radiator cap TOYOTA T100 1996 Factory Service Manual

Downloaded from www.Manualslib.com manuals search engine PP0GF−02
PP−26
− PREPARATIONCOOLING (3RZ−FE)
1996 TOYOTA T100 (RM449U)
EQUIPMENT
HeaterThermostat
Radiator cap tester
ThermometerThermostat
Torque wrench

Downloaded from www.Manualslib.com manuals search engine PP01J−02
PP−30
− PREPARATIONCOOLING (5VZ−FE)
1996 TOYOTA T100 (RM449U)
EQUIPMENT
Heater
Radiator cap tester
Thermometer
Torque wrench

Downloaded from www.Manualslib.com manuals search engine SS−8
− SERVICE SPECIFICATIONSENGINE MECHANICAL (3RZ−FE)
1996 TOYOTA T100 (RM449U) Oil strainer x Cylinder block
1818513
Oil pan x Cylinder block12.51309
Crankshaft position sensor x Timing chain cover8.58574 in.·lbf
Generator bracket x Cylinder block74.576055
Generator bracket x Timing chain cover1818513
Generator adjusting bar x Timing chain cover63.565047
A/C compressor bracket x Cylinder block4444032
A/C compressor x A/C compressor bracket2525018
Water pump pulley x Water pump2121016
Connecting rod cap x Connecting rod 1st
2nd45
Turn 90°46033
Main bearing cap x Cylinder block 1st
2nd39
Turn 90°40029
No.1 balance shaft x Timing gear3636526
No.2 balance shaft x Timing sprocket3636526
Balance shaft x Cylinder block1818513.4
Rear oil seal retainer x Cylinder block13.51359.7
RH, LH engine mounting bracket x Cylinder block4545034
Oil dipstick guide x LH engine mounting bracket2020014
Oil filter bracket union, Engine coolant drain plug x Cylinder block2525018
Oil filter bracket x Cylinder block2829021
Water bypass pipe x Cylinder block2020014
Knock sensor x Cylinder block3738027
Fuel filter x Cylinder block2020014
Rear end plate x Cylinder block1818513
Rear end plate x Water bypass pipe2020014
Flywheel x Crankshaft 1st
2nd26.5
Turn 90°27019
Front crossmember x Engine rear mounting bracket2526019
Front exhaust pipe clamp x Exhaust manifold6263046
Exhaust support bracket x Transmission3940029
Front exhaust pipe clamp1919514
Front exhaust pipe x TWC3940029
Engine rear mounting bracket x Engine rear mounting insulator1818313
Engine front mounting insulator x Frame3838728
Clutch release cylinder bracket x Transmission3940029
Clutch release cylinder x Transmission131309
Stabilizer bar bracket mounting bolt3030622
Stabilizer bar x Lower suspension arm131309
Intake air connector x Cylinder head1818513
Radiator x Body1818513

Downloaded from www.Manualslib.com manuals search engine SS098−01
− SERVICE SPECIFICATIONSCOOLING (3RZ−FE)
SS−21
195 Author: Date:
1996 TOYOTA T100 (RM449U)
COOLING (3RZ−FE)
SERVICE DATA
Thermostat
Valve opening temperature
Valve lift at 95°C (203°F)80 − 84°C (176 − 183°F)
8 mm (0.31 in.) or more
Radiator capRelief valve opening pressure STD
Minimum74 − 103 kPa (0.75 − 1.05 kgf/cm2, 10.7 − 14.9 psi)
59 kPa (0.6 kgf/cm2, 8.5 psi)

Downloaded from www.Manualslib.com manuals search engine SS00Y−03
− SERVICE SPECIFICATIONSCOOLING (5VZ−FE)
SS−23
197 Author: Date:
1996 TOYOTA T100 (RM449U)
COOLING (5VZ−FE)
SERVICE DATA
ThermostatValve opening pressure
Valve lift at 95°C (203°F)80 − 84°C (176 − 183°F)
8.5 mm (0.335 in .) or more
Radiator capRelief valve opening pressure STD
Minimum74 − 103 kPa (0.75 − 1.05 kgf/cm2, 10.7 − 14.9 psi)
59 kPa (0.6 kgf/cm2, 8.5 psi)

