Page 11 of 592
11
B
Window lock switch P. 100
Power window switches P. 100
Door lock switches P. 33
Inside door lock buttons P. 33
: If equipped
Driving position memory switches P. 80
Page 12 of 592
12
C
Pictorial indexInterior
With console box
Console box
Note pad holder P. 365
P. 381
Cup holders P. 370
Cup holders P. 370Cup holders
Auxiliary box P. 370
P. 375
Page 13 of 592
13
C
With front seat side table
Front seat side table P. 399
Cup holders P. 370
Cup holder
Auxiliary box P. 370
P. 375
Page 14 of 592
14
Tilt and telescopic
steering lock release
lever
P. 94
Pictorial index
Headlight switch
Turn signal lever
Fog light switch
P. 185
P. 172
P. 190
Instrument panel
Glove box P. 365
Windshield wiper and
washer switch
Rear window wiper and
washer switch
P. 191
P. 193
Auxiliary box P. 375
Power outlets P. 387
Fuel filler door opener P. 107
Gauges and meters P. 174
TRAC off switch P. 216
Cup holder
Coin holder P. 370
P. 369
Auxiliary box P. 375
Parking brake pedal P. 173
Bottle holders P. 374
Hood release lever P. 434
Page 15 of 592
15
A
: If equipped
Outside rear view mirror
switches
P. 97
Power quarter window switch P. 102
Headlight beam level
control dial
P. 187
Power back door
main switch
P. 48
Power sliding door main switch P. 39
Tire pressure warning reset
switch
P. 454
Page 16 of 592
16
Pictorial indexInstrument panel
B
Cruise control switch P. 194, 197
Talk switch , * P. 332
Distance switch P. 197
Engine (ignition) switch P. 167
Telephone switch , * P. 332
Audio remote control
switches
P. 292
Page 17 of 592
17
: If equipped*: Refer to “Navigation System Owner’s Manual”.
C
Power outlet main
switch
P. 388
AUX adapter P. 291
Intuitive parking assist switch P. 209
Rear window defogger switch
Outside rear view mi rror defogger switch
Windshield wiper de-icer switch
P. 260
P. 260
P. 260
Emergency flasher switch
Personal/interior light main switch
P. 362Front air conditioning system
P. 240, 246
Audio system
Rear view monito r/navigation system
*
P. 262
Page 18 of 592
18
Instrument panelPictorial index
D
Shift lever P. 170
Auxiliary box P. 375
With seat heater
Shift lock override button P. 530
Seat heater switches P. 390
Shift lever P. 170
Auxiliary box P. 375
Without seat heater
Shift lock override button P. 530
Page 19 of 592
19
: If equipped
Pictorial indexLuggage compartment
Power third seat switches P. 72, 75
Back door strap P. 47
Grocery bag hooks
Cargo hooks
Cargo net hooks P. 394
P. 402
P. 402
Cargo hooks
Cargo net hooks P. 402
P. 402
Power outlet (12 V)
Power outlet (115 VAC)
Luggage compartment light
P. 387
P. 388
P. 363
Storage box P. 403
Grocery bag
hooks
P. 394
Cargo hooks
Cargo net hooks P. 402
P. 402
Page 20 of 592
20
For your information
Main Owner’s Manual
Please note that this manual covers all models and all equipment, including
options. Therefore, you may find some explanations for equipment not
installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of equipment.
Noise from under vehicle after turning off the engine
Approximately five hours after the engine is turned off, you may hear sound
coming from under the vehicle for several minutes. This is the sound of a fuel
evaporation leakage check and, it does not indicate a malfunction.
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota
vehicles are currently available on the market. You should know that these
parts are not covered by Toyota warranty and that Toyota is not responsible
for their performance, repair, or replacement, or for any damage they may
cause to, or adverse effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products.
Modification with non-genuine Toyota products could affect its performance,
safety or durability, and may even violate governmental regulations. In
addition, damage or performance problems resulting from the modification
may not be covered under warranty.
