windshield wipers TOYOTA SUPRA 2020 Owners Manual (in English)

302-1. QUICK REFERENCE
Supra Owner's Manual
■Switching on
Press the lever up until the
desired position is reached.
• Resting position of the wipers: position 0.
• Rain sensor: position 1.
• Normal wiper speed: position 2.
• Fast wiper speed: position 3.
■Brief wipe and switching off
Press the lever down.
• Switching off: press the lever down until it reaches its stan-
dard position.
• Brief wipe: press the lever down from the standard posi-
tion.
■Activating/deactivating
To activate: press the lever up
once from its standard position,
arrow 1.
To deactivate: press the lever
back into the standard position.
■Adjusting the sensitivity
Turn the thumbwheel on the
wiper lever.
Washer/wiper system
Switching the wipers on/off
and brief wipe
Rain sensor
Cleaning the windshield

1214-1. CONTROLS
Supra Owner's Manual
4
CONTROLS
When driving and during opera-
tion of the turn signals or hazard
warning system, do not fold in
the exterior mirrors, so that the
signal lights on the exterior mir-
ror are easy to see.
Press the lever past the resis-
tance point.
Lightly tap the lever up or down.
The triple turn signal duration
can be adjusted.
Via Toyota Supra Command:
1 "My Vehicle"
2 "Vehicle settings"
3 "Exterior lighting"
4 "One-touch turn signal"
5 Select the desired setting. The setting is stored for the
driver profile currently used.
Press the lever to the resistance
point and hold it there for as
long as you want the turn signal
to flash.
Push the lever forward or pull it
backward.
1
High beams on, arrow 1.
The high beams light up when the
low beams are switched on.
2 High beams off/headlight
flasher, arrow 2.
Do not use the wipers if the
windshield is dry, as this may
damage the wiper blades or
cause them to become worn
more quickly.
Turn signal
Turn signal in exterior mir-
ror
Using turn signals
Triple turn signal activa-
tionSignaling briefly
High beams, headlight
flasher
Washer/wiper system
General information

1224-1. CONTROLS
Supra Owner's Manual
Press the lever up until the
desired position is reached.
Resting position of the wipers,
position 0.
 Rain sensor, position 1.
 Normal wiper speed, position
2.
 Fast wiper speed, position 3. When travel is interrupted with
the wiper system switched on:
when travel continues, the wip-
ers resume at their previous
speed.
Press the lever down.

Switching off: press the lever
down until it reaches its stan-
dard position.
 Brief wipe: press the lever
down from the standard posi-
tion.
The lever automatically returns to
its initial position when released.
The rain sensor automatically
controls the time between wipes
depending on the intensity of the
rainfall.
The sensor is located on the
Safety information
WA R N I N G
If the wipers star
t moving in the
folded away state, body parts can
be jammed or damage may occur
to parts of the vehicle. There is a
risk of injury or r isk of damage to
property. Make sure that the vehi-
cle is switched off when the wip-
ers are in the folded away state
and the wipers are folded in when
switching on.
NOTICE
If the wipers are frozen to the
windshield, the wiper blades can
be torn off and the wiper motor
can overheat when switching on.
There is a risk of damage to prop-
erty. Defrost the windshield prior
to switching the wipers on.
Switching on
Switching off and brief
wipe
Rain sensor
Concept
General information

1234-1. CONTROLS
Supra Owner's Manual
4
CONTROLS
windshield, directly in front of
the interior mirror.
Press the lever up once from its
standard position, arrow 1.
Wiping is started.
The LED in the wiper lever is
illuminated.
If wipers are frozen to wind-
shield, wiper operation is deacti-
vated.
Press the lever back into the
standard position. Turn the thumbwheel to adjust
the sensitivity of the rain sensor.
Upward: high rain sensor sensi-
tivity.
Downward: low rains sensor
sensitivity.
Safety information
NOTICE
If the rain sensor
is activated, the
wipers can accidentally start mov-
ing in vehicle wash es. There is a
risk of damage to property. Deac-
tivate the rain sensor in vehicle
washes.
Activating
Deactivating
Adjusting the rain sensor
sensitivity
Windshield washer system
Safety information
WA R N I N G
The washer fluid can freeze onto
the window at low temperatures
and obstruct the view. There is a
risk of an accident. Only use the
washer systems, if the washer
fluid cannot fr eeze. Use washer
fluid with antifreeze, if needed.
NOTICE
When the washer fluid reservoir is
empty, the wash pump cannot
work as intended. There is a risk
of damage to property. Do not use
the washer system when the
washer fluid reservoir is empty.

