Vehicles with power door lock sys-
tem—The sliding doors will be locked si-
multaneously when either front door or the
back door is locked with the power door
lock switch or key. If you lock either front
door or the back door with the power door
lock switch or key while the sliding door
is open, the sliding door will be locked
after it is closed. (For instructions, see
“Front doors” or “Back door” in this sec-
tion.)
Closing the sliding door with the lock knob
in the lock position will also lock the slid-
ing door. Be careful not to lock your keys
in the vehicle.
CLOSING FROM INSIDE
To close the fully−opened sliding door,
push the lock release button and then
close the door.
CAUTION
When closing the sliding door, con-
firm safety of the area around.
Keep the heads, hands and other
parts of the bodies of all occupants
away from the sliding door. Other-
wise, they will be possibly caught
and pinched by the closing door
causing an unexpected serious inju-
ry.
When the vehicle is stopped on a
gradient, the door will slide faster
when opening or closing, so be es-
pecially careful that the passengers
do not get hit or pinched by the
door.
When stopping on a downward
slope, open the door fully while
passengers are getting on or off.
Do not pull the outside handle or
push the lock release button while
the door is open as the door could
suddenly close by itself causing in-
jury.
NOTICE
Do not close the sliding door by ap-
plying the brakes. Doing so could
cause the door to be damaged.
ProCarManuals.com

01 SIENNA_U (L/O0008)
182001 MY SIENNA (OM45406U)
HALF−OPENED SLIDING DOOR
STOPPER
When opening the left side sliding door, it
stops at the half−opened position if the
fuel filler door is opened.
Left and right side power sliding door
models—The left side power sliding door
does not operate when the fuel filler door
is open.
NOTICE
Avoid forcibly opening the left side
sliding door fully when refueling.
Otherwise, the fuel filler door may be
damaged.
SLIDING DOOR CHILD−PROTECTORS
Open the sliding door fully and move
the lock lever to the “LOCK” position
as shown on the label. Then close the
sliding door.
If the child−protector is locked, you cannot
open the sliding door from the inside. We
recommend using this feature whenever
small children are in the vehicle.Vehicles with power sliding door system—
If the power sliding door system is on, the
child−protector feature is cancelled when
someone pushes one of the “DOOR L”,
“DOOR R” and “POWER DOOR” switches
inside the vehicle or “POWER DOOR”,
“D−PWR DOOR” and “P−PWR DOOR”
switches of the wireless remote control
transmitter.
CAUTION
Make sure to turn off the power slid-
ing door system after locking the
child−protectors.
ProCarManuals.com

01 SIENNA_U (L/O0008)
192001 MY SIENNA (OM45406U)
Power sliding door
Some vehicles are equipped with a power
sliding door. This system has the following
functions:
The power sliding door can be oper-
ated with the “DOOR L”, “DOOR R”
and “POWER DOOR” switches inside
the vehicle or “POWER DOOR”, “D−
PWR DOOR” and “P−PWR DOOR”
switches of the wireless remote control
transmitter. (For details about the wire-
less remote control transmitter, see
“Wireless remote control” in this sec-
tion.)
If you move the sliding door to the
opening or closing direction by hand,
the sliding door will automatically and
completely open or close after you let
go of the sliding door.
CAUTION
Do not leave small children or pets
unattended in your vehicle. They
could operate the power sliding door,
and they themselves or others could
be injured. Turn off the power sliding
door system when the power sliding
door is not in use.
“PWR DOOR OFF” SWITCH
This switch is used to turn on and off
the power sliding door system. For op-
erating the power sliding door, the
“PWR DOOR OFF” switch on the instru-
ment panel must be pushed out. (The
orange line on the top of the switch
indicates that the system is on.) To dis-
able the power sliding door feature,
push in the switch.When the power sliding door system is
on, you can open and close the sliding
door with the “DOOR L”, “DOOR R” and
“POWER DOOR” switches inside the ve-
hicle or “POWER DOOR”, “D−PWR
DOOR” and “P−PWR DOOR” switches of
the wireless remote control transmitter
even if the sliding door child−protector is
locked. If small children or pets are in the
vehicle, turn off the system to prevent the
accidental operation of the door.
CAUTION
When jacking up the vehicle, turn off
the power sliding door system and
close the sliding door completely.
NOTICE
When your vehicle goes through an
automatic car wash, make sure the
power sliding door system is off.
ProCarManuals.com

