TOYOTA SIENNA 2003 XL20 / 2.G Owners Manual
Manufacturer: TOYOTA, Model Year: 2003, Model line: SIENNA, Model: TOYOTA SIENNA 2003 XL20 / 2.GPages: 340, PDF Size: 6.77 MB
Page 331 of 340
03 SIENNA_U (L/O 0207)
3272003 MY SIENNA (OM45410U)
Instrument panel
9. HORN 10 A: Horn, theft deterrent sys-
tem
10. HAZARD 10 A: Emergency flashers
11. AM2 30 A: “IGN” and “STARTER”
fuses
12. HEAD (LH) 15 A: Left hand headlight
(high beam)
13. RADIO NO.1 20 A: Car audio system
Instrument panel
14. DOME 10 A: Clock, personal lights,
vanity mirror lights, door courtesy
lights, luggage compartment light, open
door warning light, ignition switch light,
theft deterrent system, daytime running
light system, interior lights, air condi-
tioning system, wireless remote control,
garage door opener
15. ECU B 10 A: Cruise control system,
SRS warning light, power sliding door
16. FOG 20 A: Front fog lights
17. ABS NO.3 25 A: Vehicle skid control
system 18. ABS NO.2 25 A:
Vehicle skid control
system
19. H LP LH (LO) 10 A: Left hand head-
light (low beam)
20. H LP RH (LO) 10 A: Right hand head-
light (low beam)
21. ABS NO.4 5 A: Vehicle skid control
system
22. HEATER 10 A: Air conditioning system,
rear window defogger
23. GAUGE 10 A: Gauges and meters,
service reminder indicators and warning
buzzers (except discharge and open
door warning light), power windows,
daytime running light system, back up
lights, power sliding door, auto anti
glare inside rear view mirror, compass
24. WIPER 25 A: Windshield wipers and
washer, rear window wiper and washer
25. MIRROR HEATER 10 A: Multiport fuel
injection system/sequential multiport
fuel injection system, outside rear view
mirror defogger
26. ECU IG 15 A: Cruise control system,
anti lock brake system, vehicle skid
control system, locking with wireless
remote control system, theft deterrent
system
Page 332 of 340
03 SIENNA_U (L/O 0207)
3282003 MY SIENNA (OM45410U)
27. IGN 5 A: Gauges and meters, charging
system, SRS airbag system, seat belt
pretensioners, multiport fuel injection
system/s equential multiport fuel injec-
tion system
28. STOP 15 A: Stop lights, cruise control
system, high m ounted stoplight, tail
lights
29. TAIL 10 A: Parking lights, front side
marker lights, license plate lights, tail
lights, power sliding door
30. PWR VENT 15 A: Power rear quarter
windows
31. OBD 7.5 A: On board diagnosis sys-
tem
32. PWR OUTLET 15 A: Power outlets
33. STARTER 5 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system
34. DOOR 25 A: Power door lock system,
theft deterrent system
35. PANEL 7.5 A: Gauge and meter, car
audio system, clock, air conditioning
system, instrument p anel light control,
rear window defogger, electronically
controlled automatic transmission sys-
tem, emergency flashers, parking
lights, seat heaters, power rear quarter
windows, power sliding door 36. TURN 7.5 A:
Turn signal lights, emer-
gency flashers
37. RADIO NO.2 7.5 A: Car audio system
38. CIG 15 A: Cigarette lighter, clock, pow-
er rear view mirror controls, SRS air-
bag system, seat belt pretensioners,
back up lights, theft deterrent system,
air conditioning system
39. A /C 5 A: Front air conditioning system
Fuses (type B)
40. CDS 40 A: Electric cooling fans
41. RDI 40 A: Electric cooling fans
42. CDS 30 A: Electric cooling fans
43. RDI 30 A: Electric cooling fans
44. MAIN 40 A: Daytime running light sys-
tem, “H LP RH (LO)” and “H LP LH
(LO)” fuses
45. R /R A /C 40 A: Rear air conditioning
system
46. HTR 50 A: Front air conditioning sys-
tem
47. PWR SLD 30 A: Power sliding door
(left side)
48. Rr CLR 40 A: Rear air conditioning
system
49. DEF 30 A: Rear window defogger,
“MIRROR HEATER” fuse 50. PWR 30 A:
Power windows, electric
moon roof, power seat, power sliding
door (right side), “PWR VENT” fuse
51. AM1 40 A: “CIG”, “RADIO NO.2”,
“ECU IG”, “WIPER”, “HEATER”,
“GAUGE” and “TURN” fuses
Fuses (type C)
52. ALT 140 A: Charging system, “FL
ABS”, “INP”, “HTR” and “R/R A/C”
fuses
53. INP 100 A: “AM1” and “DEF” fuses
54. FL ABS 60 A: Anti lock brake system
Page 333 of 340
03 SIENNA_U (L/O 0207)
3292003 MY SIENNA (OM45410U)
REPORTING SAFETY DEFECTS FOR U.S.
