Four−wheel drive models kg (lb.)
Cab type
EngineDeck typeVehicle capacity weight∗ 1,2
Regular cab2. 7 L 4 −cylinder
(2TR −FE) engineLong deck590 (1300)
Access cab
2. 7 L 4 −cylinder
(2TR −FE) engineLong deck590 (1300)
4. 0 L V6 (1G R −FE) engineLong deck547 (1205)
Double cab4. 0 L V6 (1G R −FE) engineShort deck544 (1200)
Long deck522 (1150)
∗
1: Maximum vehicle capacity weight including weight of driver, passengers and cargo.∗2: Installing accessories in addition to those installed at the factory increases vehicle weight, thereby reducing vehicle
capacity weight. Contact your Toyota dealer about the weight of accessory parts.

4022007 TACOMA from Sep. ’06 Prod. (OM35877U)
Without towing package1587 kg (3500 lb.)
With towing package 2948 kg (6500 lb.)
∗: Trailer weight + car go weight
Model:
2TR −FE and 1GR −FE
Type: 2TR −FE engine
4 cylinder in line, 4 cycle, gasoline
1GR −FE engine
6 cylinder V type, 4 cycle, gasoline
Bore and stroke, mm (in.):
2TR −FE engine
95.0 95.0 (3.74 3.74)
1GR −FE engine
94.0 95.0 (3.70 3.74)
Displacement, cm
3 (cu. in.):
2TR −FE engine 2694 (164.3)
1GR −FE engine 3956 (241.4) Fuel type:
Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher
Fuel tank capacity, L (gal., Imp. gal.): 80 (21.1, 17.6)
Towing capacity∗Engine Fuel

4032007 TACOMA from Sep. ’06 Prod. (OM35877U)
ENGINE
Valve clearance (engine cold), mm (in.):2.7 L 4 −cylinder (2TR −FE) engine
Automatic adjustment
4.0 L V6 (1GR −FE) engine
Intake 0.15—0.25 (0.006—0.010)
Exhaust 0.29—0.39 (0.011—0.015)
Spark plug type: 2.7 L 4 −cylinder (2TR −FE) engine
DENSO SK20HR11
NGK ILFR6C11
4.0 L V6 (1GR −FE) engine
DENSO K20HR −U11
NGK LFR6C11
Spark plug gap, mm (in.): 1.1 (0.043) ENGINE LUBRICATION
Oil capacity (drain and refill),
L (qt., Imp. qt.):
2.7 L 4 −cylinder (2TR −FE) engine
With filter 5.8 (6.1, 5.1)
Without filter 5.1 (5.4, 4.5)
4.0 L V6 (1GR −FE) engine
Tw o −wheel drive models except Pre-
Runner With filter 4.5 (4.8, 4.0)
Without filter 4.2 (4.4, 3.7)
Four −wheel drive models and
PreRunner
With filter 5.2 (5.5, 4.6)
Without filter 4.9 (5.2, 4.3)
“Toyota Genuine Motor Oil” is used in
your Toyota vehicle. Use Toyota approved
“Toyota Genuine Motor Oil” or equivalent
to satisfy the following grade and
viscosity.
Oil grade: ILSAC multigrade engine oil Recommended oil viscosity:
2.7 L 4
−cylinder (2TR −FE) engine
SAE 5W −20 or 0W −20
SOIL20
Outside temperature
Service specifications

