TOYOTA T100 1997 Owners Manual

Publication No. OM34411U
Part No. 01999-34411
Printed in Japan 01- 9608- 00
Quick index If a service reminder indicator or warning buzzer comes on 59 . . . . .
If your vehicle will not start 133
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your engine stalls while driving 136 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats 137
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you have a flat tire 138
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle needs to be towed 146 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips for driving during break- in period 108 . . . . . . . . . . . . . . . . . . . . . . . . .
How to start the engine 121
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General maintenance 158
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Complete index 209
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gas station information
Fuel type: UNLEADAD gasoline, Research Octane Number 91
(Octane Rating 87) or higher See page 129 for detailed information.
Fuel tank capacity: 91 L (24 gal., 20.0 lmp. gal.)
Engine oil:
See page 172
Automatic transmission fluid: Automatic transmission fluid D- ll or DEXRON lll (DEXRON ll)
Tire information: See pages 175 through 179.
Tire pressure: See page 198 and 199. P8
B

Part 11
OPERATION OF INSTRUMENTSAND CONTROLSÐ
Chapter 1-1 Overview of instruments and controls
Instrument panel overview
Instrument cluster overview
Indicator symbols on the instrument panel

2Instrument panel overview

3

4Instrument cluster overview

5

Indicator symbols on the instrument panel
6
4WD
Anti-lock brake system warning light*
Brake system warning light* Seat belt reminder light*
Discharge warning light*
Low oil pressure warning light*
Malfunction indicator light*
Low fuel level warning light*
SRS airbag warning light* Automatic transmission fluid
temperature warning light*
Turn signal indicator lights
Headlight high beam indicator light
Over-drive indicator light
Unengaged Parkº warning light* Low windshield washer fluid level warning light*
4WDº indicator light
Automatic transmission indicator lights
Cruise control indicator light
The indicators marked with * are service reminder indicators.
For details, see Service reminder indicators and warning
buzzersº in Chapter 1-5.

Part 1Keys
7
OPERATION OF INSTRUMENTS ANDCONTROLSÐ
Chapter 1-2 Keys and Doors
Keys
Side doors
Power windows
Quarter windows
Rear windows
Tailgate
Hood
Fuel tank cap
KEY PLATE This key works in every lock.
Since the doors can be locked without a
key, you should always carry a spare key
in case you accidentally lock your keys in-
side the vehicle.
Keep your key number plate in a safe
place such as your wallet, not in the vehicle.
If you should lose your keys or if you need
additional keys, duplicates can be made
by a Toyota dealer using the key number.
You should also put a copy of the key
number with your important papers.

8
LOCKING WITH KEY
Turn the key towards the front of the
vehicle to lock and towards the back to
unlock.
Vehicles with power door lock sys-
temÐBoth doors lock and unlock simulta-
neously with either door. In the driver's
door l ock, turning the key once will unlock
the driver's door and twice in succession
will unlock the driver's door and passen-
ger's door simultaneously.LOCKING WITH INSIDE LOCK KNOB
Turn the lock knob forward to lock and
backward to unlock the door.
Closing the door with the lock knob in the
lock position will also lock the door. Be careful not to lock your keys in the vehicle.
Vehicles with power door lock systemÐ
The door cannot be locked if you leave the key in the ignition switch.LOCKING AND POWER DOOR LOCK SWITCH
To lock and unlock both doors simul-
taneously, push the power door lockswitch.
Side doors

9
CAUTION!
Before driving, be sure that the
doors are closed and locked, espe-
cially when small children are in the
vehicle. A long with the proper use of
seat belts, locking the doors helps
prevent the driver and passengers
from being thrown out from the ve-
hicle during an accident. It also
helps prevent the doors from being
opened unintentionally.
The windows can be operated with the
switch on each door.
The power windows work when the igni- tion switch is in the ONº position. Howev-
er, if both doors are closed, they work for 60 seconds even after the ignition switch
is turned off. They stop working when ei-ther door is opened.
OPERATING THE DRIVER'S WINDOW
Use the switch on the driver's door.
Normal operation: The window moves
as long as you hold the switch.
To open: Lightly push down the switch.
To close: Pull up the switch.Automatic operation (to open only):
Push the switch completely down and
then rel ease it. The window will fully open.
To stop the window partway, lightly pull the
switch up and then release it.
Power windows
