SOLARA_U81
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1- 5
Gauges, Meters and
Service reminder indicators
Fuel gauge
Engine coolant temperature gauge
Tachometer
Odometer and two trip meters
Service reminder indicators and
warning buzzers
Fuel gauge
Low fuel level
warning light
The gauge works when the ignition
switch is on and indicates the approxi-
mate quantity of fuel remaining in the
tank.
Nearly fullÐNeedle at ºFº
Nearly emptyÐNeedle at ºEº
It is a good idea to keep the tank over
1/4 full.
This fuel gauge has a non- return type
needle which remains at the last indicated
position when the ignition switch is turned
off.
If the fuel level approaches ºEº or the low
fuel level warning light comes on, fill the
fuel tank as soon as possible. On inclines or curves, due to the move-
ment of fuel in the tank, the fuel gauge
needle may fluctuate or the low fuel level
warning light may come on earlier than
usual.
If the fuel tank is completely empty, the
malfunction indicator lamp comes on. Fill
the fuel tank immediately.
The indicator lamp goes off after driving
several times. If the indicator lamp does
not go off, contact your Toyota dealer as
soon as possible.

SOLARA_U83
Odometer and two trip meters
This meter displays the odometer and
two trip meters.
1. OdometerÐIt shows the total distance the vehicle has been driven.
2. Two trip metersÐThey show two differ- ent distances independently driven
since the last time each trip meter was
set to zero.
You can use one trip meter to calculate
the fuel economy and the other to
measure the distance on each trip. All
trip meter data is cancelled if the elec-
trical power source is disconnected. 3. Trip meter reset knobÐIt can reset the
two trip meters to zero, and also
change the meter display.
To change the meter display, quickly
push and release the knob. The meter
display changes in the order from the
odometer to trip meter A to trip meter
B, then back to the odometer each
time you push.
To reset the trip meter A to zero, dis-
play the meter A reading, then push
and hold the knob until the meter is
set to zero. The same process can be
applied for resetting the trip meter B.
(c) Fasten front passenger 's seat
belt.
(a) If parking brake
is off, stop and
check.
(b) Fasten driver 's seat belts.
If the indicator or Do this.
buzzer comes on...
(d) Stop and check.
(e) Take vehicle to
Toyota dealer.
(type A)
(type B)
(Indicator and buzzer)
Service reminder indicators
and warning buzzers

SOLARA_U
84 (g) Stop and check.
(h) Take vehicle to
Toyota dealer.
(i) Close all doors.
(j) Replace bulb.(type A)
(type B)
(f) Fill up tank.
Low fuel level
warning light
If the indicator or Do this.
buzzer comes on...
(l) Add washer fluid.
(m) Take vehicle to Toyota dealer.
(n) Remove key.Key reminder
buzzer
(k) Take vehicle to
Toyota dealer
immediately.
If the indicator or Do this.
buzzer comes on... (a) Brake System Warning Light
This light has the following functions:
Parking brake reminder
If this light is on, make sure the parking
brake is fully released. The light should
go off.
Low brake fluid level warning
If this light comes on and stays on while
you are driving, slow down and pull off
the road. Then stop the vehicle carefully.
Remember that stopping distance and ped-
al effort may be increased. There may be
a problem somewhere in the brake sys-
tem. Check the fluid level of the see-
through reservoir.
To make sure the parking brake has not
caused the warning light to come on,
check to see that the parking brake is
fully released.
If the brake fluid level is low...
At a safe place, test your brakes by start-
ing and stopping.
If you judge that the brakes still work
adequately, drive cautiously to your
nearest dealer or shop for repairs.
If the brakes are not working, have the
vehicle towed in for repairs. (For tow-
ing information, see Part 4.)

SOLARA_U
152
Part 2
INFORMATION
BEFORE DRIVING
YOUR TOYOTA
Break- in period
Fuel
Operation in foreign countries
Three- way catalytic converters
Engine exhaust cautions
Facts about engine oil
consumption