01 SIENNA_U (L/O0008)
202001 MY SIENNA (OM45406U)
Instrument panel
Center pillar
“DOOR L”, “DOOR R” AND “POWER
DOOR” SWITCHES
These switches are used to open and
close the power sliding door. Push and
release one of the “DOOR L”, “DOOR
R” and “PWR DOOR” switches.
Opening and closing can be performed by
the “DOOR L”, “DOOR R” and “PWR
DOOR” switches under the following con-
ditions:
The sliding door is unlocked.
The power sliding door system is on.
(The “PWR DOOR OFF” switch is
pushed out.)
To open the power sliding door when
the ignition key is in the “ON” position,
the transmission selector lever must be
in “P”. (To close the sliding door from
the fully−opened or half−opened posi-
tion, the transmission selector lever is
not required to be in “P”.)
Left and right side power sliding door
models—The left side power sliding door
does not operate when the fuel filler door
is opened.
CAUTION
If you shift the automatic transmis-
sion selector lever out of “P” and
accelerate before the power sliding
door is closed completely, the sliding
door may reverse to the open posi-
tion. A child or others could fall out
of the vehicle and be injured. Always
make sure the power sliding door is
closed and latched before you start
driving.
OPENING BY HAND
When the power sliding door system is
on, if you pull the outside door handle or
push the inside lock release button to re-
lease the sliding door, it will then automat-
ically and completely open.
When the power sliding door system is
off, open the sliding door as usual.
CLOSING BY HAND
When the power sliding door system is
on, if you slide the door about 10 cm (4
in.) to the closing direction and let the
door go, it will automatically and com-
pletely close.
When the power sliding door system is
off, close the sliding door as usual.
ProCarManuals.com

01 SIENNA_U (L/O0008)
212001 MY SIENNA (OM45406U)
OPEN POWER SLIDING DOOR
WARNING LIGHT AND BUZZER
This light on the instrument panel comes
on if the power sliding door is not com-
pletely closed with the ignition key in the
“ON” position. (See “Service reminder indi-
cators and warning buzzers” in Section
1−5.)If you forcibly close the power sliding door
by hand when the ignition key is in the
“ON” position, the open power sliding door
warning light may stay on. In this case,
try opening and closing the power sliding
door again by hand slowly, or use one of
the “DOOR L”, “DOOR R” and “PWR
DOOR” switches inside the vehicle or
“POWER DOOR”, “D−PWR DOOR” and
“P−PWR DOOR” switches of the wireless
remote control transmitter.
If you shift out of “P” when the power
sliding door is opened or in the process
of closing with the power sliding door sys-
tem on, a buzzer will sound and the open
power sliding door warning light will flash.
This is a warning that the sliding door is
not completely closed.JAM PROTECTION FUNCTION
If anything with sufficient resistance ob-
structs the power sliding door while it is
closing or opening, the sliding door will
automatically reverse to the opposite di-
rection. However, if the power sliding door
is between the fully−closed and half−
opened positions while it is opening, the
door will stop at that position.
Before operating the power sliding door,
make sure there is nobody near the slid-
ing door. Make sure the sliding door stops
at the fully−opened position, and then al-
low the passengers to get on and off the
vehicle.
ProCarManuals.com