4042007 TACOMA from Sep. ’06 Prod. (OM35877U)
4.0 L V6 (1GR−FE) engine
SAE 5W −30
Outside temperature
Please contact your Toyota dealer for fur-
ther details. COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):
With manual transmission2.7 L 4 −cylinder (2TR −FE) engine
8.7 (9.1, 7.6)
4.0 L V6 (1GR −FE) engine
9.7 (10.3, 8.5)
With automatic transmission 2.7 L 4 −cylinder (2TR −FE) engine
8.6 (9.1, 7.6)
4.0 L V6 (1GR −FE) engine
9.6 (10.1, 8.5)
Coolant type:
“Toyota Super Long Life Coolant” is
used in your Toyota vehicle at factory
fill. In order to avoid technical problems,
only use “Toyota Super Long Life
Coolant” or similar high quality ethylene
glycol based non −silicate, non −amine,
non− nitrite, and non− borate coolant with
long− life hybrid organic acid technology.
(Coolant with long −life hybrid organic
acid technology is a combination of low
phosphates and organic acids.)
Do not use plain water alone.
Please contact your Toyota dealer for
further details. BATTERY
Open voltage
∗ at 20
°C (68 °F):
12.6—12.8 V Fully charged
12.2—12.4 V Half charged
11.8—12.0 V Discharged
∗: Voltage that is checked 20 minutes after the key is removed with all the
lights turned off
Charging rates: 5 A max.
CLUTCH
Pedal free play, mm (in.): 5—15 (0.2—0.6)
Fluid type: SAE J1703 or FMVSS No.116 DOT 3
MANUAL TRANSMISSION
Oil capacity, L (qt., Imp. qt.): 2.7 L 4 −cylinder (2TR −FE) engine
Tw o −wheel drive models
2.6 (2.7, 2.3)
Four −wheel drive models
2.2 (2.3, 1.9)
4.0 L V6 (1GR −FE) engine
1.8 (1.9, 1.6)
Oil type: Gear Oil API GL−4 or GL−5
Recommended oil viscosity: SAE 75W −90

4052007 TACOMA from Sep. ’06 Prod. (OM35877U)
AUTOMATIC TRANSMISSION (4speed)
Fluid capacity (drain and refill),
L (qt., Imp. qt.):Up to 2.0 (2.1, 1.8)
Fluid type: Toyota Genuine ATF Type T −IV
Change automatic transmission fluid only
as necessary.
Generally, it is necessary to change
automatic transmission fluid only if your
vehicle is driven under one of the Special
Operating Conditions listed in your
“Scheduled Maintenance Guide” or
“Owner ’s Manual Supplement”. When
changing the automatic transmission fluid,
use only “Toyota Genuine ATF Type T −IV”
(ATF JWS3309 or NWS6500) to aid in
assuring optimum transmission perfor-
mance.
Notice: Using automatic transmission
fluid other than “Toyota Genuine ATF
Type TIV” may cause deterioration in
shift quality, locking up of your trans-
mission accompanied by vibration, and
ultimately damage the automatic trans-
mission of your vehicle.
Please contact your Toyota dealer for fur-
ther details. AUTOMATIC TRANSMISSION (5speed)
Fluid capacity (drain and refill),
L (qt., Imp. qt.):
Up to 3.0 (3.2, 2.6)
Fluid type: Toyota Genuine ATF WS
Change automatic transmission fluid only
as necessary.
Generally, it is necessary to change
automatic transmission fluid only if your
vehicle is driven under one of the Special
Operating Conditions listed in your
“Scheduled Maintenance Guide” or
“Owner ’s Manual Supplement”. When
changing the automatic transmission fluid,
use only “Toyota Genuine ATF WS” (ATF
JWS3324 or NWS9638) to aid in assuring
optimum transmission performance.
Notice: Using automatic transmission
fluid other than “Toyota Genuine ATF
WS” may cause deterioration in shift
quality, locking up of your transmission
accompanied by vibration, and ultimate-
ly damage the automatic transmission
of your vehicle.
Please contact your Toyota dealer for fur-
ther details. TRANSFER
Oil capacity, L (qt., Imp. qt.):
1.0 (1.1, 0.9)
Oil type: Gear Oil API GL−4 or GL−5
Recommended oil viscosity: SAE 75W −90
DIFFERENTIAL
Oil capacity, L (qt., Imp. qt.): Tw o −wheel drive models except PreRun-
ner 3.31 (3.5, 2.9)
Four −wheel drive models and PreRunner
Front (four −wheel drive models)
1.50 (1.6, 1.3)
Rear 2.80 (3.0, 2.5)
Oil type: Without limited− slip differential
Hypoid gear oil API GL −5
With limited −slip differential
Hypoid gear oil for limited −slip dif-
ferential API GL −5

