARNING
■The ABS does not operate effectively when
● The limits of tire gripping performance have been exceeded (such as
excessively worn tires on a snow covered road).
● The vehicle hydroplanes while driving at high speed on wet or s lick road.
■ Stopping distance when the ABS is operating may exceed that of nor-
mal conditions
The ABS is not designed to shorten the vehicle’s stopping distance. Always
maintain a safe distance from the vehicle in front of you, especially in the
following situations:
● When driving on dirt, gravel or snow-covered roads
● When driving with tire chains
● When driving over bumps in the road
● When driving over roads with potholes or uneven roads
■ When the TRAC/VSC/Trailer Sway Control is activated
The slip indicator light flashes. Always drive carefully. Reckless driving may
cause an accident. Exercise particular care when the indicator light flashes.
■ TRAC/VSC may not operate effectively when
Directional control and power may not be achievable while driving on slip-
pery road surfaces, even if the TRAC/VSC system is operating.
Drive the vehicle carefully in conditions where stability and p ower may be
lost.
■ Hill-start assist control does not operate effectively when
● Do not overly rely on hill-start assist control. Hill-start ass ist control may
not operate effectively on steep inclines and roads covered wit h ice.
● Unlike the parking brake, hill-start assist control is not inte nded to hold the
vehicle stationary for an extended period of time. Do not attempt to use
hill-start assist control to hold the vehicle on an incline, as doing so may
lead to an accident.

4737-2. Steps to take in an emergency
7
When trouble arises
SEQUOIA_OM_USA_OM0C047U
(U.S.A.)
(Canada)
ABS warning light Indicates a malfunction in:
• The ABS; or
• The brake assist system
 Have the vehicle inspected by your Toyota dealer
immediately.
Power steering warning light
Indicates a malfunction in the power steering system
 Have the vehicle inspected by your Toyota dealer
immediately.
Slip indicator
Indicates a malfunction in:
• The VSC system;
• Trailer Sway Control system;
• The TRAC system;
• The AUTO LSD system; or
• The hill-start assist control system
The light will flash when the VSC, Trailer Sway Control
or TRAC system is operating.
 Have the vehicle inspected by your Toyota dealer
immediately.
PCS warning light
When a buzzer sounds simultaneously:
Indicates a malfunction has occurred in the PCS (Pre-
Collision System).
 Have the vehicle inspected by your Toyota dealer
immediately.
When a buzzer does not sound:
The PCS (Pre-Collision System) has become tempo-
rarily unavailable, corrective action may be necessary.
 Follow the instructions displayed on the multi-
information display. ( P. 253, 481)
If the PCS (Pre-Collision System) or VSC (Vehicle Sta-
bility Control) system is disabled, the PCS warning
light will illuminate.
 P. 267
(Yellow)
LDA (Lane Departur e Alert) indicator*1
The indicator comes on and a warning message is dis-
played to indicate that the LDA (Lane Departure Alert)
system is not available temporarily or has detected a
malfunction.
 P. 481
Warning lightWarning light/Details/Actions

5057-2. Steps to take in an emergency
7
When trouble arises
SEQUOIA_OM_USA_OM0C047U
WARNING
■When using the temporary spare tire
●Remember that your temporary spare tire is specifically designed for
use with your vehicle. Do not use your temporary spare tire on another
vehicle.
●Do not use two temporary sp are tires simultaneously.
●Replace the temporary spare tire with a standard tire as soon a s possi-
ble.
●Avoid sudden acceleration, deceleration and braking, as well as sharp
cornering.
■Speed limit when using th e temporary spare tire
Do not drive at speeds in excess of 50 mph (80 km/h) when a temporary
spare tire is installed on the vehicle.
The temporary spare tire is not designed for driving at high sp eeds. Fail-
ing to observe this precaution may lead to an accident causing death or
serious injury.
■When the temporary spare tire is attached
The vehicle speed may not be co rrectly detected, and the following sys-
tems may not operate correctly:
Also, not only can the following system not be utilized fully, it may actu-
ally negatively effect the drive-train components:
• 4WD system (if equipped)
■After using the tools and jack
Before driving, make sure all t he tools and jack are securely i n place in
their storage location to reduce the possibility of personal in jury during a
collision or sudden braking.
• ABS & Brake assist
• VSC
• TRAC
• AUTO LSD
• Automatic High Beam
• PCS (Pre-Collision System)
• LDA (Lane Departure Alert)
• Dynamic radar cruise control
• BSM (Blind Spot Monitor)
• Intuitive parking assist-sensor
(if equipped)
• Rear view monitor system
• Navigation system (if equipped)

