TOYOTA TACOMA 2002 Owners Manual (in English)

’02 Tacoma U (L/O 0109)
2952002 MY TACOMA_U (OM35786U)
Treadwear—The treadwear grade is a
comparative rating based on the wear rate
of the tire when tested under controlled
conditions on a specified government test
course. For example, a tire graded 150
would wear one and a half (11/2) times
as well on the government course as a
tire graded 100. The relative performance
of tires depends upon the actual condi-
tions of their use, however, and may de-
part significantly from the norm due to
variations in driving habits, service prac-
tices and differences in road characteris-
tics and climate.
Traction AA, A, B, C— The traction
grades, from highest to lowest, are AA, A,
B, and C, and they represent the tire’s
ability to stop on wet pavement as mea-
sured under controlled conditions on spe-
cified government test surfaces of asphalt
and concrete. A tire marked C may have
poor traction performance.
Warning: The traction grade assigned to
this tire is based on braking (straight
ahead) traction tests and does not include
cornering (turning) traction. Temperature A, B, C—
The temperature
grades are A (the highest), B, and C,
representing the tire’s resistance to the
generation of heat and its ability to dissi-
pate heat when tested under controlled
conditions on a specified indoor laboratory
test wheel. Sustained high temperature
can cause the material of the tire to de-
generate and reduce tire life, and exces-
sive temperature can lead to sudden tire
failure. The grade C corresponds to a lev-
el of performance which all passenger car
tires must meet under the Federal Motor
Vehicle Safety Standard No.109. Grades B
and A represent higher levels of perfor-
mance on the laboratory test wheel than
the minimum required by law.
Warning: The temperature grades for this
tire are established for a tire that is prop-
erly inflated and not overloaded. Exces-
sive speed, underinflation, or excessive
loading, either separately or in combina-
tion, can cause heat buildup and possible
tire failure. This information has been prepared in ac-
cordance with regulation issued by the Na-
tional Highway Traffic Safety Administra-
tion of the U.S. Department of
Transportation. It provides the purchasers
and/or prospective purchasers of Toyota
vehicles with information on truckcamper
loading. Your Toyota dealer will help an-
swer any questions you may have as you
read this information.
Camper information—

’02 Tacoma U (L/O 0109)
2962002 MY TACOMA_U (OM35786U)
B
A
Rear end of truck bed
Recommended location
for cargo center of
gravity for cargo
weight rating
Twowheel drive models
except Pre Runner mm (in.)
AB
Regular cab
models1397
(55.0)965
(38.0)
Xtracab models 2RZFE engine
5VZFE engine
1372
(54.0) 1397
(55.0)927
(36.5) 927
(36.5)
Fourwheel drive models
and Pre Runner mm (in.)
A
B
1257
(49.5)901
(35.5)
The figures given in the illustration indi-
cate the recommended center of gravity
zone.
CAUTION
If a load is too far back, it can cause
dangerous handling. If it is too far
forward, the front axle may be over-
loaded.
Camper center of gravity
Recommended center of
gravity location zone
Cargo weight rating
Twowheel drive models
except Pre Runner Regular cab models with full options’
weight of 90 kg (205 lb.) With 2 occupants 430 kg (950 lb.)
With 3 occupants 375 kg (830 lb.)
—Center of gravity location —Cargo weight rating and
proper matching

’02 Tacoma U (L/O 0109)
2972002 MY TACOMA_U (OM35786U)
Xtracab models with full options’
weight of 85 kg (195 lb.)With 2 occupants in the front
seats and no occupants in the
rear seats 365 kg (815 lb.)
With 3 occupants in the front
seats and no occupants in the
rear seats 365 kg (810 lb.)
With 3 occupants in the front
seats and 2 occupants in the rear
seats 265 kg (590 lb.)
Fourwheel drive models
and Pre Runner Regular cab models with full options’
weight of 120 kg (265 lb.)
With 2 occupants 500 kg (1100 lb.)
With 3 occupants 465 kg (1025 lb.) Xtracab models with full options’
weight of 125 kg (280 lb.)
Vehicles with off road package
With 2 occupants in the front
seats and no occupants in the
rear seats 340 kg (750 lb.)
With 2 occupants in the front
seats and 2 occupants in the rear
seats 135 kg (300 lb.)
Vehicles without off road package With 2 occupants in the front
seats and no occupants in the
rear seats 440 kg (975 lb.)
With 3 occupants in the front
seats and no occupants in the
rear seats 370 kg (825 lb.)
With 3 occupants in the front
seats and 2 occupants in the rear
seats 235 kg (525 lb.) When the truck is used to carry a slidein
camper, the total cargo load of the truck
consists of the manufacturer ’s camper
weight figure, the weight of installed addi-
tional camper equipment not included in
the manufacturer ’s camper weight figure,
the weight of camper cargo, and the
weight of passengers in the camper.
The total cargo load should not exceed
the truck’s cargo weight rating and the
camper ’s center of gravity should fall with-
in the truck’s recommended center of
gravity zone when installed.
CAUTION
Be careful—overloading can cause
dangerous braking and handling prob-
lems, and can damage your vehicle
and its tires.

