TOYOTA SOLARA 2001 Owners Manual (in English)

'01 SOLARA_U (L/O 0009)
1572001 MY SOLARA (OM33527U)
Cup holder
Front
Rear (on some models)
The cup holder is designed for holding
cups or drink±cans securely.
Front: To use the holder, open the lid.
Rear: To use the holder, pull it out.
CAUTION

Do not place anything else other
than cups or drink±cans in the cup
holder, as such items may be
thrown about in the compartment
and possibly injure people in the
vehicle during sudden braking or in
an accident.

To reduce the chance of injury in
case of an accident or sudden stop
while driving, keep the cup holder
closed when it is not in use.
Traction control system
Slip indicator light
ªTRAC OFFº indicator/warning light

'01 SOLARA_U (L/O 0009)
1582001 MY SOLARA (OM33527U)
AUTOMATIC TRACTION CONTROL
SYSTEM
The traction control system automatical-
ly helps control the spinning of the
front wheels which may occur when ac-
celerating on slippery road surfaces,
thus assisting driver to control the driv-
ing power of the front wheels. When
you turn the ignition switch on, the
traction control system always turns on
automatically, and the slip indicator
light and ªTRAC OFFº indicator/warning
light will come on. The indicator lights
will go off after a few seconds.
Leave the system on during ordinary
driving so that it can operate when
needed. When traction control is ap-
plied, the slip indicator light blinks.
You may hear a sound in the engine
compartment for a few seconds when the
engine is started or just after the vehicle
is started. This means that the traction
control system is in the self±check mode,
and does not indicate malfunction. When
the traction control system is operating,
you may feel vibration or noise of your
vehicle, caused by operation of the
brakes. This indicates the system is func-
tioning properly.When getting the vehicle out of mud or
new snow, etc. the traction control system
will help operate to prevent the wheels
from spinning.
MANUAL OPERATION
You can turn off the traction control
system by pushing the ªTRAC OFFº
switch. The ªTRAC OFFº indicator/warn-
ing light will come on. Pushing the
ªTRAC OFFº switch a second time
turns on the traction control system
and the ªTRAC OFFº indicator/warning
light will go off.

'01 SOLARA_U (L/O 0009)
1592001 MY SOLARA (OM33527U)
CAUTION
Under certain slippery road condi-
tions, full traction of the vehicles and
power to the front wheels may not be
maintained, even though the traction
control system is in operation. Do not
drive the vehicle at any speed or con-
duct any during maneuver which will
cause the vehicle to lose traction. In
situations where the road surface is
covered with ice or snow, your ve-
hicle should be fitted with snow tires
or tire chains. Always drive at an ap-
propriate and cautious speed for the
road conditions present.
Floor mat
Use a floor mat of the correct size.
If the floor carpet and floor mat have a
hole, then it is designed for use with a
locking clip. Fix the floor mat with locking
clip into the hole in the floor carpet.CAUTION
Make sure the floor mat is properly
placed on the floor carpet. If the floor
mat slips and interferes with the
movement of the pedals during driv-
ing, it may cause an accident.

'01 SOLARA_U (L/O 0009)
1602001 MY SOLARA (OM33527U)

'01 SOLARA_U (L/O 0009)
1612001 MY SOLARA (OM33527U)
INFORMATION BEFORE DRIVING YOUR
TOYOTA
Break±in period162
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Fuel 162
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
Operation in foreign countries 164
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Three±way catalytic converters 164
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine exhaust cautions 166
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Facts about engine oil consumption 166
. . . . . . . . . . . . . . . . . . . . . . . . . .
Twin ground electrode platinum±tipped spark plugs 167
. . . . . . . . . . . .
Brake system 168
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Brake pad wear limit indicators 171
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage stowage precautions 171
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Your Toyota's identification 172
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft prevention labels 173
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
Suspension and chassis 173
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Types of tires 174
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
SECTION 2

'01 SOLARA_U (L/O 0009)
1622001 MY SOLARA (OM33527U)
Break±in period
Drive gently and avoid high speeds.
Your vehicle does not need an elaborate
break±in. But following a few simple tips
for the first 1600 km (1000 miles) can add
to the future economy and long life of
your vehicle:

Do not drive over 88 km/h (55 mph).

Run the engine at moderate speed be-
tween 2000 and 4000 rpm.

Avoid full±throttle starts.

Try to avoid hard stops during the first
300 km (200 miles).

