MA−12
− MAINTENANCECHASSIS
47 Author: Date:
1996 TOYOTA T100 (RM449U)
(f) Check that the fluid level is in the ”HOT” range at the nor-
mal operating temperature (70 − 80°C or 158 − 176°F)
and add as necessary.
NOTICE:
Do not overfill.
10. REPACK FRONT WHEEL BEARINGS AND THRUST
BUSH
(a) Change the front wheel bearing grease.
(2WD: See page SA−19)
(4WD: See page SA−25)
(b) Repack the drive shaft thrust bush grease (See page
SA−41).
11. 4WD:
LUBRICATE PROPELLER SHAFT
Lubricate propeller shaft, referring to the lubrication chart. Be-
fore pumping in grease, wipe off any mud and dust on the
grease fitting.
Grease grade:
Propeller shaft (Except Double−cardan joint)
Lithium base chassis grease NLGI No.2
Double−cardan joint
Molybdenum disulphide lithium base chassis grease
NLGI No.2

Downloaded from www.Manualslib.com manuals search engine MA0568
B02099
B02100
− MAINTENANCECHASSIS
MA−13
48 Author: Date:
1996 TOYOTA T100 (RM449U)
12. TIGHTEN BOLTS AND NUTS ON CHASSIS AND BODY
(a) Tighten these parts:
Seat mounting bolts
Torque:
37 N·m (375 kgf·cm, 27 ft·lbf)

2WD:
Strut bar bracket−to−frame mounting bolts
Torque: 52 N·m (530 kgf·cm, 38 ft·lbf)
Leaf spring U−bolt mounting nuts
Torque: 133 N·m (1,350 kgf·cm, 98 ft·lbf )
(b) Under Severe Conditions:
In addition to the above maintenance items, check for
loose or missing bolts and nuts on the following.
Steering system
Drive train
Suspension system
Fuel tank mounts
Engine mounts, etc.
13. FINAL INSPECTION
(a) Check operation of body parts:
Hood:
Auxiliary catch operates properly
Hood locks securely when closed
Doors:
Door locks operate properly
Doors close properly
Seats:
Seat adjusts easily and locks securely in any
positions
Seat backs lock securely at any angle
Fold−down seat backs lock securely
(b) Road test:
Engine and chassis parts do not have abnormal
noises.
Vehicle does not wander or pull to one side.
Brakes work properly and do not drag.

Downloaded from www.Manualslib.com manuals search engine MA−14
− MAINTENANCECHASSIS
49 Author: Date:
1996 TOYOTA T100 (RM449U)
(c) Be sure to deliver a clean vehicle and especially check:
Steering wheel
Shift lever knob
All switch knobs
Door handles
Seats
