TOYOTA TACOMA 2006 Owners Manual (in English)

2512006 TACOMA from Jan.’06 Prod. (OM35871U)
NOTICE
To prevent the battery from being
discharged, turn off all the vehicle’s
electronic equipment and accesso-
ries, such as the headlights, fog
lights and air conditioner, when
electrical appliances that consume
in excess of 100W are used contin-
uously for long periods of time.
 To prevent any damage caused by
heat, do not use any electrical ap-
pliances that give off intense heat
such as toasters, in any locations
including the internal or external
trim, seats and deck.
 Do not use any electrical ap-
pliances, which are easily affected
by vibration or heat, inside the ve-
hicle. Vibration while driving, or the
heat of the sun while parking, may
result in damage to those electrical
appliances.
 Keep the lid closed when the power
outlet is not in use. Do not insert
any items other than appropriate
plugs, as this may cause electrical
failure or short circuits.
After inserting a plug, gently close
the power outlet lid. Failure to do
so may cause damage to the plug.
 If any electrical appliances are to
be used while driving, securely fas-
ten both the appliances and their
cables to prevent them from falling
or getting caught any of the power-
train components.
 Do not use plug adaptors to con-
nect too many plugs to the power
outlet.
 If the power outlet is loose when an
electrical appliance plug is con-
nected, replace the outlet. Contact
a Toyota dealer for any necessary
replacements.
 If the power outlet gets dirty, turn
the main switch off and use a soft,
clean, drywet cloth to wipe it gent-
ly. Do not use any cleansing materi-
als, such as organic solvents, wax,
or compound cleaners, as these
may damage the power outlet or
cause it to malfunction.Keep the power outlet free from
dust and foreign materials and
clean it regularly.
The power outlet is not designed for
the following electric appliances even if
their power consumption is below the
maximum capacity. These appliances
may not operate properly.
Appliances with high initial peak watt-
age: cathode− ray tube type televisions,
compressor −driven refrigerators, electric
tools, etc.
Measuring devices which process pre-
cise data: medical equipment, measur-
ing instruments, etc.
Other appliances requiring an extremely
stable power supply: microcomputer −
controlled electric blankets, touch sen-
sor lamps, etc.
Use of the power outlet may not be
possible if the vehicle battery voltage is
low due to decreased battery capacity.
The integrated timers of electrical ap-
pliances may not function properly
when the power supply is cut by the
protection circuit.

2522006 TACOMA from Jan.’06 Prod. (OM35871U)
Some electrical appliances may not op-
erate properly unless they are installed
on a level place.
The precise power outlet voltage cannot
be measured using commercial testers.
If necessary, contact a Toyota dealer.
Certain electrical appliances may cause
radio noise.
LS10006
To open the glove box door, pull the
lever.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the glove box door
closed while driving.
LS10007
The box is designed to store a garage
door opener transmitter.
Open the cover and remove the hook−and
− loop fastener square.
Glove box Garage door opener box

2532006 TACOMA from Jan.’06 Prod. (OM35871U)
LS10008
Remove the paper strip covering the adhe-
sive on back side of square and adhere
the square to back side of the transmitter
near the center.
LS10009
Please note if transmitter has wire clip for
sun visor, this clip must be removed prior
to adhesion of the fastener.
LS10010
Place the transmitter with fastener square
facing inside of box into the box. Make
sure the transmitter button is located
above button pins.

2542006 TACOMA from Jan.’06 Prod. (OM35871U)
LS10011
Remove spacers from the center panel.
Place one spacer on the pin that would be
below transmitter button when the cover is
closed. Close the cover.
LS10012
When the garage door opener transmitter
is properly installed, you can operate the
transmitter by pushing the center panel of
the cover.
LS10013
If the center panel does not contact your
garage door opener transmitter:
Check to see if spacer is on the cor-
rect pin.
Attach another spacer to the top of
original spacer. Check operation. If re-
quired, continue to add spacers until
contact is achieved.
If the transmitter is clattering during driv-
ing, fill in a piece of felt or pad to prevent
the transmitter from clattering.

2552006 TACOMA from Jan.’06 Prod. (OM35871U)
CAUTION
To reduce the chance of injury in
case of an accident or a sudden
stop, always keep the garage door
opener box closed while driving.
Keep the remaining spacers away
from children.
To use the auxiliary boxes, open the
lids as shown in the following illustra-
tions.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden
stop, always keep the auxiliary box
closed while driving.
Type A only—As these holders are
designed for holding a light object
such as an eyeglass, do not place
any heavy objects in them. Heavy
objects may cause the holder to
open and contents to fly out result-
ing in injuries.
NOTICE
Type A only—During hot weather, the
interior of the vehicle becomes very
hot. Do not leave anything flammable
or deformable such as a lighter,
glasses, etc. inside.
LS10014
Type A (over head console)
LS10015
Type B (instrument panel)
Auxiliary boxes

2562006 TACOMA from Jan.’06 Prod. (OM35871U)
LS10016a
Front
Type C (under the rear seat of access cab
models)
LS10017a
Front
Type D (under the rear seat of double cab
models)
LS10019a
Type E (left side of bed)
LS10043
Type F (right side of bed)
LS10018a
Type G (right side of bed)

2572006 TACOMA from Jan.’06 Prod. (OM35871U)
LS10020
To use the rear console box, raise the
console box lid while pushing the lock
release button.
LS10021
The rear console box is equipped with
the flexible cargo net.
The flexible cargo net is detachable.The cup holders are designed for hold-
ing cups or drinkcans securely.
Type A and B—The cup holder can be
adjustable to the size of the cups or
drinkcans by changing the holder posi-
tion and the arm position, as shown.
CAUTION
Do not place anything else other than
cups or drinkcans in the cup holder,
as such items may be thrown about
in the compartment and possibly in-
jured people in the vehicle during
sudden braking or in an accident.
Rear console box
Cup holders

2582006 TACOMA from Jan.’06 Prod. (OM35871U)
LS10028
Type A (bench seat)
LS10027
Type B (separate seats with automatic
transmission)
LS10026
Type C (separate seats with automatic
transmission)
LS10025
Type D (separate seats with manual trans-
mission)

2592006 TACOMA from Jan.’06 Prod. (OM35871U)
LS10022
Front doors
LS10023
Rear doors (double cab models only)
LS10024
Rear console box
The bottle holders are designed to hold
bottles securely.
CAUTION
Do not attempt to use the holder for
any other purpose for which it was
intended. Inappropriately sized or
shaped objects may be thrown about
in the compartment and possibly in-
jured people in the vehicle during a
sudden braking or an accident.
NOTICE
Do not put a cup or open bottle in
the bottle holder because the con-
tents may spill when the door opens
or closes.
Bottle holders

2602006 TACOMA from Jan.’06 Prod. (OM35871U)
LS10031a
Separator
Type A (left side behind the rear seat
back)
LS10030b
Separator
Type B (right side behind the rear seat
back)
This box is designed to place things
like bottles.
The separator is detachable, and it can be
installed in various positions as required.
LS10044
The flashlight holder is designed to
hold the flashlight securely.
The flashlight holder is detachable, and it
can be installed in various positions as
required.
Storage boxes (double cab
models only) Flashlight holder (double cab
models only)
