TOYOTA T100 1996 Factory Service Manual

Downloaded from www.Manualslib.com manuals search engine RS03Y−02
Z09743
Front RS−30
− SUPPLEMENTAL RESTRAINT SYSTEMFRONT AIRBAG SENSOR
1996 TOYOTA T100 (RM449U)
INSTALLATION
1. INSTALL FRONT AIRBAG SENSOR
(a) Install the sensor so that the arrow on the sensor faces
toward the front of the vehicle.
(b) Using a torx wrench, install the sensor with 2 screws.
Torx wrench: T40 (Part No. 09042−00020 or locally
manufactured tool)
Torque: 29 N·m (300 kgf·cm, 22 ft·lbf)
(c) Connect the connector.
NOTICE:
Make sure the sensor is installed to the specified
torque.
If the sensor has been dropped, or there are cracks,
dents or other defects in the case, brackets or con-
nector, replace the removed sensor, always replace
the set bolts with new ones.
The sensor set bolts which have been anti−rust
treated. When the sensor is removed, always replace
the set bolts with new ones.
After installation, shake the sensor to check that
there is no looseness.
The front sensor is equipped with an electrical con-
nection check mechanism. Be sure to lock this mech-
anism securely when connecting the connector . If
the connector is not securely locked, a malfunction
code will be detected by the diagnostic system.
2. INSTALL REMOVED PARTS

Downloaded from www.Manualslib.com manuals search engine RS03Z−02
R12498
SRS Warning Light
Steering Wheel Pad
(with Airbag) Front Airbag Sensor RH
Front Airbag Sensor LH
Spiral Cable
Center Airbag Sensor Assembly
− SUPPLEMENTAL RESTRAINT SYSTEMWIRE HARNESS AND CONNECTOR
RS−31
1798 Author: Date:
1996 TOYOTA T100 (RM449U)
WIRE HARNESS AND CONNECTOR
LOCATION

Downloaded from www.Manualslib.com manuals search engine RS040−01
RS−32
− SUPPLEMENTAL RESTRAINT SYSTEMWIRE HARNESS AND CONNECTOR
1996 TOYOTA T100 (RM449U)
INSPECTION
HINT:
The SRS wire harness is integrated with the cowl wire harness assembly and floor wire harness assembly.
The wires for the SRS wire harness are encased in a yellow corrugated tube and all the connectors in the
system are a standard yellow color.
1. VEHICLES NOT INVOLVED IN COLLISION
Do a diagnostic system check.
(See page DI−365)
2. VEHICLES INVOLVED IN COLLISION
(a) Do a diagnostic system check.
(See page DI−365)
(b) Check for breaks in all wires of the SRS wire harness, and for exposed conductors.
(c) Check to see if the SRS wire harness connectors are cracked or chipped.

Downloaded from www.Manualslib.com manuals search engine RS041−01
− SUPPLEMENTAL RESTRAINT SYSTEMWIRE HARNESS AND CONNECTOR
RS−33
1996 TOYOTA T100 (RM449U)
REPLACEMENT
In the following cases,replace the wire harness or connector.
If any part of the SRS wire harness or any connector has been found to be faulty in troubleshoot-
ing.
If any part of the SRS wire harness or any connector has been found to be faulty during the check
in items (See page RS−32).
CAUTION:
If the wire harness used in the SRS is damaged, replace the whole wire harness assembly.
When the connector to the front airbag sensors can be repaired alone (when there is no damage
to the wire harness), use the repair wire specially designed for this purpose.

Downloaded from www.Manualslib.com manuals search engine BE – BODY ELECTRICAL

BODY ELECTRICAL SYSTEM BE-1
POWER SOURCE BE-10
IGNITION SWITCH AND KEY UNLOCK
WARNING SWITCH BE-11
HEADLIGHT AND TAILLIGHT SYSTEM BE-14
TURN SIGNAL AND HAZARD
WARNING SYSTEM BE-22
INTERIOR LIGHT SYSTEM BE-24
BACK-UP LIGHT SYSTEM BE-26
STOP LIGHT SYSTEM BE-29
WIPER AND WASHER SYSTEM BE-31
COMBINATION METER BE-35
POWER WINDOW CONTROL SYSTEM BE-46
POWER DOOR LOCK CONTROL
SYSTEM BE-50
POWER MIRROR CONTROL SYSTEM BE-56
AUDIO SYSTEM BE-59
ANTENNA BE-81
CLOCK BE-83