1244-1. CONTROLS
Supra Owner's Manual
Pull the lever.
The system sprays washer fluid
on the windshield and activates
the wipers briefly.
The windshield washer nozzles
are automatically heated while
standby state is switched on.
The fold-out position enables
the wipers to be folded away
from the windshield.
Important, for instance when
changing the wiper blades or
when folding out under frosty
conditions.1
Switch on standby state.
2 Press and hold the wiper
level down, until the wipers
stop in a close to vertical
position.
Cleaning the windshield
Windshield washer nozzles
Fold-away position of the
wipers
Concept
General information
Safety information
WA R N I N G
If the wipers start moving in the
folded away state, body parts can
be jammed or damage may occur
to parts of the veh icle. There is a
risk of injury or risk of damage to
property. Make sure that the vehi-
cle is switched off when the wip-
ers are in the folded away state
and the wipers are folded in when
switching on.
NOTICE
If the wipers are frozen to the
windshield, the wiper blades can
be torn off and th e wiper motor
can overheat whe n switching on.
There is a risk of damage to prop-
erty. Defrost the windshield prior
to switching the wipers on.
Folding away the wipers

1254-1. CONTROLS
Supra Owner's Manual
4
CONTROLS
3 Fold the wipers all the way
away from the windshield.
After the wipers are folded back
down, the wiper system must be
reactivated.
1 Fold the wipers back down
onto the windshield.
2 Switch on standby state and
press and hold the wiper
lever down again.
3 Wipers return to their resting
position and are ready again
for operation.
The Automatic transmission
combines the functions of man-
ual shifting, if needed. Selector lever position for nor-
mal vehicle operation. All gears
for forward travel are activated
automatically.
Engage selector lever position R
only when the vehicle is station-
ary.
The vehicle may be pushed or
roll without power, for instance
in vehicle washes, refer to page
127, in selector lever position N.
Selector lever position, for
instance for parking the vehicle.
The transmission blocks the
drive wheels in selector lever
position P.
Engage selector lever position P
only when the vehicle is station-
Folding down the wipers
Automatic transmission
Concept
Safety information
WA R N I N G
An unsecured vehicle can begin
to move and possibly roll away.
There is a risk of an accident.
Before exiting, secure the vehicle
against rolling, f
or instance with
the parking brake.
Selector lever positions
Drive mode D
Reverse R
Neutral N
Parking position P

2906-1. MOBILITY
Supra Owner's Manual
1Pull lever, arrow 1.
Hood is unlocked.
2After the lever is released,
pull the lever again, arrow 2.
Hood can be opened.
3Be careful of protruding parts
on the hood.
Energetically close the hood
from approx. 20 in/50 cm.
WA R N I N G
The engine compartment accom-
modates moving components.
Certain components in the engine
compartment can also move with
the vehicle switched off, for
instance the radiator fan. There is
a risk of injury. Do not reach into
the area of moving parts. Keep
articles of clothing and hair away
from moving parts.
WA R N I N G
There are protruding parts, for
instance locking hook, on the
inside of the hood. There is a risk
of injury. If the hood is open, pay
attention to protruding parts and
keep clear of these areas.
WA R N I N G
An incorrectly locked hood can
open while driving and restrict vis-
ibility. There is a risk of an acci-
dent. Stop immediately and
correctly close the hood.
WA R N I N G
Body parts can be jammed when
opening and closing the hood.
There is a risk of injury. Make sure
that the area of movement of the
hood is clear during opening and
closing.
NOTICE
Folded-away wipers can be
jammed when the hood is
opened. There is a risk of damage
to property. Mak e sure that the
wipers with the wiper blades
mounted are folded down onto the
windshield before opening the
hood.
NOTICE
When the hood is closed, it must
engage on both sides. Pressing
again can damage the hood.
There is a risk of damage to prop-
erty. Open the hood again and
then close it energetically. Avoid
pressing again.
Opening
Closing

3026-1. MOBILITY
Supra Owner's Manual
This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.
The onboard vehicle tool kit is
located under a cover on the
right side of the cargo area.
Unlock the cover of the right
side panel, arrow 1, and fold
open, arrow 2. 1
To change the wiper blades,
fold up the wiper arms, refer
to page 124.
2 Lift the wiper all the way off of
the windshield.
Replacing components
Vehicle features and
options
Onboard vehicle tool kit
Wiper blades
Safety information
NOTICE
The window may sustain damage
if the wiper falls onto it without the
wiper blade installed. There is a
risk of damage to property. Hold
the wiper firmly when changing
the wiper blade. Do not fold or
switch on the wip er without a
wiper blade installed.
NOTICE
Folded-away wipers can be
jammed when the hood is
opened. There is a risk of damage
to property. Make sure that the
wipers with the wiper blades
mounted are folded down onto the
windshield before opening the
hood.
Replacing the front wiper
blades