Downloaded from www.Manualslib.com manuals search engine EM07I−03
− ENGINE MECHANICAL (3RZ−FE)ENGINE UNIT
EM−65
1996 TOYOTA T100 (RM449U)
REMOVAL
1. REMOVE BATTERY
2. REMOVE ENGINE UNDER COVER
Remove the 4 bolts and engine under cover.
3. DRAIN ENGINE COOLANT
4. DRAIN ENGINE OIL
5. DRAIN TRANSMISSION OIL
6. REMOVE HOOD
7. REMOVE RADIATOR RESERVOIR TANK
8. REMOVE RADIATOR (See page CO−15)
9. REMOVE AIR CLEANER CAP, MAF METER AND RES-
ONATOR
(a) Disconnect the MAF meter connector, IAT sensor con-
nector and wire clamp.
(b) Loosen the air cleaner hose clamp.
(c) Loosen the 4 clips, and remove the air cleaner cap, MAF
meter and resonator.
10. REMOVE AIR CLEANER CASE
(a) Remove the air cleaner element.
(b) Remove the 3 bolts and air cleaner case.
11. M/T:
DISCONNECT ACCELERATOR CABLE FROM
THROTTLE BODY
12. A/T:
DISCONNECT ACCELERATOR AND THROTTLE
CABLES FROM THROTTLE BODY
13. REMOVE INTAKE AIR CONNECTOR
(a) Disconnect the 2 air hoses and vs hose.
(b) Remove the 2 bolts, hose clamp and intake air connector.

Downloaded from www.Manualslib.com manuals search engine EM−74
− ENGINE MECHANICAL (3RZ−FE)ENGINE UNIT
1996 TOYOTA T100 (RM449U)
23. INSTALL AIR CLEANER CASE
(a) Install the air cleaner case with 3 bolts.
(b) Install the air cleaner element.
24. INSTALL MAF METER, RESONATOR AND AIR
CLEANER CAP
(a) Connect the air cleaner hose clamp.
(b) Install the air cleaner cap, MAF meter and resonator with
the 4 clips.
(c) Connect the MAF meter connector, IAT sensor connector
and wire clamp.
25. INSTALL RADIATOR (See page CO−20)
26. INSTALL RADIATOR RESERVOIR TANK
27. FILL WITH ENGINE OIL
28. FILL WITH ENGINE COOLANT
29. FILL TRANSMISSION OIL
30. INSTALL BATTERY
31. START ENGINE AND CHECK FOR LEAKS
32. CHECK IGNITION TIMING (See page EM−11)
33. INSTALL ENGINE UNDER COVER
Install the engine under cover with the 4 bolts.
34. INSTALL HOOD
35. VEHICLE ROAD TEST
Check for abnormal noise, shock, slippage, and smooth opera-
tion.
36. RECHECK ENGINE COOLANT AND ENGINE OIL LEV-
ELS

Downloaded from www.Manualslib.com manuals search engine EM1OP−01
EM−30
− ENGINE MECHANICAL (5VZ−FE)CYLINDER HEAD
1996 TOYOTA T100 (RM449U)
REMOVAL
1. 4WD:
REMOVE ENGINE UNDER COVER
2. DRAIN ENGINE COOLANT
3. REMOVE FRONT EXHAUST PIPE (See page EM−108)
4. REMOVE AIR CLEANER CAP, MAF METER AND RES-
ONATOR
5. DISCONNECT THESE CABLES:
(a) w/ Cruise control:
Cruise control actuator cable
(b) Accelerator cable
(c) A/T:
Throttle cable
6. DISCONNECT HEATER HOSE
7. DISCONNECT UPPER RADIATOR HOSE
8. REMOVE DRIVE BELT FOR PS PUMP
(a) Stretch the belt and loosen the fan pulley mounting nuts.
9. w/ A/C:
REMOVE DRIVE BELT FOR A/C COMPRESSOR
10. REMOVE DRIVE BELT FOR GENERATOR
11. REMOVE NO. 2 FAN SHROUD
12. REMOVE FAN WITH FLUID COUPLING AND FAN PUL-
LEYS
13. DISCONNECT PS PUMP FROM ENGINE
HINT:
Put aside the pump, and suspend it.
14. w/ A/C:
DISCONNECT A/C COMPRESSOR FROM ENGINE
HINT:
Put aside the compressor, and suspend it.
15. w/ A/C:
REMOVE A/C COMPRESSOR BRACKET
16. REMOVE HIGH−TENSION CORDS WITH IGNITION
COILS
17. REMOVE SPARK PLUGS
18. REMOVE TIMING BELT AND CAMSHAFT TIMING
PULLEYS (See page EM−13)
19. REMOVE TIMING BELT IDLER NO. 2 (See page
EM−13)
20. REMOVE GENERATOR

