engine TOYOTA T100 1996 Factory Service Manual

Downloaded from www.Manualslib.com manuals search engine − DIAGNOSTICSENGINE (3RZ−FE)
DI−97
1996 TOYOTA T100 (RM449U)
DTC P0510 Closed Throttle Position Switch Malfunction
CIRCUIT DESCRIPTION
Refer to DTC P0120 on page DI−39.
DTC No.DTC Detecting ConditionTrouble Area
P0510
Closed throttle position switch does not turn ON even once
when vehicle is driven
(2 trip detection logic)Open in closed throttle position switch circuit
Closed throttle position switch
ECM
HINT:
After confirming DTC P0510 use the TOYOTA hand−held tester to confirm the closed throttle position switch
signal from ”CURRENT DATA”.
Throttle ValveClosed Throttle Position Switch SignalMalfunction
Fully closedOFFOpen circuit
Fully openONShort circuit
WIRING DIAGRAM
Refer to DTC P0120 on page DI−39.
INSPECTION PROCEDURE
HINT:
If DTC P0110, P0115 and P0120 are output simultaneously, E2 (sensor ground) may be open.
TOYOTA hand−held tester:
1 Connect TOYOTA hand−held tester and read CTP switch signal.
PREPARATION:
(a) Connect the TOYOTA hand−held tester to the DLC3.
(b) Turn the ignition switch ON and push the TOYOTA hand−held tester main switch ON.
CHECK:
Read CTP switch signal on the TOYOTA hand−held tester.
RESULT:
Throttle ValveClosed Throttle Position Switch SignalMalfunction
Fully closedOFFOpen circuit: Go to step 2
Fully openONShort circuit: Go to step 4
DI0U0−03

Downloaded from www.Manualslib.com manuals search engine P19557BE6653
A00084
ON
ECM
1
2
3
411
11 1 0
12 11
99
Throttle Position
Sensor
E6
E6
(M/T)(A/T)5 V
VCC
VTA
IDL
E2B+
E1 E6 E6
E6 E6
E6 E6
DI−98
− DIAGNOSTICSENGINE (3RZ−FE)
1996 TOYOTA T100 (RM449U)
2 Check for open in harness or ECM.
PREPARATION:
(a) Connect the TOYOTA hand−held tester to the DLC3.
(b) Disconnect the throttle position sensor connector.
(c) Connect the sensor wire harness terminals between ter-
minals 3 and 4.
(d) Turn the ignition switch ON.
CHECK:
Read CTP switch signal on the TOYOTA hand−held tester.
OK:
CTP switch signal: ON
OK Confirm good connection at sensor.
If OK, replace throttle position sensor.
NG

Downloaded from www.Manualslib.com manuals search engine BE6653
P19556
P19711
P19687
A00085
ON
ECM
1
2
3
411
11 1 0
11
99
Throttle Position
Sensor
E6 E6
(M/T)(A/T)5 V
VCC
VTA
IDL
E2B+
E1
12
For M/T
For A/TE2
E2
IDL (+)
IDL (+)
E6 E6
E6 E6
E6 E6
− DIAGNOSTICSENGINE (3RZ−FE)
DI−99
1996 TOYOTA T100 (RM449U)
3 Check for open in harness or ECM.
PREPARATION:
(a) Remove the right cowl side trim (See page MF−50).
(b) Connect between terminals IDL and E2 of the ECM con-
nector.
HINT:
Throttle position sensor connector is disconnected.
Before checking, do a visual check and contact pressure check
for the connector (See page IN−26).
(c) Turn the ignition switch ON.
CHECK:
Read CTP switch signal on the TOYOTA hand−held tester.
OK:
CTP switch signal: ON
OK Open in harness between ECM and throttle
position sensor, repair or replace harness.
NG
Confirm connection at ECM.
If OK, replace ECM.

Downloaded from www.Manualslib.com manuals search engine A00682
ON
ECM
1
2
3
411
11 1 0
12 11
99
Throttle Position
Sensor
E6 E6
(M/T)(A/T)5 V
VCC
VTA
IDL
E2
B+
E1
E6 E6
E6 E6
E6 E6
DI−100
− DIAGNOSTICSENGINE (3RZ−FE)
1996 TOYOTA T100 (RM449U)
4 Check for short in harness or ECM.
PREPARATION:
(a) Connect the TOYOTA hand−held tester to the DLC3.
(b) Disconnect the throttle position sensor connector.
(c) Turn the ignition switch ON.
CHECK:
Read CTP switch signal on the TOYOTA hand−held tester.
OK:
CTP switch signal: OFF
OK Confirm good connection at sensor.
If OK, replace throttle position sensor.
NG

Downloaded from www.Manualslib.com manuals search engine A00683
1
2
3
411
11 1 0
12 11
99E6 E6
(M/T)(A/T)5 V
VCC
VTA
IDL
E2
B+
E1E6 E6
E6 E6
E6E6
ON
For M/T
For A/TE6 Connector
E6 Connector
− DIAGNOSTICSENGINE (3RZ−FE)
DI−101
1996 TOYOTA T100 (RM449U)
5 Check for short in harness or ECM.
PREPARATION:
(a) Remove right cowl side trim (See page MF−50).
(b) Disconnect the E6 connector of the ECM.
(c) Turn the ignition switch ON.
HINT:
Throttle position sensor connector is disconnected.
CHECK:
Read CTP switch signal on TOYOTA hand−held tester.
OK:
CTP switch signal: OFF
OK Short in harness between ECM and throttle
position sensor, repair or replace harness.
NG
Confirm connection at ECM.
If OK, replace ECM.