Twin ground electrode spark plugs

Brake system
Brake pad wear limit indicators
Luggage stowage precautions
Your Toyota's identification
Theft prevention labels
Suspension and chassis
Types of tires
Break- in period
Drive gently and avoid high speeds.
Your vehicle does not need an elaborate
break- in. But following a few simple tips
for the first 1600 km (1000 miles) can add
to the future economy and long life of
your vehicle: Do not drive over 88 km/h (55 mph).
Run the engine at moderate speed be-
tween 2000 and 4000 rpm.
Avoid full- throttle starts.
Try to avoid hard stops during the first
300 km (200 miles).
Do not drive slowly with the manual
transmission in a high gear.
Do not drive for a long time at any
single speed, either fast or slow.
Do not tow a trailer during the first 800
km (500 miles). Fuel
FUEL TYPE
Your new vehicle must use only un-
leaded gasoline.
To help prevent gas station mix- ups, your
Toyota has a new smaller fuel tank open-
ing. The special nozzle on pumps with
unleaded fuel will fit it, but the larger
standard nozzle on pumps with leaded gas
will not.
At a minimum, the gasoline you use
should meet the specifications of ASTM
D4814 in the U.S.A. and CGSB 3.5- M93
in Canada.
NOTICE
Do not use leaded gasoline. Use of
leaded gasoline will cause the three-way catalytic converter to lose its ef-
fectiveness and the emission control
system to function improperly. Also,this can increase maintenance costs.

SOLARA_U
168
CAUTION
Before driving off, make sure that
the parking brake is fully released
and the parking brake reminder
light is off.
Do not leave your vehicle unat-
tended while the engine is running.
Do not rest your foot on the brake
pedal while driving. It can cause
dangerous overheating, needless
wear, and poor fuel economy.
To drive down a long or steep hill,
reduce your speed and downshift.
Remember, if you ride the brakes
excessively, they may overheat and
not work properly.
Be careful when accelerating, up-
shifting, downshifting or braking on
a slippery surface. Sudden accelera-
tion or engine braking could cause
the vehicle to spin or skid.
Do not drive in excess of the speed
limit. Even if the legal speed limit
permits it, do not drive over 140
km/h (85 mph) unless your vehicle
has high- speed capability tires.
Driving over 140 km/h (85 mph) may
result in tire failure, loss of control
and possible injury. Be sure to con-
sult a tire dealer to determine
whether the tires on your vehicle
are high- speed capability tires or
not before driving at such speeds.
Do not continue normal driving
when the brakes are wet. If they are
wet, your vehicle will require a
longer stopping distance, and it
may pull to one side when the
brakes are applied. Also, the park-
ing brake will not hold the vehicle
securely.
Winter driving tips
Make sure you have a proper freeze
protection of engine coolant.
Your coolant must contain ethylene- glycol
type coolant for a proper corrosion protection
of aluminum components. Use ºToyota Long
Life Coolantº or equivalent.
See Chapter 7- 2 for details about coolant
type selection.
NOTICE
Do not use alcohol type antifreeze or
plain water alone.
When it is extremely cold, we recommend
to use 60% solution for your Toyota, to pro-
vide protection down to about -50 5C (- 58 5F).
Do not use more than 70% solution for better
coolant performance.
Check the condition of the battery and
cables.
Cold temperatures reduce the capacity of
any battery, so it must be in top shape
to provide enough power for winter start-
ing. Chapter 7- 3 tells you how to visually
inspect the battery. Your Toyota dealer
and most service stations will be pleased
to check the level of charge.

SOLARA_U
236
Engine
Model:
5S- FE and 1MZ- FE
Type: 5S- FE engine4 cylinder in line, 4 cycle, gasoline
1MZ- FE engine 6 cylinder V type 4 cycle, gasoline
Bore and stroke, mm (in.): 5S- FE engine87.0 91.0 (3.43 3.58)
1MZ- FE engine 87.5 83.0 (3.44 3.27)
Displacement, cm 3
(cu. in.):
5S- FE engine 2164 (132.0)
1MZ- FE engine 2995 (182.8) Fuel
Fuel type:
5S- FE engine
Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher
1MZ- FE engine Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher.
For improved vehicle performance, the
use of premium unleaded gasoline with
an Octane Rating of 91 (Research Oc-
tane Number 96) or higher is recom-
mended.
Fuel tank capacity, L (gal., Imp. gal.): 70 (18.5, 15.4) Service specifications
ENGINE
Valve clearance (engine cold), mm (in.):
5S- FE engine
Intake 0.19Ð0.29 (0.007Ð0.011)
Exhaust 0.28Ð0.38 (0.011Ð0.015)
1MZ- FE engine Intake 0.15Ð0.25 (0.006Ð0.010)
Exhaust 0.25Ð0.35 (0.010Ð0.014)
Spark plug type: DENSO PK20TR11
NGK BKR6EKPB11
Spark plug gap, mm(in.): 1.1 (0.043)
Drive belt tension measured with Borroughs
drive belt tension gauge No. BT- 33- 73F
(used belt), Ibf: 5S- FE engine Generator belt 130 10
Power steering pump belt 80 20
1MZ- FE engine 115 20