4062007 TACOMA from Sep. ’06 Prod. (OM35877U)
Recommended oil viscosity:Front SAE 75W −90
Rear Above −18 C (0 F)
SAE 90
Below −18 C (0 F)
SAE 80W or 80W −90
CHASSIS LUBRICATION
Front drive shaft thrust bushings: Synthetic oil and lithium soap base
chassis grease, NLGI No.1
Propeller shafts:
SpidersLithium base chassis grease, NLGI
No.2
Slide yokes Lithium base chassis grease, NLGI
No.2 or Molybdenum −disulfide lithium
base chassis grease, NLGI No.2 BRAKES
Minimum pedal clearance when depressed
with a pressure of 490 N (50 kgf, 110 lbf)
when the engine is stopped and after de-
press the brake pedal several times,
mm (in.):
Tw o
−wheel drive models except PreRunner
Without the vehicle stability control sys-
tem 109 (4.3)
With the vehicle stability control system 89 (3.5)
Four −wheel drive models and PreRunner
Without the vehicle stability control sys-
tem
105 (4.1)
With the vehicle stability control system 88 (3.4)
Pedal free play, mm (in.): 1—6 (0.04—0.24)
Pad wear limit, mm (in.): 1.0 (0.04)
Lining wear limit, mm (in.): 1.0 (0.04)
Parking brake adjustment: Pedal type—when depressed with the
force of 300 N (30.6 kgf, 67.4 lbf)7—10 clicks Lever type—when pulled with the force
of 200 N (20.4 kgf, 44.9 lbf)
7—10 clicks
Fluid type: SAE J1703 or FMVSS No.116 DOT 3
STEERING
Wheel free play: Less than 30 mm (1.2 in.)
Power steering fluid type: Automatic transmission fluid DEXRON II
or III

4072007 TACOMA from Sep. ’06 Prod. (OM35877U)
Tire size, cold tire inflation pressure and wheel size:Ti r e siz e
Cold tire inflation pressurekPa (kgf/cm2 or bar, psi)Spare∗ 1Wheel size
FrontRear
P215/70R15 97S200 (2.0, 29)220 (2.2, 32)220 (2.2, 32)15 6J
15 6JJ
P245/75R16 109S200 (2.0, 29)200 (2.0, 29)200 (2.0, 29)16 7J
16 7JJ
P265/70R16 111T200 (2.0, 29)220 (2.2, 32)220 (2.2, 32)16 7JJ
P265/65R17 110S200 (2.0, 29)200 (2.0, 29)200 (2.0, 29)17 7 1/ 2J J
P255/45R18 99V240 (2.4, 35)240 (2.4, 35)240 (2.4, 35)188JJ
∗
1: If you affix the spare tire to a front position, please make sure to adjust the tire to the correct inflation pressure
as soon as possible.
For sustained high speeds above 160 km/h (100 mph), in countries where such speeds are permitted by law, add
the tire inflation pressure give n below to the front tires and rear tires, but never exceed the maximum cold tire inflation
pressure molded on the tire sidewall.
Except P255/45R18 20 kPa (0.2 kgf/cm
2, 0. 2 bar, 3 ps i)
P255/45R18 30 kPa (0.3 kgf/cm
2, 0. 3 bar, 4 ps i)
Wheel nut torque, N·m (kgf·m, ft·lbf): 11 3 ( 11 . 5 , 8 5 )
NOTE: For complete information on tires (e.g. replacing tires or replacing wheels), see “Checking tire inflation pressure” through “Aluminum wheel precautions”, pages 373 through 382, in Section 7 −2.
Tires

4082007 TACOMA from Sep. ’06 Prod. (OM35877U)
LS80001
Engine compartment
Fuses (type A)1. A/C 10 A: Air conditioning system
2. FR FOG 15 A: Front fog lights
3. TOWING TAIL 30 A: Trailer lights (tail
lights)
4. STOP 10 A: Stop lights, high mounted
stop light, vehicle stability control sys-
tem, anti− lock brake system, shift lock
system, multiport fuel injection system/
sequential multiport fuel injection sys-
tem, towing converter
5. OBD 7.5 A: On−board diagnosis sys-
tem
LS80002
Instrument panel
6. EFI NO.2 10 A: Multiport fuel injection
system/se quential multiport fuel injec-
tion system
7. TOWING BRK 30 A: Trailer brake con-
troller
8. BATT CHG 30 A: Trailer sub battery
9. TOWING 30 A: Towing converter
10. TRNHAZ 15 A: Turn signal lights,
emergency flashers, meter and gauge
11. RADIO NO.2 30 A: Audio system
12. HEAD (LO RH) 10 A: Right−hand
headlight (low beam) 13. HEAD (LO LH) 10 A:
Left−hand head-
light (low beam), front fog lights
14. HEAD (HI RH) 10 A: Right−hand head-
light (high beam)
15. HEAD (HI LH) 10 A: Left−hand head-
light (high beam), meter and gauge
16. ETCS 10 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system, electronic throttle control
system
17. ALTS 7.5 A: Charging system
18. EFI 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
19. HORN 10 A: Horn
20. A/F HEATER 15 A: Multiport fuel injec-
tion system/sequential multiport fuel in-
jection system
21. ECUB 7.5 A: Wireless remote control
system, air c onditioning system, multi-
plex communication system, engine im-
mobilizer system, meter and gauge,
clock, front passenger occupant classi-
fication system
22. DOME 7.5 A: Interior light, personal
lights
23. RADIO NO.1 10 A: Audio system
Fuses

