TOYOTA SUPRA 1997 Service Repair Manual

SR147-01
Z06071
SST
Vinyl Tape
Z06072
Inscribed Mark
Z06073
Inscribed
Mark
R01149
Round End SR-32
- STEERINGPOWER STEERING VANE PUMP
1916 Author
: Date
:
1997 SUPRA (RM502U)
REASSEMBLY
NOTICE:
When using a vise, do not overtighten it.
1. COAT WITH POWER STEERING FLUID
(See page SR-23)
2. INSTALL VANE PUMP SHAFT WITH BEARING
(a) Wind vinyl tape on the serrated part of the shaft.
(b) Using SST, press in the shaft with the bearing to the front
housing.
SST 09608-04031
NOTICE:
Be careful not to damage the oil seal.
(c) Using snap ring pliers, install a new snap ring to the front
housing.
3. INSTALL STRAIGHT PINS
Using a plastic hammer, drive in 2 new straight pins to the front
housing.
4. INSTALL CAM RING
Align the holes of the ring and straight pins, and install the ring
with the inscribed mark facing outward.
5. INSTALL VANE PUMP ROTOR
Install the rotor with the inscribed mark facing outward.
6. INSTALL 10 VANE PLATES
Install the plate with the round end facing outward.
7. INSTALL GASKET
Install a new gasket to the front housing.
8. INSTALL SIDE PLATE
Align the holes of the plate and straight pins.

R01174
R06769
SST
- STEERINGPOWER STEERING VANE PUMP
SR-33
1917 Author
: Date
:
1997 SUPRA (RM502U)
9. INSTALL WAVE WASHER
Install the washer so that its protrusions fit into the slots in the
side plate.
10. INSTALL REAR HOUSING
(a) Coat 2 new O-rings with power steering fluid and install
them to the housing.
(b) Torque the 2 bolts.
Torque: 17 N´m (170 kgf´cm, 12 ft´lbf)
11. INSTALL SPRING, FLOW CONTROL VALVE AND
PRESSURE PORT UNION
(a) Coat a new O-ring with power steering fluid and install it
to the union.
(b) Torque the union.
Torque: 83 N´m (850 kgf´cm, 61 ft´lbf)
12. 2JZ-GTE:
INSTALL SUCTION PORT UNION
(a) Coat a new O-ring with power steering fluid and install it
to the union.
(b) Torque the bolt.
Torque: 13 N´m (130 kgf´cm, 9 ft´lbf)
13. 2JZ-GE:
INSTALL OIL RESERVOIR
(a) Coat a new O-ring with power steering fluid and install it
to the reservoir.
(b) Torque the 3 bolts.
Torque:
Front side bolt: 13 N´m (130 kgf´cm, 9 ft´lbf)
Rear side bolts: 17 N´m (170 kgf´cm, 12 ft´lbf)
14. MEASURE PS VANE PUMP ROTATING TORQUE
(See page SR-27)
15. 2JZ-GE:
INSTALL VANE PUMP PULLEY
Using SST to stop the pulley rotating, torque the nut.
SST 09960-10010 (09962-01000, 09963-01000)
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)

SR148-01
Z09176
Stopper
R07429
R06091
SR-34
- STEERINGPOWER STEERING VANE PUMP
1918 Author
: Date
:
1997 SUPRA (RM502U)
INSTALLATION
1. INSTALL PS VANE PUMP ASSEMBLY
Torque the 2 bolts.
Torque:
RH side bolt: 39 N´m (400 kgf´cm, 29 ft´lbf)
LH side bolt: 58 N´m (590 kgf´cm, 42 ft´lbf)
2. CONNECT PRESSURE FEED TUBE
Using a spanner (24 mm) to hold the pressure port union,
torque the union bolt with a new gasket.
HINT:
Make sure that the stopper of the tube is touching the PS vane
pump assembly as shown, before torquing the union bolt.
Torque: 49 N´m (500 kgf´cm, 36 ft´lbf)
3. 2JZ-GTE:
INSTALL VANE PUMP PULLEY
Using SST to stop the pulley rotating, torque the nut.
SST 09960-10010 (09962-01000, 09663-01000)
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
4. 2JZ-GE:
CONNECT RETURN TUBE
5. 2JZ-GTE:
CONNECT OIL RESERVOIR TO PUMP HOSE
Connect the hose and install the clip.
6. INSTALL DRIVE BELT
Loosen the drive belt tension by turning the drive belt tensioner
clockwise, and install the drive belt.
7. 2JZ-GTE:
INSTALL AIR HOSE No.5
8. INSTALL BATTERY
(a) Install the battery carrier and battery.
(b) Install the battery cover.
(c) Install the battery clamp with bolt and nut.
(d) Connect the 2 terminals.
9. INSTALL ENGINE UNDER COVER
Install the 10 screws.
10. BLEED POWER STEERING SYSTEM
(See page SR-3)

SR149-01
R11266

Cotter PinUnion Bolt

Gasket
Return Tube
Union Bolt
Intermediate Shaft
Gasket
Pressure Feed Tube
Power Steering Gear
AssemblyPPS Solenoid Connector
Rack Housing Bracket
Rack Housing Grommet

Cotter
Pin
Front Suspension Member Protector
Engine Under Cover
x10

Non-reusable part
- STEERINGPOWER STEERING GEAR
SR-35
1919 Author
: Date
:
1997 SUPRA (RM502U)
POWER STEERING GEAR
COMPONENTS

SR-36
- STEERINGPOWER STEERING GEAR
1920 Author
: Date
:
1997 SUPRA (RM502U)