SOLARA_U
240
Fuses
Engine compartment
Engine compartment (vehicles with
daytime running light system and 1MZ- FE
engine with automatic transmission for
California)
Fuses (type A) 1. A/F HTR 25A: A/F sensor
2. A/C 10 A: Air conditioning system
3. SPARE 10 A: Spare fuse
4. SPARE 15 A: Spare fuse
5. SPARE 30 A: Spare fuse
6. ALT- S 5 A: Charging system
7. HEAD RH(HI) 15 A: Right- hand head-
lightEngine compartment (type A)
8. EFI 15 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
9. HORN 10 A: Horn, theft deterrent sys-
tem
10. HAZARD 10 A: Emergency flasher
11. AM2 30 A: Gauge and meter, SRS
airbag system, seat belt pretensioners,
Multiport fuel injection system/sequen-
tial multiport fuel injection system,
ºIGNº and ºSTº fuses
12. TEL 5 A: No circuit
13. HEAD LH(HI) 15 A: Left- hand head-
light

SOLARA_U241
Engine compartment (type B)
14. RADIO NO.1 20 A: Audio system
15. DOME 7.5 A: Theft deterrent system,
daytime running light system, clock,
locking with wireless remote control
system, ignition switch light, pers onal
light, trunk light, electric moon roof,
interior light, vanity mirror light, door
courtesy light, power door lock system
16. ECU- B 10 A: Cruise control system,
anti- lock brake system, SRS airbag
system, seat belt pretensi oners
17. DRL NO.2 5 A: Daytime running light
systemInstrument panel
18. H- LP LH(LWR) 10 A: Left- hand head-
light
19. H- LP RH(LWR) 10 A: Right- hand
headlight
20. SEAT- HEATER 20 A: No circuit
21. HEATER 10 A: Air conditioning system,
rear window defogger, starting system
22. GAUGE 10 A: Gauges and meters,
back- up lights, cruise control system,
charging system, traction control sys-
tem, daytime running light system,
power windows, service reminder indi-
cators and warning buzzers 23. WIPER 25 A:
Windshield wipers and
washer
24. MIRROR- HEATER 10 A: Outside rear
view mirror defogger
25. ECU- IG 15 A: Cruise control system,
anti- lock brake system, SRS airbag
system, seat belt pretensi oners, theft
deterrent system, shift lock control sys-
tem, traction control system, daytime
running light system, locking with wire-
less remote control system, multiport
fuel injection system/sequential multi-
port fuel injection system
26. IGN 5 A: Gauges and meters, charging
system, SRS airbag system, seat belt
pretensioners, multiport fuel injection
system/s equential multiport fuel injec-
tion system
27. STOP 15 A: Stop lights, cruise control
system, high- m ounted stoplight, anti-
lock brake system, shift lock control
system, multiport fuel injection system/
sequential multiport fuel injection sys-
tem
28. TAIL 10 A: Parking lights, license plate
lights, tail lights, front side marker
lights, daytime running light system,
multiport fuel injection system/sequen-
tial multiport fuel injection system
29. POWER- OUTLET 15 A: Power outlet

SOLARA_U
242
30. OBD 7.5 A:
On- board diagnosis sys-
tem
31. FOG 15 A: Front fog lights
32. STARTER 5 A: Gauges and meters,
Multiport fuel injection system/sequen-
tial multiport fuel injection system
33. DOOR 25 A: Power door lock system,
theft deterrent system
34. PANEL 7.5 A: Gauge and meter, audio
system, cigarette lighter, glov ebox light,
clock, instrument panel light control,
service reminder indicators, air condi-
tioning control panel lights, ashtray
light, emergency flasher, daytime run-
ning light system, rear window defog-
ger, electronically controlled automatic
transmission system
35. TURN 7.5 A: Emergency flasher
36. RAD- NO.2 7.5 A: Audio system
37. CIG 15 A: Cigarette lighter, shift lock
control system, power rear view mirror
controls, theft deterrent system, power
door lock system, SRS airbag system,
seat belt pretensioners, outside rear
view mirror defogger, air conditioning
system Fuses (type B)
38. CDS 30 A: Electric cooling fans
39. RDI 30 A: Electric cooling fans
40. MAIN 40 A: ºHEAD RH (HI)º, ºHEAD
RH (LWR)º fuses
41. HTR 50 A: ºAM1º, ºA/Cº fuses
42. T- STK 40 A: No circuit
43. DEF 40 A: Rear window defogger
44. PWR 30 A: Power window control sys-
tem, power seat, electric moon roof
45. AM1 40 A: No circuit
Fuses (type C)
46. ALT 100 A: ºRDIº, ºCDSº fuses
47. ABS 60 A: Anti- lock brake system
