1203-2. Opening, closing and locking the doors
Owners Manual_USA_M0C043_en
1Opening a door: The appro-
priate board deploys.
2 Closing a door: The appropri-
ate board stows.
■Jam protection function
If a board contacts an obstacle
when deploying, it will stow. If an
obstacle gets caught between a
board and the vehicle when stow-
ing, the board will deploy.
If an obstacle is de tected 3 times in
a row during power running board
operation, the boar d will stop at the
position it contacts the obstacle.
When the side door on the same
side as the board is opened and
closed, or switch is operated once
the obstacle is cl eared, the board
will attempt to stow o r deploy again.
■Automatic stowing function
The boards will be automatically
stowed, for safety, under the follow-
ing conditions:
WARNING
●Always check that the power
steps switch is turned off when
cleaning the boards, before
jacking up or placing any object
under the vehicle, or if boards
are not operating correctly.
●Do not allow children to operate
the power running boards.
Operating the power running
boards so that the boards con-
tacts someone can cause seri-
ous injury, and in some
instances, even death.
■Jam protection function
Observe the following precau-
tions.
Failure to do so m ay cause seri-
ous injury.
Do not place any body part
between the boards and vehicle.
The jam protection function may
not work depending on the shape
of the object that is caught.
Side door linked opera-
tion

3654-5. Using the driving support systems
Owners Manual_USA_M0C043_en
4
Driving
be displayed, have your vehicle
inspected by your Toyota dealer as
soon as possible.
■When the indicator turns on
Indicates a malfunction in the air
suspension system.
Have the vehicle inspected by your
Toyota dealer immediately. ( P.89,
516)
WARNING
■The electronically modulated
air suspension must be
turned off in the following cir-
cumstances:
Otherwise, the automatic leveling
function may cause the vehicle’s
height to change, and you may
catch part of yo ur body in the
vehicle, resulting in an unex-
pected accident or injury:
●When driving through water
such as shallow streams (Put
the vehicle height in “HI” mode
and turn off the electronically
modulated air suspension. Drive
at 18 mph [30 km/h] or slower.)
●When jacking up the vehicle,
installing tire chains or tying the
vehicle with chains/wires for
transportation via flat bed truck
(Turn the system to the manual
mode and stop the hybrid sys-
tem.)
●When the vehicle must be
towed (Put the vehicle height in
“N” mode and turn the system to
the manual mode.)
●When the vehicle gets stuck
(Turn the system to the manual
mode.)
●When disconnecting a trailer
(Put the vehicle height in “N”
mode and turn the system to the
manual mode.)
■Selecting the correct height
mode
Observe the following precautions
to prevent accidents or injury.
Failure to do so may cause dam-
age to parts of the vehicle, as well
as dangerous handling character-
istics, which may lead to fatal or
injury accidents.
●Before you lower the vehicle’s
height, check under the vehicle
to make sure that no one is
there.
●“HI” mode should only be used
when driving on rough roads, for
example when driving off-road.
Because the vehicle’s center of
gravity will become higher when
in the mode, the vehicle may
become unstable when turning
abruptly, resulting in an acci-
dent.
●Do not select “HI” mode when
you load cargo on the roof lug-
gage carrier.
Because the vehicle’s center of
gravity will become higher when
in the mode, the vehicle may
become unstable when turning
abruptly, resulting in an acci-
dent.
NOTICE
■Be careful in any place where
overhead space is limited.
When changing to a higher mode
or after unloading, the vehicle
height will rise. This may cause
damage to the vehicle.
■Do not select “LO” mode
when driving on bumpy
roads.
If the underbody of the vehicle
touches a rugged road surface,
the vehicle ma y be damaged.