OWNERS AND UNIFORM TIRE QUALITY
GRADING
Reporting safety defects for U.S. owners330
. . . . . . . . . . . . . . . . . . . . . .
Uniform tire quality grading 330
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 9
Page 334 of 340
03 SIENNA_U (L/O 0207)
3302003 MY SIENNA (OM45410U)
If you believe that your vehicle
has a defect which could cause a
crash or could cause injury or
death, you should immediately in-
form the National Highway Traffic
Safety Administration (NHTSA) in
addition to notifying Toyota Motor
Sales, U.S.A., Inc.
(Toll free: 1 800 331 4331).
If NHTSA receives similar com-
plaints, it may open an investiga-
tion, and if it finds that a safety
defect exists in a group of ve-
hicles, it may order a recall and
remedy campaign. However,
NHTSA cannot become involved
in individual problems between
you, your dealer, or Toyota Motor
Sales, U.S.A., Inc.To contact NHTSA, you may ei-
ther call the Auto Safety Hotline
toll free at 1 800 424 9393 (or
366 0123 in Washington, D.C.
area) or write to: NHTSA, U.S.
Department of Transportation,
Washington, D.C. 20590. You can
also obtain other information about
motor vehicle safety from the Hot-
line.
Uniform tire quality gradingThis information has been prepared in ac-
cordance with regulations issued by the
National Highway Traffic Safety Adminis-
tration of the U.S. Department of Trans-
portation. It provides the purchasers and/
or prospective purchasers of Toyota
vehicles with information on uniform tire
quality grading.
Your Toyota dealer will help answer any
questions you may have as you read this
information.
DOT quality grades—All passenger car
tires must conform to Federal Safety
Requirements in addition to these
grades. Quality grades can be found
where applicable on the tire sidewall
between tread shoulder and maximum
section width. For example: Treadwear
200 Traction AA Temperature A
Reporting safety defects
for U.S. owners
Page 335 of 340
03 SIENNA_U (L/O 0207)
3312003 MY SIENNA (OM45410U)
Treadwear—The treadwear grade is a
comparative rating based on the wear rate
of the tire when tested under controlled
conditions on a specified government test
course. For example, a tire graded 150
would wear one and a half (1 1/2) times
as well on the government course as a
tire graded 100. The relative performance
of tires depends upon the actual condi-
tions of their use, however, and may de-
part significantly from the norm due to
variations in driving habits, service prac-
tices and differences in road characteris-
tics and climate.
Traction AA, A, B, C— The traction
grades, from highest to lowest, are AA, A,
B, and C, and they represent the tire’s
ability to stop on wet pavement as mea-
sured under controlled conditions on spe-
cified government test surfaces of asphalt
and concrete. A tire marked C may have
poor traction performance.
