fuse TOYOTA SOLARA 2006 Accessories, Audio & Navigation (in English)

19
LIMITED RIGHTS
CONTRACT NO.:
CONTRACTOR (MANUFACTURER/ SUPPLIER) NAME:
NAVTEQ Corporation
CONTRACTOR
(MANUFACTURER/SUPPLIER)
ADDRESS: 222 Merchandise Mart Plaza, Suite 900, Chicago, Illinois 60654.
The Government’s rights to use,
modify, reproduce, release, perform,
display, or disclose these technical
data are restricted by paragraph (b)(3)
of the Rights in Technical Data −Non-
commercial Items clause contained in
the above identified contract. Any re-
production of technical data or portions
thereof marked with this legend must
also reproduce the markings. Any per-
son, other than the Government, who
has been provided access to such data
must promptly notify the above named
Contractor.and; (ii) for civilian agency acquisitions,
the NAVTEQ Data is licensed in
accordance with the rights set forth at
FAR 52.227 −14(g)(1), RIGHTS IN
DATA−GENERAL (Protection of limited
rights data and computer software). In
the event that the Contracting Officer
requires the delivery of limited rights
NAVTEQ Data that has been withheld or
would otherwise be withholdable in
accordance with FAR 52.227 −14(g)(1),
the NAVTEQ Data is licensed with
“Limited Rights” as set forth in the
following “Limited Rights Notice” at FAR
52.227 −14(g)(2) (Alternate II), which
shall be af fixed to the NAVTEQ Data and
the NAVTEQ Data shall be treated in
accordance with such Notice (which shall
be marked on any reproduction of these
data, in whole or in part):LIMITED RIGHTS NOTICE
(JUN 1987)
These data are submitted with limited
rights under Government Contract No.
(and subcontract , if ap-
propriate). These data may be repro-
duced and used by the Government
with the express limitation that they will
not, without written permission of the
Contractor, be used for purposes of
manufacture nor disclosed outside the
Government; except that the Govern-
ment may disclose these data outside
the Government for the following pur-
poses, if any, provided that the Gov-
ernment makes such disclosure sub-
ject to prohibition against further use
and disclosure: There are no addition-
al purposes permitting disclosure of
such Data.
The manufacturer/supplier of the Data
is NAVTEQ Corporation, 222
Merchandise Mart Plaza, Suite 900,
Chicago, Illinois 60654.
If the Contracting Officer refuses to use
either of the licenses provided in (i) or (ii),
herein, the Contracting Officer must
notify NAVTEQ Corporation prior to
seeking additional or alternative rights in
the NAVTEQ Data.

121
(b) Presetting a station
1. Tune in the desired station.
2. Touch one of the switches (1 — 6) you
want and hold it until a beep is heard. This
sets the station to the switch and the fre-
quency appears on the switch.
Each radio mode (AM, FM1 or FM2) can store
up to 6 stations. To change the preset station
to a different one, follow the same procedure.
The preset station memory is cancelled when
the power source is interrupted by battery dis-
connection or a blown fuse. (c) Selecting a station
Tune in the desired station using one of the
following methods.
Preset tuning:
Touch the switch (1 — 6) for
the station you want. The switch is high-
lighted in g reen and the station frequency ap-
pears on the screen.
Seek tuning: Push the “SEEK/TRACK” but-
ton on either side. The radio will begin seek-
ing up or down for a station of the nearest fre-
quency and will stop on reception. Each time
you push the button, the stations will be
searched out automatically after another.
To scan all the frequencies: Touch the
“SCAN” switch on the screen or push the
“SCAN” button briefly. “SCAN” appears on
the screen. The radio will find the next station
and stay there for a few seconds, and then
scan again. To select a station, touch the
“SCAN” switch or push the “SCAN” button
again.
To scan the preset stations: Touch the
“SCAN” switch on the screen or push the
“SCAN” button for longer than approximately
a second. “P. SCAN” appears on the screen.
The radio will tune in the next preset station,
stay there for a few seconds, and then move
to the next preset station. To select a station,
touch the “SCAN” switch or push the “SCAN”
button again. (d) Radio Data System
Your audio system is equipped with Radio
Data Systems
(RDS). RDS mode allows you
to receive text messages from radio stations
that utilize RDS transmitters.
When RDS is on, the radio can
— only select stations of a particular program
type,
— display messages from radio stations,
— search for a stronger signal station.
RDS features are available for use only on FM
stations which broadcast RDS information.

125
Turn this knob to select the next or pre-
vious channel.
If you turn continuously, you can rapidly scroll
forward or down through the channels.
(d) Channel category
When the channel category appears, touch
either “TYPE ” or “TYPE” switch to go to
the next or previous category.(e) Presetting a channel
1. Tune in the desired channel.
2. Touch one of the channel selector
switches (1 — 6) and hold it until a beep is
heard. This sets the channel to the switch
and the name and number of the channel
appears on the switch.
Each switch can store three SAT channels.
To change the preset channel to a different
one, follow the same procedure.
The preset channel memory is cancelled
when the power source is interrupted by bat-
tery disconnection or a blown fuse.
