TOYOTA SIENNA 2001 Owners Manual
Manufacturer: TOYOTA, Model Year: 2001, Model line: SIENNA, Model: TOYOTA SIENNA 2001Pages: 330, PDF Size: 8.53 MB
Page 201 of 330

01 SIENNA_U (L/O0008)
1972001 MY SIENNA (OM45406U)
Side vents
Driver’s side
Passenger’s side
If air flow control is not satisfactory, check
the side vents. The side vents may be
opened or closed as shown.
ProCarManuals.com
Page 202 of 330

01 SIENNA_U (L/O0008)
1982001 MY SIENNA (OM45406U)
1. Fan Speed Selector (front)
2. Fan Speed Selector (rear)
3. Temperature Selector
4. Air Flow Selector
Rear manual air conditioning system—
—Controls
ProCarManuals.com
Page 203 of 330

01 SIENNA_U (L/O0008)
1992001 MY SIENNA (OM45406U)
Fan speed selector (front)
To turn the rear air conditioning system
on/off and adjust the fan speed.
To turn the “REAR” position—You can op-
erate the rear air conditioning system by
the rear controller.
Turn the knob to adjust the fan speed—to
the right to increase, to the left to de-
crease. To turn the knob to “OFF” turns
off the rear air conditioning system and
the system cannot be operated by the
rear controller.
Fan speed selector (rear)
When the front fan speed selector is in
“REAR”, you can operate it.
Turn the knob to adjust the fan speed—to
the right to increase, to the left to de-
crease.
Temperature selector
Turn the knob to adjust the tempera-
ture—to the right to warm, to the “A/C”
position to cool.
Air flow selector
Turn the knob to select the vents used for
air flow.
1. “A/C”—Air flows only from the roof
panel vents.
This setting does not control air tem-
perature. It is only for blowing air con-
ditioned cool air.
2. Except “A/C”—Air flows only from the
floor vents.
This controls the air temperature. It is
for blowing air conditioned cool air and
warm air.
—Air flow selector settings
ProCarManuals.com
Page 204 of 330

01 SIENNA_U (L/O0008)
2002001 MY SIENNA (OM45406U)
1. Fan Position Selector
2. Fan Speed Selector
3. Temperature Selector
Rear automatic air conditioning system—
—Controls
ProCarManuals.com
Page 205 of 330

01 SIENNA_U (L/O0008)
2012001 MY SIENNA (OM45406U)
Fan position selector
“OFF”—You can turn off the rear air con-
ditioning.
“REAR”—You can operate the rear air
conditioning system by the rear controller.
“AUTO”—You can adjust the temperature
and fan speed of the front and rear air
conditioning systems simultaneously by
using the front air conditioning switches.
Fan speed selector
When the front fan position selector is in
“REAR”, you can operate it.
Turn the knob to adjust the fan speed—to
the right to increase, to the left to de-
crease.
To turn the knob to the “AUTO”—In the
automatic operation mode, the rear air
conditioning selects the most suitable fan
speed and air flow according to the tem-
perature.Temperature selector
Turn the knob to adjust the tempera-
ture—to the right to warm, to the left to
cool.
Air flow from the roof panel vents and/or
floor vents is automatically adjusted ac-
cording to the temperature when both au-
tomatic and manual modes are on.
The floor vents provide only cool air.
The roof panel vents provide warm air and
cool air.
Roof vents
Open
Close
If air flow control is not satisfactory, check
the roof vents. The roof vents may be
opened or closed as shown.
ProCarManuals.com
Page 206 of 330

01 SIENNA_U (L/O0008)
2022001 MY SIENNA (OM45406U)
ProCarManuals.com
Page 207 of 330

01 SIENNA_U (L/O0008)
2032001 MY SIENNA (OM45406U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Other equipment
Clock204 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside temperature gauge204 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray204 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power outlets205 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove box206 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Garage door opener206 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Garage door opener box208 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compass211 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Auxiliary boxes216 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cup holder218 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bottle holders218 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Juice box holder219 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
First−aid kit and warning reflector holder219 . . . . . . . . . . . . . . . . . . . . . .
Floor mat220 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1− 9
ProCarManuals.com
Page 208 of 330

01 SIENNA_U (L/O0008)
2042001 MY SIENNA (OM45406U)
Clock
The digital clock indicates the time.
The key must be in the “ACC” or “ON”
position.
To reset the hour: Push the “H” button.
To reset the minutes: Push the “M” button.
If the electrical power source has been
disconnected from the clock, the time dis-
play will automatically be set to 1:00 (one
o’clock).
When the instrument panel lights are
turned on, the brightness of the time in-
dication will be reduced.
Outside temperature gauge
The outside temperature display indi-
cates the outside air temperature when
you push the “OUTSIDE TEMP” button.
The key must be in the “ON” position.
Pushing the button once again will turn off
the display.
When the air conditioning system is on,
pushing the button once indicates the out-
side temperature and a second time
changes the display back to the air condi-
tioning temperature.
Cigarette lighter and ashtrays
Cigarette lighter and front ashtray
Rear ashtray (for second seats)
ProCarManuals.com
Page 209 of 330

01 SIENNA_U (L/O0008)
2052001 MY SIENNA (OM45406U)
Rear ashtray (for third seats)
CIGARETTE LIGHTER
To use the cigarette lighter, press it in.
When it becomes heated, it automatical-
ly pops out ready for use.
If the engine is not running, the key must
be in the “ACC” position.
Do not hold the cigarette lighter pressed
in.
Use a Toyota genuine cigarette lighter or
equivalent for replacement.ASHTRAYS
To use the ashtray, open out.
When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the ashtray, push it back
in completely.
To remove the ashtray, press down on the
lock spring plate and pull out.
CAUTION
To reduce the chance of injury in
case of an accident or sudden stop
while driving, always push the ash-
tray back in completely after using.
Power outlets
Front
Rear
ProCarManuals.com
Page 210 of 330

01 SIENNA_U (L/O0008)
2062001 MY SIENNA (OM45406U)
The power outlets are designed for
power supply for car accessories.
The key must be in the “ACC” or “ON”
position for the power outlets to be used.
NOTICE
To prevent the fuse from being
blown, do not use the electricity
over the total vehicle capacity of
12V/120W (front and rear outlets to-
gether).
To prevent the battery from being
discharged, do not use the power
outlets longer than necessary when
the engine is not running.
Close the power outlet lids when
the power outlets are not in use.
Inserting a foreign object other than
the appropriate plug that fits the
outlet, or allowing any liquid into
the outlet may cause electrical fail-
ure or short circuits.
Glove box
To use the glove box, do this.
To open: Pull the lever.
To lock: Insert the master key and turn it
clockwise.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the glove box door
closed while driving.
Garage door opener
The garage door opener is manufac-
tured under license from HomeLink
and can be programmed to operate ga-
rage doors, estate gates, security light-
ing, etc.
(a) Programming HomeLink
The HomeLink has 3 buttons and can
be programmed to operate 3 separate
devices.
NOTICE
Unplug the garage or gate device dur-
ing programming to prevent possible
motor burn−up.
ProCarManuals.com