Do not drive slowly with the manual
transmission in a high gear.

Do not drive for a long time at any
single speed, either fast or slow.

Do not tow a trailer during the first 800
km (500 miles).
Fuel
FUEL TYPE
Your new vehicle must use only un-
leaded gasoline.
To help prevent gas station mix±ups, your
Toyota has a smaller fuel tank opening.
The special nozzle on pumps with un-
leaded fuel will fit it, but the larger stan-
dard nozzle on pumps with leaded gas will
not.
At a minimum, the gasoline you use
should meet the specifications of ASTM
D4814 in the U.S.A. and CGSB 3.5±M93
in Canada.
NOTICE
Do not use leaded gasoline. Use ofleaded gasoline will cause the three±way catalytic converter to lose its ef-fectiveness and the emission control
system to function improperly. Also,this can increase maintenance costs.
OCTANE RATING
5S±FE engine: Select Octane Rating 87
(Research Octane Number 91) or higher.
1MZ±FE engine: Select Octane Rating
87 (Research Octane Number 91) or
higher. For improved vehicle perfor-
mance, the use of premium unleaded
gasoline with an Octane Rating 91 (Re-
search Octane Number of 96) or higher
is recommended.
Use of unleaded gasoline with an octane
rating or research octane number lower
than stated above will cause persistent
heavy knocking. If it is severe, this will
lead to engine damage.
If your engine knocks...
If you detect heavy knocking even when
using the recommended fuel, or if you
hear steady knocking while holding a
steady speed on level roads, consult your
Toyota dealer.
However, now and then, you may notice
light knocking for a short time while accel-
erating or driving up hills. This is no
cause for concern.

'01 SOLARA_U (L/O 0009)
1632001 MY SOLARA (OM33527U)
GASOLINE CONTAINING DETERGENT
ADDITIVES
Toyota recommends the use of gasoline
that contains detergent additives to
avoid build±up of engine deposits.
However, all gasoline sold in the U.S.
contains detergent additives to keep clean
and/or clean intake systems.
QUALITY GASOLINE
Automotive manufacturers in the U.S.,
Europe and Japan have developed a
specification for quality fuel named
World±Wide Fuel Charter (WWFC) that
is expected to be applied world wide.
The WWFC consists of three categories
that depend on required emission lev-
els. In the U.S., category 3 has been
adopted. The WWFC improves air quali-
ty by providing for better emissions in
vehicle fleets, and customer satisfaction
through better vehicle performance.CLEANER BURNING GASOLINE
Cleaner burning gasoline, including re-
formulated gasoline that contains oxy-
genates such as ethanol or MTBE is
available in many areas.
Toyota recommends the use of cleaner
burning gasoline and appropriately blended
reformulated gasoline. These types of gas-
oline provide excellent vehicle perfor-
mance, reduce vehicle emissions, and im-
prove air quality.
OXYGENATES IN GASOLINE
Toyota allows the use of oxygenate
blended gasoline where the oxygenate
content is up to 10% ethanol or 15%
MTBE. If you use gasohol in your
Toyota, be sure that it has an octane
rating no lower than 87.
Toyota does not recommend the use of
gasoline containing methanol.
SULFUR IN GASOLINE
If your vehicle is certified to California
Emission Regulations, the vehicle is
designed to operate on California
cleaner burning gasoline (CBG) that
contains lower sulfur. If you cannot use
California CBG, your emission control
system may suffer damage and turn on
the Malfunction Indicator Lamp.
If the malfunction is caused by the type
of fuel used, repairs may not be covered
by your warranty.
GASOLINE CONTAINING MMT
Some gasoline contain an octane en-
hancing additive called MMT (Methylcy-
clopentadienyl Manganese Tricarbonyl).
Toyota does not recommend the use of
gasoline that contains MMT. If fuel con-
taining MMT is used, your emission con-
trol system may be adversely affected.
The Malfunction Indicator Lamp on the in-
strument cluster may come on. If this hap-
pens, contact your Toyota dealer for ser-
vice.

