TOYOTA TACOMA 1997 Owners Manual

Publication No. OM35705U
Part No. 01999-35705
Printed in Japan 10- 9802- 05
Quick index If a service reminder indicator or warning buzzer comes on 59 . . . . .
If your vehicle will not start 139
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your engine stalls while driving 142 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats 143
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you have a flat tire 144
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle needs to be towed 152 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips for driving during break- in period 114 . . . . . . . . . . . . . . . . . . . . . . . . .
How to start the engine 127
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General maintenance 168
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Complete index 221
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gas station information
Fuel type: UNLEADED gasoline, Octane Rating 87 (Research Octane Number
91) or higher.
See page 114 for detailed information.
Fuel tank capacity: Two- wheel drive models
57 L (15.1 gal., 12.5 Imp.gal.)
Four- wheel drive models
68 L (18.0 gal., 15.0 Imp. gal.)
Engine oil: API SH, ''Energy- Conserving II'' multigrade engine oil or ILSAC mult igrade
engine oil is recommended.
See page 182 for detailed information.
Tire information: See pages 185 through 189.
Tire pressure: See page 211. T
9
I

Part 11
OPERATION OF INSTRUMENTSAND CONTROLSÐ
Chapter 1-1 Overview of instruments and controls
Instrument panel overview
Instrument cluster overview
Indicator symbols on the instrument panel

21. Side vent
2. Instrument cluster
3. Automatic transmisssion selector
lever (column shift)
4. Center vents
5. Personal lights or interior light
6. Glovebox
7. Power door lock switch
8. Power window switches
9. Manual transmission gear shift lever or autmatic transmission selector lever (floor shift)
10. Front drive control lever 11. Tilt steering lock release lever
12. Power rear view mirror control switch
Instrument panel overview

3
1. Headlight and turn signal switch
2. Wiper and washer switches
3. Driving pattern selector button
4. Emergency flasher switch
5. Clock
6. Cup holder
7. Air conditioning controls
8. Car audio
9. Ashtray
10. Cigarette lighter 11. Parking brake lever
12. Ignition switch
13. Cruise control switch
14. Hook lock release lever
15. Rear differential lock button
16. Instrument panel light control knob
17. Clutch start cancel switch

4
1. Engine coolant temperature gauge
2. Tachometer
3. Service reminder indicators or indicator lights 4. Odometer
5. SPeedometer
6. Fuel Gauge
7. Trip meter reset knob
8. Tripmeter
Instrument cluster overview
With tachometer

5
1. Engine coolant temperature guage
2. Service reminder indicators or indicator lights 3. Odometer
4. Speedometer
5. Fuel gauge

Without tachometer

6
Anti-lock brake system warning light * 1
Brake system warning light * 1
Seat belt reminder light* 1
Discharge warning light* 1
Low oil pressure warning light* 1
Malfunction indicator light* 1
Low fuel level warning light * 1
SRS airbag warning light* 1 Automatic transmission fluid
temperature warning light*
1
Turn signal indicator lights
Headlight high beam indicator light
Over-drive indicator light
Unengaged Parkºwarning light * 1
Low windshield washer fluid level light*1
Driving pattern (POWERº
model) indicator light
Four-wheel drive indicator light
Automatic transmission indicator lights
Indicator symbols on the instrument panel

7
Driving pattern indicator light
Cruise control indicator light * 2
*
1
: For details, see Service reminder indicators and
warning buzzersº in Chapter 1-5.
* 2
: If this light flashes, see Cruise controlº in Chapter 1-6.

Part 1Keys
9
OPERATION OF INSTRUMENTS ANDCONTROLSÐ
Chapter 1-2 Keys and Doors
Keys
Side doors
Power windows
Quarter windows
Rear windows
Tailgate
Hood
Fuel tank cap
Detachable moon roof
Detachable sun shade
KEY PLATE This key works in every lock.
Since the doors can be locked without a
key, you should always carry a spare key
in case you accidentally lock your keys in-
side the vehicle.
KEY NUMBER PLATE
Your key number is shown on the
plate. Keep the plate in a safe place
such as your wallet, not in the vehicle.
If you should lose your keys or if you need
additional keys, duplicates can be made
by a Toyota dealer using the key number.
You should also put a copy of the key
number with your important papers.

10
LOCKING AND UNLOCKING WITH KEY
Insert the key into the keyhole and turn
it.
To lock: Turn the key forward.
To unlock: Turn the key backward.
Vehicles with power door lock sys-
temÐBoth doors lock and unlock simulta-
neously with either door. In the driver's
door l ock, turning the key once will unlock
the driver's door and twice in succession
will unlock the driver's door and passen-
ger's door simultaneously.LOCKING AND UNLOCKING WITH IN-
SIDE LOCK BUTTON Move the lock button.
To lock: Push the button downward.
To unlock: Pull the button upward.
Closing the door with the lock button
pushed in w ill also lock the door. Be care-
ful not to lock your keys in the vehicle.
Vehicles with power door lock systemÐ
The door cannot be locked if you leave thekey in the ignition switch.Driver's side
Passenger 's side
Side doors