Downloaded from www.Manualslib.com manuals search engine BE01E−07
− BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE−1
1801 Author: Date:
1996 TOYOTA T100 (RM449U)
BODY ELECTRICAL SYSTEM
PRECAUTION
Take care to observe the following precautions when performing inspections or removal and replacement
of body electrical related parts.
1. LIGHTING SYSTEM
Halogen bulbs have pressurized gas inside and require special handling.
They can burst or scatter if scratched or dropped. Hold a bulb only by its plastic or metal case.
Don’t touch the glass part of a bulb with bare hands.
2. SRS (SUPPLEMENTAL RESTRAINT SYSTEM)
The TOYOTA T100 is equipped with an SRS (Supplemental Restraint System) such as the driver airbag.
Failure to carry out service operations in the correct sequence could cause the SRS to unexpectedly deploy
during servicing, possibly leading to a serious accident. Before servicing (including removal or installation
of parts, inspection or replacement), be sure to read the precautionary notices in the RS section.
3. AUDIO SYSTEM
If the battery negative (−) terminal is disconnected, the preset AM, FM 1 and FM 2 stations stored in
memory are erased, so be sure to note the stations and reset them after the battery terminal is recon-
nected.
If the battery negative (−) terminal is disconnected, the ”ANTI−THEFT SYSTEM” will operate when the
terminal is reconnected, but the radio, tape player and CD player will not operate. Be sure to input the
correct ID number so that the radio, tape player and CD player can be operated again.
4. MOBILE COMMUNICATION SYSTEM
If the vehicle is equipped with a mobile communication system, refer to precautions in the IN section.

Downloaded from www.Manualslib.com manuals search engine BE01F−10
BE−2
− BODY ELECTRICALBODY ELECTRICAL SYSTEM
1996 TOYOTA T100 (RM449U)
PROBLEM SYMPTOMS TABLE
The table below will be useful for you in troubleshooting these electrical problems. The most likely causes
of the malfunction are shown in the order of their probability. Inspect each part in the order shown, and re-
place the part when it is found to be faulty.
USA:
HEADLIGHT AND TAILLIGHT SYSTEM
SymptomSuspect AreaSee page
Headlight does not light up
(Taillight is normal)
1. HEAD Fuse (Relay Block)
2. Light Control Switch
3. Headlight Dimmer Switch
4. Headlight BulbBE−14
BE−17
BE−17
BE−17
Headlight does not light up
(Taillight does not light up)
1. Light Control Switch
2. Headlight Dimmer Switch
3. Wire Harness
4. Headlight BulbBE−17
BE−17
−
−
Only one light comes on
1. HEAD Fuse (Relay Block)
2. Wire Harness
3. Headlight BulbBE−14
−
−
”Lo−Beam” does not light up
1. Headlight Control Relay
2. Headlight Dimmer Relay
3. Headlight Dimmer Switch
4. Wire Harness
5. Headlight BulbBE−17
BE−17
BE−17
−
−
”Hi−Beam” does not light up
1. Headlight Control Relay
2. Headlight Dimmer Relay
3. Headlight Dimmer Switch
4. Wire Harness
5. Headlight BulbBE−17
BE−17
BE−17
−
−
”Flash” does not light up
1. Headlight Control Relay
2. Headlight Dimmer Relay
3. Headlight Dimmer Switch
4. Wire Harness
5. Headlight BulbBE−17
BE−17
BE−17
−
−
Taillight does not light up
(Headlight does not light up)
1. TAIL Fuse (Junction Block No.1)
2. Light Control Switch
3. Wire Harness
4. Headlight BulbBE−17
BE−17
−
−
Taillight does not light up
(Headlight is normal)
1. TAIL Fuse (Junction Block No.1)
2. Light Control Switch
3. Taillight Control Relay
4. Wire Harness
5. Taillight BulbBE−14
BE−17
BE−17
−
−
Only one light goes out or does not light up1. Wire Harness
2. Taillight Bulb−
−
Rear Combination light does not light up
1. TAIL Fuse (Junction Block No.1)
2. Wire Harness
3. Taillight BulbBE−14
−
−
”Light−on warning system” does not operate.
1. Integration Relay
2. DOME Fuse (Relay Block)
3. GAUGE Fuse (Junction Block No.1)
4. Door Courtesy Switch
5. Wire HarnessBE−17
BE−14
BE−14
BE−25
−

