TOYOTA TACOMA 2004 (in English) User Guide

’04 Tacoma U (L/O 0309)
3
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
1. Headlight and turn signal switches
2. Wiper and washer switches
3. Emergency flasher switch
4. Passenger airbag manual on−off switch
5. Air conditioning controls
6. Car audio
7. Ashtray
8. Cigarette lighter
9. Power outlets
10. Clock
11. Parking brake lever
12. Ignition switch
13. Cruise control switch
14. Rear differential lock switch or “AUTO LSD” switch
15. Instrument panel light control knob
16. Clutch start cancel switch (manual transmission) or driving pattern selector
button (automatic transmission)

’04 Tacoma U (L/O 0309)
4
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
1. Engine coolant temperature gauge
2. Tachometer
3. Service reminder indicators andindicator lights 4. Speedometer
5. Fuel gauge
6. Trip meter reset knob
7. Odometer and two trip meters
Instrument cluster overview

With tachometer

’04 Tacoma U (L/O 0309)
5
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
1. Engine coolant temperature gauge
2. Service reminder indicators andindicator lights 3. Speedometer
4. Odometer
5. Fuel gauge

Without tachometer

’04 Tacoma U (L/O 0309)
6
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
Seat belt reminder light∗1
Low engine oil pressure warning light∗1
Low fuel level warning light∗1
Brake system warning light∗1
Discharge warning light∗1
Malfunction indicator lamp∗1
Anti −lock brake system warning light∗
1
SRS warning light∗1
or
Automatic transmission fluid temperature
warning light∗1
Unengaged “Park” warning light∗1
Low windshield washer fluid level warning
light∗1
Headlight high beam indicator light
Traction control system warning light∗1
“AUTO LSD” system warning light∗1
Vehicle stability control system warning
light∗1
Turn signal indicator lights
Indicator symbols on the instrument panel

’04 Tacoma U (L/O 0309)
7
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
∗1: For details, see “Service reminder indicators and warning
buzzers” in Section 1 −6.
∗
2: If this light flashes, see “Cruise control” in Section 1 −7.
Cruise control indicator light
∗
2
Rear differential lock indicator light
Four −wheel drive indicator light
Overdrive −off indicator light
Driving pattern (POWER mode) indicator light
Slip indicator light
Vehicle stability control system off indicator light
(four −wheel drive models)
“AUTO LSD” indicator light

’04 Tacoma U (L/O 0309)
8
2004 TACOMA from Sep. ’03 Prod. (OM35814U)

’04 Tacoma U (L/O 0309)
9
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Keys and Doors
Keys10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . .
Side doors 10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . .
Remote keyless entry system 12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power windows 16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Quarter windows 18
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
Rear window 19
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Tailgate 19
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . .
Hood 20
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
Fuel tank cap 21
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
SECTION 1 2

’04 Tacoma U (L/O 0309)
10
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
These keys work in every lock.
Since the doors can be locked without a
key, you should always carry a spare key
in case you accidentally lock your key
inside the vehicle.KEY NUMBER PLATE
Your key number is shown on the plate.
Keep the plate in a safe place such as
your wallet, not in the vehicle.
If you should lose your keys or if you
need additional keys, duplicates can be
made by a Toyota dealer using the key
number.
We recommend writing down the key num-
ber and storing it in a safe place.LOCKING AND UNLOCKING WITH KEY
Insert the key into the keyhole and turn
it.
To lock: Turn the key forward.
To unlock: Turn the key backward.
Vehicles with power door lock system—
All the doors lock and unlock simulta-
neously with either front door. In the driv-
er’s door lock, turning the key once will
unlock the driver’s door and twice in suc-
cession will unlock all the door simulta-
neously.
KeysSide doors

’04 Tacoma U (L/O 0309)
11
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
LOCKING AND UNLOCKING WITH
INSIDE LOCK BUTTON
Move the lock button.
To lock: Push the button downward.
To unlock: Pull the button upward.
Closing the door with the lock button
pushed in will also lock the door. On ve-
hicles with power door lock system, the
doors cannot be locked if you leave the
key in the ignition switch.
Be careful not to lock your keys in the
vehicle.Driver’s side
Passenger’s side
LOCKING AND UNLOCKING WITH
POWER DOOR LOCK SWITCH
Push the switch.
To lock: Push the switch down on the
front side.
To unlock: Push the switch down on the
rear side.
All the doors lock or unlock simultaneous-
ly.
All the doors cannot be unlocked with the
power door lock switch by the following
cases:
Either front door is locked by the key.
Either front door is closed with the
inside door lock button pushed in.

’04 Tacoma U (L/O 0309)
12
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
REAR DOOR CHILDPROTECTORS
Move the lock lever to the “LOCK”
position as shown on the label.
This feature allows you to lock a rear
door so it can be opened from the outside
only, not from inside. We recommend us-
ing this feature whenever small children
are in the vehicle.
CAUTION
Before driving, be sure that the doors
are closed and locked, especially
when small children are in the ve-
hicle. Along with the proper use of
seat belts, locking the doors helps
prevent the driver and passengers
from being thrown out from the ve-
hicle during an accident. It also helps
prevent the doors from being opened
unintentionally.
Locking operation
Unlocking operation
Remote keyless entry system
(for U.S.A. only)