Z18140
Union SeatUnion Bolt

Gasket
Union Bolt

Gasket
Turn Pressure TubeDust Cover
Control Valve Housing
Pressure Control
Valve Assembly

O-Ring

Oil Seal
O-Ring

Bearing

Teflon Ring Connector Bracket
Solenoid Valve
Control Valve Assembly
Teflon Ring

O-Ring

Oil Seal
Bearing Rack Housing

Non-reusable part
Molybdenum disulfide lithium base grease
Power Steering fluid
- STEERINGPOWER STEERING GEAR
SR-37
1921 Author
: Date
:
1997 SUPRA (RM502U)

SR14A-01
SR-38
- STEERINGPOWER STEERING GEAR
1922 Author
: Date
:
1997 SUPRA (RM502U)
REMOVAL
1. PLACE FRONT WHEELS FACING STRAIGHT AHEAD
2. REMOVE STEERING WHEEL PAD
(See page SR-1 1)
3. REMOVE STEERING WHEEL
(See page SR-1 1)
4. REMOVE ENGINE UNDER COVER
Remove the 10 bolts.
5. REMOVE FR SUSPENSION MEMBER PROTECTOR
Remove the 4 bolts.
6. DISCONNECT INTERMEDIATE SHAFT
(See page SR-1 1)
7. DISCONNECT RH AND LH TIE ROD ENDS
(See page SA-12)
8. DISCONNECT PRESSURE FEED TUBE
Remove the union bolt and gasket.
9. DISCONNECT RETURN TUBE
Remove the union bolt and 2 gaskets.
10. DISCONNECT PPS SOLENOID CONNECTOR
11. REMOVE RACK HOUSING BRACKET AND GROMMET
Remove the 2 bolts and nuts.
12. REMOVE PS GEAR ASSEMBLY
Remove the 2 bolts and nuts.

SR14B-01
R06961
SST
R07510
SST
SR4371Matchmarks
Z06090
Chisel
R07107SST
- STEERINGPOWER STEERING GEAR
SR-39
1923 Author
: Date
:
1997 SUPRA (RM502U)
DISASSEMBLY
NOTICE:
When using a vise, do not overtighten it.
1. SECURE PS GEAR ASSEMBLY IN VISE
Using SST, secure the gear assembly in a vise.
SST 09612-00012
2. REMOVE 2 TURN PRESSURE TUBES
(a) Remove the union bolt and 2 gaskets.
(b) Using SST, remove the tube.
SST 09633-00020
(c) Remove the 2 union seats from the rack housing.
3. REMOVE RH AND LH TIE ROD ENDS AND LOCK
NUTS
Place matchmarks on the tie rod end and rack end, and loosen
the lock nut.
4. REMOVE RH AND LH CLIPS, RACK BOOTS AND
CLAMPS
NOTICE:

Be careful not to damage the boot.

Mark the RH and LH boots.
5. REMOVE RH AND LH RACK ENDS AND CLAW WASH-
ERS
(a) Using a chisel and a hammer, unstake the washer.
NOTICE:
Avoid any impact to the steering rack.
(b) Using a spanner (22 mm) to hold the steering rack and us-
ing SST, remove the rack end.
SST 09922-10010
NOTICE:

Use SST 09922-10010 in the direction shown in the il-
lustration.

Mark the RH and LH rack ends.

R07108
SST
R07439
SST
Self-Locking
Nut
R07336
Vinyl Tape
R07099
Vinyl Tape SR-40
- STEERINGPOWER STEERING GEAR
1924 Author
: Date
:
1997 SUPRA (RM502U)
6. REMOVE RACK GUIDE SPRING CAP LOCK NUT
Using SST, remove the nut.
SST 09922-10010
NOTICE:
Use SST 09922-10010 in the direction shown in the illustra-
tion.
7. REMOVE RACK GUIDE SPRING CAP, RACK GUIDE
SPRING, RACK GUIDE AND RACK GUIDE SEAT
Using a hexagon wrench (24 mm), remove the cap.
8. REMOVE RACK HOUSING CAP
9. REMOVE SELF- LOCKING NUT, BEARING AND
SPACER
Using SST to stop the control valve shaft rotating, remove the
nut.
SST 09616-00010
10. REMOVE DUST COVER
11. REMOVE CONTROL VALVE HOUSING WITH CON-
TROL VALVE ASSEMBLY
(a) To prevent oil seal lip damage, wind vinyl tape on the ser-
rated part of the control valve shaft.
(b) Using a hexagon wrench (6 mm), remove the 2 bolts.
(c) Remove the O-ring from the housing.
12. REMOVE CONTROL VALVE ASSEMBLY
Using a plastic hammer, tap out the control valve.
NOTICE:
Be careful not to damage the oil seal lip.
13. REMOVE CYLINDER END STOPPER AND 2 SPACERS
Using snap ring pliers, remove the snap ring from the rack hous-
ing.

R07362
Press
Socket Wrench
Extension Bar
W00208
Press
SST
Spacer
SST
Oil Seal
- STEERINGPOWER STEERING GEAR
SR-41
1925 Author
: Date
:
1997 SUPRA (RM502U)
14. REMOVE STEERING RACK AND OIL SEAL
(a) Using an extension bar or brass bar and a press, press
out the rack with the oil seal.
NOTICE:
Take care not to drop the rack.
(b) Remove the oil seal from the rack.
15. REMOVE OIL SEAL AND SPACER
Using SST, press out the oil seal and spacer.
SST 09950-60010 (09951-00280),
09950-70010 (09951-07200)