'01 SOLARA_U (L/O 0009)
1642001 MY SOLARA (OM33527U)
GASOLINE QUALITY
In a very few cases, you may experience
driveability problems caused by the partic-
ular gasoline that you are using. If you
continue to have unacceptable driveability,
try changing gasoline brands. If this does
not rectify your problem, then consult your
Toyota dealer.
NOTICE
Do not use gasohol other thanstated above. It will cause fuel sys-tem damage or vehicle performanceproblems.
If driveab ility problems are encoun-
tered (poor hot starting, vaporizing, engine knock, etc.), discontinue the
use.
Take care not to spill gasohol dur-ing refueling. Gasohol may causepaint damage.
FUEL TANK CAPACITY 70 L (18.5 gal., 15.4 lmp. gal.)
Operation in foreign countries
If you plan to drive your Toyota in
another country...
First, comply with the vehicle registration
laws.
Second, confirm the availability of the cor-
rect fuel (unleaded and minimum octane
number).
Three±way catalytic converters
Ty p e A
Ty p e B

'01 SOLARA_U (L/O 0009)
1652001 MY SOLARA (OM33527U)
Ty p e C
The three±way catalytic converter is an
emission control device installed in the
exhaust system.
The purpose is to reduce pollutants in the
exhaust gas.
CAUTION

Keep people and combustible mate-
rials away from the exhaust pipe
while the engine is running. The
exhaust gas is very hot.

Do not drive, idle or park your ve-
hicle over anything that might burn
easily such as grass, leaves, paper
or rags.
NOTICE
A large amount of unburned gasesflowing into the three±way catalyticconverter may cause it to overheatand create a fire hazard. To prevent
this and other damage, observe thefollowing precautions:
Use only unleaded gasoline.
Do not drive with an extremely lowfuel level; running out of fuel could
cause the engine to misfire, creat-ing an excessive load on the three±way catalytic converter.
Do not allow the engine to run atidle speed for more than 20 min-
utes.
Avoid racing the engine.
Do not push±start or pull±start yourvehicle.
Do not turn off the ignition whilethe vehicle is moving.
Keep your engine in good running
order. Malfunctions in the engineelectrical system, electronic ignitionsystem/distributor ignition system
or fuel system could cause an ex-tremely high three±way catalyticconverter temperature.
If the engine becomes difficult tostart or stalls frequently, take your
vehicle in for a check±up as soonas possible. Remember, your Toyotadealer knows your vehicle and its
three±way catalytic converter sys-tem best.
To ensure that the three±way cata-lytic converter and the entire emis-sion control system operate proper-
ly, your vehicle must receive theperiodic inspections required by theToyota Maintenance Schedule. For
scheduled maintenance information,refer to the ªScheduled MaintenanceGuideº or ªOwner 's Manual Supple-
mentº.

'01 SOLARA_U (L/O 0009)
1662001 MY SOLARA (OM33527U)
Engine exhaust cautions
CAUTION

Avoid inhaling the engine exhaust.
It contains carbon monoxide, which
is a colorless and odorless gas. It
can cause unconsciousness or even
death.

Make sure the exhaust system has
no holes or loose connections. The
system should be checked from
time to time. If you hit something,
or notice a change in the sound of
the exhaust, have the system
checked immediately.

Do not run the engine in a garage
or enclosed area except for the
time needed to drive the vehicle in
or out. The exhaust gases cannot
escape, making this a particularly
dangerous situation.

Do not remain for a long time in a
parked vehicle with the engine run-
ning. If it is unavoidable, however,
do so only in an unconfined area
and adjust the heating or cooling
system to force outside air into the
vehicle.

Keep the trunk lid closed while
driving. An open or unsealed trunk
lid may cause exhaust gases to be
drawn into the vehicle.

To allow proper operation of your
vehicle's ventilation system, keep
the inlet grilles in front of the wind-
shield clear of snow, leaves, or oth-
er obstructions.

If you smell exhaust fumes in the
vehicle, drive with the windows
open and the trunk lid closed. Have
the cause immediately located and
corrected.
FUNCTIONS OF ENGINE OIL
Engine oil has the primary functions of
lubricating and cooling the inside of the
engine, and plays a major role in main-
taining the engine in proper working order.
ENGINE OIL CONSUMPTION
It is normal that an engine should con-
sume some engine oil during normal
engine operation. The causes of oil
consumption in a normal engine are as
follows.

Oil is used to lubricate pistons, piston
rings and cylinders. A thin film of oil
is left on the cylinder wall when a pis-
ton moves downwards in the cylinder.
High negative pressure generated when
the vehicle is decelerating sucks some
of this oil into the combustion chamber.
This oil as well as some part of the oil
film left on the cylinder wall is burned
by the high temperature combustion
gases during the combustion process.
Facts about engine oil
consumption