’02 Tacoma U (L/O 0109)
2982002 MY TACOMA_U (OM35786U)
Gross axle weight ratingFront GAWR Rear GAWR
Secure loose items to prevent weight
shifts that could affect the balance of your
vehicle. When the truck camper is loaded,
drive to a scale and weigh on the front
and on the rear wheels separately to de-
termine axle loads. Individual axle loads
should not exceed either of the Gross
Axle Weight Ratings (GAWR). The total of
the axle loads should not exceed the
Gross Vehicle Weight Rating (GVWR).
These ratings are given on the vehicle
Certification Label which is located on the
door latch post on the left side of the
vehicle. See “Your Toyota’s identification”
in Section 2 for the Certification Label
location. If weight ratings are exceeded,
move or remove items to bring all weights
below the ratings.
Gross vehicle weight rating
Not exceed GVWR
GAWR
Twowheel drive models
except Pre RunnerFront 1000 kg (2200 lb.)
Rear 1135 kg (2500 lb.)
Fourwheel drive models
and Pre Runner Front 1200 kg (2650 lb.)
Rear 1270 kg (2800 lb.) GVWR
Twowheel drive models
except Pre Runner
Regular cab models 1920 kg (4250 lb.)
Xtracab models
2040 kg (4500 lb.)
Fourwheel drive models
and Pre Runner 2315 kg (5100 lb.)
If weight ratings are exceeded, move or
remove items to bring all weights below
the ratings.
—Gross axle and vehicle
weight ratings

’02 Tacoma U (L/O 0109)
2002 MY TACOMA_U (OM35786U)
Publication No. OM35786U
Part No. 01999-35786
Printed in Japan 01010900
(U)
Quick index
If a service reminder indicator or warning buzzer comes on 116 . . . . . . . .
 If your vehicle will not start 218
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
 If your engine stalls while driving 221
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 If your vehicle overheats 221
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
 If you have a flat tire 222
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
 If your vehicle needs to be towed 232
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Tips for driving during breakin period 189
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 How to start the engine 204
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
 General maintenance 247
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
 Complete index NO TAG
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . .
Gas station information
Fuel type:
UNLEADED gasoline, Octane Rating 87 (Research Octane Number 91)
or higher
See page 189 for detailed information.
Fuel tank capacity: Twowheel drive models except Pre Runner
60 L (16.0 gal., 13.3 lmp. gal.)
Fourwheel drive models and Pre Runner 70 L (18.5 gal., 15.4 lmp. gal.)
Engine oil:
API grade SJ “EnergyConserving”, SL “EnergyConserving” or ILSAC multi-
grade engine oil is recommended.
See page 260 for detailed information.
Tire information: See pages 264 through 269.
Tire pressure: See page 290. f
U-8
I

’02 Tacoma U (L/O 0109)
2002 MY TACOMA_U (OM35786U)
You should know as much about the quality and
importance of proper main tenance of your new
vehicle as the people who built it.
The Toyota authorized Repair Manual
tells you how to maint ain your vehicle and
enables you to correct ly perform your own
maintenance.
The best way to keep your new vehicle in top
running order is to maintain it properly from
the moment you drive it off the showroom
floor.
The Toyota authorized Repair Manual is
packed with literally everything you need to
know to perform your own maintenance in
virtually every area of your new vehicle.

’02 Tacoma U (L/O 0109)
2002 MY TACOMA_U (OM35786U)
Where to obtain the Repair Manual
The repair manual for TOYOTA Tacoma, writ-
ten in English, may be purchased as applicable
from any Toyota dealer.
Pub. Name: 2002 TOYOTA Tacoma Repair Manual
Pub. No.: RM921U1 (Maintenance, Preparation, Service specifications
and Diagnostics)
RM921U2 (Engine, Chassis and
Body)
Maintenance procedures for the engine,
chassis, body, electric al system, and more,
are clearly explained and illustrated.
Periodic maintenance and tuneup
Periodic maintenance and tuneup helps to pre-
vent small problems from growing into larger ones lat-
er on. The repair manual outlines exactly what main-
tenance is required and clearly explains how to do the
work yourself stepbystep.
Areas covered include such things as spark plug re-
placement, valve clearance adjustment and engine oil
and filter replacement.

’02 Tacoma U (L/O 0109)
2002 MY TACOMA_U (OM35786U)
WE REALLY CARE ABOUT YOU  PLEASE BUCKLE UP
Toyota has made a special effort to encourage use of seat belts.
Toyota belts are:
Comfortable
Easy to use
Convenient
We encourage you to use your belts every time you drive.