583Alphabetical index
SEQUOIA_OM_USA_OM0C047U
HooksCargo hooks ......................... 373
Cargo net hooks ................... 373
Grocery bag hooks ............... 374
Retaining hooks (floor mat)..... 26
Horn .......................................... 157
I/M test ...................................... 412
Identification Engine................................... 524
Vehicle .................................. 524
Ignition switch
(engine switch) ...................... 214
Illuminated entry system ........ 360
Immobilizer system ................... 76
Indicators ................................... 91
Initialization Maintenance ......................... 408
Moon roof.............................. 173
Power back window .............. 169
Power windows ..................... 166
Tire pressure warning
system ......... ....................... 430
Inside rear view mirror ............ 158
Instrument panel light
control ...................................... 96
Interior lights............................ 357
Intuitive parking assist............ 290 Function ................................ 290
Warning message ......... 483, 485 Jack
Vehicle-equipped jack .......... 494
Jack handle .............................. 497
Jam protection function Moon roof ............................. 172
Power back door................... 121
Power back window .............. 169
Power windows..................... 166
Keyless entry ........................... 108 Wireless remote control ........ 108
Keys .......................................... 108 Engine switch ....................... 214
Key number plate ................. 108
Keyless entry ........................ 108
Replacing the battery............ 448
Wireless remote control key...................................... 108
Knee airbags .............................. 40
Lane Departure Alert (LDA) .... 268
Language ................................. 100
LATCH anchors ......................... 64
LDA (Lane Departure Alert) .... 268
Lever Auxiliary catch lever.............. 416
Hood lock release lever ........ 416
Shift lever.............................. 220
Turn signal lever ................... 225
Wiper lever ................... 238, 241
License plate lights ................. 227
Light switch ........................... 227
Replacing light bulbs ............ 458
Wattage ................................ 532
Light bulbs Replacing.............................. 453
Wattage ................................ 532
I
J
K
L
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

586Alphabetical index
SEQUOIA_OM_USA_OM0C047U
Refueling .................................. 244Capacity ................................ 525
Fuel types ............................. 525
Opening the fuel tank cap ..... 246
Replacing
Fuses .................................... 450
Key battery............................ 448
Light bulbs ............................ 453
Tires ...................................... 493
Reporting safety defects for Canadian owners............. 563
Reporting safety defects for U.S. owners ...................... 562
Resetting the message
indicating maintenance
is required .............................. 408
Roof luggage carrier ............... 187
Safety Connect .......................... 76
Seat belt reminder light........... 474
Seat belts.................................... 30
Adjusting the seat belt ............ 33
Automatic Locking Retractor (ALR) .................... 34
Child restra int system
installation ............................ 62
Cleaning and maintaining the seat belt ........................ 405
Comfort guide ......................... 35
Emergency Locking Retractor (ELR) .................... 34
How to wear your seat belt ..... 30
How your child should wear the seat belt .......................... 34
Pregnant women, proper seat belt use ......................... 36
Reminder light and buzzer .... 474
Seat belt extender................... 34
Seat belt pretensioners ........... 33
SRS warning light ................. 472 Seat heaters ............................. 354
Seat position memory ............. 149
Seat ventilators........................ 354
Seating capacity ...................... 193
Seats ................................. 136, 138
Adjustment.................... 136, 138
Adjustment precautions................. 137, 147
Child seats/child restraint system installation . ............... 62
Cleaning ............................... 404
Climate control seat .............. 354
Driving position memory ....... 149
Head restraints ..................... 154
Properly sitting in the seat ...... 28
Seat heaters ......................... 354
Seat position memory ........... 149
Seat ventilators ..................... 354
Sensor Automatic headlight
system .......... ...................... 229
Automatic High Beam system .......... ...................... 231
Inside rear view mirror .......... 160
Intuitive parking assist .......... 290
LDA (Lane Departure Alert)................................... 268
PCS (Pre-Collision system)......... ...................... 248
S