Downloaded from www.Manualslib.com manuals search engine − BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE−3
1996 TOYOTA T100 (RM449U)
CANADA:
HEADLIGHT AND TAILLIGHT SYSTEM
SymptomSuspect AreaSee page
Only one side headlight does not light up.1. Headlight Bulb
2. Wire Harness−
−
”Lo−Beam” does not light up. (ALL)
1. D.R.L. Relay
2. Headlight Dimmer Relay
3. Headlight Control Relay
4. Headlight Dimmer Switch
5. Wire HarnessBE−14
BE−17
BE−17
BE−17
−
”Lo−Beam” does not light up. (ONE SIDE)
1. HEAD LH−Lo Fuse (Relay Block)
2. HEAD RH−Lo Fuse (Relay Block)
3. Headlight Bulb
4. Wire HarnessBE−14
BE−14
−
−
”Hi−Beam” does not light up. (ALL)
1. DRL Fuse (Junction Block No.1)
2. Headlight Dimmer Relay
3. Headlight Control Relay
4. Headlight Dimmer Switch
5. Wire HarnessBE−14
BE−17
BE−17
BE−17
−
”Hi−Beam” does not light up. (ONE SIDE)
1. HEAD LH−Hi Fuse (Relay Block)
2. HEAD RH−Hi Fuse (Relay Block)
3. Headlight Bulb
4. Wire HarnessBE−14
BE−14
−
−
”Flash” does not light up.1. Headlight Dimmer Switch
2. Wire HarnessBE−17
−
Headlight does not light up.
(Taillight is normal)
1. Headlight Control Relay
2. D.R.L. Relay
3. D.R.L. No.4 Relay
4. D.R.L. Resistor
5. Headlight Dimmer Switch
6. Light Control Switch
7. Headlight Bulb
8. Wire HarnessBE−17
BE−17
BE−17
BE−17
BE−17
BE−17
−
−
Headlight does not light up.
(Taillight does not light up)
1. Headlight Control Relay
2. D.R.L. Relay
3. D.R.L. No.4 Relay
4. D.R.L. Resistor
5. Headlight Dimmer Switch
6. Light Control Switch
7. Headlight Bulb
8. Wire HarnessBE−17
BE−17
BE−17
BE−17
BE−17
BE−17
−
−
Only one side taillight does not light up.1. Taillight Bulb
2. Wire Harness−
−
Taillight does not light up.
(Headlight is normal)
1. TAIL Fuse (Junction Block No.1)
2. Taillight Control Relay
3. Light Control Switch
4. Taillight Bulb
5. Wire HarnessBE−14
BE−17
BE−17
−
−
Taillight does not light up.
(Headlight does not light up)1. Light Control Switch
2. Taillight Bulb
3. Wire HarnessBE−17
−
−
Headlight does not light up with light control SW in HEAD.
1. Light Control Switch
2. D.R.L. Relay
3. D.R.L. No.4 Relay
4. Wire HarnessBE−17
BE−17
BE−17
−