01 SIENNA_U (L/O0008)
222001 MY SIENNA (OM45406U)
The resistance must be as strong as the
force of the moving door, or stronger. As
the sliding door approaches the fully−
closed or fully−opened position, its moving
force increases significantly.
If the sliding door receives a strong im-
pact, this function may work even if noth-
ing is caught.
CAUTION
Power sliding door could injure
people if they are caught in the door
path. When using the power sliding
door, observe the following:
Never try jamming any part of your
body to make the jam protection
function work intentionally.
The jam protection function may
not work if something gets caught
just before the sliding door is fully
closed.
You must always make sure the
heads, hands and other parts of the
bodies of all occupants are away
from the sliding door. If someone’s
neck, head or hand gets caught in
a closing sliding door, it could re-
sult in a serious injury. When any-
one closes the power sliding door,
make sure he/she operates the slid-
ing door safely.
NOTICE
Objects caught in the path of the slid-
ing door may be damaged. Make sure
there is nothing in the doorway be-
fore closing the sliding door.CAUTION
When the vehicle is stopped on a
downward slope of a steep grade
(17% or more), the sliding door may
not stay in the fully−opened position
and could suddenly close by itself,
possibly resulting a personal injury.
Making sure the sliding door does not
close abruptly, turn on the power
sliding door system. Then the sliding
door will operate under the control of
the electric power.
ProCarManuals.com

01 SIENNA_U (L/O0008)
232001 MY SIENNA (OM45406U)
RESETTING THE POWER SLIDING
DOOR SYSTEM
If the power sliding door system operates
incorrectly or does not operate under the
following conditions, the system must be
initialized and reset by the steps in the
next column.
The battery is disconnected and then
reconnected, or a discharged battery is
recharged.
In this case, initialize and reset the
system by doing the following steps
from 6 to 10.
The open power sliding door warning
light stays on though the sliding door
is closed.
In this case, initialize and reset the
system by doing the following steps
from 1 to 10.
CAUTION
To initialize and reset power sliding
door system, stop the vehicle on a
level ground.
1. Be sure to turn off the power sliding
door system by pushing in the “PWR
DOOR OFF” switch.
2. Disconnect the battery for 1 minute
and then reconnect it.
3. Close the sliding door by hand.
(Step 3 can be performed before step
2.)
4. Turn on the power sliding door system
by pushing out the “PWR DOOR OFF”
switch.
5. Wait 5 seconds.
6. Open the sliding door by using one of
the “DOOR L”, “DOOR R” and “PWR
DOOR” switches.
7. Wait 3 seconds after the sliding door
stops at the fully−opened position.
8. Close the sliding door by using one of
the “DOOR L”, “DOOR R” and “PWR
DOOR” switches inside the vehicle or
“POWER DOOR”, “D−PWR DOOR” and
“P−PWR DOOR” switches of the wire-
less remote control transmitter.
9. Wait 3 seconds after the sliding door
stops at the fully−closed position.
10. Repeat the steps from 6 to 9.If the power sliding door system does not
operate properly after the above proce-
dure, there may be a problem in the sys-
tem. Contact your Toyota dealer.
ProCarManuals.com