Warning: The traction grade assigned to
this tire is based on braking (straight
ahead) traction tests and does not include
cornering (turning) traction. Temperature A, B, C—
The temperature
grades are A (the highest), B, and C,
representing the tire’s resistance to the
generation of heat and its ability to dissi-
pate heat when tested under controlled
conditions on a specified indoor laboratory
test wheel. Sustained high temperature
can cause the material of the tire to de-
generate and reduce tire life, and exces-
sive temperature can lead to sudden tire
failure. The grade C corresponds to a lev-
el of performance which all passenger car
tires must meet under the Federal Motor
Vehicle Safety Standard No.109. Grades B
and A represent higher levels of perfor-
mance on the laboratory test wheel than
the minimum required by law.
Warning: The temperature grades for this
tire are established for a tire that is prop-
erly inflated and not overloaded. Exces-
sive speed, underinflation, or excessive
loading, either separately or in combina-
tion, can cause heat buildup and possible
tire failure.
Page 336 of 340
03 SIENNA_U (L/O 0207)
3322003 MY SIENNA (OM45410U)
Page 337 of 340
03 SIENNA_U (L/O 0207)
2003 MY SIENNA (OM45410U)
Publication No. OM45410U
Part No. 01999-45410
Printed in Japan 01−0207 −00
(U)
Quick index
If a service reminder indicator or warning buzzer comes on 139 . . . . . . . .
If your vehicle will not start 254 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
If your engine stalls while driving 257 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats 257 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
If you have a flat tire 258 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
If your vehicle needs to be towed 269 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips for driving during break −in period 226 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to start the engine 242 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
General maintenance 283 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Gas station information
Fuel type:
UNLEADED gasoline, Octane Rating 87 (Research Octane Number 91)
or higher.
For improved vehicle performance, the use of premium unleaded gasoline
with an Octane Rating of 91 (Research Octane Number 96) or higher is
recommended.
See page 226 for detailed information.
Fuel tank capacity:
79 L (21 gal., 17.5 lmp. gal.)
Engine oil: API grade SL “Energy −Conserving” or ILSAC multigrade engine oil is
recommended.
See page 297 for detailed information.
Automatic transmission fluid: Toyota Genuine ATF D −II or DEXRON III (DEXRON II)
See page 324 for detailed information.
Tire information: See pages 301 through 307.
Tire pressure: See page 325.
gU 8
I
Page 338 of 340
03 SIENNA_U (L/O 0207)
2003 MY SIENNA (OM45410U)
You should know as much about the quality and
importance of proper main tenance of your new
vehicle as the people who built it.
The Toyota authorized Repair Manual
tells you how to maint ain your vehicle and
enables you to correct ly perform your own
maintenance.
The best way to keep your new vehicle in top
running order is to maintain it properly from
the moment you drive it off the showroom
floor.
The Toyota authorized Repair Manual is
packed with literally everything you need to
know to perform your own maintenance in
virtually every area of your new vehicle.
Page 339 of 340
03 SIENNA_U (L/O 0207)
2003 MY SIENNA (OM45410U)
Maintenance procedures for the engine,
chassis, body, electrical system, and more,
are clearly explained and illustrated.
Periodic maintenance and tune up
Periodic maintenance and tune up helps to pre-
vent small problems from growing into larger ones lat-
er on. The repair manual outlines exactly what main-
tenance is required and clearly explains how to do the
work yourself step by step.
Areas covered include such things as spark plug re-
placement, valve clearance adjustment and engine oil
and filter replacement.
Where to obtain the Repair Manual
The repair manual for SIENNA, written in Eng-
lish, may be purchased as applicable from any
Toy ota dea l er.
Pub. Name: 2003 SIENNA Repair Manual
Pub. No.: RM954U1 (Maintenance, Preparation, Service specifications and Diagnos-
tics)
RM954U2 (Engine, Chassis and Body)
Page 340 of 340
03 SIENNA_U (L/O 0207)
2003 MY SIENNA (OM45410U)
WE REALLY CARE ABOUT YOU PLEASE BUCKLE UP
Toyota has made a special effort to encourage use of seat belts.
Toyota belts are:
Comfortable
Easy to use
Convenient
We encourage you to use your belts every time you drive.
U