Downloaded from www.Manualslib.com manuals search engine BE6653
P24209
A00086
ON
ECM
1
2
3
411
11 1 0
11
99
Throttle Position
Sensor
E6 E6
(M/T)(A/T)5 V
VCC
VTA
IDL
E2B+
E1
12
(+)
(−)E6 E6
E6 E6
E6
E6
DI−102
− DIAGNOSTICSENGINE (3RZ−FE)
1996 TOYOTA T100 (RM449U)
OBD II scan tool (excluding TOYOTA hand−held tester):
1 Check for open in harness or ECM.
PREPARATION:
(a) Disconnect the throttle position sensor connector.
(b) Turn the ignition switch ON.
CHECK:
Measure voltage between terminals 3 and 4 of throttle position
sensor connector.
OK:
Voltage: 9 − 14 V
OK Confirm good connection at sensor.
If OK, replace throttle position sensor.
NG
2 Check for open in harness and connector between throttle position sensor and
ECM (See page IN−26).
NG Open in harness between ECM and throttle
position sensor.
OK
Confirm connection at ECM.
If OK, replace ECM.

Downloaded from www.Manualslib.com manuals search engine S00874
IG Switch
(M/T)(A/T)
23ECM
E7 E7 1
AM2
IA3
8W−RW−R
8
2
27
B−R
R−L
W Battery
IE1R/B No.2B−R
B−R
25 V
Tr
1
20
317
E7 E7 14B−L
B−Y2
1 Tr
2
3 4
Tachometer To To
Spark plug
B−W
Igniter IgnitionCoil
IGT
IGF 5
− DIAGNOSTICSENGINE (3RZ−FE)
DI−103
1996 TOYOTA T100 (RM449U)
DTC P1300 Ignition Circuit Malfunction
CIRCUIT DESCRIPTION
The ECM determines the ignition timing, turns on Tr1 at a predetermined angle (°CA) before the desired igni-
tion timing and outputs an ignition signal (IGT) ”1” to the igniter.
Since the width of the IGT signal is constant, the dwell angle control circuit in the igniter determines the time
the control circuit starts primary current flow to the ignition coil based on the engine rpm and ignition timing
one revolution ago, that is, the time the Tr
2 turns on.
When it reaches the ignition timing, the ECM turns Tr
1 off and outputs the IGT signal ”0”.
This turns Tr
2 off, interrupting the primary current flow and generating a high voltage in the secondary coil
which causes the spark plug to spark. Also, by the counter electromotive force generated when the primary
current is interrupted, the igniter sends an ignition confirmation signal (IGF) to the ECM. The ECM stops fuel
injection as a fail safe function when the IGF signal is not input to the ECM.
DTC No.DTC Detecting ConditionTrouble Area
P1300No IGF signal to ECM for 4 consecutive IGT signal during
engine runningOpen or short in IGF or IGT circuit from igniter to ECM
Igniter
ECM
WIRING DIAGRAM
DI0U1−03

Downloaded from www.Manualslib.com manuals search engine DI−104
− DIAGNOSTICSENGINE (3RZ−FE)
1996 TOYOTA T100 (RM449U)
INSPECTION PROCEDURE
1 Check spark plug and spark (See page IG−1).
NG Go to step 4.
OK
2 Check for open and short in harness and connector in IGF signal circuit between
ECM and igniter (See page IN−26).
NG Repair or replace harness or connector.
OK

Downloaded from www.Manualslib.com manuals search engine BE6653
P24210
P24211
A00087
ON
IGF (+) For M/T
For A/T
IGF (+)
− DIAGNOSTICSENGINE (3RZ−FE)
DI−105
1996 TOYOTA T100 (RM449U)
3 Disconnect igniter connector and check voltage between terminal IGF of ECM
connector and body ground.
PREPARATION:
(a) Disconnect the igniter connector.
(b) Remove the right cowl side trim (See page MF−50).
(c) Turn the ignition switch ON.
CHECK:
Measure voltage between terminal IGF of ECM connector and
body ground.
OK:
Voltage: 4.5 − 5.5 V
OK Replace igniter.
NG
Check and replace ECM (See page IN−26).
4 Check for open and short in harness and connector in IGT signal circuit between
ECM and igniter (See page
IN−26).
NG Repair or replace harness or connector.
OK

Downloaded from www.Manualslib.com manuals search engine BE6653
P24212
P24213
A00088
START
IGT (+) For M/T
For A/T
IGT (+)
FI6680
IGT
IGF
0 V 0 V
10 msec./Division (Iding) IGT signal waveform
2 V/
Division
DI−106
− DIAGNOSTICSENGINE (3RZ−FE)
1996 TOYOTA T100 (RM449U)
5 Check voltage between terminals IGT of ECM connector and body ground.
PREPARATION:
Remove the right cowl side trim (See page MF−50).
CHECK:
Measure voltage between terminals IGT of ECM connector and
body ground when engine is cranked.
OK:
Voltage: More than 0.1 V and less than 4.5 V
Reference: INSPECTION USING OSCILLOSCOPE
During cranking or idling, check waveform between terminals
IGT and E1 of ECM.
HINT:
The correct waveforms are as shown.
NG Check and replace ECM (See page IN−26).
OK