Downloaded from www.Manualslib.com manuals search engine − ENGINE MECHANICAL (5VZ−FE)CYLINDER HEAD
EM−61
1996 TOYOTA T100 (RM449U)
27. INSTALL TIMING BELT IDLER NO. 2 (See page
EM−19)
28. INSTALL CAMSHAFT TIMING PULLEYS AND TIMING
BELT (See page EM−19)
29. INSTALL SPARK PLUGS
30. INSTALL HIGH−TENSION CORDS WITH IGNITION
COILS (See page IG−1)
31. w/ A/C:
INSTALL A/C COMPRESSOR BRACKET
32. w/ A/C:
CONNECT A/C COMPRESSOR
33. CONNECT PS PUMP
34. INSTALL FAN WITH FLUID COUPLING AND FAN PUL-
LEYS
Torque: 5.4 N·m (54 kgf·cm, 48 in.·lbf)
35. INSTALL NO. 2 FAN SHROUD
36. INSTALL AND ADJUST DRIVE BELT FOR GENERA-
TOR (See page CH−1)
37. w/ A/C:
INSTALL AND ADJUST DRIVE BELT FOR A/C COM-
PRESSOR
38. INSTALL AND ADJUST DRIVE BELT FOR PS PUMP
39. CONNECT HEATER HOSE AND UPPER RADIATOR
HOSE
40. CONNECT THESE CABLES:
(a) A/T:
Throttle cable
(b) Accelerator cable
(c) w/ Cruise control:
Cruise control actuator cable
41. I N S TA L L M A F M E T E R , R E S O N ATO R A N D A I R
CLEANER CAP ASSEMBLY
42. INSTALL FRONT EXHAUST PIPE (See page EM−108)
43. FILL WITH ENGINE COOLANT
44. START ENGINE AND CHECK FOR LEAKS
45. CHECK IGNITION TIMING (See page EM−9)
46. 4WD:
INSTALL ENGINE UNDER COVER
47. ROAD TEST VEHICLE
Check for abnormal noise, shock, slippage, correct shift points
and smooth operation.
48. RECHECK ENGINE COOLANT LEVEL

Downloaded from www.Manualslib.com manuals search engine EM06W−02
− ENGINE MECHANICAL (5VZ−FE)ENGINE UNIT (2WD)
EM−65
1996 TOYOTA T100 (RM449U)
REMOVAL
1. DRAIN ENGINE COOLANT
2. DRAIN ENGINE OIL
3. DRAIN TRANSMISSION OIL
4. REMOVE HOOD
5. REMOVE RADIATOR ASSEMBLY
(See page CO−16)
6. REMOVE DRIVE BELT FOR PS PUMP
7. w/ A/C:
REMOVE DRIVE BELT FOR A/C COMPRESSOR
8. REMOVE DRIVE BELT FOR GENERATOR
9. REMOVE FAN WITH FLUID COUPLING AND FAN PUL-
LEYS
(See page CO−5)
10. DISCONNECT PS PUMP FROM ENGINE
HINT:
Put aside the pump, and suspend it.
11. w/ A/C:
REMOVE A/C COMPRESSOR FROM ENGINE
HINT:
Put aside the compressor, and suspend it.
12. REMOVE AIR CLEANER CAP, MAF METER AND RES-
ONATOR
13. REMOVE AIR CLEANER CASE AND FILTER
14. DISCONNECT THESE CABLES:
(a) w/ Cruise control:
Cruise control actuator cable
(b) Accelerator cable
(c) A/T:
Throttle cable
15. DISCONNECT HEATER HOSES
16. DISCONNECT HOSES
Disconnect these hoses:
(1) Brake booster vacuum hose
(2) EVAP hose