01 SIENNA_U (L/O0008)
242001 MY SIENNA (OM45406U)
Wireless remote control
Locking operation
Unlocking operation
The wireless remote control system al-
lows you to lock or unlock all the
doors from a distance within approxi-
mately 1 m (3 ft.) of the vehicle. On
some models, the system also allows
you to activate the theft deterrent sys-
tem from the same distance.
LOCKING AND UNLOCKING THE
DOORS
To lock and unlock all the doors, push
the switches of the transmitter slowly
and securely.
To lock: Push the “LOCK” switch. All the
doors are locked simultaneously. At this
time one beep will be heard, parking
lights, side marker lights, tail lights and
other exterior lights will flash once.
Left and right side power sliding door
models—If the “LOCK” switch is kept
pressed in, the panic mode will work. (For
details, see “PANIC (LOCK)” SWITCH.)
Check to see that the doors are securely
locked.
If any of the doors is not securely closed,
or if the key is in the ignition switch,
locking cannot be performed by the
“LOCK” switch and a beep will sound con-
tinuously for 10 seconds. However, if the
key is in the ignition, a beep will not
sound.To stop the beep, close all the doors se-
curely or push the “UNLOCK” switch.
To unlock: Push the “UNLOCK” switch
once to unlock only the driver’s door.
Pushing the switch twice within 3 seconds
unlocks all the doors simultaneously. Each
time the “UNLOCK” switch is pushed, two
beeps will be heard, and the parking
lights, side marker lights and tail lights
will flash twice.
When the “UNLOCK” switch is pressed,
the personal lights, interior lights and/or
ignition key light come on. The lights re-
mains on for about 15 seconds unless any
of the doors are opened then and closed.
(For further information, see “Personal
lights”, “Interior lights” and/or “Ignition
switch light” in Section 1−4.)
You have 30 seconds to open a door after
using the wireless remote unlock feature.
If a door is not opened by then, all the
doors will automatically lock again.
If the “LOCK” or “UNLOCK” switch is kept
pressed in, the locking or unlocking opera-
tion is not repeated. Release the button
and then push again.
ProCarManuals.com

01 SIENNA_U (L/O0008)
252001 MY SIENNA (OM45406U)
SWITCHING BEEP SOUND ON AND OFF
You can switch the beep on and off. (The
beep is on initially and after battery re-
placement.)
To switch the beep on and off:
With the driver ’s door opened—
1. Insert the ignition key and remove it.
2. Within 5 seconds, insert the ignition
key again and turn it to the “ON” posi-
tion.
3. After 10 seconds, push the same
“LOCK”, “UNLOCK” or “PANIC” button
twice within 10 seconds.
Two beep sounds inform you that the
program has been switched on or off.
If this procedure is not followed exactly,
the beep will not operate as expected.
Check the beep ON/OFF operation by
pushing the wireless remote control trans-
mitter switch after you finish this proce-
dure. If the beep does not operate as
expected, repeat this procedure from step
1.
Right side only power sliding door mod-
els
Left and right side power sliding door
models
“POWER DOOR”, “D−PWR DOOR” AND
“P−PWR DOOR” SWITCHES (on some
models)
This switch of the wireless remote con-
trol transmitter is used to open and
close the power sliding door. Push the
switch slowly and securely.
To open: Push the switch. The sliding
door opens completely.
To close: Push the switch again. The slid-
ing door closes completely.
Opening and closing can be performed by
the “POWER DOOR”, “D−PWR DOOR”
and “P−PWR DOOR” switches under the
following conditions only:
The sliding door is unlocked.
The power sliding door system is on.
(The “PWR DOOR OFF” switch is
pushed out.)
The ignition key is not in the “ON”
position.
Left and right side power sliding door
models—The left side power sliding door
does not operate when the fuel filler door
is opened.
ProCarManuals.com

01 SIENNA_U (L/O0008)
262001 MY SIENNA (OM45406U)
“PANIC (LOCK)” SWITCH (left and right
side power sliding door models)
Pushing and holding the “PANIC
(LOCK)” switch blows the horn intermit-
tently and flashes the headlights, tail
lights and other exterior lights.
The “PANIC (LOCK)” switch is used to
deter vehicle theft when you witness any-
one attempting to break into or damage
your vehicle.The alarm will last for one minute. To stop
alarm midway, do the following:
Push any of the switch on the wireless
remote control transmitter.
Lock or unlock either front doors or
back door with the key.
Turn the ignition key from the “LOCK”
to “ON” position.
The panic mode does not work when the
ignition key is in the “ON” position.
“PANIC” SWITCH (right side only power
sliding door models)
Pushing the “PANIC” switch blows the
horn intermittently and flashes the
headlights, tail lights and other exterior
lights.
The “PANIC” switch is used to deter ve-
hicle theft when you witness anyone at-
tempting to break into or damage your
vehicle.
ProCarManuals.com