Downloaded from www.Manualslib.com manuals search engine BE−4
− BODY ELECTRICALBODY ELECTRICAL SYSTEM
1996 TOYOTA T100 (RM449U) Headlight does not go out with light control SW in OFF.
1. Headlight Control Relay
2. Light Control Switch
3. Wire HarnessBE−17
BE−17
−
Taillight does not light up with light control SW in TAIL.
1. Taillight Control Relay
2. Light Control Switch
3. Wire HarnessBE−17
BE−17
−
Taillight does not go out with light control SW in OFF.
1. Taillight Control Relay
2. Light Control Switch
3. Wire HarnessBE−17
BE−17
−
Headlight do not light up with engine running, parking brake SW
and light control SW in OFF.
1. ECU−B Fuse (Junction Block No.1)
2. GAUGE Fuse (Junction Block No.1)
3. DRL Fuse (Junction Block No.1)
4. D.R.L. Relay
5. D.R.L. No.4 Relay
6. D.R.L. Resistor
7. Wire Harness
8. Generator L Terminal
9. Parking Brake SwitchBE−14
BE−14
BE−14
BE−17
BE−17
BE−17
−
−
BE−38
”Light−on warning system” does not operate.
1. Integration Relay
2. DOME Fuse (Relay Block)
3. GAUGE Fuse (Junction Block No.1)
4. Door Courtesy Switch
5. Wire HarnessBE−17
BE−14
BE−14
BE−25
−
TURN SIGNAL AND HAZARD WARNING SYSTEM
SymptomSuspect AreaSee page
”Hazard” and ”Turn” do not light up
1. Hazard Warning Switch
2. Turn Signal Flasher
3. Wire HarnessBE−23
BE−23
−
The flashing frequency is abnormal
1. Bulb
2. Turn Signal Switch
3. Wire Harness−
BE−23
−
Hazard warning light does not light up
(Turn signal is normal)1. HAZ−HORN Fuse (Relay Block)
2. Wire HarnessBE−22
−
Hazard warning light does not light up in one direction1. Hazard Warning Switch
2. Wire HarnessBE−23
−
*1 Turn signal does not light up
1. Ignition Switch
2. TURN Fuse (Junction Block No.1)
3. Turn Signal Switch
4. Wire HarnessBE−12
BE−22
BE−23
−
*2 Turn signal does not light up
1. TURN Fuse (Junction Block No.1)
2. Turn Signal Switch
3. Wire HarnessBE−22
BE−23
−
Turn signal does not light up in one direction1. Turn Signal Switch
2. Wire HarnessBE−23
−
Only one bulb does not light up1. Bulb
2. Wire Harness−
−
*1: Combination Meter, Wiper and Washer do not operate.
*
2: Combination Meter, Wiper and Washer are normal.

Downloaded from www.Manualslib.com manuals search engine − BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE−5
1996 TOYOTA T100 (RM449U)
INTERIOR LIGHT SYSTEM
SymptomSuspect AreaSee page
Room light does not light up
1. DOME Fuse (Relay Block)
2. Room Light Switch
3. Door Courtesy Switch
4. Wire Harness
5. BulbBE−24
BE−25
BE−25
−
−
Room light remains always on
1. Room Light Switch
2. Door Courtesy Switch
3. Wire HarnessBE−25
BE−25
−
BACK−UP LIGHT SYSTEM
SymptomSuspect AreaSee page
Back−Up Light does not light up
1. GAUGE Fuse (Junction Block No.1)
2. Ignition Switch
3. Back−Up Light Relay (Column A/T)
4. Back−Up Light Switch (M/T)
5. PNP Switch (A/T)
6. Bulb
7. Wire HarnessBE−26
BE−12
BE−28
BE−28
DI−306
−
−
Back−Up Light remains always on1.Wire Harness−
Only one light does not light up1. Bulb
2. Wire Harness−
−
STOP LIGHT SYSTEM
SymptomSuspect AreaSee page
Stop light does not light up
1. STOP Fuse (Junction Block No.1)
2. Stop Light Switch
3. Wire Harness
4. BulbBE−29
BE−30
−
−
Stop light remains always on1. Stop Light Switch
2. Wire HarnessBE−30
−
Only one light does not light up1. Wire Harness
2. Bulb−
−
WIPER AND WASHER SYSTEM
SymptomSuspect AreaSee page
Wiper does not operate or turn to off position
1. WIPER Fuse (Junction Block No.1)
2. Ignition Switch
3. Wiper and Washer Switch
4. Wiper Motor
5. Wire HarnessBE−31
BE−12
BE−32
BE−32
−
Wiper does not operate in INT position
1. Wiper and Washer Switch
2. Wiper Motor
3. Wire HarnessBE−32
BE−32
−
Washer does not operate
1. Wiper and Washer Switch
2. Washer Hose and Nozzle
3. Washer Motor
4. Wire HarnessBE−32
−
BE−32
−
