TOYOTA SUPRA 1996 Owners Manual

169
To check the headlight aim, check the vertical and horizontal gauges.
1. Look at the beam angle gauge (vertical
movement). The bubble of the gauge
should not deviate from the center of the gauge by more than two marks on either side of the gauge.2. Look at the beam angle gauge (hori- zontal movement). The 0º mark should
not deviate by more than one mark on ei-
ther side of the gauge.
If the error is over the value specified
above, take the vehicle to your Toyota
dealer to adjust the headlight aim. The following illustrations show how to
gain access to the bulbs. When replacing
a bulb, make sure the ignition switch and
light switch are off. Use bulbs with the wattage ratings given in the table.
Halogen bulbs have pressurized
gas inside and require special han-
dling. They can burst or shatter ifscratched or dropped. Hold a bulb
only by its plastic or metal case. Do
not touch the glass part of a bulb
with bare hands.
CAUTION
!
NOTICE
Only use a bulb of the listed type.
Light BulbsBulb No.WType
Headlights (low beam)900655A
Headlights (high beam)900565B
Front fog lightsÐ55C
Parking lightsÐ5E
Front turn signal lights115627D
Front side marker lights1943.8E
Rear side marker lights1943.8E
Rear turn signal lights115627D
Replacing light bulbsÐ

170Light Bulbs
Bulb No.WType
Stop and tail lights115727/8D
Back-up lights115627D
License plate lightsÐ5E
Interior lightsÐ8D
Glovebox lightÐ1.2E
Luggage compartment lightÐ5F
A: HB4 halogen bulbs B: HB3 halogen bulbs C: H3 halogen bulbsD: Single end bulbs
E: Wedge base bulbs F: Double end bulbs
1. Open the hood.
RIGHT SIDE HEADLIGHT: Release the
clips of the air cleaner and remove the
air cleaner cover.2. Unplug the connector while de-
pressing the lock release. If the connector is tight, wiggle it.
ÐHeadlights (low beam)

171
3. Turn the bulb clockwise and re- move it. Install a new bulb, turn it
counterclockwise, then plug in the
connector.
To install a bulb, align the tab of the bulb
socket with the cutouts of the mountinghole.
RIGHT SIDE HEADLIGHT: Install the air
cleaner cover securely.
Aiming is not necessary after replacing
the bulb. When aiming adjustment is nec-
essary, contact your Toyota dealer.1. Open the hood.
RIGHT SIDE HEADLIGHT: Release the
clips of the air cleaner and remove the
air cleaner cover.2. Unplug the connector while de-
pressing the lock release. If the connector is tight, wiggle it.
ÐHeadlights (high beam)

172
3. Turn the bulb counterclockwise
and remove it. Install a new bulb, turn
it clockwise, then plug in the connec-
tor.
To install a bulb, align the tab of the bulb
socket with the cutouts of the mountinghole.
RIGHT SIDE HEADLIGHT: Install the air
cleaner cover securely.
Aiming is not necessary after replacing
the bulb. When aiming adjustment is nec-
essary, contact your Toyota dealer.1. Open the hood.
RIGHT SIDE HEADLIGHT: Release the
clips of the air cleaner and remove the
air cleaner cover.2. Turn the cover counterclockwise
and remove it.
ÐFront fog lights

173
3. Disconnect the cords.4. Release the bulb retaining spring
and remove the bulb. Install a new
bulb and the bulb retaining spring.
To install the bulb, align the cutouts of the
bulb with the protrusions of the mountinghole.5. Connect the cords and install the cover by turning it clockwise.
RIGHT SIDE HEADLIGHT: Install the air
cleaner cover securely.

174
Right side parking light: Release the
clips of the air cleaner and remove the
air cleaner cover.
ÐParking lightsÐFront turn signal lights

175
Use a Phillips-head screwdriver.Use a Phillips-head screwdriver.
ÐFront side marker lightsÐRear side marker lights

176
Use a Phillips-head screwdriver.
ÐRear turn signal, stop and
tail, and back-up lights

177
a: Rear turn signal light
b: Stop and tail light
c: Back-up light
Use a Phillips-head screwdriver.
ÐLicense plate lights

178