4092007 TACOMA from Sep. ’06 Prod. (OM35877U)
24. STA 7.5 A: Starting system, multiport
fuel injection system/sequential multi-
port fuel injection system, meter and
gauge, clutch start cancel switch
25. IGN 15 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, engine immobilizer system,
anti −lock brake system, traction control
system, vehicle stability control system,
SRS airbag system, front passenger
occupant classification system
26. GAUGE 7.5 A: Meter and gauge,
emergency flashers, front passenger ’s
seat belt warning system
27. TAIL 10 A: Tail lights, license plate
lights, parking lights, multiport fuel in-
jection system/sequential multiport fuel
injection system, front fog lights, instru-
ment panel light control, illuminations
28. ACC 7.5 A: Shift lock system, outside
rear view mirrors, audio system, power
outlets
29. PWR OUTLET 15 A: Power outlets
30. DR LCK 20 A: Door lock system 31. IG1 NO.2 10 A:
Anti−lock brake sys-
tem, vehicle stability control system,
stop lights, charging system, multiport
fuel injection system/sequential multi-
port fuel injection system, air condition-
ing system, instrument panel light con-
trol, clutch start cancel switch, rear
differential lock system, power outlets,
tire pressure warning system
32. IG1 10 A: Back−up lights, air condition-
ing system, passenger airbag manual
on− off switch, shift lock system
33. P RR P/W 20 A: Rear passenger ’s
power window (right side)
34. P FR P/W 20 A: Front passenger ’s
power window
35. WSH 10 A: Wipers and washer
36. D RR P/W 20 A: Rear passenger ’s
power window (left side)
37. 4WD 20 A: Four−wheel drive system,
rear differential lock system
38. WIP 30 A: Wipers and washer
Fuses (type B)
39. J/B 50 A: “TAIL”, “AC SKT”, “DR LCK”,
“D FR P/W”, “D RR P/W”, “P FR P/W”,
“P RR P/W”
40. AM1 50 A: “ACC”, “IG1”, “IG1 NO.2”,
“WIP”, “WSH”, “4WD”, “STA” 41. HEATER 50 A:
“A/C”, air conditioning
system
42. ABS NO.1 50 A: Anti−lock brake sys-
tem, vehicle stability control system
43. AM2 30 A: “IGN”, “GAUGE”, multiport
fuel injection system/sequential multi-
port fuel injection system
44. A/PUMP 50 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system
45. ABS NO.2 30 A: Anti−lock brake sys-
tem, vehicle stability control system
46. D FR P/W 30 A: Power windows
Fuses (type C)
47. AC SKT 100 A: Cigarette lighter, pow-
er outlets
Fuses (type D)
48. ALT 120 A (without towing package)/ 140 A (with towing package): “AM1”,
“

AC SKT”, “HEATER”, “FR FOG”,
“STOP”, “OBD”, “J/B”, “TOWING TAIL”,
“TOWING BRK”, “BATT CHG”

4102007 TACOMA from Sep. ’06 Prod. (OM35877U)
REPORTING SAFETY DEFECTS FOR U.S.
OWNERS AND CAMPER INFORMATION
Reporting safety defects for U.S. owners and camper
information
Reporting safety defects for U.S. owners411
. . . . . . . . . . . . . . . . . . . . . .
Camper information 411
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
SECTION 9
