2. Release the bulb retaining springand remove the bulb. Install a new
bulb and the bulb retaining spring.
To install a bulb, align the tabs of the
bulb with the cutouts of the mounting
hole.3. Install the rubber cover as shown and snuggle on the boss. Insert the
connector. Then install the plastic
cover.
Make sure the rubber cover fits snugly on
the connector and the headlight body.
Aiming is not necessary after replacing
the bulb. When aiming adjustment is nec-
essary, contact your Toyota dealer.
ÐFront fog lights
1. Remove the bolts, take out the en- gine under cover.

'01 SOLARA_U (L/O 0009)
2482001 MY SOLARA (OM33527U)
2. Turn the bulb and remove it.3. Unplug the connector while depress-ing the lock release.
If the connector is tight, wiggle it.Use a Phillips±head screwdriver.
ÐParking/front side marker/
front turn signal lights

'01 SOLARA_U (L/O 0009)
2492001 MY SOLARA (OM33527U)
Use a flat±bladed screw driver. To protect
the surface, place several sheets of paper
over the surface.
Type A Type B
Use a phillips±head screw driver. Remove
and install the cover clips as shown in
the following illustrations.
ÐRear turn signal, stop/tail,
and back±up lights

'01 SOLARA_U (L/O 0009)
2502001 MY SOLARA (OM33527U)
Removing cover clips
Installing cover clips
Ty p e ARemoving cover clips
Installing cover clips
Ty p e B

'01 SOLARA_U (L/O 0009)
2512001 MY SOLARA (OM33527U)
a: Rear turn signal light
b: Stop/tail light
c: Back±up light
ÐLicense plate lights
( lef t sid e)

'01 SOLARA_U (L/O 0009)
2522001 MY SOLARA (OM33527U)
ÐHigh mounted stoplight
ÐLicense plate lights
(right side)

'01 SOLARA_U (L/O 0009)
2532001 MY SOLARA (OM33527U)

'01 SOLARA_U (L/O 0009)
2542001 MY SOLARA (OM33527U)

'01 SOLARA_U (L/O 0009)
2552001 MY SOLARA (OM33527U)
SPECIFICATIONS
Dimensions and weight256
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
Engine 256
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . .
Fuel 257
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
Service specifications 257
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
Tires 259
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . .
Fuses 260
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . .
SECTION 8

'01 SOLARA_U (L/O 0009)
2562001 MY SOLARA (OM33527U)
Dimensions and weightEngine
Model:
5S±FE and 1MZ±FE
Type: 5S±FE engine4 cylinder in line, 4 cycle, gasoline
1MZ±FE engine 6 cylinder V type 4 cycle, gasoline
Bore and stroke, mm (in.): 5S±FE engine87.0
91.0 (3.43
3.58)
1MZ±FE engine 87.5
83.0 (3.44
3.27)
Displacement, cm
3 (cu. in.):
5S±FE engine 2164 (132.0)
1MZ±FE engine 2995 (182.8)
4825 (190.0)
1805 (71.1)
1425 (56.1)
*
1520 (59.8)
Overall length
mm (in.)
Overall width mm (in.)
Overall height mm (in.)
Wheelbase mm (in.)
Front tread mm (in.)
Rear tread mm (in.)
Vehicle capacity weight
(occupants + luggage) kg (lb.)2670 (105.1)
1545 (60.8)
345 (755)
*: Unladen vehicle
4825 (190.0)
1805 (71.1)
1400 (55.1)
*
1520 (59.8) 2670 (105.1)
1545 (60.8)410 (905)
Coupe Convertible
