AUDIO SYSTEM
11 4
Push AM´SATº, FMº or DISCº button to
turn on the desired mode. The selected
mode turns on immediately.
Push these buttons if you want to switch from
one mode to another.
If the disc is not set, the compact disc player
does not turn on.
You can turn off the compact disc player by
ejecting the compact disc. If the audio system
was previously off, then the entire audio sys-
tem will be turned off when you eject the com-
pact disc. If the another function was pre-
viously playing, it will come on again.
The switches for radio and compact disc
player operation are displayed on the
function switch display screen when the
audio control mode is selected. Touch
them lightly and directly on the screen.
The selected switch is highlighted in green or
yellow.
INFORMATION
If the system does not respond to a
touch of a switch, move your fingeraway from the screen and then touchit again.
You cannot operate dimmedswitches.
Wipe off fingerprints on the surface ofthe display using a glass cleaningcloth.

AUDIO SYSTEM
11 6
(d) Your compact disc player
When you insert a compact disc, insert it with
the label side up. The compact disc player will
play from track 1 through the end of the disc.
Then it will play from track 1 again.
NOTICE
Never try to disassemble or oil any part
of the compact disc player. Do not in-sert anything other than compact discsinto the slot.
The player is intended for use with 12 cm (4.7
in.) discs only.
Ð Radio operation
(a) Listening to the radio
Push these buttons to choose either an
AM or FM station.
AMº,  FM1º or FM2º appears on the screen.
If your vehicle is equipped with satellite ra-
dio broadcast system, when you push the
AM´SATº button, AMº, SAT1º, SAT2º or
SAT3º station appears on the display. For
details about satellite radio broadcast, see
Ð Radio operation (XM satellite radio broad-
cast)º on page 119.
Turn the knob clockwise to step up the sta-
tion band or counterclockwise to step
down.
Your radio automatically changes to stereo
reception when a stereo broadcast is re-
ceived. STº appears on the screen. If the
signal becomes weak, the radio reduces the
amount of channel separation to prevent the
weak signal from creating noise. If the signal
becomes extremely weak, the radio switches
from stereo to mono reception. In this case,
STº disappears from the screen.
